Ultra-High-Resolution CMOS
Monochrome Camera
CSC12M25BMP19
Operation manual
Contents
BEFORE USE - GENERAL SAFETY INSTRUCTIONS .................1
CASES FOR INDEMNITY (LIMITED WARRANTY).....................4
RESTRICTION FOR USE..................................................................4
Usage Precautions ...............................................................................5
1. Outline .............................................................................................8
2. Characteristic...................................................................................8
3. Configuration...................................................................................9
4. Option..............................................................................................9
5. Installation .....................................................................................10
6. Cabling ..........................................................................................11
7. Maintenance port...........................................................................12
8. Specification..................................................................................12
9. Command Communication Protocol .............................................21
10. Register map................................................................................23
11. Function.......................................................................................25
12. External-view Drawing ...............................................................29
D4163443A
Advertisement
Table of Contents
Related Manuals for Toshiba teli CSC12M25BMP19
Summary of Contents for Toshiba teli CSC12M25BMP19
-
Page 1: Table Of Contents
Ultra-High-Resolution CMOS Monochrome Camera CSC12M25BMP19 Operation manual Contents BEFORE USE - GENERAL SAFETY INSTRUCTIONS ....1 CASES FOR INDEMNITY (LIMITED WARRANTY).....4 RESTRICTION FOR USE..............4 Usage Precautions ................5 1. Outline .....................8 2. Characteristic...................8 3. Configuration...................9 4. Option....................9 5. Installation ..................10 6. Cabling ..................11 7. -
Page 2: Before Use - General Safety Instructions
BEFORE USE GENERAL SAFETY INSTRUCTIONS This instruction manual contains important information for the operator (user) and/or people in the vicinity to avoid personal injury, or property damage. • Prior to use, read this operation manual carefully to fully understand its instructions for correct use. •... - Page 3 ●Handling Precautions WARNING Immediately cease use of the equipment in the event of abnormality or malfunction. If abnormal conditions are present, such as smoke, a burning smell, ingress of water or foreign matter, or if the equipment is dropped or malfunctions, fire or electric shock may result. If such abnormalities occur, disconnect the power plug from the outlet and contact your sales unplug representative.
- Page 4 CAUTION Observe the following when installing the equipment: · Do not cover the equipment with a cloth, etc. · Do not place the equipment in a narrow location where heat is likely to accumulate. Otherwise, heat will accumulate inside the equipment, possibly resulting in a fire. Instruction Do not place the equipment in locations subject to high moisture, oil fumes, steam, or dust.
-
Page 5: Cases For Indemnity (Limited Warranty)
CASES FOR INDEMNITY (LIMITED WARRANTY) We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user in the following cases. In the case damage or losses are caused by fire, earthquake, or other acts of God, acts by a third party, deliberate or accidental misuse by the user, or use under extreme operating conditions. -
Page 6: Usage Precautions
Usage Precautions Handle carefully Do not drop the equipment or allow it to be subject to strong impact or vibration, as such action may cause malfunctions. Further, do not damage the connection cable, since this may cause wire breakage. Environmental operating conditions Do not use the product in locations where the ambient temperature or humidity exceeds the specifications. - Page 7 Following information is only for EU-member states: The use of the symbol indicates that this product may not be treated as household waste. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
- Page 8 环保使用期限标识，是根据电子信息产品污染控制管理办法以及，电子信息产 品污染控制标识要求(SJ/T11364-2006)、电子信息产品环保使用期限通则，制 定的适用于中国境内销售的电子信息产品的标识。 电子信息产品只要按照安全及使用说明内容，正常使用情况下，从生产月期算 起，在此期限内，产品中含有的有毒有害物质不致发生外泄或突变，不致对环 中华人民共和国 境造成严重污染或对其人身、财产造成严重损害。 环保使用期限 产品正常使用后，要废弃在环保使用年限内或者刚到年限的产品时，请根据国 家标准采取适当的方法进行处置。 另外，此期限不同于质量/功能的保证期限。 The Mark and Information are applicable for People's Republic of China only. ＜ ＜ ＜ ＜ 产 产 产 产 品中有毒有害物 品中有毒有害物质 质 质 质 或元素的名称及含量 或元素的名称及含量＞ ＞ ＞ ＞ 品中有毒有害物...
-
Page 9: Outline
(1) High-speed output of an ultra-high-resolution image The TOSHIBA TELI’s proprietary 1.9 type 12,580 thousand pixel ultra-precision CMOS sensor outputs the entire 12,580 thousand pixels in a speed as high as 25fps. A high amount of information in 320M Byte/Sec. -
Page 10: Configuration
(9) New lens mount TFL-II TOSHIBA TELI’s unique TFL-II mount to take advantage of the resolution of a large high-precision sensor is employed for the lens mount. The TFL-II mount is large and has a flange back as short as 17.5mm to support high performance lenses. -
Page 11: Installation
5. Installation This camera has four mounting holes on the bottom and the front each and can be mounted on the equipment with either face. Pay attention to the following points to install it. (1) The length of a screw inserted into a camera shall be 5mm or less. (2) Tighten all four screws on the installation surface. -
Page 12: Cabling
Check with the cable maker for handling the minimum bending radius if other cables than options shown below are used. ■Option cable Static minimum bending Cable Model Maker radius (recommended value) Camera link cable 14B26-SZLB-***-0LC Sumitomo 3M Ltd. 90mm Power cable CPRC3700-** TOSHIBA TELI 60mm CORPORATION “**” indicates cable length. D4163443A... -
Page 13: Maintenance Port
7. Maintenance port A rubber cap on the back of the camera is attached to protect the connector for the maintenance of the camera. If the connector is damaged, the camera may not be maintained. Do not press the rubber cap firmly. Do not remove the rubber cap to prevent foreign body from getting mixed. - Page 14 Gain ・Digital gain 0 to +18 dB [180 steps] (Factory setting: 0 dB) Setup 0 to Approx. 13% [528 steps] (Factory setting: Approx. 3.9%…132 ) (10) Dynamic range Approx. 58 dB (standard) (11) Gamma 1.0 (standard) (12) Power voltage DC12 V ± 10 % (Ripple 50 mV(p-p) or less) (13) Power consumption Approx.
- Page 15 Positive/negative Polarity switchable (Factory default: Negative) ・Pulse width 50 µsec or more [Output signal specification] None [Machine dimension] (1) Lens mount TOSHIBA TELI’s unique TFL-II mount ・Mount screw M48mm P=0.75 ・Positioning engagement Φ50mm H7 ・Flange back 17.5 mm Request: Combinational lens Some lenses may not exert full performance of a camera including the decline in the peripheral resolution, the decline in the reduction of brightness, generation of ghost and aberration.
- Page 16 -5 to 50°C Humidity: 10 to 0% (No dew formation) (3) Storage temperature Temperature: -20 to 60°C Humidity: 90% or less (No dew formation) [Representative spectral sensitivity characteristic] Spectral Sensitivity Specification for CSC12M25BMP19 100.0 90.0 80.0 70.0 60.0 50.0 40.0 30.0 20.0 10.0...
- Page 17 [Connector pin arrangement] (1) Image output/control connector (Camera Link Medium Configuration) CAMERA LINK1⋅2 ・Connector type: MDR 26-PIN connector 10226-2210PE (3M) ●Connector: CAMERALINK1 Pin No. Signal Pin No. Signal X CLK OUT- X CLK OUT+ Ser TC（RxD）+ Ser TC（RxD）- Ser TFG（TxD）- Ser TFG（TxD）+ CC1（TRIG）- CC1（TRIG）+...
- Page 18 (2) Power/synchronous signal input connector DC IN ・Connector (camera side) : HR10A-10R-12PB(71) (HIROSE ELECTRIC) ・Compatible plug (cable side): Equivalent to HR10A-10P-12S(73) (HIROSE ELECTRIC) or equivalent Pin No. Signal +12V N.C. N.C. N.C. N.C. 本体背面から見た図 View from the back N.C. TRIG [Switch setting] Various settings are available with the dip switch on the back.
- Page 19 (2) Communication speed setting The speed of the serial communication can be set by the camera link. The power of the camera needs be turned on again to switch modes. Communication speed ＊9600 bps 19200 bps 38400 bps 57600 bps (3) Specifying a memory bank before starting Specify a memory bank to be referenced before turning on the power of the camera for SW4 through SW6.
- Page 20 [Timing chart] (1) Horizontal timing *For Medium configuration The figure in parentheses indicates that for Base configuration. 1) Reading all pixels FVAL LVAL DVAL DATA OUT1～4 (DATA OUT1～2) CLK：82.5MHz a = 1048 (2096) CLK b = 4 (8) CLK c = 1024 (2048) CLK *d = 8 (16) CLK e = 16 (32) CLK f = 1052 (2104) CLK...
- Page 21 ●Base Configuration DATA CLOCK DVAL 4089 4091 4093 4095 DATA OUT1 DATA OUT2 4090 4092 4094 4096 a = 12.12ns b = 24.82μs （82.500MHz) （40.283kHz） (2) Vertical timing *For Medium configuration Figures in parentheses are for Base configuration. 1) Reading all pixels (when the shutter is OFF) FVAL LVAL DATA OUT1～4...
-
Page 22: Command Communication Protocol
9. Command Communication Protocol The command communication protocol is the TELI standard method (method in which parameters are set in the registers in the camera). In command send/receive operation, hexadecimal address and data are converted to ASCII data. All ASCII alphabetic characters used are uppercase characters. (1) Write to a register To write data in a register, send a command, as follows. - Page 23 (2) Reading the register To read data from a register, send ', (comma)', 'R', 'Q' and [CR] code following the address. For example, to read data in address 0x91, send a command, as follows: ‘9’ ‘1’ ‘ , ’ ‘R’ ‘Q’...
-
Page 24: Register Map
10. Register map The following accesses are available via the camera link serial interface. CMOS Monochrome Camera Address Access CSC12M25BMP19 Manufacturer(Maker) name Manufacturer(Maker) name Access Access Manufacturer(Maker) name Manufacturer(Maker) name Manufacturer(Maker) name Access Access 0x00 R.O. TOSHIBA TELI R/W : Read/Write possible ASCII format R.O. - Page 25 CMOS Monochrome Camera Address Access Access Access Access Access CSC12M25BMP19 R/W : Read/Write possible Scan mode Scan mode Scan mode Scan mode 0x90 Scan mode R.O. : Read Only 0(Normal)/1(WOI)/2(Binning)/3(Subsampling) 0x91 Shutter mode W.O. : Write Only Default setting：0(Normal) N.A. : Not Available...
-
Page 26: Function
11. Function 11.1 Reading mode Images can be output from the camera link connector and imported from the frame grabber board. The frame rate and the resolution of the output image supported by this model are shown below (when the shutter if OFF). Mode Setting Frame rate... - Page 27 11.2 Random trigger shutter Images can be taken and imported at arbitrary timing by inputting an external trigger signal in a random trigger shutter mode. ・External trigger signals can be input from either the camera link I/F CC1 or the DC IN connector. However, signals cannot be input at the same time.
- Page 28 2) Pulse width mode ・The exposure time is determined by the pulse width (exposure time = pulse width + 2CLK). ・The pulse width should be more than 50 µsec. *Example of timing charts to expose all pixels TRIG Exposure FVAL LVAL DATA OUT1 to 4 (DATA OUT1 to 2)
- Page 29 11.3.1 Image output for WOI Images are outputted per line. Therefore, when multiple windows are set on the same line, images of multiple windows are included in the image output of the line. (1) When multiple windows are set on the same line (2) When multiple windows overlap 11.4 Multi-slope (to be implemented) An apparently wide dynamic range is obtainable through exposure up to four times.
-
Page 30: External-View Drawing
12. External-view Drawing Dip switch Maintenance port Design specification Material Lens mount, Cover ：Aluminum die cast Chassis ：Cold rolled steel Processing Lens mount, Cover ：Cation-resistant aluminum alloy Chassis ：Nickel plating D4163443A... - Page 31 Note. D4163443A...
- Page 32 Head Office: 7-1, 4 chome, Asahigaoka, Hino-shi, Tokyo, 191-0065, Japan (Overseas Sales Department) Phone: +81-42-589-8771 Fax: +81-42-589-8774 URL: http://www.toshiba-teli.co.jp The design and specification is subject to change without notice. Distributer D4163443A...
