Page 2: Table Of Contents
Content Safety Instruction ................................Minimum System Requirement & Product Feature ....................Minimum System Requirement ............................ Product Feature .............................. Main Page ..................................Basic Setup ................................ Account ................................Network................................ Date Time ..............................Video ................................Audio................................Live View................................. Video ................................Audio................................Camera Setting ............................. PTZ Control .............................. -
Page 3: Safety Instruction
User Manual Safety Instruction Before you use this product This product has been designed with safety in mind. However, the electrical products can cause fires which may lead to serious body injury if it is not used properly. To avoid such accidents, be sure to heed the following. - Page 4 In case of system breakdown, discontinue use and contact your authorized dealer. In case of abnormal operation If the unit emits smoke or an unusual smell, If water or other foreign objects enter the cabinet. If you drop the unit or damage the cabinet:1 Disconnect the cable and the connecting cables. 2 Contact your authorized dealer or the store where you purchased the product.
-
Page 5: Minimum System Requirement & Product Feature
Minimum System Requirement & Product Feature System Requirement For normal operation and viewing of the network camera, it’s recommended that your system meet these minimum requirements for proper operation: Item Requirements Minimum Intel® Core 2 Duo or higher (Core i3 or above is recommended) Graphic Card 256 MB RAM graphic cards... -
Page 6: Product Feature
Product Features SYSTEM H.264 / MPEG-4 / Motion JPEG: Resolutions Higher than 1024 * 720 pixels Screen Resolution H.264 / MPEG-4 / Motion JPEG Compressing format Frame Rate Up to 30 fps at 1920x1080 Rotation: Mirror, Flip, Mirror Flip Brightness / Contrast / Saturation Image settings Overlay capabilities: time, date, text and privacy image Image snapshot... -
Page 7: Main Page
Main Page Toolbar of Main Page... - Page 8 Client Setting Click the drop-down menu to choose video compression mode of Live View among H.264, MPEG-4, MJPEG and H.264. Profile Note: As long as the operating system is not able to afford loading under H.264 mode, please downgrade the mode to MPEG-4 or MJPEG. Select the desired view size of image resolution between Fit View Size Screen and Full Screen.
- Page 9 Click the Home button and it brings you back to the center no matter what position you are Move the camera view to the direction that the various arrows you click on. Use the various direction arrows to steer the camera view to the required position， and name Preset it for the specified position.
-
Page 10: Basic Setup
Basic Setup Account Account List The device default account and password setting is “admin / admin”. That means everyone who knows IP address can access the device including all configuration. It is necessary to create a new password if the device is intended to be accessed by specific ones. -
Page 11: Network
Network TCP/IP Internet Protocol Version 4 (TCP/IPv4) Obtain an IP address automatically (DHCP): If a DHCP server is installed on the network, to select this while the IP address is assigned by the DHCP server. Obtain DNS server address automatically: Select this to obtain the address of DNS server automatically. - Page 12 Note: Reboot the IP Camera after the network setting has been made. Note: If you connect the IP Camera with your computer directly, the default network domain of camera is 192.168.1.xx PPPoE If your ISP provides Dynamic IP with authentication by username and password, type all PPPoE information in this part.
- Page 13 Use the following DNS server address: Select this when you set the fixed address as the IP address of DNS server. Primary DNS server: Enter the IP address of the primary DNS server. Secondary DNS server: Enter the IP address of the secondary DNS server. Note : 1.
- Page 14 3. Then click “Refresh”. All access points (AP) around you will show up. 4. Select the AP you wish to connect and click “Connect”. 5. Enter password at passphrase if you need. If you don't know the setting of the wireless AP, please ask your network administrator.
-
Page 15: Date Time
Configuration Method PBC – Select to start WPS configuration. PIN – Select and click Generate new PIN to generate a new PIN code and start WPS configuration. This list is the result of network scan that only provide wireless AP with WPS function. It will be shown where the network is currently linked. -
Page 16: Video
Note: The NTP server (Network Time Protocol) is the time server which is an Internet standard protocol built on the top of TCP / IP. This assures accurate synchronization to the millisecond of computer clock times in a network of computers. Video Video Setting Image... - Page 17 Text information can be showed on the display screen, such as Date / Time and the user-defined title. Privacy Mask Privacy Mask is an area of solid color that bans users from viewing part of monitored area. Click “Add” and a setting pop-up window comes out. A translucent rectangle is located at up left of the image, drag it to where you wish to cover and resize it.
- Page 18 Day / Night IR cut filter mode: There are 4 modes for IR cut filter to switch Auto, Night Mode, Day Mode, Schedule to make IR cut filter work based on different conditions. IR cut filter switch delay: This is interval time (by seconds) when the IR cut filter switch has been implemented till it indeed works.
-
Page 19: Audio
Audio Audio Channel Full duplex: Select it for simultaneous communication in both direction between the connected administrator and IP CAM. It means both parties can speak and be heard at the same time. Half duplex: Select it for communication in both directions, but only one direction at a time. It cannot receive signal until the transmission has been done. -
Page 20: Live View
Live View Video Please refer to p.15~17 Audio Please refer to p.17~18 Camera Setting View Setting A view area is a cropped part of the overview image. Each view area is treated as a video source in Live View with its own Video Stream, PTZ and Event settings. There are 4 areas can be preset and 6 various resolutions for each view area. - Page 21 Image Setting Image Enhancement Brightness: The image brightness can be adjusted in the range 0-100, the a higher value produces a brighter image. Saturation: Adjust the saturation in the range 0-100, the higher value gets more colorful image. ...
-
Page 22: Ptz Control
Wide Dynamic Range Enable Wide Dynamic Range auto in different level to improve the exposure when both bright and dark areas simultaneously in the field of view of the camera. The level goes from 1-8, the larger number brings stronger influence, and the default is off. Noise Reduction Select the period you wish the noise reduction being executed in the drop-down menu, there are working day, weekend, and night mode. -
Page 23: Playback
Playback Client PC This is for uploading the recorded file saved in the PC and play back to see the video. ❶ Click it to upload the recorded file in the PC ❷ Click it to stop the current video ❸... -
Page 24: Network Storage
Network Storage Network storage provides the storage function for saving image files to the specified computer and folder connected with the operating computer. Before using this function you must go to Event Server in Event to configure all settings and make the recording file saved here. -
Page 25: Event
Event Event Server Event Server Click “Add” to create a event server then the setting page pops up. Name it, select your network type put on the storage location. This is optional to create the password for certain group to use it. Then click the “Test” button to see if it works, it will show the information on the pop-up window to see your setting if has been made successfully. - Page 26 motion detection function before taking this as the trigger. Set minimum time interval between 2 triggers, and choose the desired detection area. The detection type individually stands for the following meanings: Start: The trigger would be activated when the target object starts to move. Stop: The trigger would be activated when the target object stops to move.
-
Page 27: Motion Detection
Scheduled Recording General Name the recording file and make it on or off. Action File Size: You can manually write in the file size as the suggested range. Cyclic Size: You can manually write in the cyclic size as the suggested range. Schedule You may set up the event schedule as “always”... -
Page 28: Tampering Detection
Tampering Detection Select “on” if you want to activate the tempering detection. Trigger Duration: This setting is set for the trigger will be started for the duration of tampering lasts you configure. The duration range is from 5 seconds to 900 seconds. Schedule The schedule is made for Event List to set the recording period. -
Page 29: System
System Maintenance Restart Restart button is for reboot the IP Camera digitally, you may reboot the camera manually or automatically. Click “on” and shows two modes for user to reboot the camera automatically. Sequential Mode offers the selection that how many days you would like to reboot, 7 days at most. Schedule Mode is able to select the certain day and time to reboot. -
Page 30: Network Basic
IP Address Filter Once enabled it, the listed IP address are allowed or denied access to the product. Add the IP Address that you’d like to allow or deny and select allow or deny from the list and save it. HTTPS HTTPS is a URL scheme used to indicate a secure HTTP connection. - Page 31 Multicast Status: This can be enabled or disabled the multicast. Access Name: This will be shown and changed along with the profile you select. Multicast Address: Specify the multicast server address. Video / Audio Port: Specify the transmission port number of the video data, from 1124 to 65534. Time to Live: Set the maximum TTL that multicast can pass through.
-
Page 32: Led
DDNS DDNS is a system which allows the domain name data held in a name server to be updated in real time. The most common use for DDNS is allowing an internet domain name to be assigned to a computer with a varying / dynamic IP Address.
