Summary of Contents for DAPAudio Clubmate II
- Page 1 MANUAL ENGLISH Clubmate II™ Ordercode: D3264 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Clubmate II™ Table of contents Warning ....................................2 Unpacking Instructions ..............................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Connection with the mains............................4 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Features ..................................5 Overview Subwoofer .............................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: DAP Clubmate II IEC powercord 1,5m ... -
Page 4: Operating Determinations
Clubmate II™ Do not switch the system on and off in short intervals, as this would reduce the system’s life. Do not open the device and do not modify the device. Do not drive the inputs with a signal level bigger, than required to drive the equipment to full output. -
Page 5: Connection With The Mains
Clubmate II™ Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER FASE BLUE... -
Page 6: Description Of The Device
Clubmate II™ Description of the device Features The Dap Clubmate II is a 15” active speaker set. High power, long excursion 15 inch subwoofer speaker units. Special mid speaker unit with a very high efficiency. Special high drivers and elliptical wave guide for frequencies up to 20 KHz. -
Page 7: Overview Subwoofer
Clubmate II™ Overview Subwoofer Air cooling window Protect LED Lights if the units protection circuit is active. If the protection circuit is active, the outputs will be muted. Right channel combo line input The input equipped with 3 pole XLR/ jack combo socket is electronically balanced to accept the (line) signal from any mixing console. -
Page 8: Overview Satellite
Clubmate II™ Main volume control This control allows you to adjust the total volume level of the clubmate. Left channel combo line Input The input equipped with 3 pole XLR/ jack combo socket is electronically balanced to accept the (line) signal from any mixing console. -
Page 9: Set Up And Operation
Clubmate II™ Set Up and Operation The satellite The Club Mate satellite is designed to produce a mid/high spectrum of sound. The satellite is equipped with a 8” LF loudspeaker and a 1” HF driver. The subwoofer Feel the bass with this 15” subwoofer. The subwoofer cabinet is powered through a powerful 400W amplifier. -
Page 10: Maintenance
Follow the configuration examples below for your particular connection. Maintenance The DAP Audio Clubmate II™ requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply and then wipe the cover with a damp cloth. Do not immerse in liquid. -
Page 11: Specifications
Clubmate II™ Specifications Subwoofer 15" compact vented active PA Subwoofer Amplifier Output Low: 400 Watt RMS in 8 Ohm Amplifier Output High: 2x 150 Watt RMS in 8 Ohm Frequency Response (-3 dB): 42 – 125 Hz Crossover Frequency: 125 Hz, 24 dB/Oct BW... - Page 12 ©2013 DAP Audio...
