BU Series
CMOS Camera
Instruction Manual
Model
B/W Camera
: BU205M / BU406M / BU406MN
Color Camera
: BU406MC / BU406MCF
Thank you for purchasing our product.
Before using this CMOS camera, please read through this instruction manual
carefully in order to use this product correctly and safely.
After reading, keep this instruction manual handy so that you can refer to,
whenever you need it.
Information contained in this document is subject to change without prior notice.
Standard name might be trade mark of each company.
Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved.
D4223121M
http://www.toshiba-teli.co.jp/en/

Advertisement

Table of Contents
loading

Related Manuals for Toshiba teli BU Series

Summary of Contents for Toshiba teli BU Series

  • Page 1 After reading, keep this instruction manual handy so that you can refer to, whenever you need it. Information contained in this document is subject to change without prior notice. Standard name might be trade mark of each company. D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 2: Table Of Contents

    DPCControl ........................... 74 SequentialShutterControl ......................75 Appendix ........................78 UserSetSave and UserSetQuickSave difference ................. 78 MultiFrame and Bulk function difference ..................80 Warranty rules ....................... 83 Repair ..........................84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 3: Safety Precautions

    This sign indicates MANDATORY ACTION (You are required to do). MANDATORY The content of action is shown by a picture or words beside the symbol. 2 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 4: General Handing

     Do not be handled roughly, damaged, fabricated, bent forcefully, pulled, twisted, bundled, placed under heavy objects or heated the power cable and the connection cable. Avoid Otherwise, fire or electric shock may result. CAUTION 3 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 5 (every approx. five years). Accumulation of dust inside the equipment may result in fire or electric shock. For inspection and cleaning costs, contact your sales representative. Instruction 4 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 6: Cases For Indemnity (Limited Warranty)

    ● The item that is not described in specifications of this product is out of the guarantee. ● The case of damages or losses which are caused by incorrect connection of the cable is out of the guarantee. 5 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 7: Restriction For Use

    (*2): Equipment relating to maintenance of public services/functions involving factors of safety refers to. - Traffic control systems for air transportation, railways, roads, or marine transportation - Equipment for nuclear power generation - Equipment related to the above 6 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 8: Notes On Using This Product

    C-mount lens 10mm or less ● Mounting to pedestal When mounting this product to a pedestal, make sure carefully that lens doesn’t touch with the pedestal. 7 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 9 Never use alcohol, benzene, thinner, or other chemicals because such chemicals may damage or discolor the paint and indications. If the image pickup surface becomes dusty, contaminated, or scratched, consult your sales representative. 8 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 10 The brightness of the upper part of the screen may be different from that of the lower part. Note that this is a characteristic of a CMOS image sensor and is not a fault. 9 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 11 This information is applicable for People's Republic of China only. リサイクルに関する情報（包装物） 有关再利用的信息(包装物) Information on recycling of wrapping composition 内部緩衝材料・袋 内部缓冲材料·袋 箱／箱子／Box Internal buffer materials・Bag ペーパーボード 纸板 Paper board 10 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 12: Installation

    ● TOSHIBA TELI CORPORATION Top Page http://www.toshiba-teli.co.jp/en/index.htm ● Service & Support https://www.toshiba-teli.co.jp/cgi/ss/en/service.cgi Please refer to the TeliCamSDK startup guide, about Operation environment, Installation, and Setup. 11 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 13: Specifications

    This product is based on GenICam (Generic Interface for Cameras) Ver. 2.4 and Ver. 3.0. ● IIDC2 Digital Camera Control Specification Ver.1.1.0 This product is based on IIDC2 Digital Camera Control Specification Ver.1.1.0. 12 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 14 * Suffix [F] is not shown in the common part of specifications. ● Compact and lightweight This camera is compact and lightweight; it is easy to integrate into industrial equipment. ● EU RoHS & Chinese RoHS 13 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 15: Configuration

    *1: Optional part. Contact your sales representative for details of option units. *2: Commercial items. 14 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 16: Connection

    Please confirm wires’ specifications before use them. Lost packets may occur by an electrical characteristic of the transmission line of USB3.0. (USB3.0 Interface Card, USB3.0 Cable, and USB3.0 HUB). 15 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 17: Connector Pin Assignment

    ↑TOP *Above figure is connector view from insert side. Pin No. Signal Function GPIO(Line2) GPIO Input / Output GPIO(Line1) GPIO Output Ground TRIG_IN(Line0) Trigger Input 16 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 18: Outline Drawing

    Outline Drawing 17 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 19: General Specifications

    29 mm(W) x 29 mm (H) x 16 mm (D) (Not including protrusion) Mass Approximately 32g Lens mount C-mount Flange back 17.526mm Camera body grounding: Conductive between circuit GND and camera body insulation status 18 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 20 29 mm(W) x 29 mm (H) x 16 mm (D) (Not including protrusion) Mass Approximately 32g Lens mount C-mount Flange back 17.526mm Camera body grounding: Conductive between circuit GND and camera body insulation status 19 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 21: Led Status

    Slow flash orange (ON: 400ms, OFF: 1600ms) Data being transferred Solid Green Error during data transfer Solid Red (Time period: 500ms) Stand-by Super slow flash orange (ON:200ms, OFF: 2800ms) 20 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 22: I/O Specification

    EXT_TRIG signal. Please confirm it before use. Notes of input level: Line0 and Line2 have different input level. Please use input level within the voltage described in this specification. 21 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 23 - Pin 3 is signal ground. It is conducted with camera frame. Using shield cable, terminal processing of the shield is referred as above. - Please confirm the EMC adaptability in whole of your system. 22 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 24 *Even if LineMode is set as Output, the input signal to Line2 is valid when LineSource is set as Off. Input / Output circuit diagram Inside IOLineModeAll DC5.0V 10kΩ 23 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 25 : High active / Low active (initial factory setting: Low active) Signal Source (LineSource) : Off / UserOutput / Timer0Active / AcquisitionActive FrameTriggerWait / FrameActive / FrameTransferActive ExposureActive 24 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 26: Timing Specification

    BU406M/MN/MC 11.1 11.1 application. * If the value of T2 is not set by the application, it will be the same as T1. 25 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 27 When the interval of the input trigger signal is extremely short, or when the trigger signal is noisy, there is a possibility of causing the malfunction. In this case, please input a proper trigger signal. 26 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 28: Typical Spectral Response

    Typical Spectral Response * The lens characteristics and light source characteristics is not reflected in table. ● BU205M / BU406M /BU406MN 27 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 29 ● BU406MC ● BU406MCF 28 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 30: Operating Ambient Conditions

    (Hitachi cable, Ltd.) Connection: e-CON GPIO(Line2) GPIO(Line2) GPIO(Line1) GPIO(Line1) TRIG IN(Line0) TRIG IN(Line0) Please confirm the EMC adaptability when it combines with parts other than them. 29 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 31: Functions

    FrameSynchronization Frame synchronization control LEDIndicatorLuminance LED luminance control AntiGlitch AntiGlitch control AntiChattering AntiChattering control DPCControl DPCControl Defect pixel correction control SequentialShutterControl SequentialShutterControl Sequential shutter control 30 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 32 FrameSynchronization ○ ○ ○ ○ LEDIndicatorLuminance ○ ○ ○ ○ DPCControl ○ ○ ○ ○ SequentialShutterControl Details of each feature are described in following pages. 31 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 33: Bootstrap Registers

    When opening and closing the stream channel, it is required to control StreamEnable plus SDK setups on your application. Please refer to the TeliCamSDK for details. 32 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 34: Devicecontrol

    Beginner Returns the model name. DeviceManufacturerInfo Beginner Returns the manufacturer information. DeviceVersion Beginner Returns the device version. DeviceID Beginner Returns the device ID (serial number). 33 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 35: Imageformatcontrol

    Scalable Mode / Decimation Mode Format2 Scalable Mode / Decimation Mode * initial factory setting ● Note Changing “ImageFormatSelector” register value is invalid during image stream data output. 34 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 36: Scalable

    Scalable BU series provides the scalable mode that can read out defined area of the screen. In the scalable mode, camera reads out only necessary area at the normal speed and reads out other area at high speed. The frame rate can be faster when the vertical height size is small. However, the frame rate cannot be faster only when the horizontal width size is small.
  • Page 37 Maximum unit size (*) 2048x1088 2048x2048 * initial factory setting ● Note Changing “Width”, “Height”, “OffsetX”, “OffsetY” register value is invalid during image stream data output. 36 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 38: Decimation

    Fig. Decimation operation ● Registers Register Visibility Access Description DecimationHorizontal Beginner Set the number of Horizontal Decimation line(s). DecimationVertical Beginner Set the number of vertical Decimation line(s). 37 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 39 BU205M BU406M/MN/MC Minimum (*) Value 1,2,4,8 Maximum * initial factory setting ● Note Changing “DecimationHorizontal”, “DecimationVertical” register value is invalid during image stream data output. 38 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 40: Reverse

    Set the following value to “ReverseX”, “ReverseY” registers. Setting value is Boolean type. Value Image reverse FALSE (*) Non reverse TRUE Reverse * initial factory setting 39 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 41: Pixelformat

    * initial factory setting ● Note Bayer alignment of color models is dependent on its model. Changing “PixelSize” register value is invalid during image stream data output. 40 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 42: Testpattern

    TestPattern BU series supports test pattern data output. Camera provides following Test patterns; Black White GreyA GreyB GreyHorizontalRamp GreyVerticalRamp GreyScale ColorBar (B/W model only) (Color model only) Fig. Test pattern (e.x. BU406M / BU406MC) 41 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved.
  • Page 43 All pixels = 170 @Mono8 GreyB All pixels = 85 @Mono8 GreyHorizontalRamp Horizontal Ramp GreyVerticalRamp Vertical Ramp GreyScale Grey scale ColorBar Color bars * initial factory setting 42 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 44: Acquisitioncontrol

    - Set the number of frames to transfer (In MultiFrame mode) Set the number of frames to transfer to “AcquisitionFrameCount”. Setting value is Integer type. 43 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 45 Depends on your PC or USB3.0 interface card configurations, images may not be captured normally (e.g. frame drops may occur). In this case, change to frame rate setting lower. 44 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 46: Imagebuffer

    Set “On” to “TriggerMode” register, and set “TriggerSoftware” or “Line0” to ”TriggerSource” register. - Activate image buffer mode Set “On” to “ImageBufferMode” register. ImageBufferMode Function OFF (*) Inactive Active * initial factory setting 45 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 47 [Start] button in TeliU3vViewer can’t deal with “StreamEnable” register alone. Please substitute procedure “StreamEnable” = 1 to following instructions. - Push [Start] button on TeliU3vViewer main window. - Execute [AcquisitionStop] in XML window. 46 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 48: Triggercontrol

    TriggerControl This section describes trigger control of TriggerControl category for the BU series. This camera series provides two kinds of exposure synchronization. 1. Normal Shutter mode : Free run operation (internal synchronization) 2. Random Trigger Shutter mode : Synchronized with external trigger input In Random Trigger Shutter mode, two kinds of trigger input are available.
  • Page 49 And you can add delay time from trigger edge to exposure start by register setting. Trigger signal TriggerDelay Exposure USB Streaming Image Fig. Trigger Delay Details of Random Trigger Shutter operation, refer to "Timing" of "Specification". 48 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 50 Set the following value to “TriggerSource” register. Setting value is Enumeration type. TriggerSource Function Line0 (*) Hardware trigger TriggerSoftware Software trigger * initial factory setting 49 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 51 -In SoftwareTrigger operation, the delay time from “TriggerSoftware” to exposure is not guaranteed. - TriggerDelay is applied to both of HardwareTrigger and SoftwareTrigger. - TriggerAdditionalParameter is only effective in Bulk mode. 50 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 52: Exposuretime

    ExposureTime BU series is able to adjust exposure time by using electric shutter control. BU USB series provides two kinds of exposure time control mode. - Manual : The exposure time is determined by “ExposureTime” register setting value. - NoSpecify : The exposure time is determined by “AcquisitionFrameRate”...

  • Page 53: Digitaliocontrol

    DigitalIOControl This section describes DigitalIOControl category for the BU series. This camera provides GPIO output selected by the register setting. And the polarity of the signal is able to switch by the register setting. The following chart shows the specifications of the selectable signals.
  • Page 54 This signal can be used as strobe control signal. Timer0Active The delay time and pulse width of this signal are configurable. UserOutput Outputs the value set in “UserOutputValueAll”. * initial factory setting 53 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 55 UserOutputValueAll[2] Line1 (GPIO_Output) LineStatusAll[2] LineStatusAll[1] LineStatusAll[0] LineModeAll Fig. GPIO internal circuit diagram ● Note About the details of Timer0Active signal, refer to “TimerControl” of "Functions". 54 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 56: Antiglitch / Antichattering

    Edge Edge Edge Edge Output Invalid Edge AntiChattering Insensible Insensible Value Time Time High AntiChattering Circuit Valid Valid Output Signal Signal Fig. AntiGlitch and AntiChattering 55 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 57 The setting is applied to the GPIO Input of Line0 and Line2. Insensitive time AntiChattering [sec] Minimum (*) 0.000 001 992 Maximum 0.001 999 992 * initial factory setting 56 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 58: Timercontrol

    TimerControl This section describes TimerControl category for the BU series. This camera series is able to generate Timer0Active signal, derived from exposure start, by register setting. This signal can be used as strobe control signal. (Selected by TriggerSource) TimerTriggerSource = Line0Active...
  • Page 59 HardwareTrigger and Software Trigger mode, and not to be responsed at FrameTriggerError. ExposureStart is available in both HardwareTrigger and Software Trigger mode, and not to be responsed at Timer0Active pulse delays TiggerDelay+TimerDelay[us]. FrameTriggerError. 58 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 60: Gain

    Gain This section describes Gain control of LuminanceControl category of the BU series. This control adjusts the gain of the image. Fig. Gain ● Registers Register Visibility Access Description Gain Beginner Sets the absolute Gain. ● Setting - Set Manual Gain Set the following value to “Gain”...

  • Page 61: Blacklevel

    BlackLevel This section describes BlackLevel control of LuminanceControl category of the BU series. This control adjusts the black level of the image. It is adjustable from -25% to +25% as white saturation level is 100%. However, when BlackLevel is lower than 0[%], the image level may not be saturated.

  • Page 62: Gamma

    Gamma This section describes Gamma correction of AnalogControl category for the BU series. This function allows you to apply a gamma correction to the output images. output luminance Gamma input luminance Fig. Gamma correction ● Registers Register Visibility Access Description...

  • Page 63: Balanceratio

    BalanceRatio This section describes BalanceRatio control of AnalogControl category for the BU series. This control adjusts the white balance gain of the image. This function is available only in Color models. BalanceRatio BalanceRatio Input Signal Level Output Signal Level Fig. BalanceRatio ●...
  • Page 64 Too high white balance gain increases noises. After adjusting the white balance of the image, I ask you to have final image quality checked with your environment. 63 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 65: Balancewhiteauto

    No operation Once Execute auto white balance once. * initial factory setting ● Note BalanceRatio and BalanceWhiteAuto controls are available in following PixelForamt modes. Bayer*8 64 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 66: Lutcontrol

    “LUTIndex” register value is input level of LUT, and “LUTValue” register value is output level of LUT. LUTIndex / LUTValue setting value Minimum (*) Maximum 1023 * initial factory setting 65 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 67: Usersetcontrol

    FrameSynchronization DigitalIOControl LineMode LEDIndicatorLuminance LineInverter UserOutputValue LineSelector LineSource (*) DPC and SequentialShutter entries are stored to a single channel. Entries are shared with all channels. 66 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 68 When execute “UserSetSave”, the camera saves user setting to the channel selected in “UserSetSelector” register. When execute “UserSetQuickSave”, the camera saves user setting to the channel selected in “UserSetSelector” register. 67 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 69 UserSet1 (*) - DPC feature ON in the defective pixel coordinates already set. UserSet2~15 Memory channel 2 to 15 for user setting. * initial factory setting 68 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 70: Eventcontrol

    : End of transferring streaming data. (6) ExposureStart : Start of Exposure. (7) ExposureEnd : End of Exposure. (8) Timer0Start : Start of Timer0. (9) Timer0End : End of Timer0. 69 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 71 Returns the timestamp at the time of Event. EventTimer0StartData EventTimer0StartTimestamp Expert Returns the timestamp at the time of Event. EventTimer0EndData EventTimer0EndTimestamp Expert Returns the timestamp at the time of Event. 70 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 72 Set the following value to “EventNotification” register. The setting value is Enumeration type. setting value Event notification Off (*) Inactive Active * initial factory setting 71 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 73: Framesynchronization

    Set the following value to “FrameSynchronization” register. Setting value is Enumeration type. setting value function Off (*) Internal synchronization Bus synchronization * initial factory setting 72 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 74: Ledindicatorluminance

    - Set LED indicator luminance Set the following value to “LEDIndicatorLuminance” register. Setting value is Float type. LEDIndicatorLuminance Value Minimum 0.00(%) Maximum (*) 100.00(%) * initial factory setting 73 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 75: Dpccontrol

    In the case that there is a number of defective pixels, they can be corrected by pointing new DPCIndex and setting coordinates DPCNumber DPCIndex DPCEntryX DPCEntryY Minimum Maximum WidthMax-1 HeightMax-1 74 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 76: Sequentialshuttercontrol

    Sets the number of Index to repeat the sequence. SequentialShutterIndex Expert Sets the sequence number to register. SequentialShutterEntry Expert Sets the UserSet number to register to the sequence. 75 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 77 - Set the activation of Sequential Shutter Set the following value to “SequentialShutterEnable” register. The setting value is Boolean type. setting value function OFF (*) Inactive Active * initial factory setting 76 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 78 List of registers to be applied to SequentialShutter Category Register Category Register OffsetX Gain ImageFormatControl OffsetY BlackLevel AnalogControl AcquisitionControl ExposureTime Gamma LineSource BalanceRatio DigitalIOControl UserOutputValue LUTControl LUTEnable TimerDuration CounterAndTimerControl TimerDelay 77 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 79: Appendix

    USB Bus Frame #1 Frame #2 Frame #3 Tact Time Overhead - ImageSize Save - ExposureTime UserSet1 UserSet1 - Gain UserSet - ... FPGA Serial Flash 78 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 80 Save to Serial Flash if necessary. Quick - ImageSize Save Save - ExposureTime UserSet1 UserSet1 UserSet1 UserSet1 - Gain UserSet UserSet - ... Internal RAM FPGA Serial Flash 79 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 81: Multiframe And Bulk Function Difference

    Frame 4 Frame 1 This exposure is *Exposure overlaps sensor readout. discarded. Stream USB Streaming stops Frame 1 Frame 2 Frame 3 Frame 1 AcquisitionFrameCount 80 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 82 Frame 1 TriggerAdditionalParameter *Exposure overlaps sensor readout. *Exposure time is determined by ExposureTime setting. Stream USB Streaming stops Frame 1 Frame 2 Frame 3 Frame 1 81 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
  • Page 83 This exposure is discarded. TriggerAdditionalParameter *Exposure overlaps sensor readout. *Exposure time is determined by ExposureTime setting. Stream USB Streaming stops Frame 1 Frame 2 Frame 1 AcquisitionFrameCount 82 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 84: Warranty Rules

    9. Forgery product, products which does not have proper serial number, products of which serial number is forged, damaged or deleted 10. All defects that happened after the expiration for a warranty term 83 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...

  • Page 85: Repair

    10. The immunity from responsibility of the product is applied in the repair completion products. * Please refer for the inquiry about the software to our homepage or sales personnel. 84 / 84 D4223121M Copyright © 2013 -2019 Toshiba Teli Corporation, All rights reserved. http://www.toshiba-teli.co.jp/en/...
