- Page 1 Video/Audio Decoder User Manual (V2.2.0) UD.6L0203D1040A01...
- Page 2 The content of this manual is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by Hikvision Digital Technology Co., Ltd. (Hikvision). Hikvision assumes no responsibility or liability for any errors or inaccuracies that may appear in the book.
- Page 3 User Manual of DS-6300DI-T Decoder Regulatory information FCC information compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 User Manual of DS-6300DI-T Decoder Preventive and Cautionary Tips Before connecting and operating your decoder, please be advised of the following tips: • Ensure unit is installed in a well-ventilated, dust-free environment. • Keep all liquids away from the decoder.
-
Page 5: Table Of Contents
User Manual of DS-6300DI-T Decoder Table of Contents CHAPTER 1 Introduction ......................6 1.1 Description ........................7 1.2 Features ........................... 7 CHAPTER 2 Panels and Connections ..................9 2.1 Front Panel ........................10 2.2 Rear Panel ........................10 CHAPTER 3 Initial Network Parameters Configuration ............11 3.1 Searching Active Devices Online ................ - Page 6 User Manual of DS-6300DI-T Decoder 4.2.9 Importing/Exporting Parameters ................32 4.3 Configuring Remote Playback ..................32 4.4 Rebooting, Upgrading and Restoring the Default Settings for the Decoder ....34 CHAPTER 5 Decoder Configuration and Operation by Client Software ....... 36 5.1 Adding an Encoder ......................
-
Page 7: Chapter 1 Introduction
User Manual of DS-6300DI-T Decoder CHAPTER 1 Introduction... -
Page 8: Description
User Manual of DS-6300DI-T Decoder 1.1 Description Designed for the video monitoring system, DS-6300DI-T Series Video/Audio Decoder is developed on the basis of TI platform, Linux operating system and Netra processor, ensuring high reliability and stability of system running. DS-6300DI-T Series Video/Audio Decoder is capable of decoding video at 720P resolution and outputting decoded video via BNC, VGA interfaces, and it also supports multiple network protocols and multiple stream transmission mode. -
Page 9: User Administration
User Manual of DS-6300DI-T Decoder Multiple DDNS settings: Peanut Hull, DynDNS, IPServer, NO-IP and HiDDNS. Support SADP software to automatically search and discover the online devices in local network area. Automatically get IP address by DHCP protocol. Remote upgrading and maintenance can be done via web browser or client software. -
Page 10: Chapter 2 Panels And Connections
User Manual of DS-6300DI-T Decoder CHAPTER 2 Panels and Connections... -
Page 11: Front Panel
User Manual of DS-6300DI-T Decoder 2.1 Front Panel Figure 2.1 Front Panel Table 2.1 Description of Front Panel LED Indicator & Interface Connections POWER Power LED indicator LINK Network connection LED indicator Tx/Rx Data transmitting/receiving status LED indicator 2.2 Rear Panel Figure 2.2 Rear Panel... -
Page 12: Chapter 3 Initial Network Parameters Configuration
User Manual of DS-6300DI-T Decoder CHAPTER 3 Initial Network Parameters Configuration... -
Page 13: Searching Active Devices Online
This chapter aims to tell the procedures of using the SADP software to find and configure the IP address and other parameters of the device. Note: For the first-time user, the default user name of DS-6300DI-T is admin, and password is 12345. And the default IP address is 192.0.0.64. 3.1 Searching Active Devices Online ... -
Page 14: Modifying Network Parameters
User Manual of DS-6300DI-T Decoder Search online devices manually You can also click to refresh the online device list manually. The newly searched devices will be added to the list. Note: You can click on each column heading to order the information; you can click... -
Page 15: Chapter 4 Decoder Configuration And Operation By Web Browser
User Manual of DS-6300DI-T Decoder CHAPTER 4 Decoder Configuration and Operation by Web Browser... -
Page 16: Decoding Operation
User Manual of DS-6300DI-T Decoder Purpose: Since there is no local operation GUI provided for the decoder, you can manage and configure it by web browser or the iVMS-4200 client software. In this chapter, the operation and management of the decoder by the web browser is provided. - Page 17 Scaling (BNC), Output Resolution (VGA) and Display Mode. Figure 4.4 Configure Display Parameters Select the window-division display mode. The DS-6300DI-T series supports 1/4/9/16-division display mode. Select the decoding channel from the drop-down list for each sub-window. Click Save to save the settings and the prompt pops out.
-
Page 18: Configuring Dynamic Decoding
User Manual of DS-6300DI-T Decoder Figure 4.6 Enlarge the Sub-window Click OK to enlarge the selected sub-window, and the Window Enlarged in the Sub-window Configuration field will be displayed in Task 2: Restore the Sub-window Steps: Click the button again and the following prompt will pop up: Figure 4.7 Restore the Sub-window... - Page 19 Set the IP address of the stream media server. port1: Set the port No. of the stream media server. It is 554 be default if you do not configure it. hikvision: The identifier of the Hikvision SMS (stream media server) 4.0.
-
Page 20: Configuring Cycle Decoding
User Manual of DS-6300DI-T Decoder ip2: Enter the IP address of the encoding device to be decoded. port2: Enter the port No. of the encoding device to be decoded. chan: Enter the channel No. of the encoding device for decoding. -
Page 21: Enabling/Disabling The Decoding Channel
User Manual of DS-6300DI-T Decoder Note: Refer to Chapter 4.1.2 for configuring the input stream assigned to the cycle decoding channel. Figure 4.11 Edit Cycle Decoding of a Channel Click OK to save the settings and back to the Cycle Decode interface, or click Back to back to the Cycle Decoding interface without saving. -
Page 22: Configuring Picture Overlay
User Manual of DS-6300DI-T Decoder Figure 4.13 Configure Channel On/Off Select a decode channel in the drop-down list in the Decode Channel field. Set the decoding channel to On or Off. Click Save to save the settings. 4.1.5 Configuring Picture Overlay... -
Page 23: Checking The Connection Status
User Manual of DS-6300DI-T Decoder 4.1.6 Checking the Connection Status Purpose: The connection status shows the status of the decoding status and the network connection status of the decoding channel. Click Decode Operation > Decoding Status > Connection Status to view the connection status of the current decoding channel. -
Page 24: Checking The Display Channel Status
User Manual of DS-6300DI-T Decoder 4.1.8 Checking the Display Channel Status Purpose: The display channel status interface shows the video output status of the decoder, including the status for the VGA output, BNC output, and the sub-window information. Click Decode Operation > Decoding Status > Display Channel to view the working status of the display channel. -
Page 25: Decoder Configuration
User Manual of DS-6300DI-T Decoder Local Serial Port: the serial port used as the transparent channel by the decoder. Remote Serial Port: the serial port used as the transparent channel by the encoding device. Note: When the RS-232 port is used as the Local Serial Port, you must select the operating mode to Transparent Channel by entering the Configuration >... -
Page 26: Configuring Time Settings
User Manual of DS-6300DI-T Decoder Figure 4.20 Check Device Information 4.2.2 Configuring Time Settings You can set the time for the decoder in the Time Settings interface. Steps: Click Configuration > Time Settings to enter the following interface: Figure 4.21 Configure Time Settings Configure the time synchronization by NTP server or by manually. -
Page 27: Configuring Basic Network Settings
User Manual of DS-6300DI-T Decoder function, such as the server at the National Time Center (IP Address: 210.72.145.44). If the device is set up in a more customized network, NTP software can be used to establish a NTP server used for time synchronization. - Page 28 User Manual of DS-6300DI-T Decoder Steps: Click Configuration > Network Settings > DDNS to enter the DDNS Settings interface: Figure 4.25 Configure DDNS Settings Check the Enable DDNS checkbox to enable this feature. Select DDNS Type. Four different DDNS types are selectable: IPServer, DynDNS, PeanutHull and HiDDNS.
- Page 29 User Manual of DS-6300DI-T Decoder Figure 4.27 IPServer Settings • PeanutHull: (1) Enter User Name and Password obtained from the PeanutHull website. (2) Click Save to save the settings. Figure 4.28 PeanutHull Settings • HiDDNS: (1) Enter the Server Address of the HiDDNS server: www.hik-online.com.
-
Page 30: Configuring Rs-485/Rs-232 Serial Port
User Manual of DS-6300DI-T Decoder Figure 4.29 HiDDNS Settings After having successfully registered the device on the HiDDNS server, you can access your device via web Note: browser or Client Software with the Device Domain Name (Device Name). 4.2.5 Configuring RS-485/RS-232 Serial Port... -
Page 31: Configuring Alarm Input / Output Settings
User Manual of DS-6300DI-T Decoder Click Configuration > Serial Port Settings > RS-485 Port to enter the following interface: Figure 4.31 Configure RS-485 Settings Configure the RS-485 parameters, including the baud rate, data bit, stop bit and parity type. Click Save to save the settings. -
Page 32: Configuring Arming Time
User Manual of DS-6300DI-T Decoder Click Save to save your settings. Figure 4.33 Configure Alarm Output Settings 4.2.7 Configuring Arming Time Purpose: Set the time schedule for alarm input and alarm output. Steps: Click Configuration > Arming Time to enter the following interface. -
Page 33: Importing/Exporting Parameters
User Manual of DS-6300DI-T Decoder Figure 4.35 Configure User Account Note: For the admin user, only the password can be modified. 4.2.9 Importing/Exporting Parameters The configuration files of the device can be imported from or exported to local device for backup, which maintains convenient and easy parameters configuration. - Page 34 User Manual of DS-6300DI-T Decoder Click Decode Operation >Remote Playback to enter the remote playback interface: Figure 4.37 Configure Remote Playback Select a Decoding Channel from the drop-down list for playback. Enter the device information in the Remote Host IP Address, Remote Host Port, Remote Host Channel No., and login User Name and Password of the encoding device.
-
Page 35: Rebooting, Upgrading And Restoring The Default Settings For The Decoder
User Manual of DS-6300DI-T Decoder Figure 4.40 Playback Control Notes: The speed of slow forward can be set to 1/2X, 1/4X and 1/8X; and the speed of fast forward can be set to 2X, 4X and 8X. During decoding the playback on the screen, if you change the resolution of the video output, the decoding stops. - Page 36 User Manual of DS-6300DI-T Decoder Click icon to enter the Restore Default interface. Click Complete to restore all factory settings of the decoder. Click Simple to restore the settings except the user management and network parameters of the decoder. Figure 4.42 Restore Default Settings...
-
Page 37: Chapter 5 Decoder Configuration And Operation By Client Software
User Manual of DS-6300DI-T Decoder CHAPTER 5 Decoder Configuration and Operation by Client Software... -
Page 38: Adding An Encoder
User Manual of DS-6300DI-T Decoder Run the disk of iVMS-4200 software, and double click the icon to install it in your PC. In this chapter, the basic procedure of operating the decoder by the software is described. Please refer to the user manual of iVMS-4200 for more detailed information. - Page 39 User Manual of DS-6300DI-T Decoder Figure 5.2 Add Device by IP Address Task2: Add the device by IP server or HiDDNS. Check the checkbox of Edit the nickname of the encoding device. Select the DDNS type to IP Server or HiDDNS by checking the checkbox.
- Page 40 User Manual of DS-6300DI-T Decoder Figure 5.4 Add Third-party Device Note: The added third-party encoding device is only a virtual node, and the live view and parameters configuration cannot be realized via the iVMS-4200 client software. You can check the successfully added device on the Device Management interface.
-
Page 41: Adding A Decoder
User Manual of DS-6300DI-T Decoder 5.2 Adding a Decoder Steps: Click in the control panel to enter the decoding device management interface. Click to add the decoder to the management list of the software. Enter the Nickname, IP address and port number of the device, and input the user name and password to get access to it. - Page 42 User Manual of DS-6300DI-T Decoder Figure 5.9 List of Added Decoders You can also click Show online devices to add the decoder. Please refer to Section 0 Adding an Encoder for operating instructions.
-
Page 43: Setting Tv Wall Layout
User Manual of DS-6300DI-T Decoder 5.3 Setting TV Wall Layout Steps: In the control panel, click to enter the TV Wall setting interface. Click to add the screen information. Figure 5.10 Add Screen Information Edit the nickname, and enter the number of screens in row and column. -
Page 44: Decoding Operation
User Manual of DS-6300DI-T Decoder Figure 5.12 Configure Screen Layout You can double click a decode channel on the list to modify its nickname and video standard (BNC) or resolution (VGA). Figure 5.13 Modify Output Information 5.4 Decoding Operation Steps: In the control panel, click to enter the TV Wall interface. - Page 45 User Manual of DS-6300DI-T Decoder Figure 5.14 TV Wall Interface In this configuration interface, the left bar lists the encoding devices which has been added to the client software, and the bottom bar with the configuration of the decoding action.
-
Page 46: Configuring Remote Settings For The Decoder
User Manual of DS-6300DI-T Decoder 5.5 Configuring Remote Settings for the Decoder Steps: On the Decoding Device Management interface, select a decoder from the list and click to enter the remote settings interface. Figure 5.16 Decoder List You can view the device information, and configure the parameters for the device. -
Page 47: Chapter 6 Appendix
User Manual of DS-6300DI-T Decoder CHAPTER 6 Appendix... -
Page 48: Appendix A. Specifications
User Manual of DS-6300DI-T Decoder Appendix A. Specifications Model DS-6304DI-T DS-6308DI-T DS-6316DI-T 2-ch 4-ch 4-ch 1920×1080@60/50Hz, 1600×1200@60Hz, VGA Output 1280×1024@60Hz, Audio/ 1280×720@50/60Hz, 1024×768@60Hz Video Output CVBS Output 4-ch 8-ch 16-ch 2-ch, RCA connector; 4-ch, RCA connector; 4-ch, RCA connector; Audio Output 4-ch, DB15 connector×1... -
Page 49: Appendix B. Faq
User Manual of DS-6300DI-T Decoder Appendix B. FAQ Why cannot ping the decoder? Check the cable and the switch. Please refer to Chapter 3 to configure the IP address of the decoder. Why cannot connect the decoder with client software? Check the decoder IP address. -
Page 50: Appendix C. List Of Third-Party Ip Cameras Access
User Manual of DS-6300DI-T Decoder Appendix C. List of Third-party IP Cameras Access IP Camera Model Manufacturer Supported Video Format SP306H Panasonic SP336H SNC-CH220 Sony SNC-RH124 P5532 Axis Q7404 H.264, MPEG4 Sanyo VCC-HD2500P Bosch NBC265P Zavio D5110 Arecont AC1305M IX30DN-ACFZHB3...
