See-thru direct vent fireplace
Hide thumbs Also See for Trimont TMT-3875:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operation & Installation Manual, Installation Manual
Quality Fireplaces for Life
SEE-THRU DIRECT VENT FIREPLACE
WARNING
: This product must be installed by a
licensed plumber or gas fitter when installed in the
commonwealth of Massachusetts.
IMPORTANT: Installation of a CO detector is required in
the fireplace room when installed in the commonwealth
of Massachusetts.
WARNING:
If the information in these instructions are not followed exactly, a fire or
explosion may result, causing property damage, personal injury or loss of life.
◙
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
IF YOU SMELL GAS:
◙ Do not light any appliance.
◙ Do not touch any electrical switch: do not use any phone in your building.
◙ Immediately call gas supplier from a neighbors phone. Follow the gas supplier instructions.
◙ If you cannot reach your gas supplier, call the fire department.
◙ Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type (s) of gas indicated on
the rating plate. A conversion kit is supplied with the appliance.
OPERATION MANUAL
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Shown with optional
Pier Conversion Kit
www.kozyheat.com
INSTALLATION
AND
October - 2008
TMT-10-08-R02

Advertisement

Table of Contents
loading

Related Manuals for kozy heat Trimont TMT-3875

Summary of Contents for kozy heat Trimont TMT-3875

  • Page 1 INSTALLATION OPERATION MANUAL INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE. CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE. Quality Fireplaces for Life SEE-THRU DIRECT VENT FIREPLACE WARNING : This product must be installed by a licensed plumber or gas fitter when installed in the commonwealth of Massachusetts.
  • Page 3 Please retain this owner’s manual for future reference. CONGRATULATIONS! We welcome you as a new owner of a Kozy Heat gas fireplace. Kozy Heat products are designed with superior components and materials and assembled by trained craftsmen who take pride in their work. The burner and valve assembly are 100% test-fired and the complete fireplace is thoroughly inspected before packaging to ensure that you receive a quality product.

  • Page 5: Table Of Contents

    15-16 Maintenance GAS LINE CONNECTION TROUBLESHOOTING Gas Line Connection TMT-3875 Troubleshooting 49-51 TMT-3875 THERMOSTAT / WALL SWITCH / REMOTE TMT-3875-RF Troubleshooting 52-54 TMT-3875 Thermostat / Wall Switch / Remote REPLACEMENT PARTS LIST VENTING Replacement Parts List Horizontal Vent System Clearances WARRANTY Min.

  • Page 6: Safety Information

    SAFETY INFORMATION This fireplace has been tested to and complies with ANSI Z21.88a-2007·CSA 2.33a-2007·CSA P.4.1-02 “VENTED GAS FIREPLACE HEATERS” by OMNI-Test Laboratories, Portland, OR. Installation must conform with local building codes or in the absence of local building codes, with the National Fuel Gas Code, ANSIZ223.1/NFPA 54 - Current Edition, or the Natural or Propane Installation Code, CSAB149.1 •...

  • Page 7: Features

    Removable millivolt board with 30-second delay pilot • (2) Upper grill / hood & lower grills (black) • Automatic pressure relief glass system • Accepts rigid pipe or Kozy Heat flexible vent system • Requires no electricity to operate • High - Low regulator (excluding fan) •...

  • Page 8: Commonwealth Of Massachusetts Information

    COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS NOTE: The following requirements reference various Massachusetts and national codes not contained in this manual. For all sidewall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: INSTALLATION OF CARBON MONOXIDE DETECTORS...

  • Page 9: Specifications

    SPECIFICATIONS FIREPLACE DIMENSIONS LETTER KEY DESCRIPTION Height Width Depth Glass Frame Stand-off Height Vent end to See-Thru sides Front to Gas Line Floor to Gas Line Height Vent Center to Vent Center Hole Center Hole Center INCHES 34-1/2 38-3/4 11-1/2 7-7/8 8-1/4 2-1/2...

  • Page 10: Clearances

    SPECIFICATIONS WARNING: NON-COMBUSTIBLE ZONE: STAND-OFFS PROVIDE THE 11-1/2” (292mm) MINIMUM CLEARANCE TO HEADER. USE ONLY NONCOMBUSTIBLE MATERIAL IN THIS AREA FOR THE ENTIRE WIDTH OF FIREPLACE. DO NOT USE WOOD, SHEETROCK ETC. IN THIS ZONE. NOTE: OTHER CLEARANCES APPLY. ALL CLEARANCES MUST BE MAINTAINED.

  • Page 11: Components List

    SPECIFICATIONS MODEL #TMT-3875 COMPONENTS MODEL #TMT-3875-RF COMPONENTS • • (#TMT-770) - Millivolt Board Assembly with 18” Flexible (#TMT-800-RF) - Millivolt Board Assembly with 18” Flexible Gas Line attached Gas Line attached • • (#700-203) - Manual Gas Shut-off Valve (#700-203) - Manual Gas Shut-off Valve •...

  • Page 12: Prepare The Fireplace

    PREPARE THE FIREPLACE NAILING FLANGE ASSEMBLY & INSTALLATION When installed, nailing flanges provide the minimum 1-3/4” (44 mm) clearance from fireplace sides. Remove nailing flanges from fireplace sides. SEE-THRU INSTALLATIONS: All (8) stud tabs will be used to secure fireplace to framing studs. PIER INSTALLATIONS: REMOVE SCREWS The (4) stud tabs on vented end only will be used to secure fireplace to...

  • Page 13: Framing

    FRAMING WALL ENCLOSURE ROUGH OPENING IMPORTANT: Framing dimensions should allow for wall covering thickness and fireplace facing materials. If using a hearth, adjust rough opening size as necessary to maintain at least the minimum clearance requirements. IMPORTANT: OVERALL FINISHED DEPTH IS 24” (610 mm). THIS MEASUREMENT INCLUDES FACING MATERIAL. MATE- RIAL USED WILL DETERMINE FRAMING DEPTH.

  • Page 14: Vertical Terminations

    Follow vent pipe manufacturer’s installation instructions for horizontal terminations. Include the required 3” (76 mm) top clearance and 1” (25 mm) sides and bottom clearances for approved rigid vent systems and the Kozy Heat #800 series flexible vent system. Frame a 12-1/2” (318 mm) high (H) x 10-7/8” (276 mm) wide (W) opening on the exterior wall for chimney termination.

  • Page 15: Wall Pass-Thru Installation

    #800-WPT2 (6-1/2” (165 mm) - 12-1/2” (318 mm) ), MUST BE USED ON ALL HORIZONTAL VENT RUNS. IMPORTANT: If installing Kozy Heat #800 series flex venting; Use tin snips to remove inner ring on each wall thimble section. Measure wall thickness. Cut insulation (included) this length.

  • Page 16: Mantel Requirements

    MANTEL REQUIREMENTS 20 in. (508 mm) 12 in. (305 mm) 3/4 in. (20 mm) 20 in. (508 mm) 11-3/4 in. 12 in. (298 mm) (305 mm) NOTE: Hearth Extension: Combustible material may be used. PAGE 13...

  • Page 17: Glass Frame Assembly

    GLASS FRAME ASSEMBLY REMOVE GLASS FRAME ASSEMBLIES CAUTION: TO PREVENT THE GLASS FRAME ASSEMBLY FROM FALLING FROM THE FIREPLACE AND BECOMING DAMAGED, FOLLOW THESE INSTRUCTIONS EXACTLY WHEN REMOVING GLASS FRAME ASSEMBLY. A. Locate the spring-loaded handles securing glass frame assembly at the top & bottom of firebox. Pull bottom handles out and ‘down’...

  • Page 18: Tmt-3875Only) Optional Fan Installation

    OPTIONAL FAN INSTALLATION (TMT-3875 only) INSTALLATION OF THIS FAN SHOULD BE DONE ONLY BY A QUALIFIED INSTALLER WARNING: MAKE SURE HOUSEHOLD BREAKER IS SHUT OFF PRIOR TO WORKING ON ANY ELECTRICAL LINES. IMPORTANT: If installing a fan, it is easier to complete before the millivolt board is connected to the gas line.
  • Page 19 OPTIONAL FAN INSTALLATION (TMT-3875 only) Insert fan through the lower grill opening (left side of valve). Align mounting slots in fan bracket onto the mounting studs. Secure with nuts. From inside the vented end of fireplace, loosen screw securing removable access panel (with electrical box & romex connector installed).

  • Page 20: Gas Line Connection

    This fireplace is manufactured for use with Natural Gas. An LP conversion kit, is included with this fireplace. Follow instructions included with conversion kit if converting to LP gas. Model TMT-3875; #OCK-S45A Model TMT-3875-RF; #OCK-H45L-RF ATTENTION: The conversion shall be carried out in accordance...

  • Page 21: Tmt-3875 Thermostat / Wall Switch / Remote

    THERMOSTAT / WALL SWITCH / REMOTE (TMT-3875 only) CAUTION: DO NOT CONNECT HIGH NOTE: INSTALLATION OF THERMOSTAT OR WALL VOLTAGE (115V) WIRE TO THE GAS SWITCH SHOULD ONLY BE DONE BY A QUALIFIED VALVE! INSTALLER. If desired, a thermostat (wireless style also available), wall switch, or remote control assembly may be used to turn the fireplace ‘OFF’...

  • Page 22: Horizontal Vent System Clearances

    1 inch (25 mm) WARNING: THE KOZY HEAT WALL PASS-THRU, PART #800-WPT (4-1/2” (114 mm) - 6-1/2” (165 mm) ) WALL THICKNESS OR #800-WPT2 (6-1/2” (165 mm) - 12-1/2” (318 mm) ), MUST BE USED ON ALL HORIZONTAL VENT RUNS.

  • Page 23: Horizontal / Vertical Combination Venting

    VENTING HORIZONTAL & VERTICAL COMBINATION TERMINATIONS 30 ft. (9.144 m) = 10 ft. (3.046 m) maximum horizontal / 20 ft. (6.096) maximum vertical. CAUTION: This gas appliance must not be connected to or joined with any other chimney flue serving another appliance. ELBOWS For each additional 90°...

  • Page 24: Horizontal Venting Illustrations

    NOTE: Horizontal sections require 1/4” (6 mm) rise for every 12” (305 mm) of travel. WARNING: THE KOZY HEAT WALL PASS-THRU, PART #800-WPT (4-1/2” (114 mm) - 6-1/2” (165 mm) ) WALL THICKNESS OR #800-WPT2 (6-1/2” (165 mm) - 12-1/2” (318 mm) ), MUST BE USED ON ALL HORIZONTAL VENT RUNS.

  • Page 25: Vertical Venting Illustrations

    VENTING (VERTICAL) IMPORTANT: WE RECOMMEND INSTALLING A RESTRICTOR (INCLUDED IN THE FIREPLACE COMPONENTS PACKET) ON ALL VERTICAL VENT TERMINATIONS INSTALLED WITHOUT ELBOWS. NOTE: Page 20 has information on restrictor installation in conjunction with venting installation. Page 47 has information on restrictor recom- mendations depending on burner flame appearance and instructions on installation after venting is completed.

  • Page 26: Horizontal / Vertical Combination Venting Illustrations

    VENTING (HORIZONTAL / VERTICAL COMBINATION) HORIZONTAL & VERTICAL COMBINATION MAXIMUM MAXIMUM: 10 ft. (3.05) horizontal + 20 ft. (6.10 m) vertical + cap. 30 ft (9.14m) total. For each additional 90° elbow used after the first elbow, 3 ft. (914 mm) must be subtracted from the maximum allowed venting. For each 45°...

  • Page 27: Series Flex Vent Installation

    VENTING (Flexible (#800 Series) HORIZONTAL TERMINATIONS ONLY INSTALLATION OF #800 SERIES DIRECT VENT TERMINATION KIT(S) IMPORTANT: The flex pipe is permanently attached to the exterior plate. DO NOT ATTACH #844 or #845 termination kit to fireplace (or extension kit ) until it has passed through the wall. Install termination plates to outside wall exterior.
  • Page 28 VENTING (Flexible #800 Series cont) TERMINATION BOX SLOTS IN EXTERIOR WALL PLATE 5” FLEX PIPE COLLAR 5” PIPE ON FIREPLACE OR EXTENSION KIT 8” FLEX PIPE COLLAR 8” PIPE ON FIREPLACE OR EXTENSION KIT VINYL SIDING PROTECTOR INTERIOR FIRESTOP PAGE 25...

  • Page 29: Termination Cap Location

    TERMINATION VENT CAP LOCATION This gas appliance must not be connected to a chimney serving any other appliance. Terminations against vinyl siding must use a vinyl siding protector. Follow instructions included. DO NOT RECESS TERMINATION KIT INTO OUTSIDE BUILDING MATERIALS - i.e.: brick, stone, siding, etc. If necessary, extend framing so that termination kit will be exposed once building materials are installed.

  • Page 30: Vertical Cap Requirements

    VENTING (Vertical Cap Requirements) VENT TERMINATION CLEARANCES Roof Pitch H (Min.) Ft. H (Min.) m Flat to 6/12 0.30 Over 6/12 to 7/12 1.25 0.38 Over 7/12 to 8/12 0.46 Over 8/12 to 9/12 0.61 CAUTION: This appliance must not be connected to or joined with any chimney Over 9/12 to 10/12 0.76...

  • Page 31: Pier Conversion Installation

    PIER CONVERSION Remove screws and top bracket from top of non-vented end of fireplace. Lift end panel up and off mounting studs located along top and bottom sides of pier end frame. Remove nuts (4) securing valance at top and bottom. Remove valance.

  • Page 32: Log Set Installation

    LOG SET INSTALLATION NOTE: Log numbers are located on the bottom of each log. Refer to following instructions and illustrations for proper placement. CAUTION: Do not place logs directly over burner port holes. Improper log placement may affect flame appearance and cause excessive soot to build up on logs and glass.
  • Page 33 LOG SET INSTALLATION STEP 3: (2) #TM6 & (2) #TM7 LOG PLACEMENT Position (2) #TM6 and (2) #TM7 logs, aligning to notches in base logs. STEP 4: COMPLETE LOG SET INSTALLATION Use a steel or stiff bristle nylon brush to distribute Rock Wool Embers onto logs and burner. PAGE 30...

  • Page 34: Millivolt Board Removal

    Shut off gas supply at the manual shut-off valve. Disconnect gas line flex tube from the manual shut-off valve. Model TMT-3875: Disconnect any wall switch, remote con- trol or thermostat wires from top & bottom terminals on the gas valve.

  • Page 35: Millivolt Board Installation

    Model TMT-3875: Reconnect any wall switch, remote con- trol or thermostat wires to the top & bottom terminals on gas valve. Model TMT-3875-RF: Re-connect the (2) wires to fan cord. Plug fan cord into receptacle. 10. Reinstall glass frame assembly. Page 14.

  • Page 36: Grill Set

    GRILL SET UPPER LOUVER, HOOD & LOWER GRILL INSTALLATION & REMOVAL INSTALLATION Slide flange on upper hood into clips in the top of the upper air passage opening. Upper hood clips A. Align hooks in the upper louver to slots located in the fire- Insert upper hood flange into clips located at the top of the place face.

  • Page 37: Tmt-3875 Valve And Pilot Assembly Components

    TMT-3875 VALVE & PILOT ASSEMBLY COMPONENTS ELECTRODE PILOT HOOD PILOT SHIELD THERMOPILE THERMOCOUPLE HI /LO FLAME ADJUSTMENT KNOB GAS CONTROL KNOB PIEZO IGNITOR VALVE TERMINALS ON/OFF ROCKER SWITCH PAGE 34...

  • Page 38: Tmt-3875 Lighting And Shutdown Instructions

    TMT-3875 LIGHTING AND SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. DUE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY.
  • Page 39 TMT-3875 LIGHTING AND SHUTDOWN (cont.) LIGHTING 5 MINUTES Set thermostat to the lowest setting, if installed. Turn off all electrical power to the appliance. (Fan). Open lower grill to access the gas valve & controls. A. Push gas control knob in slightly and turn clockwise to “OFF”.
  • Page 40 TMT-3875 LIGHTING AND SHUTDOWN (cont.) TURN BURNER OFF G. To turn the burner ‘OFF’, depress the ON/OFF rocker switch to ‘OFF’, flip ‘off’ wall switch or adjust setting on the thermostat or remote control. NOTE: The pilot will stay lit.

  • Page 41: Tmt-3875 Pressure Testing

    TMT-3875 PRESSURE TESTING IMPORTANT NOTICE: Pressure check taps for the manifold (outgoing) and inlet (incoming) pressure have been incorporated into the valve. The pressure tap marked ‘OUT’ measures outgoing pressure and the pressure tap marked ‘IN’ measures incoming pressure. Follow instructions below for proper testing procedures.

  • Page 42: Tmt-3875-Rf Valve And Pilot Assembly Components

    TMT-3875-RF VALVE & PILOT ASSEMBLY COMPONENTS INLET PRESSURE OUTLET GAS CONTROL PRESSURE KNOB PIEZO MOTOR PILOT ADJUSTMENT SCREW MOTOR FUEL CONVERSION COVER PLUG PILOT RF VALVE (bottom view) THERMOPIL ELECTRODE WIRING THERMOPILE TERMINALS ANTENNA WHITE TERMINALS WHITE DOTS PAGE 39...

  • Page 43: Tmt-3875-Rf Lighting And Shutdown Instructions

    TMT-3875-RF LIGHTING AND SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. DUE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY.
  • Page 44 TMT-3875-RF LIGHTING AND SHUTDOWN (cont.) LIGHTING Turn off all electrical power to the appliance. (Fan). 5 MINUTES Open lower grill to access the gas valve & controls. A. Push control knob in slightly and turn clockwise to the OFF position. Wait five (5) minutes to clear out any gas.
  • Page 45 TMT-3875-RF LIGHTING AND SHUTDOWN (cont.) IMPORTANT: INITIAL USE OF TRANSMITTER On the initial use of the transmitter, a recognition operation is required between the receiver / valve and the transmitter. 2 SECONDS Turn gas control knob to the PILOT position. Move LOCAL / REMOTE...

  • Page 46: Tmt-3875-Rf Pressure Testing

    PRESSURE TESTING (TMT-3875-RF) IMPORTANT NOTICE: Pressure check taps for the manifold (outgoing) and inlet (incoming) pressure have been incorporated into the valve. The pressure tap marked ‘OUT’ measures outgoing pressure and the pressure tap marked ‘IN’ measures incoming pressure. Fol- low instructions below for proper testing procedures.

  • Page 47: Tmt-3875-Rf Remote Receiver Functions

    TMT-3875-RF REMOTE RECEIVER FUNCTIONS IMPORTANT: PLEASE REVIEW AND RETAIN THE INSTRUCTIONS INCLUDED WITH THE RF TRANSMITTER. IT PRO- VIDES ADDITIONAL INFORMATION AND DETAILS CONCERNING THE OPERATIONAL PROCEDURES AND FUNCTIONS FOR THE RF REMOTE CONTROL. FUNCTIONS: • Flame powered system. •...
  • Page 48 TMT-3875-RF REMOTE RECEIVER FUNCTIONS FIRST USE OF TRANSMITTER: STATUS ACTION Begin communication between transmitter and Move LOCAL/REMOTE Switch to LOCAL position for at least two seconds; then move receiver / valve. switch to the REMOTE position. Transmit unique code. Press Fan or Flame key within 30 seconds.

  • Page 49: Finalizing The Installation

    FINALIZING THE INSTALLATION FLAME APPEARANCE: Flame appearance is affected by several factors including altitude, venting configuration and fuel quality. Although the venturi setting has been factory set, adjustments may be necessary for optimal performance and visual aesthetics. When fireplace is first lit, the flames will be blue. The flames will gradually turn yellowish-orange during the first 15 minutes of opera- tion.

  • Page 50: Restrictor Troubleshooting / Installation After Termination Completion

    FINALIZING THE INSTALLATION RESTRICTOR USAGE: Turn the fireplace on and allow to burn for 15 minutes. If flames indicate there is excessive draft (flickering, short flames) or insufficient draft (lifting or ghosting flames) a restrictor may be necessary, or the previously installed restrictor may need to be modified or removed. WARNING: TO AVOID PROPERTY DAMAGE OR PERSONAL INJURY, ALLOW FIREPLACE AMPLE TIME TO COOL BEFORE MAKING ANY ADJUSTMENTS AND / OR INSTALLATIONS.

  • Page 51: Maintenance

    Visually check pilot light and burner when in operation. The flames should be steady, not lifting or floating. Burner Ports TMT-3875-RF Pilot TMT-3875 Pilot Burner Orifice The fan should be disconnected from electrical current, and cleaned (vacuumed) every six months. The bearings are sealed and require no oiling.

  • Page 52: Tmt-3875 Troubleshooting

    TROUBLESHOOTING (TMT-3875 only) CAUTION: THE FOLLOWING MUST BE PERFORMED BY A QUALIFIED TECHNICIAN NO SPARK FROM ELECTRODE TO PILOT WHEN PIEZO BUTTON IS TRIGGERED. A. Check wiring at back of piezo for proper connection. B. Check wiring at electrode for proper connection.
  • Page 53 ♦ Free pinched wires if necessary. Refractory panel placement (if installed). ♦ Refractory panels must be tight against firebox walls. It may be necessary to secure panels with high-temp sealant, especially around the intake duct. MORE TMT-3875 TROUBLESHOOTING ON FOLLOWING PAGE PAGE 50...

  • Page 54: Troubleshooting

    TROUBLESHOOTING (TMT-3875 only) PILOT AND BURNER EXTINGUISH WHILE IN OPERATION A. No LP (propane) in tank. ♦ Check tank and refill if necessary. B. Glass frame assembly not installed correctly. ♦ Refer to page 14 in this manual for proper glass frame assembly installment instructions.

  • Page 55: Tmt-3875-Rf Troubleshooting

    RF REMOTE TROUBLESHOOTING (TMT-3875-RF only) AUTO PATH If the manual switch is set to Move switch from LOCAL to REMOTE, press the Mode REMOTE. Press any key button to display AUTO on within 30 seconds. the transmitter, Does the REMOTE PATH...
  • Page 56 TROUBLESHOOTING (TMT-3875-RF only) CAUTION: THE FOLLOWING MUST BE PERFORMED BY A QUALIFIED TECHNICIAN NO SPARK FROM ELECTRODE TO PILOT WHEN PIEZO BUTTON IS TRIGGERED. A. Check piezo wiring for proper connection. B. Check position of electrode (1/8” (3 mm) between electrode and pilot). Readjust if necessary.
  • Page 57 TROUBLESHOOTING (TMT-3875-RF only) BURNER WON’T STAY LIT A. Thermopile wires loose at valve terminals. ♦ Adjust if necessary. B. Thermopile wires ground out due to pinched wires. ♦ Free pinched wires if necessary. C Refractory panel placement (if installed). ♦ Refractory panels must be tight against firebox walls. It may be necessary to secure panels with high-temp sealant, especially around the...

  • Page 58: Replacement Parts List

    This appliance tested & certified by: Manufactured by: OMNI - Test Laboratories, Inc. 13327 NE Airport Way Hussong Mfg. Co., Inc. Portland OR. 97230 204 Industrial Park Drive Lakefield, Minnesota 56150 Model #TMT-3875 Trimont 507-662-6641 Model #TMT-3875-RF Trimont - RF www.kozyheat.com October 2008-R02 PAGE 55...
  • Page 60 PAGE 56...
  • Page 62 PAGE 57...
