Preparation
(continued)
● Mass distribution via redistribution server
Images of VN-E4 may be recorded in the redistribution server and distributed to a large number of clients.
AUDIO VIDEO INPUT
IN 1CH
OUT
3CH
● Recording images at the FTP server
FTP can be set such that JPEG files are transferred from VN-E4 to FTP server when alarm occurs. Images before and after
the alarm input time (pre/post images) may be recorded at the FTP server.
● Control via customized application software
The following uses are also possible by developing a customized application software that supports the API of VN-E4.
Monitoring via the PC while at the same time recording images/audio to the HDD.
Recording by increasing the frame size/frame rate during alarm occurrence.
Recording the type and time of alarm occurrence at the PC.
Remote control of some external devices using the pass-through feature of VN-E4.
ALARM
CONTROL
COM1 SERVICE
2CH COM OUT 1 2 3 4 G INPUT
OUTPUT
PUSH
4CH RESET
COM2 DC 5V
10BASE-T/100BASE-TX
Network
Network
AUDIO VIDEO INPUT
COM1
IN 1CH 2CH
OUT
3CH 4CH
COM2
SERVER
Network
Network
ALARM
CONTROL
SERVICE
COM OUT 1 2 3 4 G INPUT
OUTPUT
PUSH
RESET
10BASE-T/100BASE-TX DC 5V
Network Network
PC
PC
PC
FTP
SERVER
