chapter 4
Connecting Your Studio
This chapter explains how to connect your Mbox to a monitoring system, a digital recorder, and to
audio sources for recording.
Your studio setup will differ depending on the equipment in your studio. The following illustrations
show two possible setups.
USB
cable
FireWire
drive
display
Figure 1. Mbox micro studio configuration running Pro Tools LE on a desktop computer
monitor
outputs
S/PDIF
digital I/O
Mbox
headphones
computer
mixer
DAT or powered speakers
CD recorder
microphone
instrument
Chapter 4: Connecting Your Studio 27
