Understanding Phone Screen Features

The following figure shows how your main phone screen may look with an active call.
7
6
5
4
Primary
1
phone line
Programmable
2
buttons
3
Softkey labels
4
Status line
Call activity area Displays current calls per line, including caller ID, call duration, and call state
5
Phone tab
6
Feature tabs
7
Note
The Messages, Directories, and Services screens on your phone may appear in Normal mode
or in Wide mode depending on how your phone has been set up. A phone window in Wide
mode spans the entire width of the phone screen. However, neither you nor your administrator
can adjust the phone screen viewing mode.
8
1
Displays the phone number (directory number) for your primary phone line.
When several feature tabs are open, the phone number and the time and date
display alternately in this area.
Serve as phone line buttons, intercom line buttons, speed-dial buttons, phone
service buttons or phone feature buttons. Icons and labels indicate how these
buttons are configured. For an icon reference, see
page
iv.
Displays a softkey function for the corresponding softkey button.
Displays audio mode icons, status information, and prompts.
for the highlighted line (standard view). See
Icons, page
7, and
Viewing Multiple Calls, page
Indicates call activity.
Indicates an open feature menu. See
Menus, page
10.
2
3
Understanding Line and Call
Understanding Feature Buttons and
Phone Screen Icons,
9.
