- Insert the spring and the by-pass piston on the

flywheel cover.

LUBRICATE THE BY-PASS VALVE.

Refitting the flywheel cover components

- Before reassembling, check that all components

are perfectly clean.

- For the cover, carefully check all lubrication chan-

nels, in particular:

- The 3 by-pass channels.

- Oil feeding duct at the water pump shaft connec-

- Pump drainage duct.

Beverly 500 i.e.
