CamIO
User Manual
MOBOTIX
CamIO
1 2 3 4
Lamp
Out1
Door
Out2
Complete integration for web and security
MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com • 9.11.2007
5 6
7 8
10 11
13 14 15 16
Line-In
Speaker
In1
8 to 230 V~ (8 to 48 V~)
In2
8 to 230 V~ (8 to 48 V~)
www.mobotix.com > Support > Manuals
Security-Vision-Systems
Security-Vision-Systems
MOBOTIX
8
RJ45
Microphone with
pre-amplifier
Speaker
Current PDF File:
X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CamIO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mobotix CamIO

Summary of Contents for Mobotix CamIO

  • Page 1 Current PDF File: www.mobotix.com > Support > Manuals Vandalism-protected Wall bracket with cable cover for RJ45 wall outlet MOBOTIX AG • Security-Vision-Systems • Made in Germany Robust no moving parts www.mobotix.com • sales@mobotix.com • 9.11.2007 fiber glass housing...
  • Page 2 MOBOTIX CamIO User Manual Caution Only qualified personnel may install and open the CamIO and con- nect it to the mains power; make sure that the relevant regula- tions of your country are respected! It is imperative that all electrical wires have been disconnected...

  • Page 3: Table Of Contents

    2.1.3 Dimensions and Drilling Template 2.1.4 Connectors and Wiring Information on Connecting the MOBOTIX CamIO Mounting the CamIO Wall Mount and the Control Cable 2.3.1 Mounting with an M12 Camera 2.3.2 Mounting with an M22 Camera Mounting the CamIO Housing and Installing the Cables 2.4.1 Mounting the CamIO Housing on the Wall...
  • Page 4 Copyright © 1999-2007 MOBOTIX AG, Kaiserslautern, Germany. All rights reserved. MOBOTIX, MxPEG and MxControlCenter are worldwide trademarks of MOBOTIX AG. Microsoft, Windows and Windows Server are reg- istered trademarks of Microsoft Corporation. Apple, the Apple logo, Mac and Mac OS X are trademarks of Apple Inc. Linux is a trademark of Linus Torvalds.
  • Page 5 MOBOTIX CamIO User Manual Notes © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 6: Introduction

    An external device (e.g. a lamp) connected to the can be CamIO-AC/ACplus powered directly by the CamIO and is switched on or off using the first signal out The CamIO can switch Ohm resistive loads with put of the MOBOTIX camera. The second signal output can be used for potential max.
  • Page 7 When mounting the MOBOTIX CamIO, the foot of the CamIO wall mount replaces Currently, the audio the original foot of an M12 or M22 camera mount. The foot of the CamIO wall features of the CamIO can only be used with mount covers the CamIO and reliably protects it against atmospheric exposure M12 cameras.

  • Page 8: Mobotix Camio Concept

    MOBOTIX CamIO Concept Simple Installation When designing the MOBOTIX CamIO, special focus was placed on easy installa- tion of the expansion box. The supplied drilling template facilitates mounting the CamIO and connecting the cabling for devices and data connections is easy, secure and weatherproof.
  • Page 9 45 minutes. At room temperature (20°C/68°F), the CamIO can power a MOBOTIX M12D for about 45 minutes; at -20°C (-4°F), the CamIO still provides 20 minutes of backup Using the backup power power. Providing backup power for an M22M using a CamIO-ACplus is currently feature of the CamIO- not possible.

  • Page 10: The Mobotix Camio And Mobotix Cameras

    11 to 68 V= eras. Note In order to use all features of the CamIO, make sure that you are activating it in the camera software (Admin Menu > Manage Hardware Expansions). Please note that you will need a software version 3.3.1.x or higher on the MOBOTIX M22M and a software version 3.1.0.x or higher on the MOBOTIX M12.

  • Page 11: Connection Cables Between Camio And Mobotix Cameras

    MOBOTIX CamIO User Manual 1.2.2 Connection Cables between CamIO and MOBOTIX Cameras Two cables are required to connect the MOBOTIX camera to the CamIO: • Ethernet cable: Establishes the data connection and the power supply to the camera. The control cable re- •...

  • Page 12: Important Notes

    • Connecting an electrical device: In order to provide power to an external device (Ohm resistive load, max. 5 A, 500 W lamp on 230 V, max. 300 W lamp on 115 V), the CamIO switches two wires (phase conductor and neutral). A ground conductor for grounding the external device needs to come from the junction box.

  • Page 13: Minimum Load At The Signal Outputs

    When installing the wiring inside or outside of buildings, make sure you always ad- here to the relevant regulations on wiring, fire prevention and protection against lightning. MOBOTIX recommends having MOBOTIX devices installed only by certified special- ists accustomed to installing network devices and having proper respect for the ap- plicable regulations regarding...

  • Page 14: Maximum Cable Lengths

    +140°F). 1.3.8 Cleaning Instructions The housing of the MOBOTIX CamIO and the wall mount foot are made of fiber-re- inforced PBT-30GF. This material is robust, maintenance-free and can be cleaned using a mild household detergent without solvents or abrasive particles.
  • Page 15 MOBOTIX CamIO User Manual Notes © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 16: Mounting

    Washers ø6.4 mm Wood screws 5x80 mm Dowels 8 mm Screw caps for wall mount Speaker with audio cables (mounted in wall mount foot) Allen wrench 5 mm Wood screw 3x10 mm Washer ø3.4 mm © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 17: Wall Mount Foot And Housing

    MOBOTIX CamIO User Manual 2.1.2 Wall Mount Foot and Housing The MOBOTIX CamIO housing (item 1) and the housing of the CamIO itself (item 2) are made of white, fiber-reinforced plastic (PBT-30GF, Polybutyleneterephtalate with 30% fiberglass). This material is used heavily in the automotive industry and is sturdy, resistant against high temperatures, environmental influences, chemicals, etc.

  • Page 18: Dimensions And Drilling Template

    2.1.3 Dimensions and Drilling Template Dimensions of the MOBOTIX CamIO Housing The appendix of this man- ual contains a 1:1 drilling template for drilling the dowel holes for the CamIO. 25 mm/1 in 100 mm/3.94 in © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 19 MOBOTIX CamIO User Manual Dimensions of the MOBOTIX CamIO Housing with Wall Mount Foot 136 mm/5.4 in 158 mm/6.22 in © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 20 MOBOTIX CamIO User Manual © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 21 MOBOTIX CamIO User Manual © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 22: Connectors And Wiring

    In1 - (signal input 1) (min. 2 mA) Speaker + Ext. speaker can be connected Speaker - directly, max. 2.5 W/8 Ω Line-In + Ext. microphone with ext. pre- Line-In - amplifier © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 23 White cable/brown line 6 (Rx-) Orange cable/white line White cable/blue line Blue cable/white line White cable/orange line 3 (Rx+) 2 (Tx-) Green cable/white line 1 (Tx+) White cable/green line © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 24: Information On Connecting The Mobotix Camio

    MOBOTIX CamIO User Manual 2.2 Information on Connecting the MOBOTIX CamIO The CamIO can be used with a MOBOTIX M12 or an M22. Simply replace the origi- nal foot of the corresponding SecureFlex mount of the camera by the supplied foot of the CamIO wall mount.
  • Page 25 MOBOTIX CamIO User Manual Mounting the CamIO in four steps Mounting the CamIO is done in four steps (or three, if no external devices are con- nected; skip step 3 in this case): 1) Preparing the camera: Mounting the CamIO Wall Mount and the Control...

  • Page 26: Mounting The Camio Wall Mount And The Control Cable

    MOBOTIX CamIO User Manual 2.3 Mounting the CamIO Wall Mount and the Control Cable 2.3.1 Mounting with an M12 Camera Remove cover • Unscrew the upper Allen screw in the original foot of the mount, which holds the turn/tilt unit in place (5 mm Allen wrench, item 12).
  • Page 27 MOBOTIX CamIO User Manual • Insert the M12 control cable for the CamIO from below into the turn/tilt unit of the cam- era. Remove the blue plug labeled RS-232 from the insect protection. Connect the HD 15 connector to the M12.

  • Page 28: Mounting With An M22 Camera

    Pull out • Insert the M22 control cable for the CamIO (USB connector first) from above into the turn/ tilt unit of the camera. • Now guide the M22 control cable through the bent opening of the USB plug.
  • Page 29 Ethernet cable, USB for the USB cable)! Also make sure that the plugs are not bent or the cable is under tension as this could lead to water entering the camera! © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 30: Mounting The Camio Housing And Installing The Cables

    2.4.1 Mounting the CamIO Housing on the Wall The appendix of this manual contains a 1:1 drilling template for mounting the CamIO. Use this template for drilling the holes for the dowels. • Mount the CamIO using the supplied screws, washers and dowels.

  • Page 31: Power Supply Of The Camio

    Direct power supply: Mains power (230 V~/115 V~) is connected to termi- the CamIO-AC and nals 1 and 2 of the CamIO's terminal connector at the bottom. The CamIO will CamIO-ACplus models either directly or indi- power a MOBOTIX camera and an external device attached to terminals 3 rectly.
  • Page 32 Make sure that you are respecting the minimum cable diameters. Caution The power supply cable to the CamIO needs to have a basic insula- tion level (BIL) of at least 230 V/115 V (depending on the mains volt- age). Never lay bell wires (BIL 50 V) next to 230 V or 115 V cables!
  • Page 33 The seals will protect the ca- bles against water entering along the wires. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 34: Ethernet Connection Of The Camio

    MOBOTIX CamIO User Manual 2.4.3 Ethernet Connection of the CamIO • Remove the outer insulation (sheath) of the Ethernet cable and guide it through the proper opening at the bottom of the CamIO housing right–hand side (see figure). Make sure that you...

  • Page 35: Connecting External Components To The Camio

    2.5 Connecting External Components to the CamIO 2.5.1 Connecting External Devices, Sensors and Audio Devices The MOBOTIX CamIO supplies connectors for the following functions: • Switch and supply power to external devices without individual power supply with loads of up to 5 A.
  • Page 36 CamIO's bottom terminal connector. Connecting and sealing the cables follows the same instructions as for power cables (see sec- tion 2.4.2, Power Supply of the CamIO ). Make sure that you are adhering to the applicable regulations in your country regarding the al- lowed cables when connecting the wires to the terminal connector.
  • Page 37 MOBOTIX CamIO User Manual MOBOTIX CamIO Connection Example © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 38: Mounting The Camera On The Camio

    MOBOTIX CamIO User Manual 2.6 Mounting the Camera on the CamIO Once the camera has been mounted to the foot of the CamIO wall mount, the Eth- ernet and control cables have been connected and optional external devices have been attached, you can mount the CamIO/camera assembly to the CamIO hous- ing.

  • Page 39: Connecting The Ethernet And The Camio Control Cables

    MOBOTIX CamIO User Manual 2.6.2 Connecting the Ethernet and the CamIO Control Cables In order to connect the camera to the CamIO, you need to attach the Ethernet and control cables of the camera to the CamIO. • Insert the cover into the guides at the bottom of the CamIO housing (1) and press at the top of the cover until it clicks in place (2).

  • Page 40: Wiring, Fire Prevention, Lightning And Surge Protection

    When installing the wiring inside or outside of buildings, make sure you always ad- here to the relevant regulations on wiring, fire prevention and protection against lightning. MOBOTIX recommends having MOBOTIX devices installed only by specialists ac- customed to installing network devices and having proper respect for the pertinent regulations regarding...
  • Page 41 This includes surge protectors for 19" racks, add- ing an uninterruptible power supply (UPS) to the MOBOTIX camera, and in- stalling surge arresters or similar for routers, switches, servers, etc.

  • Page 42: Accessories, Replacement Parts

    MOBOTIX CamIO. CamIO Housing Replacement housing for all CamIO models. M12 Control Cable (MX-CAMIO-OPT-M12) Control cable for connecting the CamIO and an M12 camera. M22 Control Cable (MX-CAMIO-OPT-M22) Control cable for connecting the CamIO and an M22M camera.
  • Page 43 M22 USB Plug Plug for sealing off the USB cable on M22M camera models. Additional CamIO Speaker Replacement speaker with audio cables for the CamIO wall mount foot. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 44 Once the CamIO and the MOBOTIX camera have been properly installed (see chapter 2), you can set up the camera for proper operation. To begin with, it is nec- essary to establish the power supply of the CamIO (either 230 V/115 V directly or in- directly via the network cabling using a PoE switch).
  • Page 45 3.2.1 Functional Overview A MOBOTIX camera and a CamIO are used at the entrance of a building for access control purposes and should open the door when prompted to do so. If a visitor rings the doorbell (signal input 1), the MOBOTIX camera automatically ac- tivates an additional source of light near the entrance (signal output 1), plays back...
  • Page 46 As an alternative, you can also use the doorbell system's UPS for this pur- pose. 3.2.2 Terminal Connections of the CamIO • Terminals 1 and 2: Power supply of the CamIO and the additional lighting (230 V~/115 V~). • Terminals 3 and 4 (Out1): Additional lighting •...
  • Page 47 1) Activate arming of the camera • Activate arming (Setup Menu > General Event Settings). 2) Configure recording • Set up event storage on an external file server (Admin Menu > Event Stor- age). © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 48 MOBOTIX CamIO User Manual • Activate recording for VM event (Setup Menu > Recording). • Activate VM event and set up video motion window (Setup Menu > Event Settings). © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 49 Audio Input temporarily to Microphone (only required when recording the voice message via the camera microphone). • Record the voice message (Admin Menu > Manage Voice Messages); op- tional: upload sound file to the camera. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 50 • Set up and activate SI event (Setup Menu > Event Settings). • Set up and activate SD message (Setup Menu > Messaging 2), select SI event and recorded voice message. © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 51 MOBOTIX CamIO User Manual 5) Configure SI event and VoIP phone call (CL message) For more information on setting up the SIP telephony features of MOBOTIX cam- eras, read chapter 9, Telephony Features in the Software Manual . • Configure the VoIP settings and activate VoIP (Admin Menu > VoIP Settings).
  • Page 52 • Configure the softphone and make sure that it is running on the computer. For more information on setting up a softphone for use with MOBOTIX cameras, read chap- ter 9, Telephony Features in the Software Manual . © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 53 MOBOTIX CamIO User Manual Notes © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 54: Technical Specifications

    Speaker (Audio Out) Output rating CamIO main board Max. power input 3.5 W (without camera) approx. 45 minutes (20°C/68°F) Recharg. battery (ACplus only) Endurance approx. 20 minutes (-20°C/-4°F) © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 55 You need to make sure, however, that the minimum voltage at the corresponding terminal is reached. ETHERNET CAMERA © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 56 Caution The power supply cable to the CamIO needs to have a basic insula- tion level (BIL) of at least 230 V/115 V (depending on the mains volt- age). Never lay bell wires (BIL 50 V) next to 230 V or 115 V cables!
  • Page 57 White cable/brown line 6 (Rx-) Orange cable/white line White cable/blue line Blue cable/white line 3 (Rx+) White cable/orange line 2 (Tx-) Green cable/white line 1 (Tx+) White cable/green line © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 58 MOBOTIX CamIO User Manual Declaration of Conformity © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 59 MOBOTIX – The HiRes Video Company To demonstrate our confidence in the quality of our products, MOBOTIX cameras were used to capture all the images that appear in this manual. Manufacturer Executive Board MOBOTIX AG Dr. Ralf Hinkel Kaiserstrasse D-67722 Langmeil...
  • Page 60 Current PDF File: www.mobotix.com > Support > Manuals Vandalism-protected Wall bracket with cable cover for RJ45 wall outlet MOBOTIX AG • Security-Vision-Systems • Made in Germany Robust no moving parts www.mobotix.com • sales@mobotix.com • 9.11.2007 fiber glass housing...
