Main Unit; Parts List - Icom IC-F33GT Service Manual

SECTION 7

[MAIN UNIT]

REF ORDER
NO. NO.
IC2 1110002751 S.IC TA75S01F (TE85R,F)
IC6 1110005340 S.IC NJM12902V-TE1
IC8 1110005771 S.IC S-80942CNMC-G9CT2G
IC9 1110003201 S.IC TA31136FNG (EL)
IC10 1130011581 S.IC 24LC64T-I/SN G
IC12 1190001350 S.IC M62364FP 600D
IC13 1130006221 S.IC TC4W53FU (TE12L,F)
IC14 1110006221 S.IC AK2346P-E2/P
IC15 1110001811 S.IC TA7368FG (5,ER)
IC17 1110005350 S.IC NJM2870F05-TE1
IC19 1110005330 S.IC NJM12904V-TE1-
1110006380 S.IC LM2904PWR
IC20 1130009090 S.IC LC75834W-TLM-E
IC21 1130010100 S.IC LMX2352TMX/NOPB
IC22 1140011511 S.IC HD64F2238BTF13V
IC23 1110005330 S.IC NJM12904V-TE1
1110006380 S.IC LM2904PWR
IC24 1110002751 S.IC TA75S01F (TE85R,F)
IC25 1130007021 S.IC TC7S66FU (TE85L,F)
Q2 1590003321 S.FET TPC6103 (TE85L,F)
Q3 1590003290 S.TR UNR9213J-(TX)
Q4 1560000841 S.FET 2SK1829 (TE85R,F)
Q5 1580000731 S.FET 3SK293 (TE85L,F)
Q6 1580000760 S.FET 3SK299-T1 U73
Q7 1530002601 S.TR 2SC4215-O (TE85R,F)
Q14 1530003260 S.TR 2SC5006-T1
Q15 1530003260 S.TR 2SC5006-T1
Q16 1530003260 S.TR 2SC5006-T1
Q17 1530003260 S.TR 2SC5006-T1
Q18 1590001400 S.TR XP1214 (TX)
Q19 1590003290 S.TR UNR9213J-(TX)
Q20 1530002851 S.TR 2SC4116-BL (TE85R,F)
Q21 1560000541 S.FET 2SK880-Y (T5RICOM,F)
Q22 1530002851 S.TR 2SC4116-BL (TE85R,F)
Q24 1510000920 S.TR 2SA1577 T106 Q
Q25 1510000920 S.TR 2SA1577 T106 Q
Q26 1520000450 S.TR 2SB1132 T100 Q
Q27 1590001190 S.TR XP6501-(TX) .AB
Q28 1590003230 S.TR UNR9113J-(TX)
Q29 1530003260 S.TR 2SC5006-T1
Q38 1590003290 S.TR UNR9213J-(TX)
Q40 1590003290 S.TR UNR9213J-(TX)
Q41 1590001190 S.TR XP6501-(TX) .AB
Q42 1520000450 S.TR 2SB1132 T100 Q
UNR9111J-(TX) except q, w, y
Q43 1590003380 S.TR
1590003400 S.TR UNR9112J
Q44 1590003270 S.TR UNR9210J-(TX)
Q45 1590003230 S.TR UNR9113J-(TX)
Q500 1590003290 S.TR UNR9213J-(TX)
Q501 1590003290 S.TR UNR9213J-(TX)
Q502 1560001360 S.FET 2SK3019 TL
Q503 1590003290 S.TR UNR9213J-(TX)
D5 1160000060 S.DIO DAN202U T106
D6 1790001260 S.DIO MA2S077-(TX)
D8 1790001250 S.DIO MA2S111-(TX)
D9 1750000771 S.VCP HVC376BTRF-E
D10 1750000771 S.VCP HVC376BTRF-E
D11 1750000721 S.VCP HVC375BTRF-E
D12 1720000471 S.VCP 1SV239 (TPH3,F)
D13 1750000721 S.VCP HVC375BTRF-E
D14 1750000711 S.VCP HVC350BTRF-E
D15 1750000711 S.VCP HVC350BTRF-E
D16 1790001260 S.DIO MA2S077-(TX)
D17 1790001260 S.DIO MA2S077-(TX)
D18 1790001250 S.DIO MA2S111-(TX)
D19 1750000721 S.VCP HVC375BTRF-E
D20 1790001240 S.DIO MA2S728-(TX)
D21 1160000060 S.DIO DAN202U T106
D24 1750000721 S.VCP HVC375BTRF-E
D25 1790001240 S.DIO MA2S728-(TX)
D28 1790001670 S.DIO RB706F-40T106
D500 1750000771 S.VCP HVC376BTRF-E
D501 1750000771 S.VCP HVC376BTRF-E
D502 1790001260 S.DIO MA2S077-(TX)
D503 1790001260 S.DIO MA2S077-(TX)
D504 1750000940 S.DIO ISS400 TE61
D506 1790000620 S.DIO MA77 (TX)
q: GT [USA-01] w: GT [GEN-01] e: GT [EUR-01] r: GT [USA-02] t: GT [CHN-01]
y: GS [USA-01] u: GS [GEN-01] i: GS [EUR-01] o: GS [USA-02] !0 : GS [USA-01]
!1 : GS [CHN-01] !2 : GS [SWE-07] !3 : GS [NOR-08] !4 : GS [SWE-09]

PARTS LIST

DESCRIPTION M.
LOCATION
T
B
B
T
B
B
B
B
T
B
q, w, e, y, u, i
B
r, t, o, !0 , !1 , !2 , !3
B
T
T
r, t, o, !0 , !3 only
B
q, w, e, y, u, i
B
r, t, o, !0 , !1 , !2 , !3
B
B
B
T
T
T
B
B
B
B
B
B
B
T
T
T
T
T
B
B
B
B
B
B
B
B
T
T
T
q, w, y
T
B
T
T
T
B
r, t, o, !0 , !1 , !2 , !3 only
T
T
B
T
r, t, o, !0 , !3 only
B
r, t, o, !0 , !3 only
B
r, t, o, !0 , !3 only
B
B
r, t, o, !0 , !3 only
B
r, t, o, !0 , !3 only
B
r, t, o, !0 , !3 only
B
B
B
T
r, t, o, !0 , !3 only
B
B
B
r, t, o, !0 , !3 only
B
B
B
r, t, o, !0 , !3 only
B
r, t, o, !0 , !3 only
B
B
T
B
r, t, o, !0 , !1 , !2 , !3
B
[MAIN UNIT]
H/V REF ORDER
NO. NO.
88.1/12.4 FI1 2030000150 S.MLH FL-335 (46.350 MHz)
55.4/23.8 FI2 2020001530 CER
20.8/41.5
81.5/17
29.7/13.2 X1 6070000191 S.DCR CDBKB450KCAY24-R0
38.9/26.2 X2 6050011931 S.XTL
47.1/24 X5 6050011730 S.XTL
41.5/13.2 X6 6050011830 S.XTL
97.3/15.4
93.2/20.2
L7 6200008090 S.COL LQW2BHN68NJ03L
42.9/39.6 L8 6200008090 S.COL LQW2BHN68NJ03L
L9 6200007750 S.COL LQW2BHN56NJ03L
42.9/39.6 L11 6200007750 S.COL LQW2BHN56NJ03L
57.3/20.3 L12 6200009351 S.COL ELJRE R22GFA
79.5/34.1 L13 6200007850 S.COL ELJNC R82K-F
L21 6200011031 S.COL ELJRF R10JFB
17.4/22.4 L22 6200011031 S.COL ELJRF R10JFB
L24 6200003640 S.COL MLF1608E 100K-T
36.9/39.3 L25 6200007760 S.COL LQW2BHN82NJ03L
L27 6200003550 S.COL MLF1608A 4R7K-T
36.9/39.3 L28 6200003550 S.COL MLF1608A 4R7K-T
56.2/36.9 L31 6200007001 S.COL ELJRE 82NGFA
58.2/33 L32 6200007911 S.COL ELJRF 18NJFB
L33 6200004480 S.COL MLF1608D R82K-T
L35 6200003540 S.COL MLF1608D R22K-T
98.4/4.8 L37 6200008090 S.COL LQW2BHN68NJ03L
93.4/5 L41 6200007911 S.COL ELJRF 18NJFB
90.9/34.7 L42 6200003550 S.COL MLF1608A 4R7K-T
90.9/39 L43 6200003550 S.COL MLF1608A 4R7K-T
86.8/29.5 L47 6200007720 S.COL LQW2BHN33NJ03L
89.2/19.7 L48 6200008090 S.COL LQW2BHN68NJ03L
78.7/34.3 L500 6200003640 S.COL MLF1608E 100K-T
74.9/28.1 L501 6200003960 S.COL MLF1608A 1R0K-T
76.6/25.1 L502 6200011001 S.COL ELJRF 56NJFB
76.1/33.9
73.7/27.9
73.9/25.6 R1 7030005530 S.RES ERJ2GEJ 100 X (10)
86.5/25.6 R4 7030007570 S.RES ERJ2GEJ 122 X (1.2 k)
70.8/23.8 R5 7030007340 S.RES ERJ2GEJ 153 X (15 k)
81.3/24.3 R6 7030005070 S.RES ERJ2GEJ 683 X (68 k)
63.3/14.3 R7 7030005310 S.RES ERJ2GEJ 124 X (120 k)
64.4/10.4 R8 7030005110 S.RES ERJ2GEJ 224 X (220 k)
56.6/11.3 R9 7030004980 S.RES ERJ2GEJ 101 X (100)
57.5/7.3 7030004990 S.RES ERJ2GEJ 221 X (220)
54.1/7.1
78.8/23.1 R12 7030005530 S.RES ERJ2GEJ 100 X (10)
81.8/39.2 R13 7030005090 S.RES ERJ2GEJ 104 X (100 k)
49.5/18.4 R15 7030005310 S.RES ERJ2GEJ 124 X (120 k)
90.8/21.3 R16 7030008280 S.RES ERJ2GEJ 271 X (270)
89.3/17.2 R17 7030004970 S.RES ERJ2GEJ 470 X (47)
77.7/4.9 R18 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
77.7/4.9 R19 7030005090 S.RES ERJ2GEJ 104 X (100 k)
29.8/5.8 R21 7030005090 S.RES ERJ2GEJ 104 X (100 k)
54.6/4.5 R22 7030005050 S.RES ERJ2GEJ 103 X (10 k)
78.6/23.7 R23 7030005090 S.RES ERJ2GEJ 104 X (100 k)
84.7/11.9 R24 7030005120 S.RES ERJ2GEJ 102 X (1 k)
36/11.7 R25 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R29 7030007270 S.RES ERJ2GEJ 151 X (150)
81.9/42.8 R31 7030004980 S.RES ERJ2GEJ 101 X (100)
R32 7030010040 S.RES ERJ2GEJ-JPW
R33 7030007280 S.RES ERJ2GEJ 331 X (330)
93.6/7.3 R34 7030005090 S.RES ERJ2GEJ 104 X (100 k)
27.6/31 R35 7030004980 S.RES ERJ2GEJ 101 X (100)
86.7/28.6 R36 7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
R38 7030005090 S.RES ERJ2GEJ 104 X (100 k)
69.4/30.5 R39 7030004970 S.RES ERJ2GEJ 470 X (47)
R40 7030007270 S.RES ERJ2GEJ 151 X (150)
69.1/26.5 R43 7030004970 S.RES ERJ2GEJ 470 X (47)
R44 7030005240 S.RES ERJ2GEJ 473 X (47 k)
73.3/33.7 R45 7030008290 S.RES ERJ2GEJ 183 X (18 k)
72/28.4 R46 7030005000 S.RES ERJ2GEJ 471 X (470)
R48 7030005010 S.RES ERJ2GEJ 681 X (680)
73.5/23.1 R50 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R68 7030005120 S.RES ERJ2GEJ 102 X (1 k)
86.1/35.4 R69 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R70 7030004980 S.RES ERJ2GEJ 101 X (100)
87.4/39.5 R71 7030005070 S.RES ERJ2GEJ 683 X (68 k)
84.3/18 R72 7030005090 S.RES ERJ2GEJ 104 X (100 k)
83.4/22.2 R73 7030008010 S.RES ERJ2GEJ 123 X (12 k)
92.9/36.6 R74 7030006610 S.RES ERJ2GEJ 394 X (390 k)
R75 7030005240 S.RES ERJ2GEJ 473 X (47 k)
94.8/39.1 R76 7030004980 S.RES ERJ2GEJ 101 X (100)
94.9/33.4 R77 7030004980 S.RES ERJ2GEJ 101 X (100)
28.4/22.6 R78 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R79 7030008340 S.RES RR0510P-182-D (1.8 k)
96.6/37.7 R80 7030005050 S.RES ERJ2GEJ 103 X (10 k)
94.9/34.7 R81 7030005090 S.RES ERJ2GEJ 104 X (100 k)
29.8/2.9 R82 7030009320 S.RES ERJ2GEJ 4R7 X (4.7)
R83 7030008340 S.RES RR0510P-182-D (1.8 k)
68.2/32.2 R84 7030011000 S.RES RR0510P-392-D (3.9 k)
R85 7030011000 S.RES RR0510P-392-D (3.9 k)
68.1/24.9 R86 7030005090 S.RES ERJ2GEJ 104 X (100 k)
79.9/28.1 R87 7030005000 S.RES ERJ2GEJ 471 X (470)
R88 7030008370 S.RES ERJ2GEJ 561 X (560)
80.2/26.7
28.2/24.5 R89 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R90 7030005110 S.RES ERJ2GEJ 224 X (220 k)
45.4/35.3 R91 7030005060 S.RES ERJ2GEJ 333 X (33 k)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
7 - 1
DESCRIPTION M.
CFWLB450KFFA-B0
CR-781A (15.3 MHz)
CR-765 (3.6864 MHz)
CR-774 (12.288 MHz)
q, w, y
except q, w, y
S.=Surface mount
H/V
LOCATION
T 91.3/27.1
B 80/16.9
B 63.3/38.3
B 38.3/4
B 30.9/31.5
B 99.2/38.1
B 93.1/40.3
B 88.7/36.5
B 85.9/33.8
B 84.3/26.5
B 89.4/32
B 80.5/22.8
B 77.2/28.5
B 70.3/26.6
B 71.9/23.5
T 68.7/26.7
T 68.8/30.4
B 95.3/31.3
T 77.8/27.4
T 81.4/22.4
T 84.6/25.5
B 71.6/33.4
B 80.2/33.5
T 71.2/34.2
T 69.4/21.9
B 69.1/34.3
B 69.3/22.7
B 70.6/30.4
T 74.7/31.9
B 86.3/25.4
T 87.4/14.6
T 86.3/9.7
T 86.6/8.1
T 86/15.7
T 85.5/13.4
T 88/10.2
T 90.5/12.3
T 90.5/12.3
B 90.2/36.8
T 95.2/40.2
T 92.2/39.3
B 89.8/41.2
T 88.7/36.8
T 70.8/30.1
T 91.1/37.6
T 87.3/41.4
T 88.5/38.9
T 86.5/35.6
B 86.2/22.8
B 85.7/31.2
B 89.2/27.5
T 89.2/33.7
T 92.2/31.9
B 90.2/22.9
B 88.6/21.6
B 87.2/21.2
B 81.9/12.6
T 81.8/12.2
B 81.4/11.6
T 81.8/21.3
T 77.8/14.1
T 77.9/21.3
T 77.2/17.9
T 76.6/20.7
B 87.2/19.9
B 84.9/22.8
B 85.6/15.9
B 85.6/18.2
B 80.1/26.4
B 80.1/25.5
B 35.5/34.2
B 39.1/19.5
B 40.1/19.5
B 78.5/31
B 78.7/32
B 77.2/30.9
B 75.9/29.7
B 76.1/32.4
T 75.1/23.9
B 47.9/20.8
B 74.8/25.7
B 75.3/23.9
B 74.6/22.7
B 73.5/29.7
T 71.5/25.8
B 75.4/31.2
B 75.1/26.6
T 70.2/25.6
T 71.3/21
T 70.7/19.7
