6 Operation guide

Operation upon Fixtures

6.1 Control Fixture channels by "joystick"

•
This unit has 8 FIXTURE buttons to select 1—8 fixtures respectively.
•
Each fixture can be selected by pressing relevant Chase button. Its LED will be lit
when being selected. Pressing the Chase button again can turn off the fixture.
•
More fixtures can be selected while holding down the "Group" button simultaneously.
•
"Joystick" can be used to control the selected fixtures (its LED will blink) conveniently.
And relevant adjustment will be shown on the LCD-display through 100/255 mode.
•
The disabled fixtures (LED is "off") will show no signal input.
•
Fixture channel can be controlled by the "joystick". Adjustment of PAN, TILT, PAN
FINE and TILT FINE are available as user's desire.

6.2 Program or record a Fixture Scene / Chase

Before programming, press and hold down the RECORD button for about 5 seconds
to enter the Scene/Chase mode, its LED will be lit, LCD shows:

6.2.1 Program / record a Fixture Scene

(1) Press and hold down the RECORD button for about 5 seconds to enter the
CHASE/SCENE mode. Then choose the Scene page by UP or DOWN button.
(2) Select and press a Scene button to be recorded, its LED will begin to blink quickly.
LCD will show you as below:
(3) Select one or more fixtures, set a scene by faders. User can also insert a recorded
scene for new scene setting.
(4) select another series of fixtures, repeat step (3).
(5) Press RECORD button to record this scene, all LEDs will flash suddenly. User can
then set and record another Scene as desire.
SELECT A SCENE
OR CHASE ! PAGE××
EDIT SCENE× / PG××
SAVE ESC PAGE××
