11. EXPLODED DIAGRAM AND PARTS LIST.

ö
DWC-070C PARTS LIST
§ §
NO. COMPONENTS
1 PAN BASE
2 BOLT-COMP
3 SCROLL LOWER
4 SEALING PUTTY
5 COMPRESSOR
6 GROMMET
7 WASHER PLAN
8 NUT LOCK
9 AS CONDENSOR
10 SCREW TAPPING
11 PIPE COND IN
12 AS PIPE CAPILLARY
13 PIPE CAPI
14 AS EVAPORATOR
15 AS PIPE EVA OUT
16 AS PIPE EVA IN
17 AS PIPE SUCTION
18 SCREW TAPPING
19 MOTOR FAN
20 PANEL HOUSING
21 COVER ORIFICE
22 SCREW TAPTITE
23 SCRE TAPPING
24 FAN BLOWER
25 WASHER PLAIN
26 NUT HEX(R)
27 FAN PROPELLER
28 WASHER PLAIN
29 NUT HEX(L)
30 BUSHING GUIDE
31 LOCK TWIST STANDOFF
32 BUSHING HOUSING
33 CONTROL BOX
34 ROTARY S/W
35 SCREW MACHINE
36 THERMOSTAT
37 CAPACITOR
38 CLAMP CAPACITOR
39 SCREW TAPTITE
40 POWER CORD
41 SCREW TAPTITE
42 SCREW TAPTITE
43 LABEL CIRCUIT
44 BUSHING COVER
45 HARNESS ROTARY S/W
46 SEAL CONT BOX
47 HARNESS COMP AS
48 OLP
49 GASKET
50 COVER TERMINAL
51 NUT
52 SEAL EVA TOP
53 PLATE SCROLL
54 SEAL SCROLL
55 SCREW TAPPING
56 SCROLL UPPER
57 SEAL COND TOP
58 AS CABINET
60 PLT WINDOW TOP
61 SCREW TAPPING
62 SEAL CAB TOP
63 SEAL CAB SIDE(R)
64 SEAL CAB SIDE(L)
65 SEAL CAB FLANGE
66 SCREW TAPPING
67 GRILLE FRONT
68 SEAL FRONT (C)
69 SEAL FRONT (A)
70 SEAL FRONT (B)
71 BLADE
72 DECO FRONT
73 SCREW TAPPING
74 AS KNOB
75 FILTER PRE
CODE
3100300700
3106002400
3106600400
2221040001
3100039100
3108100000
7400208411
7392801211
3100029400
7112401211
3104414400
3100034300
3104414600
3100029300
3100034500
3100034400
3100034600
7112401211
3108002710
3104201500
3101402400
7S432X4081
7122401211
3101801820
3106000600
3106000500
3101801910
3106000600
3106000400
3100700600
3103800400
3100700900
3100504000
5S10503100
7001400611
5SM0101600
3109501600
3101201600
7S432X4081
3101397900
7S432X4081
7S432X4081
3103520500
3100701100
3102702100
3108502900
3102702000
—
—
—
—
3108502700
3104504800
3108503800
7122401211
3106600300
3108502800
3100034900
3104505600
7112401211
3108503100
3108503400
3108503200
3108503000
7112401211
3102401900
3108503700
3108503500
3108503600
3106501100
3101600400
7112400811
3100035200
3101901800
13
SPECIFICATION
P.P T30% or P.P CaCl (40%)
3
M8XP1.25
E.P.S
JOINT SEALER
QB110CL12A
EPDM 45
IB 8.4ƒTOD22ƒTT1.6
M8P1.25(R)
2RƒTICƒT17S
T1 TRS 4X12
OD7.94ƒTT0.7
DWC-070C
ID1.4
2RƒT2CƒT12S
C122OT-OD0.7
C122OT-OD0.7
OD9.52
T1 TRS 4X12
A9525HS601-1
SGCC(Z-27) T1.0
PP
TT3 TRS SE 4X8
T2S TRS 4X12
ABS+GF20%
M6X19.8
M6(R)
ABS
M6X19.8
M6(L)
NBR
DASTL-3NA
NBR
SGCC T0.8
SRB315-4-7D (DAESUNG)
M/C PAN 4X6
PFA 602D-06B
4+35uF/370VAC
SGCC T0.8
TT3 TRS SE 4X8
SJT AWG #16X3
TT3 TRS SE 4X8
TT3 TRS SE 4X8
P.E T0.05
DACB-008
AWG-16 UL (BR)
F-PE T0.5
AWG-16 UL (BR/RD/OR)
MRA 12061-12026
SILICON
P.C
HEXAGON FLANGE
F-US L350X40XT5
PP+T30%
F-US L115X60XT5
T2S TRS 4X12
EPS
F-US L400X30XT10
SGCC T0.8
SECC T1.2
T2S TRS 4X12
F-US L470X155X10
F-US L310X155XT5
F-US L310X90XT5
F-US L540X10XT5
T2S TRS 4X12
ABS
F-US L80X20XT30
F-US L600X20XT10
F-US L420X20XT10
PP
PC T0.4
T1 TRS 4X8 MFZN
ABS
ABS (MESH #32)
Q'TY REMARK
1
3
1
0.05 Kg
1
3
3
3
1
2
1
1
1
1
1
1
1
2
1
1
1
4
3
1
1
1
1
1
1
1
3
1
1
1
4
1
1
1
1
1
1
1
1
0.4
1
1
1
1
1
1
1
1
1
1
3
1
1
1 PAINT
1 PAINT
3
1
1
1
1
6
1
2
1
1
2
1
1
2
1
