CA-SERIES
OPERATION MANUAL
COLD WATER DIRECT DRIVEN

PRESSURE WASHER

CAUTION
RISK OF INJURY!
READ MANUAL BEFORE OPERATING!
This manual is an important part of the pressure washer and must remain with this unit!
CA-Series Operator's Manual
©
Copyright 2006, Mi-T-M
®
Corporation
Form #37-088-E/S-2709


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CA-SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mi-T-M CA-SERIES

  • Page 1: Pressure Washer

    COLD WATER DIRECT DRIVEN PRESSURE WASHER CAUTION RISK OF INJURY! READ MANUAL BEFORE OPERATING! This manual is an important part of the pressure washer and must remain with this unit! CA-Series Operator’s Manual © Copyright 2006, Mi-T-M ® Corporation Form #37-088-E/S-2709...
  • Page 2: Table Of Contents

    START-UP ......................4 CLEANING wITH DETERGENTS (OPTION Aw-8400-002) ......5 SHUTDOwN ....................... 5 storage & maintenance ..................16-17 SPECIFIC MAINTENANCE ................6 wINTERIZING ..................... 7 troublesHooting ..................... 18 accessories ....................... 19 statement of warranty ..................20 notes ..........................21 CA-Series Operator’s Manual...
  • Page 3: Introduction

    Inspect for signs of obvious or concealed freight damage. If something appears to be damaged, file a claim with the transportation company immediately. Be sure that all damaged parts are replaced and that the mechanical problems are corrected prior to operation of the unit. If you require service, contact a Mi-T-M Customer Service Representative at 800-553-9053.
  • Page 4: Important Safety Warnings

    The arrester must be maintained in effective working order by the operator. See your engine or equipment dealer for spark arrester muffler options. CA-Series Operator’s Manual...
  • Page 5: Spray Precautions

    8. Even after you shut off the unit, there is high pressure water left in the pump, hose and gun until you release it by triggering the gun. Before removing the spray nozzle or servicing the unit, ALwAYS shut off the unit and trigger the gun to release trapped pressure. CA-Series Operator’s Manual...
  • Page 6: Detergent Cleaning Precautions

    2. KNOW YOUR DETERGENTS! Be prepared to tell a physician exactly what you are using in the event of an emergency. Read the Material Safety Data Sheet (MSDS) provided with your Mi-T-M Detergent and all detergent labels. Follow all appropriate instructions regarding preparation use, safety and transportation.
  • Page 7: Adjustment Precautions

    . NEVER alter or modify the equipment, be sure any accessory items and system components being used will withstand the pressure developed. Use ONLY genuine Mi-T-M parts for repair of your pressure washer. Failure to do so can cause hazardous operating conditions and will void warranty.
  • Page 8: Features Drawing

    . Engine 7. water Inlet 2. Adjustable Unloader Knob 8. Thermal Relief Valve 3. Oil Sight Glass 9. High Pressure Discharge Hose 4. Pump 0. Gun Assembly 5. Vibration Isolation Plate . Quick Connect Nozzle 6. water Outlet CA-Series Operator’s Manual...
  • Page 9: Safety Decals

    •DESPUES DE DETENER EL MOTOR. CIERRE DIEMPRE EL SUMINSTRO •PROTEJA LA BOMBA DE LA CONGELACION. DEL AGUA AND APRIETE EL GATILLO PARA LIBERAR LA PRESION ADECUADA. •COLOQUE EL SUGURO DEL GATILLO EN LA POSICION APAGADO ATRAPADA. CUANDO NO ESTE USANDO EL PRODUCTO. 34-1244-E/S-021401-ENG. CA-Series Operator’s Manual...
  • Page 10: Installation & Preparation

    5. Once properly installed, check the oil sight glass on the pump crankcase. Make certain the oil level is in the center of the sight glass before each use. risK of aspHyXiation! If the level appears low, use Mi-T-M pump oil #Aw-4085-006. DO NOT -do not operate in an OVERFILL! enclosed area.
  • Page 11: Nozzle Review

    2. The nozzle assembly should be disconnected from the gun/wand assembly at this by retracting the locking ring on the quick-connect fitting to remove risK of severe injury! tHe trigger gun sHould the nozzle. always be locKed in tHe off position wHen not in use! QUICK-CONNECT FITTING CA-Series Operator’s Manual...
  • Page 12: Water Supply

    Using a screw driver, remove the screen from the water inlet. b. Clean or replace with Mi-T-M #9-000 if necessary. 3. Connect the hoses: a. Connect one end of the water supply hose to the water inlet of the unit.
  • Page 13: Pre-Start Inspection Procedures

    Have read and understood all safety precautions and instructions listed in tHis manual. incorrect operation of tHis unit can cause serious injury!! do not alter or modify tHis equipment in any manner! CA-Series Operator’s Manual...
  • Page 14: Operating Instructions

    10. Because your pressure washer delivers a high pressure spray and a variety of spray patterns, there are many cleaning jobs that can be done without the use of detergents. If a cleaning agent is required, see “Cleaning with Detergents” pg. 5 for the correct procedures. CA-Series Operator’s Manual...
  • Page 15: Cleaning With Detergents (Option Aw-8400-002)

    4. Once pressure is relieved, disconnect the nozzle assembly. 5. Disconnect and drain gun, wand and hoses. 6. wipe unit clean and store with gun, wand and hoses in a safe, non- freezing area. CA-Series Operator’s Manual...
  • Page 16: Storage & Maintenance

    3 months or 250 hour intervals. If oil appears dirty or milky, changes may be required at a greater frequency. Use Mi-T-M pump oil #AW-4085-0016 and fill only to the center of the oil sight glass. DO NOT OVERFILL! NOZZLES: water flow through the spray nozzle will erode the orifice, making it larger, resulting in a pressure loss.
  • Page 17: Winterizing

    . Gather the following items: a. Two 5 gallon containers. 32˚F 0˚C b. One gallon of antifreeze. (Mi-T-M recommends an environmentally safe antifreeze.) c. water supply. d. Three foot hose, 1/2-3/4 I.D. with a 3/4 inch male garden hose fitting.
  • Page 18: Troubleshooting

    Change pump oil. Fill to proper level. Oil leaking from unit. DO NOT USE!!!!! Contact Mi-T-M Customer Service. Detergent will not siphon into Detergent strainer is not completely Check, submerge if necessary. Low Pressure Detergent mode. submerged in detergent solution.
  • Page 19: Accessories

    Mi-T-M All Purpose Cleaner, Paint Surface Prep, House and Deck wash and Heavy Duty Degreaser are specially formulated detergents for use with all Mi-T-M pressure washers and are packaged in one (1), five (5) and fifty-five (55) gallon containers. contact Mi-T-M Customer Service Department at (800) 553-9053 for more information.
  • Page 20: Statement Of Warranty

    4. The use of other than genuine Mi-T-M repair parts will void warranty. Parts returned, prepaid to our factory or to a Mi-T-M authorized service center will be inspected and replaced free of charge if found to be defective and subject to warranty. There are no warranties which extend beyond the description of the face hereof.
  • Page 21: Notes

    CA-Series Operator’s Manual...
