swisherinc.com
OWNER'S
MANUAL
STARTING SERIAL #:
L114-200001
MODEL NO.
WBRC11524C
WBRC11524CXP
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
19706
REV 14-200
PREDATOR TALON
Operation
Service and Adjustment
Repair Parts
PHONE (660) 747-8183 FAX (660) 747-8650
24" WALK BEHIND
ROUGH CUT
Made In The
USA
Advertisement
Related Manuals for Swisher PREDATOR TALON WBRC11524C
Summary of Contents for Swisher PREDATOR TALON WBRC11524C
-
Page 1: Repair Parts
OWNER’S MANUAL STARTING SERIAL #: L114-200001 MODEL NO. WBRC11524C WBRC11524CXP PREDATOR TALON 24” WALK BEHIND IMPORTANT ROUGH CUT Read and follow all Safety Precautions and Instructions before operating this Operation equipment. Service and Adjustment Repair Parts Made In The... - Page 2 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.
-
Page 3: Safety Precautions
Thank you for choosing Swisher’s 24” Walk Behind Rough Cut. Before operating your Walk Behind, please read, understand and follow all of the safety precautions and other instructions explained in this manual. As with all power equipment, lawn mowers can be potentially dangerous if not properly used. - Page 4 • Turn off the blade when not mowing. Before leaving the machine, turn off the blade and stop the engine. • Watch for traffic when operating near or crossing roadways. • Do not operate the mower if it has been dropped or damaged in any manner or if the mower vibrates excessively.
- Page 5 OPERATING YOUR NEW WALK BEHIND The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine.
- Page 6 STARTING THE ENGINE See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Engine must be level to accurately check and fill oil. Do not overfill. • Make sure unit is level, blade is disengaged, and transaxle in “NEUTRAL” •...
- Page 7 TRANSPORTING • Shut off engine. • Secure in place while unit is being transported. • Unit should be left in low gear to avoid any slight rolling. SUGGESTED PRACTICES • Always operate engine at full throttle when cutting to assure the best cutting performance and proper discharge of material.
- Page 8 SAFETY AND OPERATIONAL DECALS Replace decal immediately if damaged. Order by part number from Swisher. OD55--DANGER DECAL OD45--WARNING DECAL OD83--RN1234 SHIFT DECAL 10749--REVERSE LOCK DECAL OD99112--LARGE LOGO WHITE DECAL OD99156--SMALL LOGO WHITE DECAL OD39--SWISHER FLAG DECAL DECALS NOT SHOWN 19722-- Predator Talon LH Decal...
- Page 9 ASSEMBLY DETAIL Item # Description Part # Cover - Belt 10682* Bolt - Serrated Flange 5/16-18 X 3/4 NB596 Nut - Serrated Flange 5/16-18 NB170 Channel - Right Side 19211* Channel - Left Side 19212* Clip - Twistlock, Nylon 1/2" NB683 Height Adjustment Mount 19214*...
- Page 10 ENGINE & PULLEY ASSEMBLY Item # Description Part # 5/16-18 X 1 1/4 Serr. Flange Bolt NB253 5/16-18 X 3/4 Serr. Flange Bolt NB596 Bracket - ON/OFF Switch, Txt Blk 19201* Switch - Toggle 19192 5/16-18 Serr. Flange Nut NB170 Belt Retention Weldment 10767 Engine Pulley Spacer 1.75"...
- Page 11 REAR COVER ASSEMBLY Item # Description Part # 5/16-18 Serr. Flange Nut NB170 Rear Cover 10679* Anti Reverse Arm 10680* Spacer B99S 5/16-18 X 3/4 Serr. Flange Bolt NB596 HANDLE BAR & LEVER ASSEMBLY Item # Description Part # Lever - Blade Engagement Weldment 19444* Weldment - Handle 19220*...
-
Page 12: Brake Assembly
BLADE DRIVER ASSEMBLY Item # Description Part # 3/4-16 Jam Nut NB175 1.5x.761x.098x.134 Belleville Washer AS155 Blade Pulley-5.5" 6114 Spacer - 3/4 ID x 1 Powder Metal 12823 3/4 ID X 1 1/4 OD 18 GA Washer NB179 Blade Bearing Blade Shaft 6"- Long Shoulder 9078 5/16-18 Serr. -
Page 13: Transaxle Assembly
DECK & CASTER ASSEMBLY Item # Description Part # Deck Weldment 14748* PAGE 12 1/4-20 X 3/4 GR5 ZP Bolt NB250 Blade Engagement Cable Clip 10673* 1/4-20 Nyloc Nut NB180 Nut - Serrated Flange 5/16-18 NB170 Deck Side Skid 18512* Bolt - Serrated Flange, 5/16-18 X 3/4 NB596 Washer - 5/8 ID X 1 OD 14 GA NB149... - Page 14 2410 TRANSAXLE PULLEY 690 – TRANSAXLE BELT TOP ENGINE PULLEY CONFIGURATION B27 – TRANSAXLE IDLER PULLEY 2411 – TOP ENGINE PULLEY BB105 – LOWER ENGINE PULLEY BA50 – BLADE ENGAGEMENT BELT T30V – V-BELT PULLEY BOTTOM ENGINE PULLEY CONFIGURATION B527 – BLADE IDLER PULLEY BELT CONFIGURATION 6114 –...
- Page 15 MAINTENANCE LOG Date of Service Service Performed Notes...
- Page 16 MODEL NO. All cutter parts listed herein may be ordered directly from Swisher or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the engine supplied with your cutter WBRC11524C...
