Note: In Record mode, user can delete a Fixture Scene. Select and press a recorded
Scene button in the Record mode, its LED will blink quickly. Then press the DEL button to
delete the scene, all LEDs will blink suddenly. (Press ESC button to exit.)

6.2.2 Program / record a Fixture Chase

(1)
Press and hold down the RECORD button for about 5 seconds to enter the CHASE /
SCENE mode.
(2) Select and press a Chase button to be recorded, its LED will begin to blink quickly.
LCD will show you as below:
(3)
Use UP or DOWN button to select the Chase Step to be programmed.
(4)
Set a scene for Chase recording.
(5)
Press the RECORD button, all LEDs will blink briefly, and LCD will show you the new
step.
(6) Pressing the DEL button can delete the current step, all LEDs will blink briefly.
(7) User can press ESC button to exit .

6.3 Select or deselect a Fixture Scene / Chase

6.3.1 Select / deselect a Fixture Scene

•
Press "PAGE" button, the relevant LED will light up, you can just use UP/DOWN
buttons to select the scene page. And PAGE : ×× will be shown on the top left
corner of the LCD-display.
•
If the scene LED is "on", that means the scene was programmed, while "off" means
unprogrammed. When the LED lights up, press its relevant button to start the scene,
the LED will start to flash.
•
You can also control the channels by using "joystick".
•
Press the scene button for 1 second to restart , and press it again for "off ".

6.3.2 Select / deselect a Fixture Chase

•
Choose program mode
Press "MIX/SEQUENCE" button to select program mode when no program running.
When LED is "on", that means it is in "MIX" mode, while "flashing" means
"SEQUENCE" mode. The "MIX / SEQUENCE" button is useless when program is
running .
•
Sequence mode:
EDIT CHASE× / TL××
ADD ESC STEP××
:
