OWNER'S
MANUAL
STARTING SERIAL #:
L115-335001
MODEL NO.
WBERC11524
PREDATOR
COMMERCIAL PRO
24" WALK BEHIND
IMPORTANT
12V ROUGH CUT
Read and follow all
Safety Precautions
Operation
and Instructions
before operating this
Service and Adjustment
equipment.

Repair Parts

Made In The
SWISHER ACQUISITION INC.
USA
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
PHONE (660) 747-8183 FAX (660) 747-8650
of US and Global Parts
19890
REV 15-335
