FLEXNet DC Measurements

The FLEXNet DC can measure and record:

• Volts for one battery bank*

• Amps**

• KiloWatts

• kWhrs removed from the batteries

• kWhrs returned to the batteries

• Amp hours removed from the batteries

• Amp hours returned to the batteries

• Battery bank state-of-charge

• Lifetime kiloamp hours removed from the batteries***

• Days since charge parameters last met

• Lowest battery state-of-charge reached

• Minimum battery voltage***

• Maximum battery voltage***

• Maximum amp charged***

• Maximum amp discharged***

• Maximum kWhrs charged***

• Maximum kWhrs discharged***

Battery volt input: 0-80 VDC in .1 volt resolution

2000 amp DC span (+/- 1000 amps DC) (net amps are charging, net amps

are discharging), .1 amp resolution

***

The user can manually reset these data. At any given time, the values

displayed are the most recent since the values were last displayed
