- Page 1 Technisches Handbuch / Technical Manual Mainboard D1607 / D1605 Deutsch / English / Français...
- Page 2 Sie haben ..technische Fragen oder Probleme? Wenden Sie sich bitte an: • Ihren zuständigen Vertriebspartner • Ihre Verkaufsstelle Aktuelle Informationen und Updates (z. B. BIOS-Update) zu unseren Mainboards finden Sie im Internet: http://www.fujitsu-siemens.com/mainboards Are there ..any technical problems or other questions you need clarified? Please contact: •...
- Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH Bestell-Nr./Order No.: A26361-D1607-Z122-1-6319 Printed in the Federal Republic of Germany AG 0304...
- Page 5 Deutsch English Mainboard D1607 / Français D1605 Technisches Handbuch Technical Manual Ausgabe März 2004 March 2004 edition...
- Page 6 Dieses Handbuch wurde erstellt von cognitas. Gesellschaft für Technik-Dokumentation mbH www.cognitas.de Copyright Fujitsu Siemens Computers GmbH 2004 AMD, AMD Arrow logo, AMD Athlon, AMD Opteron and combinations thereof, and 3DNow! are trademarks of Advanced Micro Devices, Inc. HyperTransport is a licensed trademark of the HyperTransport Technology Consortium.
- Page 7 Übersicht/Overview Mainboard D1607 / D1605 Lüfter 1 / Fan 1 Interne Anschlüsse und Steckplätze / Internal Stromversorgung / Power supply connectors and slots Bedienfeld / Front panel Diskettenlaufwerk / Floppy disk drive IDE-Laufwerke 3/4 / IDE-drives 3/4 IDE-Laufwerke 1/2 / IDE-drives 1/2...
-
Page 9: Table Of Contents
Contents Übersicht/Overview Mainboard D1607 / D1605................1 Mainboard D1607 / D1605........................1 Notational conventions.......................1 Important notes ..........................2 Information about boards ......................2 List of features...........................3 Special features.........................5 Brief instructions on installing mainboard...................7 Prior to installation ........................7 Interfaces and connectors ......................9 External ports ............................9 LAN connector...........................9... -
Page 11: Übersicht/Overview Mainboard D1607 / D1605
Mainboard D1607 / D1605 Your mainboard is available in different configuration levels. Depending on the configuration chosen, some of the hardware components described may not be available on your mainboard. Additional information Information on the BIOS Setup and additional descriptions of the drivers are contained: •... -
Page 12: Important Notes
• Remove the power plug from the mains supply before inserting or removing boards containing ESDs. • Always hold boards with ESDs by their edges. • Never touch pins or conductors on boards fitted with ESDs. 2 - English A26361-D1607-Z122-1-6319... -
Page 13: List Of Features
List of features List of features Onboard features D1607-G/A D1605-A Chipset VIA K8T800 VIA K8T800 Board size Audio / 6-channel / S/PDIF 5.1 ! / ! / ! ! / ! / ! Buzzer / int. Speaker Support ! / -... - Page 14 List of features Internal ports (continued) D1607-G/A D1605-A SMBus Connector* (Case Temperature) Cover monitoring* (Casing open) Power Connectors ATX / ATX12V / AGP PRO 1 / 1 / - 1 / 1 / - Serial Ports* (FIFO, 16550 compatible) Fan Connectors PSU** / CPU / AUX1 / AUX2...
-
Page 15: Special Features
Silent Fan A micro controller developed by Fujitsu Siemens Computers monitors and controls the fans in the PC and thus prevents any unnecessary noise annoyance. Should the processor become in spite of full turning ventilator too hot, then the processor clock rate will automatically be reduced so that the system continues to run stably. - Page 16 OEM CD "Drivers & Utilities" and on the Internet. Multi Boot The BIOS of the Fujitsu Siemens Computers mainboards enables booting from all types mass storage devices. In addition to IDE hard disks, this also includes optical drives, such as CD-ROM, DVD and external drives that can be connected to USB or FireWire.
-
Page 17: Brief Instructions On Installing Mainboard
Installation ► Equip the mainboard with the processor, heat sink and memory modules before installation if possible. Further information can be found in "Replacing processor" chapter. ► Open the casing as described in the operating manual. English - 7 A26361-D1607-Z122-1-6319... - Page 18 Connect the plugs for the power supply, control panel and drives to the corresponding connections on the mainboard. Driver installation ► Install the drivers for the chipset. You may find the driver on the "Drivers & Utilities" CD. Please refer to chapter "Drivers" for a description of installing drivers. 8 - English A26361-D1607-Z122-1-6319...
-
Page 19: Interfaces And Connectors
(FIFO) and supports WOL function through Magic Packet. The LAN RJ45 connector has two LEDs (light emitting diodes). LED 1 lights green: A connection exists (e.g. to a hub). flashes green: Activity LED 2 glows yellow: 100 Mbit/s off: 10 Mbit/s English - 9 A26361-D1607-Z122-1-6319... -
Page 20: Audio Ports And Audio Configuration
Depending on driver, software or hardware version and operating system the functions may differ from this presentation. If necessary, further information is provided in the respective help system as well as in the "Audio configuration" section. 10 - English A26361-D1607-Z122-1-6319... - Page 21 If the required software was not preinstalled, it can be found on the supplied "Drivers & Utilities" CD. BIOS In a current BIOS MIC-In can be configured for operation at the front or rear of the PC Additional information is contained in the "BIOS Setup" manual. English - 11 A26361-D1607-Z122-1-6319...
-
Page 22: Internal Ports And Connectors
If you have connected audio devices to both Line out connections, only the connection on the front of the system is active. If you have connected audio devices to both Microphone connections, only the connection on the back of the system is active. 12 - English A26361-D1607-Z122-1-6319... -
Page 23: Pin Assignment Of Internal Ports
Power On LED Indicates the system state APM or ACPI (see annex, "APM and ACPI system status, energy-saving modes" section). Password see "Settings with switches and jumpers" chapter Recovery see "Settings with switches and jumpers" chapter English - 13 A26361-D1607-Z122-1-6319... - Page 24 Data 0 (high asserted) CS 1 (low asserted) Data 15 (high asserted) CS 3 (low asserted) IDE-LED (low asserted) Serial ATA (internal) Signal Signal Transmit data positive Transmit data negative Receive data negative Receive data positive 14 - English A26361-D1607-Z122-1-6319...
- Page 25 Write Protect (low asserted) Drive B Select (low asserted) Read Data (low asserted) Drive A Select (low asserted) Side 1 Select (low asserted) Motor B Enable (low asserted) Disk Change (low asserted) Audio S/PDIF In Signal SPDIF in English - 15 A26361-D1607-Z122-1-6319...
- Page 26 Micro bias Analogue VCC Right line output Right line return not connected Left line output Left line return If the audio front panel is not used, you must plug jumpers on pin pairs 5/6 and 9/10. 16 - English A26361-D1607-Z122-1-6319...
- Page 27 Fan 1 CPU Fan 2 AUX (processor fan - only for 3 pin fans) Signal Controlled Fan voltage (0 V, +6 V...+12 V, max. 1 A) or fix Fan voltage (+12 V, max. 1 A) Fan sense English - 17 A26361-D1607-Z122-1-6319...
- Page 28 PS on (low asserted) +5V (VCC) Powergood (high asserted) -5V (5PVN) +5V Auxiliary (VCC Aux) +5V (VCC) +12V (P12VP) +5V (VCC) Power supply ATX12 V Signal Signal +12 V +12 V SMB for Temperature sensor Signal P3V3P_DUAL SMB_PIC_CLK_H SMB_PIC_DATA_H 18 - English A26361-D1607-Z122-1-6319...
-
Page 29: Settings With Switches And Jumpers
Pin pair A inserted = Skipping system and BIOS Setup password Pin pair B inserted = System BIOS recovery Pin pair C inserted = factory setting Please pay attention on the exact position of the pin pairs! English - 19 A26361-D1607-Z122-1-6319... - Page 30 Diskette" restores the System BIOS on the mainboard. Off / not inserted Normal operation (default setting). Reserved - switch 3 and switch 4 (if present) Switch 3 and 4 are reserved. The position of the switch doesn't matter. 20 - English A26361-D1607-Z122-1-6319...
-
Page 31: Add-On Modules / Upgrading
(A) with regard to the position (4). The angled corner of the processor can also be at a different location than shown in the illustration. ► Push the lever back down until it clicks into place (5). English - 21 A26361-D1607-Z122-1-6319... - Page 32 Depending on the processor variant, clips may also be supplied for mounting the heat sink that fix it in place. When you have mounted the optional fan, Ê connect the fan plug to the corresponding connection on the mainboard. Schematic illustration 22 - English A26361-D1607-Z122-1-6319...
-
Page 33: Upgrading Main Memory
Push the holders on each side of the memory slot outwards. ► Insert the memory module into the location (1). ► At the same time flip the lateral holders upwards until the memory module snaps in place (2). English - 23 A26361-D1607-Z122-1-6319... -
Page 34: Upgrading Agp Screen Controllers
3.3 V AGP graphics cards can cause serious damage to the mainboard and the AGP graphics cards. Adding PCI cards Technical data: 32 bit / 33 MHz PCI slots 5 V and 3.3 V supply voltage 3.3 V auxiliary voltage 24 - English A26361-D1607-Z122-1-6319... -
Page 35: Pci Bus Interrupts - Selecting Correct Pci Slot
PCI slot with IRQ sharing, check whether the expansion card properly supports IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all cards and components on this PCI IRQ Line must also support IRQ sharing. English - 25 A26361-D1607-Z122-1-6319... -
Page 36: Replacing The Lithium Battery
Press the locking lug in the direction of the arrow; the battery jumps somewhat out of the holder (1). ► Remove the battery (2). ► Push the new lithium battery of the identical type into the holder (3) and press it downward until it engages (4). 26 - English A26361-D1607-Z122-1-6319... -
Page 37: Bios Update
BIOS update BIOS update When should a BIOS update be carried out? Fujitsu Siemens Computers makes new BIOS versions available to ensure compatibility to new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated. -
Page 38: Drivers
Insert the CD "Drivers & Utilities Collection" into the CD-ROM drive. ► If the CD does not start automatically, run the START.EXE programme in the main directory of the CD. ► Select DeskUpdate - Fully automatic installation . ► Follow the instructions on screen. 28 - English A26361-D1607-Z122-1-6319... -
Page 39: Annex
Mainboard current requirement (TBD) You require a Pentium4 power supply nit as per the ATX12V specification for this mainboard. If you do not have a PC from Fujitsu Siemens Computers, make sure that the power supply unit provides the required amperages. -
Page 40: Apm And Acpi System Status, Energy-Saving Modes
* G = Global status; S = System status The power supply unit must provide sufficiently loadable 5 V standby voltage. To use the WOL functionality the power supply must provide a 5 V auxiliary voltage (5V SB) of at least 1 A. 30 - English A26361-D1607-Z122-1-6319... -
Page 41: Mainboard Revision And Bios Version
. Mainboard Revision The revision status of the mainboard exactly identifies which mainboard you have. It is indicated on a sticker on the edge of the mainboard: D1607-G11 GS 1 05618476 Example Mainboard-Revision BIOS version The BIOS version can be displayed in the BIOS Setup . -
Page 42: Error Messages
Check the entry for the hard disk drive in the Main menu and the entry for the IDE drive controller in the Advanced - Peripheral Configuration menu of the BIOS Setup . Check the hard disk drive's connections and jumpers. 32 - English A26361-D1607-Z122-1-6319... - Page 43 Boot Sequence submenu of the BIOS Setup . Parity Check 1 Parity Check 2 Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre. English - 33 A26361-D1607-Z122-1-6319...
- Page 44 Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre. Verify CPU frequency selection in Setup The frequency setting for the processor is invalid. Correct the BIOS Setup and the setting. 34 - English A26361-D1607-Z122-1-6319...
-
Page 45: Glossary
SMBus System Management Bus Accelerator Inter Integrated Circuit SVGA Super Video Graphic Adapter IAPC Instantly Available Power Universal Serial Bus Managed Desktop PC Design I/O Controller Hub Video Graphic Adapter Intelligent Drive Electronics Wake On LAN 35 - English A26361-D1607-Z122-1-6319...
