Related Manuals for QSSC QSSC-310DA
Summary of Contents for QSSC QSSC-310DA
-
Page 3: Regional Emc Compliance Information
Regional EMC Compliance Information FCC Verification Notice (USA only) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Class A This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. - Page 4 Preface CCC (China only) The following CCC EMC Warning is marked on the product: EMC Warning are required for Class A products. 此为 A 级产品，在生活环境中，该产品可能会造成无线电干扰，在这种情况下，可能需要用户 对其干扰采取可行的措施 China RoHS Declaration Table 部件名称 有毒有害物质或元素 (Hazardous Substance) (Component Name) 铅 汞 镉 六价铬 多溴联苯...
- Page 5 Preface BSMI (Tawain only) The following BSMI EMC Warning is marked on the product: BSMI ID No and EMC Warning are required for Class A products. 這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情況下，使用者會被 要求採取某些適當對策。 Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved.
-
Page 6: Safety Information
Preface Safety Information READ THIS IMPORTANT SAFETY INFORMATION SECTION. RETAIN THIS MANUAL FOR REFERENCE. READ THIS SECTION BEFORE SERVICING. CAUTION! TO REDUCE THE RISK OF ELECTRIC SHOCK, THIS SERVER SHOULD ONLY BE SER- VICED BY QUALIFIED SERVICE PERSONNEL. RTC Battery CAUTION! DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. -
Page 7: Typographic Conventions
Preface CAUTION! DO NOT OVERLOAD THE AC SUPPLY BRANCH CIRCUIT THAT PROVIDES POWER TO THE RACK. THE TOTAL RACK LOAD SHOULD NOT EXCEED 80 PERCENT OF THE BRANCH CIRCUIT RATING. CAUTION! ENSURE THAT PROPER AIRFLOW IS PROVIDED TO COMPONENTS IN THE RACK. DO NOT STEP ON OR STAND ON ANY COMPONENT WHEN SERVICING OTHER COMPO- NENTS IN A RACK. -
Page 8: Table Of Contents
Preface CHAPTER 1 Introduction Checklist A Tour of the System QSSC-310DA/ QSSC-310DS SKU Front View QSSC-310FA/ QSSC-310LA SKU Front View Rear View CHAPTER 2 Installing Hardware Safety Measures QSSC-310 Mainboard Components Jumper and Connections Installing Hard Drives (QSSC-310DA/QSSC-310DS) Installing Hard Drives (QSSC-310FA/QSSC-310LA) - Page 9 Preface Remote Access Configuration Security Menu Exit Menu CHAPTER 4 Using the Web UI Setting the KVM TCP Port on Network Logging into the Web User Interface System Information Version Session Time-Out Components System Monitoring Sensor Reading Event Logs Locator Indicator Fault LED Configuration Network...
- Page 10 Preface APPENDIX A Support Before You Begin Installing the Rack Brackets Troubleshooting Sequence Installation Problems APPENDIX B Updating the BMC Firmware BMC Firmware Update Utility BMC Firmware Update Procedure APPENDIX C Specifications viii...
-
Page 11: Introduction
IPMB connects externally through the (ICMB) Intelligent Chassis Management Bus. The ICMB is used to con- nect the QSSC-310 server to the outside world, providing data such as temperature, voltage, or chassis intrusion to the system administrator. ASPEED 1000/2000 server management firmware enables the administrator to monitor the QSSC-310 status through a typical web browser. -
Page 12: A Tour Of The System
Chapter 1 — Introduction A Tour of the System The following sections describe the external features of the QSSC-310 server. QSSC-310DA/ QSSC-310DS SKU Front View HDD Present LED LED displays HDD status: Present: Green Fault: Amber Note: Fault indicates SAS HDD errors only; SATA HDD errors are not shown. -
Page 13: Qssc-310Fa/ Qssc-310La Sku Front View
QSSC-310FA/ QSSC-310LA SKU Front View Dummy DVD Cover QSSC-310FA SKU dummy DVD bay cover. Note: QSSC-310LA SKU has no DVD bay cutout on the front bezel. USB port Connect USB device to this port. Front ID LED / status LED •... -
Page 14: Rear View
Chapter 1 — Introduction Rear View Power socket Connect the power cable to the installed socket. PS/2 mouse Connect a PS/2 pointing device to this port. LAN port 1 Connect an RJ-45 jack to this port to connect to a Gigabit Ethernet LAN or a second server. -
Page 15: Installing Hardware
Chapter 2 Safety Measures Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to yourself. •... -
Page 16: Qssc-310 Mainboard Components
Port 80 debug connector Mainboard power connector P1 Four DDR2 DIMM slots J11, J12, J13, J14 FAN1 connector FAN2 connector SATA active control connector PCI FAN connector SGPIO connector Note: Items 6, 19, and 21are not supported by the QSSC-310LA SKU. -
Page 17: Jumper And Connections
Pin2: Fault_LED1 Pin3: Fault_LED2 Pin4: Fault_LED3 Port 80 debug This connector is used for debug board connector connector Intrusion switch Pin1: GND connector Pin2: Intrusion pin Pin3: NC Note: J9 – Fault LED is not supported by the QSSC-310LA SKU. -
Page 18: Installing Hard Drives (Qssc-310Da/Qssc-310Ds)
Chapter 2 — Installing Hardware Installing Hard Drives (QSSC-310DA/QSSC-310DS) Refer to the following instructions to install hard drives. 1. Push the locking latch (1) in the direction of the arrow (2). The HDD tray’s locking lever springs open. 2. Pull the locking lever to remove the HDD tray. - Page 19 Chapter 2 — Installing Hardware 4. Secure the hard drive (1) to the tray with four screws (2). Do not over tighten the screws. 5. Push the HDD tray firmly and slide in the direction of the arrow until it is seated in the cradle. 6.
-
Page 20: Installing Hard Drives (Qssc-310Fa/Qssc-310La)
Chapter 2 — Installing Hardware Installing Hard Drives (QSSC-310FA/QSSC-310LA) The QSSC-310 Fixed SKU accommodates two fixed HDDs (not supplied). Depending on the location of the HDD, refer to the following instructions to install the hard drives. Note: Fixed HDDs must be purchased separately and installed as instructed. -
Page 21: Left-Side Hdd
Chapter 2 — Installing Hardware Left-side HDD Remove the chassis cover. See Removing the Chassis Cover on page 12. Remove the dummy cover from the DVD-ROM bay. Note: If the DVD-ROM Combo is installed, see Replacing the DVD-ROM Combo on page 25 for instructions on removal. -
Page 22: Removing The Chassis Cover
Chapter 2 — Installing Hardware Removing the Chassis Cover Refer to the following instructions to remove the chassis cover: Loosen the two captive screws on the rear of the server. Slide the cover in the direction of the arrow and remove from the chassis. -
Page 23: Installing The Cpu
Chapter 2 — Installing Hardware Installing the CPU Refer to the following instructions to install the CPU: Remove the CPU dust cover by lifting the tab marked Remove. 2. Pull the locking lever of the CPU socket out and up as shown. Push down as demonstrated to lift the CPU bracket. - Page 24 Locate the notches on the CPU and the socket. WARNING! The QSSC-310 uses an LGA 775 socket (Zero Insertion Force socket), which is designed for trouble free insertion of the CPU. After placing the CPU into the socket, press the lever down and lock in place. If you notice any resistance when inserting the CPU, ensure that it is aligned correctly.
-
Page 25: Installing The Heatsink
Chapter 2 — Installing Hardware Installing the Heatsink Refer to the following instructions to install the heatsink: Apply thermal compound evenly on the top of the CPU. Remove the protective cover from the underside of the heatsink. Place the heatsink on top of the CPU as shown. Tighten the four retaining screws clockwise, in the order shown, to secure the heatsink. -
Page 26: Installing The Fan Duct
Chapter 2 — Installing Hardware Installing the Fan Duct Refer to the following instruction to install the fan duct: Align the fan duct between the heatsink and the fan assembly as shown. Insert fan duct as shown. Ensure that the fan duct is flush with the heatsink. -
Page 27: Installing A Pci Card
Chapter 2 — Installing Hardware Installing a PCI Card Refer to the following instructions to install a PCI card: CAUTION! VOLTAGES CAN BE PRESENT WITHIN THE SERVER WHENEVER AN AC POWER SOURCE IS CONNECTED. THIS VOLTAGE IS PRESENT EVEN WHEN THE MAIN POWER SWITCH IS IN THE OFF POSITION. - Page 28 Chapter 2 — Installing Hardware Orient the PCI card with the riser guide slot and push in the direction of the arrow until the PCI card sits in the PCI card connector. Note: Ensure that the guide slot on the right-hand side of the PCI card is correctly located.
-
Page 29: Installing Memory
Installing Memory The motherboard has four DDR2-DIMM slots for the installation of up to four memory DIMMS @ DDR2- 667/800 memory chips. Refer to QSSC-310 Mainboard Components on page 6 for the location of the memory modules. Refer to the following instructions to install memory modules: 1. -
Page 30: Supported Dimm Configuration
Chapter 2 — Installing Hardware Supported DIMM Configuration The system is designed to populate any rank on either channel, including either degenerate single channel case. DIMM and memory configurations must adhere to the following: • DDR2 667/800, un-buffered, DDR2 DIMM modules •... -
Page 31: Installing A Compact Flash Card
Chapter 2 — Installing Hardware Installing a Compact Flash Card The QSSC-310 Server incorporates a standard Compact Flash (CF) slot for use with CF cards. Note: Compact flash cards are not supported by the QSSC-310LA SKU. Refer to the following instructions to install a CF card: Ensure that the CF card is face up, with the label visible. -
Page 32: Replacing The Fan Assembly
Chapter 2 — Installing Hardware Replacing the Fan Assembly Refer to the following instructions to replace the fan assembly: 1. Remove the chassis cover. See Removing the Chassis Cover on page 12. 2. Remove the fan duct by lifting the duct clear of the chassis. 3. - Page 33 Chapter 2 — Installing Hardware 4. Remove the two securing screws from the fan assembly and lift the fans clear of the chassis. 5. Insert the replacement fan assembly into the chassis and secure with the supplied screws. 6. Reconnect the two power cables to the mainboard. 7.
-
Page 34: Replacing The Power Supply
Chapter 2 — Installing Hardware Replacing the Power Supply In case of a power supply failure, you can quickly replace the power supply unit. Refer to the following instructions to replace the power supply: Remove the chassis cover. See Removing the Chassis Cover on page 12. Disconnect the three power cables (1) from the chassis as shown. -
Page 35: Replacing The Dvd-Rom Combo
Chapter 2 — Installing Hardware Replacing the DVD-ROM Combo Refer to the following illustrations for instructions on replacing the DVD-ROM Combo unit: Note: The DVD-ROM Combo is an optional component and does not come as standard with all SKUs. Remove the chassis cover. See Removing the Chassis Cover on page 12. Remove the screw securing the DVD-ROM Combo assembly to the chassis (1), and slide the assembly back shown by the arrow (2). - Page 36 Chapter 2 — Installing Hardware Remove the screws securing the DVD-ROM Combo assembly brackets and DVD-ROM Combo PCB board from the DVD-ROM Combo drive. 5. Attach the DVD-ROM Combo assembly brackets and PCB board to the new DVD-ROM Combo drive. Replace the DVD-ROM Combo assembly into the chassis and slide the assembly in the direction of the arrow.
-
Page 37: Replacing The Chassis Cover
Chapter 2 — Installing Hardware Replacing the Chassis Cover Refer to the following instructions to replace the chassis cover: 1. Replace the cover, locating the six securing lugs in the slots on the chassis. Slide the chassis in the direc- tion of the arrow. -
Page 38: Bios
Chapter 3 Setup Menu The computer employs the latest AMI CMOS BIOS, which is stored in Flash memory. The Flash memory sup- ports the Plug and Play specification, and contains a BIOS Setup program, the Power On Self Test (POST) routine, and the PCI auto-configuration utility. -
Page 39: Configuring Special Keys
Console redirection uses ANSI terminal emulation, which is limited to basic ASCII characters. There are no func- tion keys, arrow keys, or control keys in this character set. However, the QSSC-310 BIOS software requires the use of function keys and control keys for ordinary functions. You can emulate a function key or control key by us- ing a special key sequence called an escape sequence, to represent a specific key. -
Page 40: The Legend Bar
Chapter 3 — BIOS The Legend Bar The legend bar is at the side of the Setup screen. The keys in the legend bar allow you to navigate through the various setup menus. The following table lists the keys found in the legend bar with their corresponding alternates and functions. -
Page 41: Main Menu
AMIBIOS select a field. Version: S47_2A03 Build Date: 11/09/07 Use [+] or [-] to configure system Time. Product Name: QSSC-310/QR1-1000 Board Serial Number: QTFMMI74300058 Processor Intel(R) Core(TM)2 Quad CPU Q6600 @ 2.40GHz Speed: 2400 MHz Select Screen ←→ Counter: 1 ↑↓... -
Page 42: Advanced Menu
Chapter 3 — BIOS Advanced Menu This option displays a table of items that define advanced information about your system. WARNING! Making incorrect settings to items on these pages may cause the system to mal- function. Unless you have experience adjusting these items, we recommend that you leave these settings at the default values. -
Page 43: Cpu Configuration
Chapter 3 — BIOS CPU Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Disabled for Windows XP Configure advanced CPU settings Intel(R) Core(TM)2 Quad CPU Q6600 @ 2.40GHz Frequency : 2.40 GHz FSB Speed : 1066 MHz Cache L1 : 128 KB... -
Page 44: Acpi Configuration
Chapter 3 — BIOS ACPI Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Enable RSDP pointers Advanced ACPI Configuration To 64 bit Fixed System ACPI Version Features [ACPI v2.0] Description Tables. Different ACPI version has some additions. -
Page 45: Ide Configuration
Chapter 3 — BIOS IDE Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Options IDE Configuration SATA#1 Configuration [Compatible] Disabled Configure SATA#1 as [IDE] Compatible Enhanced SATA#2 Configuration [Enhanced] ►Primary IDE Master [Not Detected] ►Primary IDE Slave [Not Detected]... -
Page 46: Third Ide Master
Chapter 3 — BIOS Third IDE Master Device: displays the type of device assigned to this channel. Vendor: displays the manufacturer’s name of the device. Size: displays the size of the device (GB). LBA Mode: indicates whether LBA access mode is supported or not supported. Block Mode: indicates whether multi sector transfer is supported. - Page 47 Chapter 3 — BIOS LBA/LARGE Mode: enables LBA access mode. • Disabled: LBA access mode is disabled • Auto: LBA is set to optimal or default mode if the device supports it and is not formatted with LBA mode disabled. Block Mode: enables multi-sector transfer block mode.
-
Page 48: Super Io Configuration
Chapter 3 — BIOS Super IO Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Allows BIOS to Select Configure Win627DHG Super IO Chipset Serial Port1 Base Serial Port1 Address [3F8/IRQ4] Addresses. Serial Port2 Address [2F8/IRQ4] Select Screen... -
Page 49: Trusted Computing
Chapter 3 — BIOS Trusted Computing Note: Trusted Computing is NOT supported by the QSSC-310LA SKU. Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Trusted Computing Enable/Disable TPM TCG (TPM 1.1/1.2) TCG/TPM SUPPORT... -
Page 50: Usb Configuration
Chapter 3 — BIOS USB Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Enables support for USB Configuration Legacy USB. AUTO Module Version – 2.24.3-13.4 Option disables Legacy support if USB Devices Enabled: no USB devices are 1 Keyboard, 1 Mouse connected. -
Page 51: Pci Configuration
Chapter 3 — BIOS PCI Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Enable or Disable PCI Configuration Onboard LANs Onboard NIC [Enabled] Onboard NIC OptionROM [Enabled] Select Screen ←→ ↑↓ Select Item Change Option General Help... -
Page 52: Mps Configuration
Chapter 3 — BIOS MPS Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Select MPS MPS Configuration Revision. MPS Revision [1.4] ←→ Select Screen Select Item ↑↓ Change Option General Help Save and Exit Exit V02.61 ©Copyright 1985-2006, American Megatrends Inc. -
Page 53: Boot Menu
Chapter 3 — BIOS Boot Menu This page enables you to set POST boot parameters. Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Main Advanced Boot Server Security Exit Boot Settings Configuration Configure Settings during System Boot. -
Page 54: Boot Device Priority
Chapter 3 — BIOS Wait For ‘F1’ If Error: enable this item to have the system prompt you to press F1 if an error occurs. This enables you to view the error. Hit ‘F2’ Message Display: enable this item to have the system prompt you to press ‘DEL’ to enter the BIOS Setup Utility Interrupt 19 Capture: Enable and disable option ROMs for INT19 Boot Device Priority... -
Page 55: Server Menu
Chapter 3 — BIOS Server Menu This page enables you to configure Server parameters. Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Main Advanced Boot Server Security Exit Server Configuration Enable/Disable the BMC LAN Interface. Status of BMC Working IPMI Specification Version... -
Page 56: Set Ast1000/2000 Lan Configuration
Chapter 3 — BIOS Set AST1000/2000 LAN Configuration These pages enable you to configure AST1000/2000 LAN parameters. Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Server Enter for IP Address LAN Configuration Configuration. Channel Number [01] Channel Number Status:... -
Page 57: Remote Access Configuration
Chapter 3 — BIOS Remote Access Configuration Select Remote Access Configuration to view the following submenu: BIOS SETUP UTILITY Server Select Remote Access Configure Remote Access Type and parameters type. Remote Access [Disabled] Select Screen ←→ Select Item ↑↓ Change Option General Help Save and Exit Exit... -
Page 58: Security Menu
Chapter 3 — BIOS Security Menu This page enables you to set the security parameters. Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Main Advanced Boot Server Security Exit Security Settings Install or Change the password. -
Page 59: Exit Menu
Chapter 3 — BIOS Exit Menu Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Main Advanced Boot Server Security Exit Exit Options Exit system setup After saving the Save Changes and Exit changes. Discard Changes and Exit Discard Changes F10 key can be used... -
Page 60: Using The Web Ui
Chapter 4 The AST1000/2000 firmware features an embedded web server, enabling users to connect to the AST1000/2000 using an Internet browser (Microsoft Internet Explorer) without needing to install KVM and Virtual Storage soft- ware on the remote console side PC. The following web browsers are supported: •... -
Page 61: System Information
Chapter 4 — Using the Web UI After passing authentication, the following web page appears. System Information The System Information tab enables you to view the Version Information, enable session time-out and interval, and view Components options. Click the System Information tab to view the following web page. Version Click the BMC version tab to view BMC information including: the device ID, Device Revision, Firmware Revi- sion, and IPMI Revision numbers. -
Page 62: Session Time-Out
Chapter 4 — Using the Web UI Click the Server Board version tab to view Server Board information including: manufacturer, date, product name, P/N, and S/N. Session Time-Out 1. Click the Session Time-Out tab. 2. Click Enable Timeout and select a timeout value from the drop-down list, as seen in following image. 3. -
Page 63: Components
Chapter 4 — Using the Web UI Components Click the Components tab to view CPU and memory information. Click the CPU tab to view the CPU model, speed, and number. Memory Click the Memory tab to view memory model, size, DIMM slot status, and slot location. -
Page 64: System Monitoring
Chapter 4 — Using the Web UI System Monitoring The System Monitoring tab enables the administrator to view data about the system, including LED, system, fan, temperature and voltage status, and event logs. You can also enable server LED blinking on the Locator Indicator page to identify a particular server. - Page 65 Chapter 4 — Using the Web UI Click the Fan tab to view CPU and SYS fan information. Temperature Click the Temperature tab to view system component temperature information. Note: Click the hyperlinks as the top of the screen to view associated information.
-
Page 66: Event Logs
Chapter 4 — Using the Web UI Voltage Click the Voltage tab to view system component voltage information. Note: Click the hyperlinks as the top of the screen to view associated information. Event Logs Click the Event Logs tab to view reports about system events. View Event Logs Click View Event Logs to view specific event information. -
Page 67: Clear Event Logs
Chapter 4 — Using the Web UI Save Event Logs 1. Click the Save Event Logs tab to view the following screen. 2. Click Save Event Logs to save the log to disk. You are prompted to save the event log text file to disk. 3. -
Page 68: Locator Indicator
Chapter 4 — Using the Web UI Locator Indicator 1. Click the Locator Indicator tab to view the following screen. 2. Click on the desired setting. • Turn system indicator LED on: set the system indicator LED on the remote server to blink. •... -
Page 69: Configuration
Chapter 4 — Using the Web UI Configuration The Configuration tab enables you to set network parameters, e-mail notification, Platform Event Filter, load and enable an SSL certificate, and to set Time options. Network 1. Click the Network tab to set network parameters. •... -
Page 70: E-Mail Notification
Chapter 4 — Using the Web UI E-mail Notification The E-mail Notification tab enables you to configure e-mail SMTP server sender and receiver details for system events notification. Click the E-mail Notification tab to display the following web page. Enter server, sender, and receiver details and click Submit. Platform Event Filter The Platform Event Filter tab allows you to modify the Trap Receiver Destination Address. -
Page 71: System Management Access
Chapter 4 — Using the Web UI System Management Access The System Management Access page enables the Administrator to generate SSL certificates and configure SNMP. SSL Certificate The SSL Certificate page enables the Administrator to generate a new CSR (Certificate Signing Request) key automatically or upload the key. - Page 72 Chapter 4 — Using the Web UI Uploading a Manually Created CSR 1. Click the Browse button next to Certificate Upload, and browse to the location of the saved key, for ex- ample Savekey.pem. 2. Click Upload to upload the key. 3.
-
Page 73: User Management
Chapter 4 — Using the Web UI User Management The User Management web page enables the administrator to change the administrative account password, and to add, modify, and delete users and set user privileges. Click the User Management tab to view the following web page. Changing the Administrative Password Follow these instructions to change the administrative password. -
Page 74: Managing Users
Chapter 4 — Using the Web UI Managing Users This section describes how to add a new user, and set user privileges. Adding a User 1. Click Add User. The following screen appears. 2. Type the Username in the text box. 3. -
Page 75: Ads Configuration
Chapter 4 — Using the Web UI ADS Configuration The ADS Configuration web page enables the administrator to configure an Active Directory Server (ADS). ADS Configuration requires a Domain Name Server (DNS), an Active Directory Server (ADS), a Certificate Au- thority Server (CAS), and an AD certificate. -
Page 76: Remote Control
Chapter 4 — Using the Web UI Remote Control Note: Remote Control is NOT supported by the QSSC-310LA SKU. By using the included Java client, users have access to robust remote control features. Note: Refer to the next chapter for more information on remote control features. - Page 77 Chapter 4 — Using the Web UI 3. Click Close and then right-click the Information Bar to open the following screen. 4. Click Download File. The following screen appears. 5. Click Run. Note: You may see several security screens during installation of the remote application. On each screen, click Yes to continue.
-
Page 78: Remote Power Control
Chapter 4 — Using the Web UI Using the Java Remote KVM The Java Remote KVM interface has several buttons that provide different functionality. • Video Quality: Enables you to select the video quality: low, medium, or high. High: Fewest video loss and biggest size image transmitted. Normal: Few video loss and big size image transmitted. -
Page 79: Hotkey Setup
Chapter 4 — Using the Web UI Hotkey Setup This page enables the administrator to create user profiles that include control modes, KVM settings, hot key set- tings, and storage settings. These settings are loaded after the Java Remote KVM is launched. Click the Hotkey Setup tab to view the following web page. -
Page 80: Maintenance
Chapter 4 — Using the Web UI Maintenance The Maintenance web page enables you to upgrade the firmware and reset the BMC. Firmware Upgrade Use the Firmware Update feature to upgrade to the latest firmware version. See BMC Firmware Update Utility on page 87 for more information on upgrading firmware. -
Page 81: Using The Client
Note: The KVM over IP feature described in this chapter is NOT supported by the QSSC-310LA SKU. KVM stands for Keyboard, Video, and Mouse. KVM over IP redirects server video screen, keyboard, and mouse data to or from a remote console PC via a network, so that the administrator can monitor the server and control keyboard and mouse to operate the server remotely. -
Page 82: Usb Keyboard And Mouse Emulation
Chapter 5 — Using the Client USB Keyboard and Mouse Emulation Once the AST2000 KVM over IP function is launched, AST2000 emulates USB 1.1 keyboard and mouse devices. As a result, the managed server’s BIOS or OS will detect the USB keyboard and mouse attached, and load their drivers to service them. -
Page 83: Mouse Synchronization At Console Side
Chapter 5 — Using the Client Mouse Synchronization at Console Side When the Java remote KVM application is launched on the console PC, the mouse position of the remote server and the console are automatically synchronized. However, once the managed server’s mouse is moved locally, the console PC mouse position will be different from the redirected managed server mouse. -
Page 84: Hide Console Side Mouse
Chapter 5 — Using the Client Hide Console Side Mouse You can hide or show the console side (local) mouse by clicking the Local Cursor button on the toolbar or by clicking Control on the main menu and selecting Local Cursor. Hardware Cursor Mode AST2000 provides the means to separate mouse data from video data and send the cursor position directly to the console side after positional updates or icon changes. -
Page 85: Hot-Key Simulation
Chapter 5 — Using the Client Hot-Key Simulation Since Windows or other application programs have priority in using hot-keys before the remote server, (for exam- ple Ctrl-Alt-Del), the Java remote KVM ignores these keys and does not send them. However, you can assign hotkeys in the Java remote KVM application (see Hotkey Setup on page 69) and these hotkeys are available on the menu-bar where user can select hot keys to send to AST2000 and the managed server directly, instead of pressing keys. -
Page 86: Full Screen Display On Console Pc
Chapter 5 — Using the Client Full Screen Display on Console PC The Java Remote KVM enables you to display the redirected video image in full screen as seen at the local side server in place of the window at the remote server side. To display full screen: Click Control on the main menu bar. -
Page 87: Dynamic Scaling Video Resolution
Chapter 5 — Using the Client Dynamic Scaling Video Resolution From managed server power on to entering the Operating System, the video output resolution changes frequently. The AST2000 detects these changes and adjusts the display window automatically. In addition, user can adjust the display window to the size required by clicking and dragging the bottom right-hand corner of the inner window. -
Page 88: Encryption Mode
Through the USB storage emulation functions of the AST2000, users can install an operating system, device driv- ers or application software from the convenience of a remote side. Mounting a Device This section describes how to set up virtual storage for the QSSC-310. Follow these instructions to configure a storage device. Click Storage | Mount Device. -
Page 89: Supported Devices
Chapter 5 — Using the Client The following screen appears. Select the storage device or ISO image from the drop down list. When a storage device is mounted, the status bar displays an icon: If you select ISO-Image, you will be prompted to Mounted browse to the location of the ISO file. -
Page 90: Usb Dvd Emulation
Chapter 5 — Using the Client USB DVD Emulation When DVD Emulation function is enabled, the managed server finds a USB DVD drive. As shown in the image below the user puts a target DVD disk into the remote console PC DVD drive. While managed server access this virtual attached USB DVD, AST2000 will redirect to the DVD in console PC and Java Remote KVM will access the target DVD disk instead. -
Page 91: Usb Cd-Rom Emulation
Chapter 5 — Using the Client The below table describes the floppy LED status description. Legacy Floppy As disk inside (LED As No Disk inside (LED behavior status) status) Blinking (On: 3.5 sec, Off: Mount Begin Light On about 1.5 min 2.5 sec) Blinking (On: 3.5 sec, Off: Ready... -
Page 92: Multidevice Configuration
Chapter 5 — Using the Client Multidevice Configuration Use the procedure below to configure OS specific managed devices on the server. Redhat AS4.0 You are required to rebuild the initial ramdisk. /etc/modprobe.conf add the following line: options scsi_mod max_luns=xxx (whereas xxx is the number of LUNs to support) 2. -
Page 93: Virtual Storage Configuration (Linux Kernel 2.4)
Chapter 5 — Using the Client Virtual Storage Configuration (Linux Kernel 2.4) Use the procedure below to configure your OS (Linux kernel 2.4) on your local computer. After configuring the system, mount a local IDE CD/DVD ROM to the remote server. Redhat AS3.0 (Linux kernel 2.4.x) Using LILO /etc/lilo.conf... -
Page 94: Support
Appendix A Before You Begin CAUTION! BEFORE REMOVING THE SERVER COVER, DISCONNECT ALL POWER. UN- PLUG THE AC POWER CORD; DISCONNECT ALL PERIPHERALS, AND ALL LAN LINES. Make sure you have a stable, clean working environment. Dust and dirt can get into computer components and cause a malfunction. -
Page 95: Installing The Rack Brackets
Appendix A — Support Installing the Rack Brackets When the server is to be installed into a rack, it is necessary to install two rack mount brackets onto the server chassis prior to installing the server into the rack. Follow the procedures below to install the rack mount brackets onto the server. -
Page 96: Troubleshooting Sequence
Appendix A — Support Troubleshooting Sequence Installation Problems Perform the following checks if you are troubleshooting an installation problem: Check all cable and power connections (including all rack cable connections). Unplug the power cord, and wait one minute. Then reconnect the power cord and try again. If the network is reporting an error, see if the server has enough memory and disk space available. -
Page 97: Updating The Bmc Firmware
Appendix B BMC Firmware Update Utility The BMC (Baseboard Management Controller) firmware update utility is a DOS-based program used to update the BMC firmware code. This utility should only be run if new firmware code is necessary. BMC Firmware Update Procedure Before proceeding, read the BMC firmware release notes to determine which update utility version is appropriate for the new firmware version. -
Page 98: Appendix C
Broadcom 5715C - PCI Express X4 X8 speed • NEC uPD720404 - PCI Express X1 QSSC-310DS SKU: One PCI-E X8 slot + • LSI 1064E SAS controller - PCI Express X4 One PCI-E X4 slot with X1 speed + LSI... -
Page 99: Specifications
On board AST1000 on QSSC-310LA Main Logic Board Sensors: Controller SKU: VGA, BMC. • Voltage Power Good Detection On board AST2000 on QSSC-310DA/ • CPU and System Temperature Detection. QSSC-310FA/QSSC-310DS SKUs: VGA, • FAN Speed Detection BMC, KVM Over IP •...
