4 Features and Specifications

4.1 Features

•
Hybrid console for 16 DMX units (8 intelligent fixtures & 8 PARs)
•
6 freely programmable PAR programs, ONE/MIX/SEQ available
•
8 freely programmable fixture programs, MIX/SEQUENCE available
•
136 DMX channels(8 channels for PARs and up to 16 channels per fixture)
•
96 freely programmable fixture scenes / PAR scenes
•
Speed, Fade Time and Master control for chases
•
Joystick for Pan / Tilt & Pan fine / Tilt fine movement of fixture
•
Free access of CF card(32M) for the exchange of data and memories
•
Blackout overall output
•
Fade time/Non-fade time under control
•
Power failure memory and Fog Machine trigger
•
MIDI control over scenes, chases and blackout
•
Audio input and built-in microphone for music sync. function

4.2 Specifications

•
Model
•
Power Input
•
LCD
•
Audio Trigger
•
DMX Output
•
Dimensions
•
Weight

5 Basic Control Parts

5.1 Front view

•
SCENE buttons:
Press the scene buttons to load or store relevant Scenes.
•
CHASE buttons:
These buttons are used to load or store relevant Chases.
•
FIXTURE buttons:
To select fixtures for setting, programming or recording.
•
Dimmer faders:
To control and adjust relevant dimming level for each channel.
DC-136
DC 9~15V, 600 mA min.
2×16 characters
Built-in microphone or line in
3 PIN female DMX connector
482×178×80mm
Approx. 6.2 kg
