MAIN FEATURES:
WEATHER STATION:
16
10
1
2
3
4
5
6
7
8
9
1. SNOOZE/LIGHT key:
- Turn on the projector and backlight for 5 seconds.
- Stop the current alarm when it is sounding and enter
into snooze mode.
2 . TIME WINDOW:
- Displays normal time and day of the week.
3.DATE AND TEMPERATURE WINDOW:
- Shows indoor/outdoor temperature, alarm time and the
date
1
13
14
ON OFF
11
12
15
17
18
SPECIFICATION
MAIN UNIT
Operating range:
-5°C~50°C
23° F~122°F
Resolution:
0.1°C/°F (above -10°C/32°F)
1°C/°F (below -10°C/32°F)
Radio controlled signal:
WWVB/DCF/MSF
REMOTE SENSOR
Operating range:
-20°C~60°C
-4°F~140°F
Resolution:
0.1°C/°F (above -10°C/32°F)
1°C/°F (below -10°C/32°F)
RF transmission frequency:
433MHz
No. of remote sensor:
up to 3 units
RF transmission range:
maximum 50 meters
Temperature sensing cycle:
around 60-64 seconds
14
