SYSTEM OVERVIEW
CHARGE CONTROLLER BATTERY -
BAT +
BAT -
SHUNT C
CHARGE CONTROLLER
FX BATTERY -
SHUNT B
B DEVICE
net DC
T M
FX INVERTER/CHARGER
OTHER DC
BATTERY -
SOURCE OR
LOAD
SHUNT A
Think of the input shunts as breaks or junctions in the DC (-) conductor. The current is conducted
as though it were a continuous conductor, but the shunts allow the user to monitor the current,
providing information for more accurate battery recharging.
