Basic Drobo Dashboard
Each Drobo attached to your PC will have a specific drive tab. If the Drobo is connected over the network via a
DroboShare, it is specifically identified by the DroboShare logo
Item
Drive Tab
Storage Capacity
Used Space
Free Space
Advanced Controls
How Is My Storage being
Used?
Related Topics
The Capacity Breakdown Bar
Description
Shows the Windows drive letter and volume name assigned to Drobo.
Note: Multiple volumes on a single Drobo will show up on a single tab separated
by a comma.
Note: Multiple Drobos attached to a single PC will show up as separate tabs with
unique drive letters.
Shows Drobo's total available protected capacity.
Portion of the total protected capacity currently in use.
Portion of the total protected capacity available for use.
Click to access Drobo's Advanced Control Panel.
Click to view the Capacity Breakdown Bar.
in the drive tab.
