Kimba Cross
Bedienungsanleitung .................................................. 7
Instruction for use ..................................................... 19
Gebruiksaanwijzing ................................................... 30
© Otto Bock HealthCare GmbH · 647G117 – 05.03/2 · Printed in Germany

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kimba Cross and is the answer not in the manual?

Questions and answers

Related Manuals for Otto Bock Kimba Cross

Summary of Contents for Otto Bock Kimba Cross

  • Page 1 Kimba Cross Bedienungsanleitung ..........7 Instruction for use ............. 19 Gebruiksaanwijzing ........... 30 © Otto Bock HealthCare GmbH · 647G117 – 05.03/2 · Printed in Germany...

  • Page 7: Table Of Contents

    Slipsacks ................................27 Groin strap ................................27 Tray ..................................27 Thoracic supports ..............................27 Using your Kimba Cross as a Seat in Motor Vehicles ..................28 Instructions for Maintenance and Cle*aning ......................28 Warranty ................................28 Technical Data ..............................29...

  • Page 8: Preface

    When using the Kimba Cross with rigidly mounted or with swivelling front wheel: • Get to know in particular how the Kimba Cross with your seating system reacts when the center of gravity is shifted; for example on slopes or inclines or when clearing obstacles, like steps and curbs.
  • Page 9 • When your child reaches for objects in front, to the side or behind the Kimba Cross, make sure that he or she does not lean out of it too far, since the shift in the center of gravity might cause the Kimba Cross to tilt or tip over.

  • Page 10: Unpacking And Setting Up

    Important: Make sure the axle is properly engaged and has enough clamping pressure! The clamping pressure can be adjusted by turning the quick-release lever or the counternut. • To fold the Kimba Cross together, please reverse the directions mentioned above. Outdoor Mobility Base...

  • Page 11: Accessories For Outdoor Mobility Base

    The Kimba Cross mobility base is designed as a modular assembly system, which means that certain accessories may be adapted to it. The following options and accessories may make it easier to use your Kimba Cross mobility base (Fig. 18).

  • Page 12: Kimba Multifunctional Seating Unit

    Reflectors: Attach the two red reflectors with the tube clamps to the rear crosstube (Fig. 33). (As an alternative to a second red reflector a combination of rear light plus reflector may be included with the Kimba Cross.) Attach the two white reflectors at the front of the Kimba Cross to the deflector angles using adhesive tape (Fig.

  • Page 13: Seating Shell Interfaces

    Then open the cam-lock buckles at the lower end of the pad (Fig. 52, item B), pull out the straps, and position them on the sides of the seat. Place the child in the Kimba Cross and pull the chest and shoulder pad over the child’s head onto his or her chest.

  • Page 14: Canopy

    To ensure the correct fit, make sure that the straps are not touching the child and that the reinforced edge of the pad is not in contact with the strap guide slot. The pad will provide the best upper-body support when the strap guide slot is approx. 2-3 cm above the child’s shoulder.

  • Page 15: Headrests

    Slipsacks (Fig. 67) Place the summer, winter or sheepskin slipsack in the Kimba Cross. Tie the straps to the lower back section and tie the upper straps to the frame of the back insert. If using an abductor or belts, make a cut in the corresponding synthetic leather strips using a sharp blade.

  • Page 16: Using Your Kimba Cross As A Seat In Motor Vehicles

    • Check the tightness of all screw connections on a regular basis. • After any adjustments, snugly re-tighten the screws that have been loosened. • We recommend that you have your Kimba Cross – when used on a normal basis – checked once a year by a Reha- bilitation Technology Specialist.

  • Page 17: Technical Data

    Technical Data Measurements are in cm and weights are in kg Outdoor mobility base Push handle height 90-115 Total width Total length 140-170 Wheelbase 80-92 Front wheel diameter 40 rigid front wheel 30 swivel. front wheel Rear wheel diameter Seat tilt -5°...
  • Page 18 Otto Bock HealthCare GmbH Sälzerstraße 16 · D-56235 Ransbach-Baumbach Otto Bock HealthCare GmbH has been certified by the German Society for the Certification of Quality Assurance Systems (DQS) in accordance with DIN EN ISO 9001 standard, reg. no. 779 (management system)
