H3-05,H3-09 Settings
Set-
ting Function
Value
0 Add to terminal A1*
1 Frequency gain
Auxiliary frequency reference (2nd
2
step analog)
Auxiliary frequency reference 2
3
(3rd step analog)
4 Voltage bias
Accel/decel change (reduction
5
coefficient)
6 DC injection braking current
Overtorque/undertorque detection
7
level
8 Stall prevention level during run
Frequency reference lower limit
9
level
A Jump frequency
B PID feedback
C PID target value
D Frequency bias 2
E Motor temperature input
10 Positive torque limit
11 Negative torque limit
12 Regenerative torque limit
Torque reference/torque limit at
13
speed control
14 Torque compensation
15 Positive/negative torque limit
1F Analog input not used.
16 to 1E Not used
* 0 and D can not be set at the same time. 0PE07 is displayed.
Contents (100%)
Maximum output frequency
Frequency reference (voltage) command
value
Maximum output frequency
Maximum output frequency
200 V (200 V Class)/400 V (400 V Class)
Set acceleration and deceleration times
(C1-01 to C1-08)
Inverter rated output current
Motor rated torque for vector control
Inverter rated output current for V/f control
Inverter rated output current
Maximum output frequency
Maximum output frequency
Maximum output frequency
Maximum output frequency
Maximum output frequency
10 V = 100%
Motor's rated torque
Motor's rated torque
Motor's rated torque
Motor's rated torque
Motor's rated torque
Motor's rated torque
-
-
User Constant Tables
Control Methods
Open Open
V/f Loop Flux Loop
V/f with Vec- Vec- Vec-
PG tor tor tor
1 2
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes No No No
Yes Yes Yes Yes Yes
Yes Yes Yes No No
Yes Yes Yes Yes Yes
Yes Yes No No No
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
No No Yes Yes Yes
No No Yes Yes Yes
No No Yes Yes Yes
No No No Yes Yes
No No No Yes Yes
No No Yes Yes Yes
Yes Yes Yes Yes Yes
- - - - -
Page
6-28
6-125
6-28
6-5
6-5
-
6-16
6-15
6-54
6-48
6-33
6-30
6-105
6-105
6-28
6-59
6-45
6-45
6-45
6-125
6-125
6-45
6-6
-
