  • Page 1 M511W User Manual...

  • Page 2: Table Of Contents

    M511W User Manual M511W Wireless Day/Night Pan/Tilt IP Camera Hardware User Manual -Contents- Statement and Declaration ………………………………………………….….2 CHAPTER 1. SAFETY INSTRUCTION ..................6 CHAPTER 2. INTRODUCTION .....................8 CHAPTER 3. PACKAGE CONTENTS ..................9 CHAPTER 4. PHYSICAL DESCRIPTION..................10 CHAPTER 5. BASIC CONNECTION ..................11 ...............................

  • Page 3: Statement And Declaration

    M511W User Manual Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC:...
  • Page 4 M511W User Manual Česky [Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se základními [Czech] požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Dansk Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr [udstyrets [Danish] typebetegnelse] overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
  • Page 5 M511W User Manual Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in Nederlands overeenstemming is met de essentiële eisen en de andere relevante bepalingen van [Dutch] richtlijn 1999/5/EG. Malti Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott] jikkonforma [Maltese] mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva...

  • Page 6: Federal Communication Commission Interference Statement

    M511W User Manual Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 7: Chapter 1. Safety Instruction

    M511W User Manual Hardware User Manual Chapter 1. Safety Instruction  Before you use this product This product has been designed with safety in mind. However, the electrical products can cause fires which may lead to serious body injury if not used properly. To avoid such accidents, be sure to heed the following.
  • Page 8 M511W User Manual  In case of a breakdown In case of system breakdown, discontinue use and contact your authorized dealer.  In case of abnormal operation If the unit emits smoke or an unusual smell,  If water or other foreign objects enter the cabinet, or ...

  • Page 9: Chapter 2. Introduction

    M511W User Manual Chapter 2. Introduction The M511W Wireless Day/Night Pan/Tilt IP Camera provides full overview and true day/night capabilities to be the perfect solution for indoor applications that need to cover everything at anytime, but still be cost-effective. Key Features: Simultaneous MPEG-4 and Motion JPEG video stream ...

  • Page 10: Chapter 3. Package Contents

    Chapter 3. Package Contents Quick Installation Guide Software CD Component Pack Camera – M511W Wireless Day / Night Pan / Tilt IP Camera Camera - To provide brief product information and quick installation and Quick Installation Guide wireless setting - To provide IP Surveillance Software, Intelligence IP Installer, User Manuals, and...

  • Page 11: Chapter 4. Physical Description

    M511W User Manual Chapter 4. Physical Description Overview  Focus Adjustment Ring - Adjust focus manually to achieve the best image quality  Infrared LEDs - Infrared LEDs for night use up to 10 working distance  Wireless Antenna - For connection of IEEE 802.11 b / g wireless network.
  • Page 12 M511W User Manual DI / DO Terminal connector diagram Please refer the following illustration below for connection method. D+ D- COM NO Ground Switch Alarm out device Ground Max. 30W...

  • Page 13: Chapter 5. Basic Connection

    M511W User Manual Chapter 5. Basic Connection M511W is for both wire and wireless connection. You can follow the procedure below to connect the IP Camera with power and Ethernet for both wire and wireless connection. 5.1 Wire Connection 1. Connect the power adaptor to IP Camera.

  • Page 14: Chapter 6. Application

    M511W User Manual Chapter 6. Application...
