CMOS Camera
BU Series
BU205M
BU406M
BU406MC/BU406MCF
Specifications
Ver.2.5
Information contained in this document is subject to change without prior notice.
D4222901E
Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved.
http://www.toshiba-teli.co.jp/index.htm

Advertisement

Table of Contents
loading

Related Manuals for Toshiba teli BU205M

Summary of Contents for Toshiba teli BU205M

  • Page 1 CMOS Camera BU Series BU205M BU406M BU406MC/BU406MCF Specifications Ver.2.5 Information contained in this document is subject to change without prior notice. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 2: Table Of Contents

    Configuration ..............................6 Optional part ..............................6 Functions ................................ 7 Specifications .............................. 14 Timing chart ..............................23 Warranty rules ............................. 25 Repair ................................26 10. Outline Drawing ............................27 D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 3: Restriction For Use

    (*2) :Equipment relating to maintenance of public services/functions involving factors of safety refers - Traffic control systems for air transportation, railways, roads, or marine transportation - Equipment for nuclear power generation - Equipment related to the above D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 4: Cases For Indemnity (Limited Warranty)

     Expenses we bear on this product shall be limited to the individual price of the product.  The item that is not described in specifications of this product is off the subject of the guarantee.  The attachment mistake of a cable. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 5: Usage Precautions

    If an intense magnetic or electromagnetic field is generated near the camera or connection cable, noise may be generated on the screen. If this occurs, move the camera or the cable. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 6 The brightness of the upper part of the screen may be different from that of the lower part. Note that this is a characteristic of a CMOS image sensor and is not a fault. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 7: Overview

    Overview This BU CMOS series is an integrated-(one-body)-type camera that adopts a global shutter CMOS sensor. These are BU205M (2M 2/3 type) BU406M (4M 1/1 type). Suffix [C] or [CF] are attached to the color models. For video output and camera control, the USB 3.0 interface standard is adopted for high transfer rate, and it is easy to integrate into industrial equipment.

  • Page 8: Configuration

    * No application software and manuals are attached to this camera. Optional part - Camera mounting kit Model name: CPTBU * Contact your dealer / distributor for details of option units. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 9: Functions

    (OPWB). Select the mode to suit the subject and purpose. 5.6.1 MWB R/B gain can be set independently. 5.6.2 OPWB When OPWB is executed, the camera adjusts R/B gain automatically. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 10 - When the interval of the input trigger signal is extremely short, or when the trigger signal is noisy, there is a possibility of causing the malfunction. In this case, please input a proper trigger signal. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 11 - In Sequential Shutter mode, window size is unchangeable. Trigger Delay You can add the delay between trigger signal input and the start of exposure. Trigger signal TriggerDelay Exposure USB bus Image D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 12 : End of transferring streaming data. (6) ExposureStart : Start of Exposure. (7) ExposureEnd : End of Exposure. (8) Timer0Start : Start of Timer0. (9) Timer0End : End of Timer0. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 13 An External trigger is input during this period, exposure starts immediately. EXT_TRIG Exposure CMOS Transfer USB Bus Delay Duration TIMER0 ACTIVE EXPOSURE ACTIVE FRAME ACTIVE FRAME TRANSFER FRAME TRIGGER WAIT * ActiveLow D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 14 In the scalable mode, camera reads out only necessary area at the normal speed and reads out other area at high speed. The trigger interval can be shorter when the vertical height size is small. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 15 ) (@ 8-bit) Grey B : Full screen 170 LSB (10101010 ) (@ 8-bit) Horizontal ramp waveform Vertical ramp waveform Grey scale (B/W model only) Color bars (Color model only) D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 16: Specifications

    Black, White, Grey A, Grey B Horizontal ramp waveform, Vertical ramp waveform Grey scale (factory setting : OFF) Power supply DC +5V5% (from USB connector) Power consumption(*1) 2.7W (maximum) D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 17 Horizontal ramp waveform, Vertical ramp waveform Color bars (factory setting : OFF) Power supply DC +5V5% (from USB connector) Power consumption(*1) 2.7W (maximum) (*1) at the all pixel readout (*2) with IR-cut filter D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 18 The exposure time depends on the MANUAL Exposure time setting 255 times (maximum) Number of Exposures in Bulk mode Sequential Shutter 16 entries (maximum) 0 to 2000000μs (factory setting : 0μs) Trigger Delay D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 19 Delay 0 to 2000000μs (factory setting : 0μs) Duration TimerTriggerSource Line0Active, ExposureStart, FrameTrigger Interface specification Interface USB 3.0 (Only SuperSpeed is supported) Transmission speed 5Gbps (Maximum) USB3 Vision Protocol D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 20 (e.g. dropping frames may occur). In this case, change to frame rate setting lower. Event notification FrameTrigger, FrameTriggerError, FrameTriggerWait Event name FrameTransferStart, FrameTransferEnd ExposureStart, ExposureEnd Timer0Start, Timer0End Event notification delay approx. 10us later from the event occurs Time stamp unit 16.7ns (60.0MHz) D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 21 - Shielded wire UL1533 (AWG28) (Hitachi Cable, Ltd.) Connection: e-CON GPIO(Line2) GPIO(Line2) GPIO(Line1) GPIO(Line1) TRIG IN TRIG IN Please confirm the EMC adaptability when it combines with parts other than them. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 22 * Matching connector is not an accessory of this product. Pin assignment ↑TOP * Above figure is connector view from insert side. Pin No. Signal Name Function GPIO(Line2) GPIO Output GPIO(Line1) GPIO Output Ground TRIG_IN Trigger Input D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 23 6.13 Typical spectral response The lens characteristics and light source characteristics is not reflected in table. <BU205M / BU406M> D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 24 <BU406MC> <BU406MCF> D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 25: Timing Chart

    BU205M Frame Rate setting BU406M/C 11.1 by the application. 11.1 * If the value of T2 is not set by the application, it will be the same as T1. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 26 - When the interval of the input trigger signal is extremely short, or when the trigger signal is noisy, there is a possibility of causing the malfunction. In this case, please input a proper trigger signal. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 27: Warranty Rules

    9. Forgery product, products which does not have proper serial number, products of which serial number is forged, damaged or deleted 10. All defects that happened after the expiration for a warranty term D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 28: Repair

    10. The immunity from responsibility of the product is applied in the repair completion products. * Please refer for the inquiry about the software to our homepage or sales personnel. D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 29: Outline Drawing

    Outline Drawing D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 30 □ It certainly occurs. □ It sometimes occurs. □ It occurs, after time passes. （ □ Others ） <For dealer use> Reception date : Receipt No. : JOB No. : Check : D4222901E Copyright © 2014 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
