Click the arrow for the appropriate input port
6
of the device and drag a cable to the output ar-
row of the corresponding port of the MIDI inter-
face.
To remove a connection, select the cable and
press Delete. To delete all connections, click
Clear Cables.
Repeat steps 3–6 for each MIDI device in your
7
MIDI setup.
To configure an external MIDI device:
Select the external device icon and click Show
1
Info (or double-click the new device icon).
External Device Icon
62 Getting Started with Mbox
Select a manufacturer and model for the new
2
device from the corresponding pop-up menus.
(If the Manufacturer and Model pop-up menus
do not provide a name for your particular de-
vice, you can type a name.)
Naming a new MIDI device
AMS refers to one or more files with the suf-
fix ".middev" in the directory Root/Li-
brary/Audio/MIDI Devices for Manufac-
turer and Model names. Pro Tools installs
two such files that contain information for
many commercially available MIDI devices,
"Legacy Devices.middev" and "Digidesign
Devices.middev." If the Manufacturer or
Model names for any of your external MIDI
devices is not available in the AMS Manu-
facturer and Model pop-up menus, you can
add them by editing any of the current .mid-
dev files in any text editor (such as
TextEdit).
