OWNER'S
MANUAL
MODEL NO.
WB80042F
Read and follow all Safety
Rules and Instructions
before operating this
equipment.
Rev. 12.18.2002
1602 CORPORATE DRIVE, P.O. BOX 67, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
ONWB842
Visit us at: www.swisherinc.com
THE FINISHING TOUCH
42" FINISH CUT MOWER SELF PROPELLED
Assembly
Operation
Service and Adjustment
Repair Parts
PHONE (660) 747-8183 FAX (660) 747-8650
WALK BEHIND
Made In The
USA
Advertisement
Table of Contents
Related Manuals for Swisher WB800042F
Summary of Contents for Swisher WB800042F
-
Page 1: Service And Adjustment
Visit us at: www.swisherinc.com OWNER’S MANUAL MODEL NO. WB80042F THE FINISHING TOUCH 42” FINISH CUT MOWER SELF PROPELLED WALK BEHIND Read and follow all Safety Rules and Instructions Assembly before operating this Operation equipment. Service and Adjustment Rev. 12.18.2002 Repair Parts 1602 CORPORATE DRIVE, P.O. -
Page 2: Safety And Operational Decals
SAFETY AND OPERATIONAL DECALS Replace decal immediately if damaged. Order by part number from Swisher Mower and Machine Co. Inc. OD36 – DEFLECTOR DECAL OD30 – WARNING DECAL OD55 – DANGER DECAL OD43 – FLYING DEBRIS DECAL OD29 – SPINNING BLADE DECAL... -
Page 3: Service And Adjustments
SERVICE AND ADJUSTMENTS Stop engine, let all moving parts come to a complete stop. Disconnect spark plug. BLADE SPINDLE BELT TRANSMISSION BELT BLADE DRIVE BELT BELTS CONFIGURATION BLADE SPINDLE BELT REPLACEMENT REMOVAL • Stop engine, let all moving parts come to a complete stop. Disconnect spark plug. -
Page 4: Wheel Brake Adjustment
WHEEL DRIVE BELT REPLACEMENT REMOVAL • Stop engine, let all moving parts come to a complete stop. Disconnect spark plug. • Remove belt cover. • Remove Blade Drive Belt, (See “Blade Drive Belt replacement”) • Locate belt guide for wheel drive belt and loos en. •... -
Page 6: Replacement Parts
REPLACEMENT PARTS When ordering painted parts, please indicate with corresponding letters: C = Red Parts; TK = Textured Black Parts (ex. 4207TK, 4237C) Item # Description Part # Item # Description Part # Motor Base 4270 Tension Spring 682S Wire Link BRS6H 1/2 x 1 9/16 Shoulder Bolt NB220... - Page 7 REPLACEMENT PARTS When ordering painted parts, please indicate with corresponding letters: C = Red Parts; TK = Textured Black Parts (ex. 4207TK, 4237C) Item # Description Part # Sway Bar 4207 3/16 x 1 1/2 Keystock 2434 3/4 E-Clip NB621 3/4 x 10 GA Washer NB184 5/16-18 x 1/2 Set Screw...
- Page 8 OWNER’S fan housing. All cutter parts listed herein may be ordered directly from MANUAL Swisher Mower & Machine Co. Inc. or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the MODEL NO. engine supplied with your cutter...
