Door Glass:
A commercial glass cleaner designed for stoves is recommended for cleaning the glass. The glass
can also be cleaned as follows: Dip a moist cloth or old newspaper in the ashes and use this to clean
the glass. Attention: The ashes should not get into contact with your skin! Wipe with a dry cloth.
The ceramic door packing cord must not get wet.
Be careful not to abuse the glass by striking or slamming the door shut.
Do not operate the stove with broken glass. If the glass breaks then replace it promptly.
Use only replacement packing cord listed for the door, glass and ash drawer.
Replacing Broken Door Glass:
The door must be dismounted from the stove before installing a new glass.
1. Loosen the door hinges:
SCAN 5.2: loosen the screw underneath each hinge with a hexagon spanner (see sketch on
page 20).
2. Place the door on a soft pad.
3. Loosen the fastening screws that hold the inside door frame. Remove the door frame and
carefully remove the remainder of the old glass.
4. Clean the area where the glass and packing cord are to be installed.
5. For SCAN 5.2 make sure that the small pivots of the closing device fit into the holes of the
locking pawls.
6. Install the new flat self-adhesive packing cord on the edge of the inside surface of the outer
door frame around the opening and cut off surplus packing cord to make an air tight joint.
(The side with the adhesive is to fix the packing cord to the inside of the outer doorframe).
7. Carefully place the glass on the outer doorframe and install the inner doorframe using the
screws removed in disassembly. Hold the parts together and install the screws only with two
revolutions.
Install the flat part of the P-packing cord so it will fit between the outer doorframe and the
inner door frame. (When installing the P-packing cord use your fingers or a screwdriver to push
the flat part of the cord under the inner doorframe. Make sure the cord is not pushed in so far
that the round part will not seal against the door opening of the stove). Tighten the inner
doorframe by mounting the screws evenly around the frame (enough to be sure the door
packing cord stays in place) then fully tighten the screws.
8. Carefully turn around the door and install the tube packing cord between the glass and the
outer doorframe with your fingers.
9. Install the door on to the stove again in reverse order of dismounting (see under 1).
Make sure that there is the same distance between the door edges and the stove on both
sides and that the door and the latch work properly.
SCAN 5 the only difference is the P-packing cord, which is instead a 15 mm (⅜ inch) glass
packing cord.
