- Page 1 MANUAL ENGLISH CS-850S Order code: D6588 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
CS-850S Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Return Procedure ................................4 Claims ....................................4 Description of the Device ..............................5 Overview ..................................5 Installation ................................... 6 Speaker Wiring ................................7 Painting the Grill ................................8 Troubleshooting ................................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture will be returned in the original factory box and packing. Your shipment includes: ● DAP Audio CS-850S 50W 8" in-ceiling subwoofer ● Template for in-ceiling mounting ● User manual... -
Page 4: Operating Determinations
● Clean only with dry cloth. ● When making the hole in your ceiling to mount the CS-850S, make sure there is sufficient clearance above the ceiling and there are no obstructions like A/C channels, power lines, etc. ● Take care of your speaker wires, they should be free of damage. Damaged speaker wires might result in poor sound quality and can damage amplifiers. -
Page 5: Return Procedure
CS-850S Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 6: Description Of The Device
The crossover can be easily disconnected from the transformer using the push terminals, which allows the subwoofer to be connected to an external low impedance amplifier. The subwoofer features infinite baffle as it has no enclosure. The grill and the frame of the CS-850S can be painted to match any interior. -
Page 7: Installation
CS-850S Installation Before installing the DAP CS-850S, ensure that the chosen location on the ceiling is free of any obstructions such as pipe work, ducting or wiring. In existing constructions, if no crawlspace is available, use a stud-finding tool to map the ceiling construction and a pipe detector to scan the installation location. -
Page 8: Speaker Wiring
CS-850S 09) Lift the mounting clamps (04) and rotate them clockwise as shown on Fig. 05 and 06. Fig. 05 Fig. 06 10) Insert the speaker into the mounting hole. Make sure the flange of the mounting frame (01) is flush on the ceiling. -
Page 9: Painting The Grill
CS-850S Painting the Grill If you want to paint the frame and the grill to match the interior, you can use the inner ring of the cut out template to cover the speaker as protection. Remove the grill before painting! It is advisable to paint the frame before mounting the speaker in the ceiling, as it is difficult to remove the grill once the speaker is installed. -
Page 10: Product Specification
CS-850S Product Specification Model: DAP Audio CS-850S Line voltage: 100 V Power taps: 70 V: 50 W red, 30 W brown, 15 W yellow, 5 W green, 3 W white, common = black 100 V: 50 W brown, 30 W yellow, 15 W green, 5 W white,... -
Page 11: Notes
CS-850S Notes Order code: D6588... - Page 12 ©2019 DAP Audio...
