MANUAL FOR MODELS: JLS400-LP
MODEL NAMES:
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
ASSEMBLY, USE AND CARE MANUAL
LUX Series 2 Burner Pedestal Model
JACKSON GRILLS INC.
#106-2480 Mt. Lehman Rd.
Abbotsford, BC
V4X 2N3
TELEPHONE: (604) 855-6756
FAX:
SUPPORT: support@jacksongrills.com
WEB SITE: www.jacksongrills.com
FOR OUTDOOR
WARNING
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
(604) 855-5373
USE ONLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JLS400-LP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jackson Grills JLS400-LP

Summary of Contents for Jackson Grills JLS400-LP

  • Page 1 V4X 2N3 TELEPHONE: (604) 855-6756 FAX: (604) 855-5373 SUPPORT: support@jacksongrills.com WEB SITE: www.jacksongrills.com ASSEMBLY, USE AND CARE MANUAL MANUAL FOR MODELS: JLS400-LP LUX Series 2 Burner Pedestal Model MODEL NAMES: FOR OUTDOOR USE ONLY DANGER WARNING If you smell gas: 1.
