Napoleon PRESTIGE 450 Instruction Manual

Hide thumbs Also See for PRESTIGE 450:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , Instruction Manual
This gas grill must be used only outdoors in a well-ventilated space and must not be used inside a
building, garage, screened-in porch, gazebo or any other enclosed area.
DANGER
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open lid.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Notice to Installer: Leave these instructions with the grill owner for future reference.
Fax: (705)725-2564 email: wecare@napoleonproducts.com web site: www.napoleongrills.com
Napoleon Appliance Corp.,
214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: (705)726-4278
Serial No.
XXXXXX000000
MODEL NO.
PRESTIGE 450
WARNING
Do not try to light this appliance without
reading the "LIGHTING" instructions section of
this manual.
Do not store or use gasoline or other flammable
liquids or vapors in the vicinity of this or any
other appliance. An L.P. cylinder not connected
for use must not be stored in the vicinity of
this or any other appliance. If the information
in these instructions is not followed exactly, a
fire or explosion may result, causing property
damage, personal injury or death.
APPLY SERIAL NUMBER LABEL FROM CARTON
N415-0234CE APR 20/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRESTIGE 450 and is the answer not in the manual?

Questions and answers

Related Manuals for Napoleon PRESTIGE 450

Summary of Contents for Napoleon PRESTIGE 450

  • Page 1 APPLY SERIAL NUMBER LABEL FROM CARTON Serial No. XXXXXX000000 MODEL NO. PRESTIGE 450 WARNING DANGER Do not try to light this appliance without IF YOU SMELL GAS: reading the “LIGHTING” instructions section of this manual.

  • Page 2: Conditions And Limitations

    NAPOLEON will not be responsible for the installation, labor or any other costs or expenses related to the re-installation of a warranted part, and such expenses are not covered by this warranty.

  • Page 3: Safe Operating Practices

    WARNING! Failure to follow these instructions could result in property damage, personal injury or death. Read and follow all warnings and instructions in this manual prior to operating grill. Safe Operating Practices • This gas grill must be assembled exactly according to the instructions in the manual. If the grill was store assembled, you must review the assembly instructions to confirm correct assembly and perform the required leak tests before operating the grill.

  • Page 4: Gas Cylinder

    Gas Cylinder Use only gas cylinders, which meet national and regional codes. The minimum cylinder size for butane units is 13kg, and for propane units is 6kg. Ensure that the cylinder can provide enough fuel to operate the appliance. If in doubt, check with your local gas supplier. •...

  • Page 5: Leak Testing Instructions

    Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.

  • Page 6: Lighting Instructions

    Lighting Instructions Rear Burner Lighting Hole Igniter Left Burner Centre Burner Right Burner Off Position WARNING! Open lid WARNING! Ensure all burner controls are in the off position. Slowly turn on the gas supply valve. Main Tube Burner Rear Burner Lighting Main Infrared Burner Side Burner Lighting Lighting...

  • Page 7: Cooking Instructions

    Should a flare-up occur, move food away from the flames and reduce the heat. Leave the lid open. See Your All Season Grill cookbook by Napoleon for more detailed instructions. Direct Cooking: Place food to be cooked on the grill directly over the heat. This method is generally used for searing or for foods that do not require prolonged cooking times such as hamburgers, steaks, chicken pieces, or vegetables.
  • Page 8 Any juices or oils that escape from the food drip onto the charcoal and vaporize into smoke giving the food its delicious grilled taste. The Napoleon infrared burner cooks in the same way. In each burner, 10,000 ports – each with its own tiny flame – cause the surface of the ceramic tile to glow red. This glow emits the same type of infrared heat to the food as charcoal, without its hassle or mess.
  • Page 9 To add an exotic taste to your meat, High setting 3 min. each side. 6 min. – Well done try adding hickory-flavored woodchips to Napoleon’s woodchip smoker. Chicken pieces High setting 2 min. each side. 20-25 min. The joint connecting the...

  • Page 10: Cleaning Instructions

    Cleaning The Outer Grill Surface: Do not use abrasive cleaners or steel wool on any painted, porcelain or stainless steel parts of your Napoleon Grill. Doing so will scratch the finish. Exterior grill surfaces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner.

  • Page 11: Maintenance Instructions

    WARNING! Hose: Check for abrasions, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the gas grill. Have the part replaced by your Napoleon Gas Grill dealer or qualified gas installer. Aluminum Castings: Clean castings periodically with warm soapy water. Aluminum will not rust, but high temperatures and weathering can cause oxidation to occur on aluminum surfaces.

  • Page 12: Troubleshooting

    i) Never throw water into the grill to control flare-ups. ii) Do not attempt to operate the infrared burners in open air while raining. iii) If you find standing water in your grill (because of exposure to rainfall, sprinklers, etc.), inspect the ceramic for evidence of possible watersoaking.
  • Page 13 Cracked ceramic tile. Allow burner to cool and inspect very closely for cracks. If any cracks are found, contact your authorized Napoleon dealer to order a replacement burner assembly. Leaking gasket surrounding Contact your authorized Napoleon dealer for...

  • Page 14: Ordering Replacement Parts

    KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE YOUR WARRANTY. Ordering Replacement Parts Warranty Information MODEL: DATE OF PURCHASE: SERIAL NUMBER: (Record information here for easy reference) Before contacting the Customer Care Department, check the NAC Website for more extensive cleaning, maintenance, troubleshooting and parts replacement instructions at www.napoleongrills.com.

  • Page 15: Getting Started

    CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly.
  • Page 16 2 X N570-0086 (#14 x 1/2”) 3/8”(10mm) If necessary the center panel can be tapped down with a rubber mallet. Si nécessaire, le panneau central peut être enfoncé avec un maillet en caoutchouc. Het middelste paneel kan indien nodig met een rubberen hamer worden ingeslagen.
  • Page 17 4 x N570-0086 (#14 x 1/2”) 3/8”(10mm) If necessary the cross beam can be tapped down with a rubber mallet. Si nécessaire, le barre de traverse peut être enfoncé avec un maillet en caoutchouc. Het dwarsbalk kan indien nodig met een rubberen hamer worden ingeslagen.
  • Page 18 4 x N570-0086 (#14 x 1/2”) 3/8”(10mm) Two people are required for this step. Deux personnnes son nécessaires pour cette étappe. Voor deze stap zijn twee mensen nodig. Für diesen schritt Sind zwei personen erforderlich. Per questa operazione sono richieste due persone.
  • Page 19 2 x N570-0086 (#14 x 1/2”) 3/8”(10mm) disposable grease tray jetable du récipient à graisse wegwerp afdruipbakje Fett-Auffangbehälter (Einweg) vassoio raccolta dei grassi, a perdere ”Rasvakuppi joka asetetaan rasvapellin alle (poisheitettävä).” www.napoleongrills.com...
  • Page 20 3/8”(10mm) 2 x N570-0086 (#14 x 1/2”) 2 x N120-0010 www.napoleongrills.com...
  • Page 21 4 x N570-0029 (1/4-20 x 3/8”) 3/8”(10mm) 4 x N735-0002(1/4 lock washer) If necessary the doors can be adjusted by sliding the leveling brackets. Si nécessaire, les portes peuvent être ajustées en glissant les supports de mise à niveau. Indien nodig kunnen de deuren worden bijgesteld door de console te verschuiven. Die Tür durch Verschieben der Ausgleichswinkel ausrichten, falls notwendig.
  • Page 22 450RB 10 x N570-0076 (#8 X1/2”) 3/8”(10mm) 4 x N570-0086 (#14 X1/2”) 450SB/450RSIB 4 x N570-0086 (#14 X1/2”) WARNING! The Infrared side burner is supplied with a drip pan which holds only a minimal amount of grease. To prevent grease fires, the pan must be cleaned after each use. AVERTISSEMENT! Le brûleur latéral infrarouge est muni d’un plateau d’égouttement qui ne peut contenir qu’une petite quantité...
  • Page 23 450RSIB 2 x N715-0093 Cooking Grid Placement: The cooking grid can be placed at two different heights. The lower height is for use with pots or pans. The higher position is to be used when searing meats. Ensure the burner is off and the grid is cool to the touch before changing between the two heights.
  • Page 24 Twist tab to lock in place. Tournez la patte pour verrouiller. Draai de haak om hem op zijn plaats te bevestigen Lasche drehen, um sie zu verriegeln. Per bloccare, girare l’aletta. Tuerza la lengüeta para bloquearla. ”Väännä tappia jotta se lukittuisi paikoilleen.”...
  • Page 25 N305-0021 N305-0022 Ensure holes in sear plates are positioned to the front of the grill. Assurez-vous que les trous dans les plaques de brûleur soient placés à l’avant du gril. Zorg dat de gaten in de schroeiplaten zich aan de voorkant van de gril bevinden. Sicherstellen, dass sich die Glühplatten an der Vorderseite des Grills befinden.
  • Page 26 Rotisserie Kit Assembly Instruction (included with most rear burner units) Assemble rotisserie kit components as shown. Instructions D’assemblage De L’ensemble De Rôtissoire (inclus avec la plupart des appareils avec brûleur arrière) Assemblez les composantes de la rôtissoire tel qu’illustré. Monteerinstructies voor de Roterende Braadkit (inclusief de meeste achterbranders) Monteer de componenten van de roterende braadkit zoals weergegeven.
  • Page 27 Proper Hose Connection Branchement Adéquat Du Boyau Juiste Slang Verbinding Ordnungsgemäßer Schlauchanschluss Collegamento Corretto Del Tubo Conexión correcta del conector flexible Oikein tehty letkun kiinnitys WARNING! The installation must be performed by a licensed gas fitter, and all connections must be leak tested before operating the grill.
  • Page 28 WARNING! Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire. AVERTISSEMENT! Assurez-vous que le boyau ne touche à aucune surface à haute température sinon il risque de fondre, de provoquer une fuite et causer un feu. WAARSCHUWING! Zorg ervoor dat de spuitslang geen contact heeft met hete oppervlaktes, want de slang kan smelten, een lekkage veroorzaken met brandgevaar als gevolg.
  • Page 29 Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.
  • Page 30 PART # DESCRIPTION n135-0040g left side lid casting / moulage gauche du couvercle n385-0129 NAPOLEON logo/ logo NAPOLEON w450-0005 logo spring clips / écrous à réssort pour logo n510-0002 black silicone lid bumper / pare-chocs du couvercle (silicone noir) n335-0059...
  • Page 31 Parts List / Liste Des Pièces ITEM PART # DESCRIPTION n010-0305l manifold assembly / ensemble du collecteur n455-0013 main burner orifice (30 mbar) / bec d’orifice brûleur principal (30 mbar) n455-0023 main burner orifice (50 mbar) / bec d’orifice brûleur principal (50 mbar) n051-0007 control knob bezel n357-0013...
  • Page 32 www.napoleongrills.com...
  • Page 33 PART # DESCRIPTION RSIB n135-0040g left side lid casting / moulage gauche du couvercle n385-0129 NAPOLEON logo/ logo NAPOLEON w450-0005 logo spring clips / écrous à réssort pour logo n510-0002 black silicone lid bumper / pare-chocs du couvercle (silicone noir) n335-0059...
  • Page 34 Parts List / Liste Des Pièces ITEM PART # DESCRIPTION RSIB n010-0218l manifold assembly / ensemble du collecteur n455-0013 main burner orifice (30 mbar) / bec d'orifice brûleur principal (30 mbar) n455-0023 main burner orifice (50 mbar) / bec d'orifice brûleur principal (50 mbar) n051-0007 control knob bezel / monture de bouton de commande n357-0014...
  • Page 35 Parts List / Liste Des Pièces ITEM PART # DESCRIPTION RSIB n485-0009 push pin / clavette à pression n345-0011 hose, side burner / tuyau brûleur latérale n240-0001 rear burner electrode / électrode du brûleur arrière n240-0016 main burner electrode / électrode du brûleur principal n350-0054 collector box - main burner / boîte du collecteur du brûleur principal n020-0130...
  • Page 36 www.napoleongrills.com...
  • Page 37 FAX TO: 705 727 4282 ACCESSORIES & PARTS ORDER FORM PLEASE PRINT CLEARLY CONTACT NAME:______________________________________________________________________ SHIP TO :_____________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ TEL :_________________________________ FAX :______________________________ EMAIL: __________________________________________________________________ VISA OR MASTERCARD # :_______________________________________ EXPIRY DATE: _____________ SIGNATURE:_____________________________________________________________________________ QUANTITY PART NUMBER DESCRIPTION TAXES MAY APPLY SHIPPING EXTRA IF CONFIRMATION IS REQUIRED PLEASE INCLUDE A FAX NUMBER OR EMAIL ADDRESS...
  • Page 38 NOTES www.napoleongrills.com...
  • Page 39 NOTES www.napoleongrills.com...
  • Page 40 NOTES www.napoleongrills.com...
  • Page 42 www.napoleongrills.com...
