- Page 1 OWNER’S MANUAL: Single Side Burner Models: JGSB-LP (Propane) JGSB-NG (Natural Gas) Important Notice Please read ALL safety notices on PP. 2 before assembling or operating this Side Burner. Version: OCT 2015...
-
Page 2: Safety Warnings
!SAFETY WARNINGS! IMPORTANT Please read and understand all warnings and precautions before using your Side Burner. !DANGER! !WARNING! If you smell gas: 1. Do not store or use gasoline or other Flammable liquids or 1. Shut off gas to the appliance. vapors in the vicinity of this or 2. -
Page 3: Table Of Contents
CERTIFICATION & TESTING This side burner has been tested by Labtest Certification (LC) and has been tested to ANSI Z21.58b-2012 & CSA 1.6b-2012, and Certified for Canada and the USA. NOTE: The use and installation of this product must conform to local codes. In the absence of local codes, use the National Fuel and Gas Code, ANSI A223.1, Storage and Handling of Liquefied Petroleum Gasses, NFPA / ANSI 58. -
Page 4: Exploded Diagram & Parts List
EXPLODED DIAGRAM & PARTS LIST: Lid with Handle: JH-000 Shoulder Bolt: JH-001 Electrode: JE-14 Cook Grid: JG-19 Heat Shield: JH-156 Natural Gas Regulator: JF-99 (NG units ONLY) Burner: JB-22 Venturi & Orifice: JF-85 Burner Support Plate: JB-23 Gas Valve: JF-02 Control Knob: JK-14 Burner Fuel Line: JF-84 Chrome Bezel: JK-17... - Page 5 STEP 1 Remove the cutting board from the right hand side shelf (The side burner can be installed only on the right hand side of the unit, as it will interfere with the rotisserie otherwise.) STEP 2 Drop the Side Burner assembly onto the rails that formerly supported the cutting board. This may be a tight fit;...
-
Page 6: Installation Instructions: (Built In Version)
INSTALLATION INTO BUILT-IN CABINET: STEP 1 Cut hole in cabinet to size as shown in Figure 7 (J,K,L; High-lighted in Yellow). !WARNING! SHUT OFF FUEL before attempting to install this side burner assembly. Figure 7 Non-Combustible material J = 9” Width (Left to Right) ONLY K = 17”... -
Page 7: Clearance To Combustibles
Clearance to Combustibles: A) TOP: from top of grate to any combustibles* above unit: 5 feet minimum *Such as decks, ceilings, hanging plants, etc. B) REAR: from rear of unit to any combustibles behind unit: 1 inch minimum C) SIDE: from the outside edges the unit, to any adjacent combustibles: 1 inch minimum !WARNING! Please allow extra space when the unit is backed up to vinyl siding;... -
Page 8: Gas Conversion
GAS CONVERSION: (Optional Orifice not included) 1. Remove the Cook Grid, Heat Shield, and Burner, 2. Remove the original Orifice, using a ¼” Socket Wrench, with an extension and 7mm socket (Fig. 9) 3. Lightly coat threads of the replacement Orifice with Teflon Tape or Gas Fitting Dope. 4. -
Page 9: Limited Warranty
Limited Warranty: MODELS: JGSB-LP & JGSB-NG Side Burner Jackson Grills warrants the materials and workmanship in this accessory to be free of defects for two (2) years from the date of purchase, to the original purchaser only. Two (2) Year Limited Warranty Subject to the following Conditions & Limitations: NOTE1: Shipping and Labor Charges are NOT covered under this warranty.
