Page 1: Rotary Mower
Safety Video that can READ, UNDERSTAND, be instantly accessed FOLLOW the Safety and Operation internet Instructions contained this www.algqr.com/ave manual before operating equipment. C01-Cover_A ® ALAMO INDUSTRIAL 1502 E. Walnut Seguin, Texas 78155 830-372-3551 E-mail: parts@alamo-industrial.com $0.00 ©2012 Alamo Group Inc.
Page 3 Your Authorized Alamo Industrial Dealer may have shown this video and presented you a DVD Video when you purchased your mower. If you or any mower operator have not seen this video, Watch the Video, Read this Operator’s Manual, and Complete the Video Guidebook before operating your new mower.
Page 4 Alamo Industrial Division is willing to provide one (1) AEM Mower Safety Practices Video Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video DVD Format – AEM/FEMA Mower Operator Safety Video Mower Operator’s Manual AEM Mower Operator’s Safety Manual...
Page 5 A Manual canister is provided on the implement where this manual can be properly stored. If you lose or damage this manual a free replacement manual can be obtained from an authorized Alamo Industrial dealer or by down loading the manual from the Alamo Industrial website www.www.alamo-industrial.com...
Page 6 DEALER to CUSTOMER Pre-Delivery/ Operation Instructions Dealer should inform the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable. Dealer should inform Purchaser to review the contents of the Operator’s Manual including safety equipment, safe operation and maintenance, to review the Safety Signs on the implement (and tractor if possible) and of Purchaser’s responsibility to train his/her operators of safe operation procedures.
Page 7: Table Of Contents
TAIL WHEEL INSTALLATION - LIFT TYPE (Model RX84 Only) ..............3-4 DUAL TAIL WHEEL INSTALLATION - LIFT TYPE (Model RX84 Only) ............3-4 A-FRAME INSTALLATION (Quick Hitch) (Model RX60 & RX72) ..............3-5 A-FRAME INSTALLATION (Model RX84) ......................3-6 DRIVELINE ATTACHMENT ..........................3-7 TONGUE (Pull Type) ............................
Page 8 HAZARDS WITH MAINTENANCE OF IMPLEMENT ..................5-2 Lubrication ................................ 5-3 GEARBOX (Model RX60 & RX84) ........................5-6 GEARBOX (Model RX72) ..........................5-6 DRIVELINE LUBRICATION ..........................5-7 LIFT TYPE DRIVELINE & PULL JACKSHAFT SHIELDS ................5-8 CV TYPE DRIVELINE ............................5-9...
Page 9 Parts Inspection .............................. 5-21 Output Shaft Installation ..........................5-21 Input Shaft Installation ............................ 5-22 GEARBOX SERVICING (Model RX72) ......................5-23 Top Input Shaft Preload Setting ........................5-25 Right Angle Gearbox Assembly & Disassembly Procedures ................5-25 Assembly Procedure ............................5-26...
Page 12: General Safety Instructions And Practices
SAFETY GENERAL SAFETY INSTRUCTIONS AND PRACTICES A careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner/operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions.
Page 13: Operator Safety
SAFETY OPERATOR SAFETY TO AVOID SERIOUS INJURY OR DEATH DO THE FOLLOWING: • READ, UNDERSTAND and FOLLOW Operator's Manual instructions, Warnings and Safety Messages. • WEAR SAFETY GLASSES, safety shoes, hard hat, hearing protection and gloves when operating or repairing equipment •...
Page 14: Connection Or Disconnecting Implement Safety
SAFETY CONNECTION OR DISCONNECTING IMPLEMENT SAFETY TO AVOID SERIOUS INJURY OR DEATH FROM BEING CRUSHED BY TRACTOR OR IMPLEMENT: WHEN BACKING tractor to implement hitch: • DO NOT ALLOW BYSTANDERS between tractor and implement BEFORE connecting and disconnecting implement hitch: •...
Page 15: Crushing Hazards
SAFETY CRUSHING HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM FALLING OFF TRACTOR, EQUIPMENT RUN OVER, ROLLOVER AND CRUSHING BY FALLING WING OR IMPLEMENT: • USE ROPS and SEAT BELT equipped tractors for mowing operations. • KEEP ROPS lock in up position. •...
Page 16: Thrown Objects Hazards
SAFETY THROWN OBJECTS HAZARDS ROTARY MOWERS CAN THROW OBJECTS 300 FEET OR MORE UNDER ADVERSE CONDITIONS. TO AVOID SERIOUS INJURY OR DEATH TO OPERATOR OR BYSTANDERS FROM THROWN OBJECTS: • KEEP bystanders 300 feet away STOP MOWING IF PASSERSBY ARE WITHIN 300 FEET UNLESS: •...
Page 17: Thrown Objects Hazards (Continued)
SAFETY THROWN OBJECTS HAZARDS (CONTINUED) MOWER OPERATION: • DO NOT exceed mower's rated Cutting Capacity or cut non-vegetative material. • USE ENCLOSED TRACTOR CABS when two or more mowers are operating in mowing area. • ADJUST mower sections or wing close and parallel to ground without exposing blades •...
Page 18: Run Over Hazards
SAFETY RUN OVER HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM FALLING OFF TRACTOR OR EQUIPMENT RUN OVER: • USE ROPS and SEAT BELT equipped tractors for mowing operations. • KEEP ROPS locked in UP position. • ONLY start tractor while seated in tractor seat. •...
Page 19: Pto Entanglement Hazards
SAFETY PTO ENTANGLEMENT HAZARDS KEEP AWAY FROM ROTATING DRIVELINES AND ELEMENTS TO AVOID SERIOUS INJURY OR DEATH: hands, feet and body AWAY from rotating blades, drivelines and parts until all moving STAY AWAY KEEP elements have stopped. • STOP, LOOK and LISTEN before approaching the mower to make sure all rotating motion has stopped. •...
Page 20: Mower Blade Contact Hazards
SAFETY MOWER BLADE CONTACT HAZARDS KEEP AWAY FROM ROTATING BLADES TO AVOID SERIOUS INJURY OR DEATH FROM BLADE CONTACT: • STAY AWAY and KEEP HANDS, FEET and BODY AWAY from rotating blades, drivelines and parts until all moving elements have stopped. •...
Page 21: High Pressure Oil Leak Hazards
SAFETY HIGH PRESSURE OIL LEAK HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM HIGH PRESSURE HYDRAULIC OIL LEAKS PENERATING SKIN: • DO NOT OPERATE equipment with oil or fuel leaks. • KEEP all hydraulic hoses, lines and connections in GOOD CONDITION and TIGHT before applying system pressure.
Page 22: Electrical & Fire Hazards
SAFETY ELECTRICAL & FIRE HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM ELECTRICAL CONTACT WHEN WORKING AROUND ELECTRICAL POWER LINES, GAS LINES AND UTILITY LINES: • INSPECT mowing area for overhead or underground electrical power lines, obstructions, gas lines, cables and Utility, Municipal, or other type structure. •...
Page 23: Transporting Hazards
SAFETY TRANSPORTING HAZARDS TO AVOID SERIOUS INJURY AND DEATH WHEN TOWING OR TRANSPORTING EQUIPMENT: • KEEP transport speed BELOW 20 mph to maintain control of equipment. • REDUCE SPEED on inclines, on turns and in poor towing conditions. • DO NOT TOW with trucks or other vehicles •...
Page 24: Hazards With Maintenance Of Implement
SAFETY HAZARDS WITH MAINTENANCE OF IMPLEMENT AVOID SERIOUS INJURY OR DEATH FROM COMPONENT FAILURE BY KEEPING IMPLEMENT IN GOOD OPERATING CONDITION PERFORMING PROPER SERVICE, REPAIRS MAINTENANCE. BEFORE PERFORMING SERVICE, REPAIRS AND MAINTENANCE ON THE IMPLEMENT: SECURE EQUIPMENT FOR SERVICE BLOCK OUT POTENTIAL ENERGY HAZARDS; Rotating Parts, Raised Components, Hydraulic Pressure. STOP ENGINE AND PTO •...
Page 25 SAFETY PARTS INFORMATION Alamo Industrial mowers use balanced and matched system components for blade carriers, blades, cuttershafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Alamo Industrial specifications. Non-genuine "will fit" parts do not consistently meet these specifications.
Page 26: Decal Location
NOTE: Alamo Industrial supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Alamo Industrial cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 27 PART NO. TYPE DESCRIPTION D821 DANGER Multi Hazard D388 WARNING Driveline Hazards D534 WARNING Replace Blades in Pair/Torque 600ft/lbs D816 WARNING Use Genuine Alamo Industrial Parts 00785564 LOGO Alamo Industrial 00771283 WARRANTY 5-Year 03200347 REFLECT SMV sign 00785560 NAME RX60 00785561...
Page 37: Federal Laws And Regulations
SAFETY Federal Laws and Regulations This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such.
Page 40 INTRODUCTION We are pleased to have you as an Alamo Industrial customer. Your Rotary Cutter has been carefully designed with care and built with quality materials by skilled workers to give maximum service with minimum down time. This manual is provided to give you the necessary operating and maintenance instructions for keeping your rotary cutter in top operating condition.
Page 41: Equipment Specifications
INTRODUCTION The Alamo Industrial RX60/72/84 Rotary Mower is designed for medium duty applications such as weed, grass, corn stalks, and light brush to 2-1/2” diameter. These mowers are single spindle with two free-swinging blades. Free swinging blades reduce the shock of impact when a stationary object is hit. Additional protection is provided by a slip clutch on the gearbox input shaft.
Page 42: Key Operation Points
A. Warranty is ONE-YEAR (12 MONTHS) for Seals (After one year, seals are considered to be WEARING PARTS and replacement is the users' responsibility.) B. Users' Gearboxes may be rebuilt by Alamo Industrial or replaced by new or rebuilt Gearboxes at the option of Alamo Industrial.
Page 43: Limited Warranty
LIMITED WARRANTIES 1.01. Alamo Industrial warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”) that the goods purchased are free from defects in material or workmanship.
Page 46: Dealer Setup Instructions
ASSEMBLY DEALER SETUP INSTRUCTIONS The mower as received from the factory is partially assembled and requires minimum time to complete assembly and is ready for sale. This mower is shipped vertically with shipping brackets. These shipping brackets are intended for use in transporting the mower from the factory to dealer.
Page 47: Shield Assembly (All Models)
Tighten bolts to recommended torque. Figure Asm-R-0091. TAIL WHEEL INSTALLATION (Model RX60 & RX72) Align Tail Wheel Beam Weldment (1) between pivot brackets located behind gearbox mount on the Mainframe Weldment. NOTE: Long side of caster fork pivot tube is positioned up.
Page 48: Tail Wheel Installation - Lift Type (Model Rx84 Only)
ASSEMBLY TAIL WHEEL INSTALLATION - LIFT TYPE (Model RX84 Only) 1. Slide bracket (2) onto beam (1). 2. Insert bolt (28) through lugs on end of beam (1) and lug on deck. NOTE: Insert spacer (10)into deck lug before inserting bolt (28). Install locknut (3). 3.
Page 49: A-Frame Installation (Quick Hitch) (Model Rx60 & Rx72)
ASSEMBLY A-FRAME INSTALLATION (Quick Hitch) (Model RX60 & RX72) 1. Attach the A-Frame Bars (2) to the right and left Hitch Lugs (14 & 15) with two 5/8” x 2” bolts (16), 5/8” washers (17), bushing (18) and 5/8” locknuts (19) Figure Asm-R-0342.
Page 50: A-Frame Installation (Model Rx84)
ASSEMBLY A-FRAME INSTALLATION (Model RX84) 1. Attach the A-Frame Bars (2) to the right and left Hitch Lugs (14 & 15) with two 5/8” x 2” bolts (16), 5/8” washers (17), bushing (18) and 5/8” locknuts (19). 2. Attach the Lift Strap Bars (1) to the Mainframe with two 5/8” bolts (16), 5/8” flatwasher (17), bushing (18) and 5/8”...
Page 51: Driveline Attachment
ASSEMBLY DRIVELINE ATTACHMENT Before starting assembly, make certain that all paint, dirt, and grease are removed from gearbox shaft (1). To ease assembly apply a light coat of grease to splines and assemble. Do not assemble a driveline without a shield.
Page 52: Axle Assembly
ASSEMBLY AXLE ASSEMBLY Attach rear axle (1) to the lugs on the rear of the mainframe using 3/4 x 3 (8) bolts, bushings (7), flatwashers (4) and locknuts (6). Tighten all bolts. Attach level lift rod assemblies to axle (1) Figure Asm-R-0406 and tongue (1) Figure Asm-R-0405 using clevis pin (15), flatwashers (31) and cotter pin (38).
Page 53: Wheels (Model Rx84 Only)
ASSEMBLY WHEELS (Model RX84 Only) Install the Wheels on the Wheel Hubs. Note: If Laminated Tires are used, place the flat side of the Lug Nut against the Wheel Asm-R-0127. Note direction of travel and curvature of rubber segments in tire and install as shown in Asm-R-0127.
Page 54: Front And Rear Deflectors (Standard Equipment)
ASSEMBLY Front and Rear Deflectors (Standard Equipment) Front and Rear rubber-fabric Deflectors are Standard Equipment and Front and Rear Chain Guards are optional . One type of guard must be installed (and maintained in good repair) except for agricultural purposes only in areas where persons, vehicles, livestock, or other property will not be endangered by thrown objects and where such safety equipment would prevent the mower's reasonable performance of its assigned agricultural task.
Page 55: Chain Guards (Optional Equipment - All Models)
ASSEMBLY CHAIN GUARDS (Optional Equipment - All Models) CHAIN GUARDS: Front and Rear Chain Guards (Optional Equipment) are recommended for higher than normal usage (100 hours or more per year) and will provide protection from thrown objects with careful operation. Chain Guards must be maintained in good repair by replacing missing or worn sections or by being replaced when seriously worn or damaged.
Page 56: Hydraulic Or Manual Lift (Model Rx84 Only)
NOTE: For additional safety in transport, raise mower as high as possible without allowing the driveline to contact the deck, and shorten the chains as much as possible to prevent inadvertent falling in transport. NOTE: RX60 and RX72 units use a Cat I Kit and RX84 Units use a Cat II Kit. RX60/72/84 10/12 Assembly Section 3-12 ©...
Page 57: Offset Adapter Hitch (Extra Equipment)
ASSEMBLY OFFSET ADAPTER HITCH (EXTRA EQUIPMENT) 1. Fasten the Offset Adapter Hitch Weldment to the lift lugs using the Hitch Pin holes. Fasten the Adjustable Leg to the left side lug if the Mower is to offset to the left. The Mower will make a cleaner cut behind the wheel tracks if it is offset to the left.
Page 60: Operation Instructions
ALAMO INDUSTRIAL RX60/72/84 ROTARY MOWER OPERATION INSTRUCTIONS Alamo Industrial mowers are manufactured with quality material by skilled workers. These mowers are designed to cut grass, weeds, small brush and other vegetative material up to 2-1/2” diameter in areas such as pastures, industrial areas, and roadsides.
Page 61: Operator Requirements
OPERATION 1. OPERATOR REQUIREMENTS Safe operation of the unit is the responsibility of a qualified operator. A qualified operator has read and understands the implement and tractor Operator’s Manuals and is experienced in implement and tractor operation and all associated safety practices. In addition to the safety messages contained in this manual, safety signs are affixed to the implement and tractor.
Page 62: Tractor Requirements
ASABE approved Roll-Over Protective Structure (ROPS) or ROPS cab and seat belt. • Tractor Safety Devices ..... Slow Moving Vehicle (SMV) emblem, lighting, PTO master shield • Tractor Horsepower:......RX60 Mower RX72 Mower RX84 Mower -Minimum ....35 HP 45 HP Lift 60 HP, Pull 30 HP -Maximum ....
Page 63: Tractor Horsepower
The power required to operate a mower is determined by the tractor PTO horsepower. For most mowing conditions, the RX60 mower requires a tractor with at least 35 HP, the RX72 mower requires a tractor with at least 45 HP and the RX84 mower requires a tractor with at least 65 HP. Operating the mower with a tractor that does not have adequate power may damage the tractor engine.
Page 64: Drawbar-Pull Type Mower
OPERATION 2.6 Drawbar-Pull Type Mower For equipment operating at 540 RPM, the tractor drawbar must be positioned at a 14” distance from the hitch point to the PTO shaft end for proper operation and minimal wear to the driveline. If attaching the mower tongue clevis to a 3-point hitch drawbar supported by the lower lift arms, the attaching point must be extended past the main bar to allow for turning without binding the clevis and bar.
Page 65: Tire Spacing
OPERATION DO NOT use a PTO adapter to attach a non-matching Implement driveline to a Tractor PTO. Use of an adapter can double the operating speed of the Implement resulting in excessive vibration, thrown objects, and blade and implement failure. Adapter use will also change the working length of the driveline exposing unshielded driveline areas.
Page 66: Boarding The Tractor
OPERATION 3.1 Boarding the Tractor Use both hands and equipped handrails and steps for support when boarding the tractor. Never use control levers for support when mounting the tractor. Seat yourself in the operator’s seat and secure the seat belt around you.
Page 67: Starting The Tractor
OPERATION 4. STARTING THE TRACTOR The operator must have a complete understanding of the placement, function, and operational use of all tractor controls before starting the tractor. Review the tractor operator’s manual and consult an authorized dealer for tractor operation instructions if needed. Essential Tractor Controls: •...
Page 68: Connecting The Mower-Lift Type
OPERATION 5.1 Connecting the Mower-Lift Type 1. Make sure the tractor is equipped with the correct PTO shaft. Change shafts if needed. 2. Shorten or remove the tractor drawbar to avoid interference when raising and lowering the mower. 3. Board the tractor and start the engine. Position the tractor to the mower with the 3-point lift arms positioned at the same height and to the outside of the mower hitch pins.
Page 69: Connecting Mower - Lift Type (Quick Hitch)
OPERATION 5.3 Connecting Mower - Lift Type (Quick Hitch) Crushing Hazard between Quick-Hitch and Implement. Do not allow anyone to stand between the Quick-Hitch and implement during hook-up operations. Never operate the hydraulic 3-point lift controls while someone is directly behind the tractor. 1.
Page 70: Setting The Mower
OPERATION IMPORTANT: Scan this QR Code with your smart phone to link to the PAMI Safe Implement Hitching Manual for more information on correctly connecting agricultural tractors to implements. Or type in your internet browser the following web address: www.algqr.com/hme Ops-0008-MISC 6.
Page 71 OPERATION 5. Level the mower side to side by manipulating one lower lift arm length. On most tractors, at least one of the lift arms is designed to allow for manipulation of its length. Shortening or extending will allow for deck leveling from side to side.
Page 72: Connecting The Mower-Pull Type
OPERATION 6.2 Connecting the Mower-Pull Type 1. Make sure the tractor is equipped with the correct PTO shaft and the drawbar is extended 14” from the end of the PTO shaft to the hitch point. 2. Block the mower wheels in place and use the attached parking jack to raise or lower the tongue clevis to the height of the tractor drawbar.
Page 73: Setting Mowing Height-Pull Type
OPERATION 6.3 Setting Mowing Height-Pull Type 1. Park the tractor and mower on level ground. 2. Using the tailwheel ratchet jack or hydraulic cylinder, position the mower so the skid shoes are 1” less off the ground than the desired final cut height.
Page 74: Setting Deck Pitch
OPERATION 6.4 Setting Deck Pitch Lower Horse Power - Better Fuel Efficiency To increase fuel efficiency and lower horsepower requirements for mower operation, the mower should be operated with the deck approximately 3/4" LOWER IN THE FRONT THAN THE REAR. Operating the mower at this pitch will allow the mower to cut the grass only once and requires less work from the tractor.
Page 75: Driveline Length Check
OPERATION When attaching the Implement input driveline to the Tractor PTO, it is important that the connecting yoke spring activated locking collar slides freely and the locking balls are seated securely in the groove on the Tractor PTO shaft. Push and pull the driveline back and forth several times to ensure it is securely attached.
Page 76: Pre-Operation Inspection And Service
OPERATION Shorten the driveline profiles as follows: • Remove the driveline from the tractor. • Raise and lower the mower to find the position with the shortest distance between the tractor PTO shaft and cutter gearbox. Shut down the tractor and securely block the mower in this position.
Page 77: Tractor Pre-Operation Inspection/Service
OPERATION Periodically inspect all moving parts for wear and replace when necessary with authorized service parts. Look for loose fasteners, worn or broken parts, and leaky or loose fittings. Make sure all pins have cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order.
Page 78 OPERATION The operator’s manual and safety signs affixed on the unit contain important instructions on the safe and proper use of the equipment. Maintain these important safety features on the implement in good condition to ensure the information is available to the operator at all times.
Page 79 OPERATION All Safety Shields, Guards and Safety devices including (but not limited to) - the Deflectors, Chain Guards, Steel Guards, Gearbox Shields, PTO integral shields, and Retractable Door Shields should be used and maintained in good working condition. All safety devices should be inspected carefully at least daily for missing or broken components.
Page 80 OPERATION • Inspect the gearbox oil level. A low oil level is a warning sign that the gearbox may be cracked or its seal is damaged and needs replacement. • Ensure the gearbox vent is in place and free from clogs. OPS-R-0040_B •...
Page 81: Cutting Component Inspection
OPERATION 8.3 Cutting Component Inspection Inspect blade pan and blade assembly for the following: OPS-U-0031 RX60/72/84 10/12 Operation Section 4-23 © 2012 Alamo Group Inc.
Page 82 OPERATION Operating the mower with loose blade hardware will damage the blade holder or blades and can result in blade breakage or blade fastener failure. Broken blades or bolts can be thrown out from under the mower for distances up to 300 feet. When the blades are replaced, the fastening hardware must be replaced.
Page 83 OPERATION Inspect the Blades daily for abnormal wear. REPLACE BOTH BLADES on that carrier IMMEDIATELY if either blade has: • Become bent or deformed from it’s original shape or • Any cracks are visible, or • Deep gouges in the blade’s surface are present, or •...
Page 84: Blade Bolt Inspection
OPERATION 8.4 Blade Bolt Inspection Inspect Blade Bolt Head daily for wear as followed: Inspect the Blade Bolt Heads daily for abnormal wear. REPLACE BOTH BLADE BOLTS on the Blades IMMEDIATELY if either blade bolts has: • Visible cracks or •...
Page 85 OPERATION Rotary Mower PRE-OPERATION Inspection IMPORTANT: Scan this QR Mower ID#___________________ Code for an electronic copy of this inspection sheet. Date:________________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 86 OPERATION Tractor PRE-OPERATION Inspection Mower ID#________________ Make ____________________ Date: ________________ Shift ____________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 87: Driving The Tractor And Implement
OPERATION 9. DRIVING THE TRACTOR AND IMPLEMENT Safe tractor transport requires the operator possess a thorough knowledge of the model being operated and precautions to take while driving with an attached implement. Ensure the tractor has the capacity to handle the weight of the implement and the tractor operating controls are set for safe transport.
Page 88: Starting The Tractor
OPERATION 9.1 Starting the Tractor The procedure to start the tractor is model specific. Refer to the tractor operator’s manual for starting procedures for your particular tractor. Consult an authorized dealer if the starting procedure is unclear. Ensure the 3-point control lever is in the lowered position and the PTO is disengaged before starting the tractor.
Page 89: Raising The Mower
OPERATION 9.3 Raising the Mower Using the tractor 3-point hitch control lever, raise the mower off the ground about 6”, or just high enough to clear any ground obstacles. When raising the mower, make sure all connection points are securely attached and at least 1” clearance is maintained between the driveline and the deck.
Page 90: Crossing Ditches And Steep Inclines
OPERATION 9.5 Crossing Ditches and Steep Inclines When crossing ditches with steep banks or going up sharp inclines, it is possible that the main driveline inner profile will penetrate into the outer housing to its maximum depth until the assembly becomes solid (driveline is at its extreme shortest length).
Page 91: Operating The Tractor And Implement
OPERATION Inclines and ditches should be approached along a line which is at an angle as shown. This type of path will reduce the possibility of over-collapse of the driveline and resulting damage. If the gradient is so steep that such an approach increases the possibility of a tractor roll-over, select an alternate crossing path.
Page 92: Foreign Debris Hazards
OPERATION Many varied objects, such as wire, cable, rope, or chains, can become entangled in the operating parts of the mower head. These items could then swing outside the housing at greater velocities than the blades. Such a situation is extremely hazardous and could result in serious injury or even death.
Page 93: Engaging The Power Take Off (Pto)
OPERATION Rotary Mowers are capable under adverse conditions of throwing objects for great distances (300 ft (100 m) or more) and causing serious injury or death. Follow safety messages carefully. STOP MOWING IF PASSERSBY ARE WITHIN 300 Feet (100 m) UNLESS: -Front and Rear Deflectors, Chain Guards, or Bands are installed and in good, workable condition;...
Page 94: Pto Rpm And Ground Speed
OPERATION 10.4 PTO RPM and Ground Speed Ground speed for mowing will depend upon the height, type, and density of vegetation to be cut. Recommended speed for efficient mower performance is between 2 and 5 mph(3-8 kph). Operate the mower at its full rated PTO speed to maintain blade speed for a clean cut.
Page 95: Cutting Material
OPERATION 10.6 Cutting Material When cutting trees and brush approach material to be cut with the head perpendicular to the material. The cutting edge of the blades should be the only elements in contact with material. The blade bar should not contact the material. Material should be fed through the head rather than the head being lowered on top of material.
Page 96 OPERATION Follow these guidelines to reduce the risk of equipment and grass fires while operating, servicing, and repairing the Mower and Tractor: -Equip the Tractor with a fire extinguisher in an accesible location. -Do Not operate the Mower on a Tractor with an underframe exhaust. -Do Not smoke or have an open flame near the Mower and Tractor.
Page 97 OPERATION Large, dense, or wet vegetation may need to be mowed in two or more passes to achieve a uniform cut. In such conditions, raise the cutting height to 12” or more on the first pass OPS-R-0043 Then lower the mower to the desired height and mow the vegetation a second time.
Page 98: Right Of Way (Highway) Mowing
OPERATION 10.7 Right of Way (Highway) Mowing Do not mow, or drive the tractor into material that is burning, or areas that recently burnt and may contain hot spots. Burning material, sparks, and coals could be thrown from the mower to areas of vegetation that might ignite.
Page 99: Shutting Down The Implement
OPERATION 10.8 Shutting Down the Implement To shut down attached mower head, first bring the tractor to a complete stop. Decrease engine RPM to idle then disengage cutterhead. The mower head will come to a complete stop within a suitable amount of time.
Page 100 OPERATION Always shut the Tractor completely down, place the transmission in park, and set the parking brake before you or anyone else attempts to connect or disconnect the Implement and Tractor hitches. (S3PT-15) To disconnect the mower, first extend the tractor 3- point hitch top link to remove tension on the top link hitch pin.
Page 101: Mower Storage
OPERATION 12. MOWER STORAGE Properly preparing and storing the mower at the end of the season is critical to maintaining its appearance and to help ensure years of dependable service. The following are suggested storage procedures: • Thoroughly clean all debris off the mower to prevent damage from rotting grass and standing water.
Page 102: Transporting On Public Roadways
OPERATION Before transporting the tractor and mower, idle the tractor engine, disengage the PTO and wait for all mower moving parts to come to a complete stop. Once all mower parts are completely stopped, raise the mower to transport height. NOTE: When raising the mower, maintain 1”...
Page 103 OPERATION The SMV (Slow-Moving Vehicle) emblem is universal symbol used to alert drivers of the presence of equipment traveling on roadways at a slow speed. SMV signs are a triangular bright orange with reflective red trim for both easy day and night visibility.
Page 104: Hauling The Tractor And Implement
OPERATION Reduce speed before turning or applying the brakes. Ensure that both brake pedals are locked together when operating on public roads. OPS-U- 0023 13.2 Hauling the Tractor and Implement Before transporting a loaded tractor and implement, measure the height and width dimensions and gross weight of the complete loaded unit.
Page 105: Trouble Shooting Guide
OPERATION 14. TROUBLE SHOOTING GUIDE Problem Possible Cause Remedy Uneven Cut Excessive ground speed. Reduce ground speed. Blades worn, dull, or bent. Replace blades. (Refer to “Maintenance” section). Mower not level side to side. Adjust. (Refer to “Assembly” section) Improper height adjustment. Adjust Mower height.
Page 106 OPERATION Blade Bolts Working Loose Bolts not tightened. Tighten Bolts to 300 ft./lbs. Bolt hole elongated or oversized. Replace Blade Carrier. Locknut worn out. Replace Locknut. Gearbox Noisy Low Lubricant. Check lubricant level. Rough gears. Run in or change Gears. Worn Bearing.
Page 108: Hazards With Maintenance Of Implement
MAINTENANCE HAZARDS WITH MAINTENANCE OF IMPLEMENT AVOID SERIOUS INJURY OR DEATH FROM COMPONENT FAILURE BY KEEPING IMPLEMENT IN GOOD OPERATING CONDITION PERFORMING PROPER SERVICE, REPAIRS MAINTENANCE. BEFORE PERFORMING SERVICE, REPAIRS AND MAINTENANCE ON THE IMPLEMENT: SECURE EQUIPMENT FOR SERVICE BLOCK OUT POTENTIAL ENERGY HAZARDS; Rotating Parts, Raised Components, Hydraulic Pressure. STOP ENGINE AND PTO •...
Page 109: Lubrication
MAINTENANCE PARTS INFORMATION Alamo Industrial mowers use balanced and matched system components for blade carriers, blades, cuttershafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Alamo Industrial specifications. Non-genuine "will fit" parts do not consistently meet these specifications.
Page 112: Gearbox (Model Rx60 & Rx84)
If required, oil should be added until it comes to proper level. Recommended lubricant is multi-purpose gear oil, Alamo Industrial P/N 00786250. NOTE: Make sure mower is level when checking oil in the gearbox. Gearbox capacity is 3 quarts.
Page 113: Tail Wheel Assembly
MAINTENANCE TAIL WHEEL ASSEMBLY Tail Wheel Bearings are packed at the factory with heavy-duty bearing grease. Grease Fittings are provided in the Wheel Hub and Tail Wheel Beam. Grease after 10 hours of use. Figure Mnt-0004. DRIVELINE LUBRICATION Grease Fittings are located on the Cross Assembly of each U-Joint and on the telescoping tubes. Grease the U-Joint after each 8 hours of use.
Page 114: Lift Type Driveline & Pull Jackshaft Shields
MAINTENANCE LIFT TYPE DRIVELINE & PULL JACKSHAFT SHIELDS To remove the main inner driveline shield, Remove the locking screws. Align the bearing tabs with the cone pockets. FIGURE Mnt-0026. Remove the half-guard and remove the bearing ring. FIGURE Mnt-R-0012. Inspect the driveline shield for worn areas or cracks. If the shield has any dents or cracks, replace the Shield. While the Shields are off, examine the Driveline for signs of abnormal wear, bent or twisted shafts, or cracks in the shafts or tubes.
Page 115: Cv Type Driveline
MAINTENANCE CV TYPE DRIVELINE MAIN CV DRIVELINE SAFETY SHIELD 1. To remove the outer CV cone, remove the locking screws from shield cone. Remove cone over yoke. Remove bearing ring and remove the locking screws from inner shield cone. Turn inner cone to assembly position and remove half shield.
Page 116 MAINTENANCE 2. To assemble outer CV driveline, grease yoke groove and inner profile tube. Attach bearing ring on groove with recesses facing profile tube. Slide on half shield with cone. Turn cone until it engages correctly. Tighten locking screws. Grease bearing groove in double yoke. Insert bearing ring. Slide guard cone for double yoke over cam from the connecting end.
Page 117: Blade Servicing
MAINTENANCE BLADE SERVICING Inspect blades before each use to determine that they are properly installed and in good condition. Replace any blade that is bent, excessively nicked, worn, or has any other damage. Small nicks can be ground out when sharpening. Use only original equipment blades on this cutter.
Page 118: Blade Sharpening
MAINTENANCE BLADE SHARPENING When sharpening blades, grind each blade the same amount to maintain balance. Follow original sharpening pattern as shown in Figure Mnt-R-0008. Always sharpen blades by grinding. Always sharpen both blades at same time to maintain balance. The difference in blade weights should not exceed 1 ounce.
Page 119: Blade Carrier Installation
MAINTENANCE Failure to replace a worn blade carrier bushing as described above may lead to catastrophic failure of the blade, blade bolt, and/or blade bolt nut resulting in the ejection of the broken parts out from under the mower at tremendous speed and force which could result in serious bodily injury or death.
Page 120: Blade Removal
MAINTENANCE BLADE REMOVAL Remove locknut from blade bolt through inspection hole in deck of mower near the gearbox to remove blades for sharpening or replacement. See Figure MntP-R-0057. Always replace nut when replacing blade bolt. When installing blades be sure and check blade bolt pivot diameter for wear. Replace bolt if worn more than 1/ 4 inch at any point.
Page 121: Seasonal Clutch Maintenance
MAINTENANCE All Safety Shields, Guards and Safety devices including (but not limited to) - the Deflectors, Chain Guards, Steel Guards, Gearbox Shields, PTO integral shields, and Retractable Door Shields should be used and maintained in good working condition. All safety devices should be inspected carefully at least daily for missing or broken components.
Page 122: Storage
MAINTENANCE STORAGE Your rotary cutter represents an investment from which you should get the greatest possible benefit. Therefore, when the season is over, the cutter should be thoroughly checked and prepared for storage so that a minimum amount of work will be required to put it back into operation for the next season. The following are suggested storage procedures: 1.
Page 124: Gearbox Servicing (Models Rx60 & Rx84)
MAINTENANCE GEARBOX SERVICING (Models RX60 & RX84) TOOLS NEEDED FOR DISASSEMBLY AND ASSEMBLY OF GEARBOX Slide Hammer Puller Locktite #5900 Punch - Long Drift Needle Nose Pliers Screw Driver External Snap Ring Pliers Socket Wrench 9/16 Socket Ball Pin Hammer Pry Bar Be certain to clamp or securely support the gearbox and sub-assemblies to prevent injuries to hands and feet due to inadvertent dropping or falling over.
Page 125: Gearbox Disassembly
MAINTENANCE GEARBOX DISASSEMBLY 1. Remove 6 cover bolts from input shaft bearing housing (2). 2. Tap around circumference of bearing housing (2) to loosen housing and shims. Then pull complete shaft (6) and housing assembly out of main housing. 3. Remove 4 capscrews (14), break gasket loose (11 & 12), and then remove the bearing retainer cap (18). (Mnt-R-0211) 4.
Page 126: Right Angle Gearbox (Outboard) Assembly & Disassembly Procedures
MAINTENANCE RIGHT ANGLE GEARBOX (OUTBOARD) ASSEMBLY & DISASSEMBLY PROCEDURES Input Shaft Removal Step I. Place Gearbox on appropriate work surface. Step II. Remove Vent Plug (item #32) and Dipstick (item #31). Step III. Turn Gearbox upside down allowing Oil to drain from gearbox into catch pan for proper disposal. Step IV.
Page 127: Parts Inspection
MAINTENANCE Step lV. Reach in from front or top of Main Housing and remove upper Output Shaft Cone Bearing (item # 23) Step V. From the top of Main Housing drive out top and bottom Bearing Cups (item # 23). Spacer (item # 12) will fall out once lower bearing cup comes out of housing.
Page 128: Input Shaft Installation
MAINTENANCE STEP VII Press new output seal (item # 19) into output cap (item # 13). Using one gasket (item # 20) install lower output cap into main housing. Retain using bolts and washers (items # 14 & 15). NOTE!: Use gasket sealant between all parts! Input Shaft Installation STEP I...
Page 129: Gearbox Servicing (Model Rx72)
MAINTENANCE GEARBOX SERVICING (Model RX72) TOOLS NEEDED FOR DISASSEMBLY AND ASSEMBLY OF GEARBOX Slide Hammer Puller Locktite #5900 Punch - Long Drift Needle Nose Pliers Screw Driver External Snap Ring Pliers Socket Wrench 9/16 Socket Ball Pin Hammer Pry Bar Be certain to clamp or securely support the gearbox and sub-assemblies to prevent injuries to hands and feet due to inadvertent dropping or falling over.
Page 130 MAINTENANCE ITEM DESCRIPTION Casing Crown Wheel Bearing Oil Seal Shaft Internal Clip Shim External Clip Shim Protective Shield Oil Seal Bearing Shaft Bevel Pinion Cotter Pin Shim Plug Hex Bolt Breather Dipstick Cover Shim Nut, Output Shaft Washer, Output Shaft Cotter Pin RX60/72/84 10/12 Maintenance Section 5-24...
Page 131: Top Input Shaft Preload Setting
MAINTENANCE Top Input Shaft Preload Setting Step I. Drive bearing cup #3 into place on side of gearbox closest to gear. Insert shim #17 if used and install retaining ring #6. Drive bearing cup #3 back against shim #17 retaining ring #6. Step II.
Page 132: Assembly Procedure
MAINTENANCE Output Shaft Removal Step I. Remove protective shield #11 by prying out. Step II. Remove cotter pin #16 and slotted nut #9 from top end of output shaft. Step III. Using long punch or bar inserted through top drive shaft #14 out bottom end. NOTE: Bearing will push seal out bottom.
