68 describes how to use and configure OnSite quality of service (QoS) features. • Chapter 8 on page 87 provides LED definitions • Chapter 9 on page 89 contains information on contacting Patton technical support for assistance • Appendix A on page 92 contains compliance information • Appendix B on page 95 contains specifications for the routers •...
OnSite Model 3210 User Manual About this guide Precautions Notes, cautions, and warnings, which have the following meanings, are used throughout this guide to help you become aware of potential problems. Warnings are intended to prevent safety hazards that could result in per- sonal injury.
About this guide Safety when working with electricity The OnSite contains no user serviceable parts. The equipment shall be returned to Patton Electronics for repairs, or repaired by qualified service per- sonnel. Opening the OnSite case will void the warranty. WARNING Mains Voltage: Do not open the case the when the power cord is attached.
OnSite Model 3210 User Manual About this guide The power supply automatically adjusts to accept an input volt- age from 100 to 240 VAC (50/60 Hz). Verify that the proper voltage is present before plugging the CAUTION power cord into the receptacle. Failure to do so could result in equipment damage.
OnSite Model 3210 User Manual About this guide Typographical conventions used in this document This section describes the typographical conventions and terms used in this guide. General conventions The procedures described in this manual use the following text conventions: Table 1. General conventions Convention Meaning Indicates a cross-reference hyperlink that points to a figure, graphic, table, or sec-...
Chapter 1 General information Chapter contents OnSite Model 3210 Series overview........................17 OnSite 3210 Series detailed description ......................18 Model code extensions ..........................18 Ports descriptions .............................19 Applications overview............................20 Branch-Office virtual private network over Frame Relay service ..............20 Corporate multi-function virtual private network...
LAN. Besides assuring first priority for key information, Patton's advanced QoS tech- nology enhances the quality and clarity of realtime application such as live voice and video communications with the main office.
Enhanced IP services include domain name service (DNS) resolver and relay, NAT/NAPT, dynamic DNS, and DHCP server. OnSite 3210 Series detailed description The OnSite 3210 Series G.SHDSL VPN Router provides secure managed VPN routed networking with 2- port Ethernet LAN connectivity and a G.SHDSL WAN interface (see figure IPLink 3210 G.SHDSL WAN port connector...
OnSite Model 3210 User Manual 1 • General information • EUI stands for external 100–240V AC universal input power supply (see figure Ports descriptions The OnSite 3210 Series rear-panel ports are described in table Table 2. Rear panel ports Port Location Description...
VPN connection through a frame-relay service network as delivered on serial lines. The OnSite 3210 Series can support a similar scenario with network service delivered via an Ether- net WAN interface. For remote sites where PPP service is available, the 3210 Series also supports PPP network access over all the standard WAN interface options mentioned above.
42 to configure the VPN. Corporate multi-function virtual private network The OnSite 3210 Series can deliver both private corporate intranet service and public Internet access to multi- ple remote sites by leveraging OnSite’s multiple frame-relay PVC support (see figure 6).
Page 22
OnSite Model 3210 User Manual 1 • General information The corporate multi-function application carries two types of traffic between each remote office and corpo- rate’s central office: • Private corporate traffic (the intranet/extranet) • Internet traffic The service provider offers a Frame Relay network for access, so both the private corporate traffic and the Inter- net traffic is transported over a Frame Relay PVC with one DLCI.
Chapter 2 Hardware installation Chapter contents Planning the installation............................24 Installation checklist ............................25 Site log ................................26 Network information .............................26 Network Diagram .............................26 IP related information ............................26 Software tools ..............................26 Power source ..............................26 Location and mounting requirements ......................27 Installing the VPN router .............................27 Mounting the VPN router ..........................27...
OnSite Model 3210 User Manual 2 • Hardware installation Planning the installation Before you start the actual installation, we strongly recommend that you gather all the information you will need to install and setup the device. See table 3 for an example of what pre-installment checks you might need to carry out.
3) lists the tasks for installing an OnSite 3210 Series VPN Router. Make a copy of this checklist and mark the entries as you complete each task. For each OnSite 3210 Series VPN Router, include a copy of the completed checklist in your site log.
2 • Hardware installation Site log Patton recommends that you maintain a site log to record all actions relevant to the system, if you do not already keep such a log. Site log entries should include information such as listed in table Table 4.
29) Installing the Ethernet cable The OnSite 3210 Series has automatic MDX (auto-cross-over) detection and configuration on the Ethernet ports. Any of the two ports can be connected to a host or hub/switch with a straight-through wired cable (see...
1 Rx+ 2 Rx- 3 Tx+ 6 Tx- Figure 7. Connecting an OnSite 3210 Series device to a hub Installing the DSL cable The OnSite 3210 comes with a G.SHDSL interface. Use a straight-through RJ-11 cable to connect the DSL port.
OnSite Model 3210 User Manual 2 • Hardware installation Connecting to external power source The VPN Router comes with one of the following power supply options as best-suited to the expected installa- tion environment: • 120/140VAC internal power supply (designated by the model code extension UI) •...
3. Verify that the AC power cord included with your VPN Router is compatible with local standards. If it is not, refer to chapter 9, “Contacting Patton for assistance” on page 89 to find out how to replace it with a compatible power cord.
Chapter 3 Getting started with the OnSite Chapter contents Introduction ................................32 1. Configure IP address ............................33 Power connection and default configuration ....................33 Connect with the serial interface ........................33 Login ................................34 Changing the IP address ..........................34 2. Connect the OnSite VPN Router to the network....................35 3.
E ne E ne Internet Note You can manually configure the IPLink Router. You do not have to load a configuration file. Patton Web server with configuration examples Figure 10. Steps for setting up a new OnSite VPN Router Introduction...
Activate the terminal emulation program on the PC or workstation that supports the serial interface (e.g. HyperTerm). Serial Terminal L i n o le Note A Patton Model 16F-561 RJ45 to DB-9 adapter is included with each IPLink Series device Figure 11. Connecting to the terminal Terminal emulation program settings: • 9600 bps •...
OnSite Model 3210 User Manual 3 • Getting started with the OnSite • 1 stop bit • No flow control Login Accessing your OnSite VPN Router via the local console port (or via a Telnet session) causes the login screen to display.
3. Load configuration Patton provides a collection of configuration templates online at www.patton.com/support/upgrades—one of which may be similar enough to your application that you can use it to speed up configuring the OnSite router. Simply download the configuration note that matches your application to your PC. Adapt the configu- ration as described in the configuration note to your network (remember to modify the IP address) and copy the modified configuration to a TFTP server.
Page 36
OnSite Model 3210 User Manual 3 • Getting started with the OnSite After the OnSite VPN Router has been rebooted the new start up configuration will be activated. 172.16.1.99(if-ip)[eth0]#reload Running configuration has been changed. Do you want to copy the 'running-config' to the 'startup-config'? Press 'yes' to store, 'no' to drop changes : no Press 'yes' to restart, 'no' to cancel : yes The system is going down...
OnSite Model 3210 User Manual 4 • G.SHDSL Basic Configuration Introduction The OnSite 3210 model has an option for a built-in G.SHDSL modem. The modem appears in the configura- tion as "port dsl 0 0" mode. port dsl 0 0 vpi 8 vci 35 pppoe...
OnSite Model 3210 User Manual 4 • G.SHDSL Basic Configuration Next, you will need to create a WAN profile, create a WAN interface, and create a subscriber. Then, you can configure the DSL port (port dsl 0 0) for PPPoE. Follow this example: profile napt WAN context ip router...
OnSite Model 3210 User Manual 4 • G.SHDSL Basic Configuration Setting up permanent virtual circuits (PVC) The modems currently available are using ATM to multiplex traffic over the DSL framing connection. ATM allows you to have separate logical connections running in parallel. Those connections are called permanent virtual circuits (PVC).
OnSite Model 3210 User Manual 4 • G.SHDSL Basic Configuration Diagnostics Table 10. Diagnostics commans Command Purpose Step 1 node> show dsl type Displays the type of modem installed. Step 2 node> show dsl line-state Displays information about the state of the DSL link.
Chapter 5 VPN configuration Chapter contents Introduction ................................43 Authentication ..............................43 Encryption ..............................43 Transport and tunnel modes ...........................44 VPN configuration task list ...........................44 Creating an IPsec transformation profile ......................44 Creating an IPsec policy profile ........................45 Creating/modifying an outgoing ACL profile for IPsec ...................47 Configuration of an IP interface and the IP router for IPsec ................48...
OnSite Model 3210 User Manual 5 • VPN configuration Introduction This chapter describes how to configure the VPN connections between two OnSite routers or between an OnSite and a third-party device. A virtual private network (VPN) is a private data network that uses the public telecommunications infrastruc- ture, maintaining privacy through the use of a tunneling protocol and security procedures.
OnSite Model 3210 User Manual 5 • VPN configuration Transport and tunnel modes The mode determines the payload of the ESP packet and hence the application: • Transport mode: Encapsulates only the payload of the original IP packet, but not its header, so the IPsec peers must be at the endpoints of the communications link.
OnSite Model 3210 User Manual 5 • VPN configuration Creating an IPsec policy profile The IPsec policy profile supplies the keys for the encryption and/or the authenticators for the authentication, the security parameters indexes (SPIs), and IP address of the peer of the secured communication. Furthermore, the profile defines which IPsec transformation profile to apply and whether transport or tunnel mode shall be most effective.
Page 46
OnSite Model 3210 User Manual 5 • VPN configuration Mode: Configure Step Command Purpose node(cfg)#profile ipsec-policy-man- Creates the IPsec policy profile name ual name node(pf-ipstr)[name]#use profile Selects the IPsec transformation profile to be ipsec-transform name applied node(pf-ipstr)[name]#session-key Sets a key for encryption or an authenticator for optional authentication, either for inbound or outbound { inbound | outbound }...
OnSite Model 3210 User Manual 5 • VPN configuration Example: Create an IPsec policy profile The following example defines a profile for AES-encryption at a key length of 128. 3210(cfg)#profile ipsec-policy-manual ToBurg 3210(pf-ipsma)[ToBurg]#use profile ipsec-transform AES_128 3210(pf-ipsma)[ToBurg]#session-key inbound esp-encryption 1234567890ABCDEF1234567890ABCDEF 3210(pf-ipsma)[ToBurg]#session-key outbound esp-encryption FEDCBA0987654321FEDCBA0987654321 3210(pf-ipsma)[ToBurg]#spi inbound esp 1111...
OnSite Model 3210 User Manual 5 • VPN configuration Configuration of an IP interface and the IP router for IPsec The IP interface that provides connectivity to the IPsec peer, must now activate the outgoing ACL profile con- figured in the previous section. Furthermore, the IP router must have a route for the remote network that points to the respective IP interface.
OnSite Model 3210 User Manual 5 • VPN configuration MANUAL ToBurg Tunnel 200.200.200.1 1111 AES-CBC 128 3622/unlimited 19047/unlimited OUT MANUAL ToBurg Tunnel 200.200.200.1 2222 AES-CBC 128 2857/unlimited 19047/unlimited Sample configurations The following sample configurations establish IPsec connections between an OnSite and a Cisco router. To interconnect two OnSite routers instead, derive the configuration for the second OnSite by doing the follow- ing modifications: •...
OnSite Model 3210 User Manual 5 • VPN configuration Rest of the configuration, see above, just change the name of the IPsec policy pro- file in the ACL profile ‘VPN_Out’ Cisco router configuration crypto ipsec transform-set AES_SHA1 ah-sha-hmac esp-aes 256 crypto map VPN_AES_SHA1 local-address FastEthernet0/1 crypto map VPN_AES_SHA1 10 ipsec-manual set peer 200.200.200.2...
Page 53
OnSite Model 3210 User Manual 5 • VPN configuration set session-key inbound esp 8888 cipher FEDCBA0987654321FEDCBA0987654321FEDCBA0987654321 authenticator FEDCBA0987654321FEDCBA0987654321 set session-key outbound esp 7777 cipher 1234567890ABCDEF1234567890ABCDEF1234567890ABCDEF authenticator 1234567890ABCDEF1234567890ABCDEF set transform-set 3DES_MD5 match address 110 For the remainder of the configuration (see above), just change the name of the IPsec policy profile in the ACL profile VPN_Out.
Chapter 6 Access control list configuration Chapter contents Introduction ................................55 About access control lists ............................55 What access lists do ............................55 Why you should configure access lists ......................55 When to configure access lists .........................56 Features of access control lists .........................56 Access control list configuration task list........................57 Mapping out the goals of the access control list ....................57...
OnSite Model 3210 User Manual 6 • Access control list configuration Introduction This chapter provides an overview of IP Access Control Lists and describes the tasks involved in configuring them through the OnSite router. This chapter includes the following sections: •...
OnSite Model 3210 User Manual 6 • Access control list configuration For example, access lists can allow one host to access a part of your network, and prevent another host from accessing the same area. In figure 14 host A is allowed to access the Human Resources network and host B is prevented from accessing the Human Resources network.
OnSite Model 3210 User Manual 6 • Access control list configuration • All access control lists have an implicit deny ip any any at the end. A packet that does not match the criteria of the first statement is subjected to the criteria of the second statement and so on until the end of the access control list is reached, at which point the packet is dropped.
OnSite Model 3210 User Manual 6 • Access control list configuration Before you begin to enter the commands that create and configure the IP access control list, be sure that you are clear about what you want to achieve with the list. Consider whether it is better to deny specific accesses and permit all others or to permit specific accesses and deny all others.
Page 59
OnSite Model 3210 User Manual 6 • Access control list configuration Mode: Profile access control list Step Command Purpose node(pf-acl)[name]#deny ip {src src-wildcard | any | host Creates an IP access of control list src} {dest dest-wildcard | any | host dest} [cos group] entry that denies access defined according to the command options...
OnSite Model 3210 User Manual 6 • Access control list configuration Adding an ICMP filter rule to the current access control list profile The command permit or deny are used to define an ICMP filter rule. Each ICMP filter rule represents an ICMP access of control list entry.
Page 61
OnSite Model 3210 User Manual 6 • Access control list configuration Where the syntax is as following: Keyword Meaning The source address to be included in the rule. An IP address in dotted-decimal-format, e.g. 64.231.1.10. src-wildcard A wildcard for the source address. Expressed in dotted-decimal format this value specifies which bits are significant for matching.
OnSite Model 3210 User Manual 6 • Access control list configuration The same effect can also be obtained by using the simpler message name option. See the following example. 3210(cfg)#profile acl WanRx 3210(pf-acl)[WanRX]#deny icmp any any msg echo 3210(pf-acl)[WanRX]#exit 3210(cfg)# Adding a TCP, UDP or SCTP filter rule to the current access control list profile The commands permit or deny are used to define a TCP, UDP or SCTP filter rule.
Page 63
OnSite Model 3210 User Manual 6 • Access control list configuration Where the syntax is: Keyword Meaning The source address to be included in the rule. An IP address in dotted-decimal-format, e.g. 64.231.1.10. src-wildcard A wildcard for the source address. Expressed in dotted-decimal format this value specifies which bits are significant for matching.
OnSite Model 3210 User Manual 6 • Access control list configuration Binding and unbinding an access control list profile to an IP interface The command use is used to bind an access control list profile to an IP interface. This procedure describes how to bind an access control list profile to incoming packets on an IP interface Mode: Profile access control list Step...
OnSite Model 3210 User Manual 6 • Access control list configuration Unbind an access control list profile from an interface. 3210(cfg)#context ip router 3210(cfg-ip)[router]#interface wan 3210(cfg-if)[wan]#no use profile acl in Note When unbinding an access control list profile the name argument is not required, since only one incoming and outgoing access control list can be active at the same time on a certain IP interface.
Page 66
OnSite Model 3210 User Manual 6 • Access control list configuration Mode: Interface Step Command Purpose node(cfg)#context ip router Selects the IP router context node(ctx-ip)[router]#interface if-name Selects IP interface if-name for which access control list profile shall be debugged node(if-ip)[if-name]#debug acl {in | out} [level] Enables access control list debug monitor with a certain debug level for the selected interface if-name...
OnSite Model 3210 User Manual 6 • Access control list configuration Examples Denying a specific subnet Figure 15 shows an example in which a server attached to network 172.16.1.0 shall not be accessible from outside networks connected to IP interface lan of the OnSite device. To prevent access, an incoming filter rule named Jamming is defined, which blocks any IP traffic from network 172.16.2.0 and has to be bound to IP interface lan.
OnSite Model 3210 User Manual 7 • Link scheduler configuration Introduction This chapter describes how to use and configure the OnSite Quality of Service (QoS) features. Refer to 6, “Access control list configuration” on page 54 for more information on the use of access control lists. This chapter includes the following sections: •...
OnSite Model 3210 User Manual 7 • Link scheduler configuration NAPT Profile Service Policy Profile router Context use command use command Interfaces Profile bind command bind command Circuit Ports Figure 16. IP context and related elements Configuring quality of service (QoS) In the OnSite 3210, the link scheduler enables the definition of QoS profiles for network traffic on a certain interface, as shown in figure...
OnSite Model 3210 User Manual 7 • Link scheduler configuration can be used to mark a specific packet type for the other network nodes. By default the traffic-class tag is empty. Refer to figure 17 on page 71 when using the ACL to classify traffic. It illustrates the sequence of processing stages every routed packet passes.
7 • Link scheduler configuration Each traffic-class is in fact assigned a relative weight, which is used to share the bandwidth among the currently active classes. Patton recommends that you specify the weight as percent which is best readable. Shaping There is another commonly used way to assign bandwidth.
OnSite Model 3210 User Manual 7 • Link scheduler configuration Mode priority critical_q min. 30% min. 40% Level_1 min. 30% Mail Low_Priority Default Mode Shaper Define 2nd level Define 1st level Use arbiter on arbiter arbiter an interface Figure 18. Example of Hierarchical Scheduling Quick references The following sections provide a minimal “standard”...
OnSite Model 3210 User Manual 7 • Link scheduler configuration • “modem-512” is the title of the profile which is referred to when installing the scheduler • “rate-limit 512” allows no more than 512 kbit/sec to pass which avoids queueing in the modem. •...
OnSite Model 3210 User Manual 7 • Link scheduler configuration • Displaying link scheduling profile information (see page 85) • Enable statistics gathering (see page 85) Profile Packet Classification Predefined Classes Different Types (Classes) of Traffic The service-policy profile defines the arbitration mode and order in which packets of different classes are served.
OnSite Model 3210 User Manual 7 • Link scheduler configuration Some types of packets you do not have to tag with ACL. Voice and data packets from of for the OnSite itself are automatically tagged with predefined traffic-class names: Predefined internal classes for data are: •...
OnSite Model 3210 User Manual 7 • Link scheduler configuration Mode: Configure Step Command Purpose node(cfg)#profile acl name Creates a new access control list profile named name node(pf-acl)[name]#permit ip host ip-address any traffic-class Creates an IP access con- class-name trol list entry that permits access for host at IP address ip-address, and specifies that packets...
OnSite Model 3210 User Manual 7 • Link scheduler configuration profile service-policy <profile-name> link rate, arbitration common settings common parameters source traffic-class <x> bandwidth, packet mark settings for class x queue-size, etc. source traffic-class <y> settings for class y source traffic-class default settings for all other traffic-classes not listed Figure 21.
OnSite Model 3210 User Manual 7 • Link scheduler configuration At a some point the source traffic-class default must be listed. This class must be present, because it defines how packets, which do not belong to any of the traffic-classes listed in the profile are to be handled. When all listed “traffic-classes”...
OnSite Model 3210 User Manual 7 • Link scheduler configuration Mode: Source Command Purpose node(src)[name]#share percentage Defines fair queuing weight (relative to other sources) to percent- age for the selected class or policy name Defining the bit-rate The command is used with shaper link arbitration to assign the (average) bit-rate to the selected source. rate When enough bandwidth is available each source will exactly receive this bandwidth (but no more), when overloaded the shaper will behave like a wfq arbiter.
OnSite Model 3210 User Manual 7 • Link scheduler configuration The type-of-service (TOS) byte in an IP header specifies precedence (priority) and type of service (RFC791, RFC1349). The precedence field is defined by the first three bits and supports eight levels of priority. The next four bits—which are set by the command—determine the type-of-service (TOS).
OnSite Model 3210 User Manual 7 • Link scheduler configuration “traffic-class” number called. With OnSite you can inspect the DSCP value in the ACL rules and modify the DSCP value with the link scheduler command. set ip dscp Note When configuring service differentiation on the OnSite router, ensure that codepoint settings are arranged with the service provider.
OnSite Model 3210 User Manual 7 • Link scheduler configuration Defining random early detection The command is used to request random early detection (RED). When a queue carries lots of random-detect TCP transfers that last longer than simple web requests, there is a risk that TCP flow-control might be ineffi- cient.
OnSite Model 3210 User Manual 7 • Link scheduler configuration Devoting the service policy profile to an interface Any service policy profile needs to be bound to a certain IP interface to get activated. According the terminol- ogy of OnSite a service policy profile is used on a certain IP interface, as shown in figure Service Policy...
OnSite Model 3210 User Manual 7 • Link scheduler configuration 3210>enable 3210#configure 3210(cfg)#context ip router 3210(ctx-ip)[router]#interface wan 3210(if-ip)[wan]#use profile service-policy Voice_Prio out Displaying link arbitration status command displays link arbitration status. This command supports the optional show service-policy argument interface that select a certain IP interface.
OnSite Model 3210 User Manual 7 • Link scheduler configuration The command has optional values (in the range of 1 to 4) that define the level of detail (see table 14). Table 14. Values defining detail of the queuing statistics Optional Value Implication on Command Output Statistic gathering is switched off...
Console Enet 0 Enet 1 Console port L i n o le Figure 23. Examples of OnSite 3210 Series front panels Table 15. OnSite LED Indications Description Note If an error occurs, all LEDs will flash once per second. Power When lit, indicates power is applied.
Contacting Patton for assistance Chapter contents Introduction ................................90 Contact information..............................90 Patton Support Headquarters in the USA .......................90 Alternate Patton support for Europe, Middle Ease, and Africa (EMEA) ............90 Warranty Service and Returned Merchandise Authorizations (RMAs)..............90 Warranty coverage ............................90 Out-of-warranty service ..........................91 Returns for credit ............................91...
RAS warranty and obtaining a return merchandise authorization (RMA). Contact information Patton Electronics offers a wide array of free technical services. If you have questions about any of our other products we recommend you begin your search for answers by using our technical knowledge base. Here, we have gathered together many of the more commonly asked questions and compiled them into a searchable database to help you quickly solve your problems.
RMA#: xxxx 7622 Rickenbacker Dr. Gaithersburg, MD 20879-4773 USA Patton will ship the equipment back to you in the same manner you ship it to us. Patton will pay the return shipping costs. Warranty Service and Returned Merchandise Authorizations (RMAs)
Page 92
Appendix A Compliance information Chapter contents Compliance ................................93 ................................93 Safety ................................93 PSTN Regulatory ............................93 Radio and TV Interference (FCC Part 15) ......................93 CE Declaration of Conformity ..........................93 Authorized European Representative ........................94 FCC Part 68 (ACTA) Statement ...........................94 Industry Canada Notice ............................94...
The safety advice in the documentation accompanying this product shall be obeyed. The conformity to the above directive is indicated by the CE sign on the device. The signed Declaration of Conformity can be down- loaded from the Patton website at www.patton.com/certifications. Compliance...
OnSite Model 3210 User Manual A • Compliance information Authorized European Representative D R M Green European Compliance Services Limited. Oakdene House, Oak Road Watchfield, Swindon, Wilts SN6 8TD, UK FCC Part 68 (ACTA) Statement This equipment complies with Part 68 of FCC rules and the requirements adopted by ACTA. On the bottom side of this equipment is a label that contains—among other information—a product identifier in the format US: AAAEQ##TXXXX.
Page 95
Appendix B Specifications Chapter contents Ethernet interfaces..............................96 PPP support ................................96 services................................96 Management .................................96 Operating environment ............................96 Operating temperature ............................96 Operating humidity ............................96 System...................................97 Dimensions ................................97 G.SHDSL Daughter Card.............................98 Power supply .................................99 Internal AC version ............................99 12VDC version with External AC Power Adapter ...................99 5VDC Version with External Power Adapter ....................99...
OnSite Model 3210 User Manual B • Specifications Ethernet interfaces 10/100Base-TX Ethernet WAN port 10/100Base-TX Ethernet LAN port All ports full duplex, autosensing, auto-MDIX 10/100 Full Duplex/Autosensing Ethernet RJ-45 PPP support Frame-Relay (8 PVCs) RFC1490, FRF.12 fragmentation LMI, Q.933D, ANSI 617D, Gang of Four PPP, PAP, CHAP, LCP, IPCP IP services IPv4 router;...
OnSite Model 3210 User Manual B • Specifications System CPU Motorola MPC875 operating at 66 MHz Memory: • 32 Mbytes SDRAM • 8 Mbytes Flash Dimensions 7.3W x 1.6H x 6.1D in. (18.5H x 4.1W x 15.5D cm) System...
OnSite Model 3210 User Manual B • Specifications G.SHDSL Daughter Card Note For information on configuring the G.SHDSL daughter card, see Chapter 4, “G.SHDSL Basic Configuration” on page 37. Table 16. G.SHDSL Daughter Card Specifications Factor Specs • ITU-T G.991.2 (and Amendment 2) •...
OnSite Model 3210 User Manual B • Specifications Power supply Internal AC version Internal power supply 100–240 VAC, 50/60 Hz, 200 mA 12VDC version with External AC Power Adapter Uses external AC Adaptor which provides 12VDC via barrel type connector AC Adapter Input: 90-264VAC, 47-63Hz AC Adapter Output: 12 VDC, 1.25A max Note...
Appendix C Cabling Chapter contents Introduction ................................101 Serial console ..............................101 Ethernet 10Base-T and 100Base-T ........................102...
The OnSite can be connected to a serial terminal over its serial console port, as depicted in figure Serial Terminal L i n o le A Patton Model 16F-561 RJ45 to DB-9 adapter is included Note with each IPLink Series device Figure 24. Connecting a serial terminal Note See section “Console port, RJ-45, EIA-561 (RS-232)”...
OnSite Model 3210 User Manual C • Cabling Ethernet 10Base-T and 100Base-T Ethernet devices (10Base-T/100Base-T) are connected to the OnSite over a cable with RJ-45 plugs. Use a cross-over cable to a host, or a straight cable to a hub. See figure 25 (host) and figure 26...
OnSite Model 3210 User Manual C • Cabling Straight-through cable RJ-45, male RJ-45, male 1 Rx+ 2 Rx- 3 Tx+ 6 Tx- Figure 26. Ethernet straight-through Ethernet 10Base-T and 100Base-T...
Page 104
Appendix D Port pin-outs Chapter contents Introduction ................................105 Console port, RJ-45, EIA-561 (RS-232)......................105 Ethernet 10Base-T and 100Base-T port ......................106 ..................................106...
OnSite Model 3210 User Manual D • Port pin-outs Introduction This section provides pin-out information for the ports of the OnSite router. Console port, RJ-45, EIA-561 (RS-232) The RS-232 serial console port of the OnSite is configured to operate as a DCE. View the image in figure 27 showing the RJ-45 receptacle with the numerical identification of the pin numbers and functions.
OnSite Model 3210 User Manual D • Port pin-outs Ethernet 10Base-T and 100Base-T port Table 18. RJ-45 socket Signal Direction from OnSite from OnSite to OnSite to OnSite The Ethernet ports are auto-detect MDI-X. Note Pins not listed are not used. Table 19.
OnSite Model 3210 User Manual E • OnSite 3210 Series factory configuration Introduction The factory configuration settings for the OnSite 3210 Series devices are as follows: #----------------------------------------------------------------# # 3210 Series # R3.xx BUILDxxxxx # 2005-01-18T00:00:00 # Factory configuration file #----------------------------------------------------------------#...
This appendix lists the tasks for installing an OnSite 3210 Series G.SHDSL VPN Router (see table 20). Make a copy of this checklist and mark the entries as you complete each task. For each OnSite 3210 Series Router, include a copy of the completed checklist in your site log. Table 20. Installation checklist...
