This gas grill must be used only outdoors in a well-ventilated space and must not be used inside a
building, garage, screened-in porch, gazebo or any other enclosed area.
DANGER
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open lid.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Notice to Installer: Leave these instructions with the grill owner for future reference.
Fax: (705)725-2564 email: wecare@napoleonproducts.com web site: www.napoleongrills.com
Napoleon Appliance Corp.,
214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: (705)726-4278
Serial No.
XXXXXX000000
MODEL NO.
PRESTIGE 450
WARNING
Do not try to light this appliance without
reading the "LIGHTING" instructions section of
this manual.
Do not store or use gasoline or other flammable
liquids or vapors in the vicinity of this or any
other appliance. An L.P. cylinder not connected
for use must not be stored in the vicinity of
this or any other appliance. If the information
in these instructions is not followed exactly, a
fire or explosion may result, causing property
damage, personal injury or death.
APPLY SERIAL NUMBER LABEL FROM CARTON
N415-0234 APR 21/11
Advertisement
Table of Contents
Related Manuals for Napoleon PRESTIGE 450
Summary of Contents for Napoleon PRESTIGE 450
- Page 1 APPLY SERIAL NUMBER LABEL FROM CARTON Serial No. XXXXXX000000 MODEL NO. PRESTIGE 450 WARNING DANGER Do not try to light this appliance without reading the “LIGHTING” instructions section of IF YOU SMELL GAS: this manual.
- Page 2 NAPOLEON will not be responsible for the installation, labor or any other costs or expenses related to the re-installation of a warranted part, and such expenses are not covered by this warranty.
- Page 3 WARNING! Failure to follow these instructions could result in property damage, personal injury or death. Read and follow all warnings and instructions in this manual prior to operating grill. Safe Operating Practices • This gas grill must be assembled exactly according to the instructions in the manual. If the grill was store assembled, you must review the assembly instructions to confirm correct assembly and perform the required leak tests before operating the grill.
-
Page 4: General Information
General Information This Gas Barbecue Is Certified Under Canadian And American National Standards, CSA 1.6-2007 and ANSI Z21.58-2007 respectively for Outdoor Gas Grills and should be installed to conform with local codes. In absence of local codes, install to the current CAN/CSA-B149.1 Propane Installation Code in Canada or to the National Fuel Gas Code, ANSI Z223.1 in the United States. -
Page 5: Leak Testing Instructions
Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer. -
Page 6: Lighting Instructions
Lighting Instructions Lighting Hole Right Burner Left Burner Centre Burner Rear Burner Igniter WARNING! Open lid Off Position WARNING! Ensure all burner controls are in the off position. Slowly turn on the gas supply valve. Main Tube Burner Rear Burner Lighting Main Infrared Side Burner Lighting Lighting... -
Page 7: Cooking Instructions
Should a flare-up occur, move food away from the flames and reduce the heat. Leave the lid open. See Your All Season Grill cookbook by Napoleon for more detailed instructions. Direct Cooking: Place food to be cooked on the grill directly over the heat. This method is generally used for searing or for foods that do not require prolonged cooking times such as hamburgers, steaks, chicken pieces, or vegetables. - Page 8 Any juices or oils that escape from the food drip onto the charcoal and vaporize into smoke giving the food its delicious grilled taste. The Napoleon infrared burner cooks in the same way. In each burner, 10,000 ports – each with its own tiny flame – cause the surface of the ceramic tile to glow red. This glow emits the same type of infrared heat to the food as charcoal, without its hassle or mess.
- Page 9 To add an exotic taste to your meat, High setting 3 min. each side. 6 min. – Well done try adding hickory-flavored woodchips to Napoleon’s woodchip smoker. Chicken pieces High setting 2 min. each side. 20-25 min. The joint connecting the...
-
Page 10: Cleaning Instructions
To clean the panel, use only warm soapy water or stainless steel cleaner available from your Napoleon dealer. Never apply abrasive cleaners on any stainless surfaces, especially the printed portion of the control panel or the printing will gradually rub off. -
Page 11: Maintenance Instructions
Cleaning The Outer Grill Surface: Do not use abrasive cleaners or steel wool on any painted, porcelain or stainless steel parts of your Napoleon Grill. Doing so will scratch the finish. Exterior grill surfaces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner. -
Page 12: Troubleshooting
WARNING! Hose: Check for abrasions, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the gas grill. Have the part replaced by your Napoleon Gas Grill dealer or qualified gas installer. Aluminum Castings: Clean castings periodically with warm soapy water. Aluminum will not rust, but high temperatures and weathering can cause oxidation to occur on aluminum surfaces. - Page 13 Cracked ceramic tile. Allow burner to cool and inspect very closely for cracks. If any cracks are found, contact your authorized Napoleon dealer to order a replacement burner assembly. Leaking gasket surrounding the ceramic Contact your authorized Napoleon dealer for...
-
Page 14: Ordering Replacement Parts
KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE YOUR WARRANTY. Ordering Replacement Parts Warranty Information MODEL: DATE OF PURCHASE: SERIAL NUMBER: (Record information here for easy reference) Before contacting the Customer Care Department, check the NAC Website for more extensive cleaning, maintenance, troubleshooting and parts replacement instructions at www.napoleongrills.com. -
Page 15: Getting Started
CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly. - Page 16 2 X N570-0086 (#14 x 1/2”) 3/8”(10mm) If necessary the center panel can be tapped down with a rubber mallet. Si nécessaire, le panneau central peut être enfoncé avec un maillet en caoutchouc. 4 X N570-0086 (#14 X1/2”) 3/8”(10mm) www.napoleongrills.com...
- Page 17 4 x N570-0086 (#14 x 1/2”) 3/8”(10mm) If necessary the cross beam can be tapped down with a rubber mallet. Si nécessaire, le barre de traverse peut être enfoncé avec un maillet en caoutchouc. 4 x N570-0086 (#14 x 1/2”) 3/8”(10mm) Propane Only Propane Seulement...
- Page 18 4 x N570-0086 (#14 x 1/2”) 3/8”(10mm) Two people are required for this step. Deux personnnes son nécessaires pour cette étappe. www.napoleongrills.com...
- Page 19 2 x N570-0086 (#14 x 1/2”) 3/8”(10mm) Propane Only Propane Seulement disposable grease tray jetable du récipient à graisse www.napoleongrills.com...
- Page 20 2 x N570-0086 (#14 x 1/2”) 3/8”(10mm) 2 x N120-0010 www.napoleongrills.com...
- Page 21 4 x N570-0029 (1/4-20 x 3/8”) 3/8”(10mm) 4 x N735-0002(1/4 lock washer) If necessary the doors can be adjusted by sliding the leveling brackets. Si nécessaire, les portes peuvent être ajustées en glissant les sup- ports de mise à niveau. www.napoleongrills.com...
- Page 22 450RB 10 x N570-0076 (#8 X1/2”) 3/8”(10mm) 4 x N570-0086 (#14 X1/2”) 450RSIB 4 x N570-0086 (#14 X1/2”) WARNING! The Infrared side burner is supplied with a drip pan which holds only a minimal amount of grease. To prevent grease fires, the pan must be cleaned after each use.
- Page 23 450RSIB 2 x N715-0093 Cooking Grid Placement: The cooking grid can be placed at two different heights. The lower height is for use with pots or pans. The higher position is to be used when searing meats. Ensure the burner is off and the grid is cool to the touch before changing between the two heights.
- Page 24 N305-0021 N305-0022 Ensure holes in sear plates are positioned to the front of the grill. Assurez-vous que les trous dans les plaques de brûleur soient placés à l’avant du gril. N520-0029 N305-0067 450RSIB N305-0026 www.napoleongrills.com...
- Page 25 Rotisserie Kit Assembly Instruction (included with most rear burner units) Assemble rotisserie kit components as shown. Instructions D’assemblage De L’ensemble De Rôtissoire (inclus avec la plupart des appareils avec brûleur arrière) Assemblez les composantes de la rôtissoire tel qu’illustré. Ensure stop bushing is tightened on the inside of hood casting.
- Page 26 Propane Only – Proper Hose Connection Propane Seulement - Branchement Adéquat Du Boyau WARNING! Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire. AVERTISSEMENT! Assurez-vous que le boyau ne touche à aucune surface à haute température sinon il risque de fondre, de provoquer une fuite et causer un feu.
- Page 27 Natural Gas Only – Proper Hose Connection Gaz Naturel Seulement - Branchement Adéquat Du Boyau WARNING! The installation must be performed by a licensed gas fitter, and all connections must be leak tested before operating the grill. AVERTISSEMENT! L’installation doit être effectuée par un installateur certifié pour le gaz et tous les raccordements doivent être testés pour des fuites avant de faire fonctionner le gril.
- Page 28 WARNING – FIRE HAZARD ATTENTION - RISQUE D’INCENDIE WARNING! Do not route hose underneath drip pan. AVERTISSEMENT! Ne pas passer le tuyau d’alimentation sous le tiroir d’égouttement afin de garder. WARNING! Supply hose must be routed through rear panel only. Do not route hose through left side panel and underneath drip pan.
- Page 29 Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.
- Page 30 N/RB UNITS RB UNITS n135-0040g left side lid casting / moulage gauche du couvercle n385-0129 NAPOLEON logo/ logo NAPOLEON w450-0005 logo spring clips / écrous à réssort pour logo n510-0002 black silicone lid bumper / pare-chocs du couvercle (silicone noir)
- Page 31 P450/P450RB Parts List / Liste Des Pièces ITEM PART # DESCRIPTION N/RB UNITS RB UNITS n530-0014 1-outlet regulator / tuyau de régulateur à 1 sortie n345-0001 10ft n/g hose w/quick disconnect / tuyau de 10 pieds avec débranchement rapide n010-0305l manifold assembly / ensemble du collecteur n010-0306l manifold assembly / ensemble du collecteur...
- Page 32 P450/P450RB PARTS DIAGRAM / DIAGRAMME DE PIÈCES www.napoleongrills.com...
- Page 33 DESCRIPTION RSIB UNITS n135-0040g left side lid casting / moulage gauche du couvercle n385-0129 NAPOLEON logo/ logo NAPOLEON w450-0005 logo spring clips / écrous à réssort pour logo n510-0002 black silicone lid bumper / pare-chocs du couvercle (silicone noir) n335-0059...
- Page 34 P450RSIB Parts List / Liste Des Pièces ITEM PART # DESCRIPTION RSIB UNITS n010-0219l manifold assembly / ensemble du collecteur n051-0007 control knob bezel / monture de bouton de commande n357-0014 electronic ignition - 2 spark / allumeur électronique - 2 étincelles n475-0273g left/right cart enclosure panel / panneau pour chariot gauche/droite n570-0086...
- Page 35 P450RSIB Parts List / Liste Des Pièces ITEM PART # DESCRIPTION RSIB UNITS n010-0216 rear burner orifice assembly / ensemble des orifices brûleur arrière n010-0217 rear burner orifice assembly / ensemble des orifices brûleur arrière n240-0001 rear burner electrode / électrode du brûleur arrière n240-0016 main burner electrode / électrode du brûleur principal n350-0054...
- Page 36 P450RSIB PARTS DIAGRAM / DIAGRAMME DE PIÈCES www.napoleongrills.com...
- Page 37 FAX TO: 705 727 4282 ACCESSORIES & PARTS ORDER FORM PLEASE PRINT CLEARLY CONTACT NAME:______________________________________________________________________ SHIP TO :_____________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ TEL :_________________________________ FAX :______________________________ EMAIL: __________________________________________________________________ VISA OR MASTERCARD # :_______________________________________ EXPIRY DATE: _____________ SIGNATURE:_____________________________________________________________________________ QUANTITY PART NUMBER DESCRIPTION TAXES MAY APPLY SHIPPING EXTRA IF CONFIRMATION IS REQUIRED PLEASE INCLUDE A FAX NUMBER OR EMAIL ADDRESS...
- Page 38 NOTES www.napoleongrills.com...
- Page 39 NOTES www.napoleongrills.com...
- Page 41 www.napoleongrills.com...
