Jackson Grills JGSB Owner's Manual

Single side burner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model # JGSB
FOR OUTDOOR USE ONLY
!WARNING!
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from
appliance and immediately call your gas
supplier & fire department.
OWNER'S MANUAL:
JACKSON GRILLS INC.
#106-2480 Mt. Lehman Rd.
Abbotsford, BC V4X 2N3
TEL:
1(888) 287-3333
FAX:
1(877) 855-5373
SUPPORT: support@jacksongrills.com
WEB SITE: www.jacksongrills.com
Single Side Burner
!WARNING!
1. Do not store or use gasoline or other
flammable liquids in the vicinity of this
appliance.
2. Do not store disconnected propane
tanks in the vicinity of this appliance.
1
Version: Dec.12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JGSB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jackson Grills JGSB

Summary of Contents for Jackson Grills JGSB

  • Page 1 TEL: 1(888) 287-3333 FAX: 1(877) 855-5373 SUPPORT: support@jacksongrills.com WEB SITE: www.jacksongrills.com OWNER’S MANUAL: Model # JGSB Single Side Burner FOR OUTDOOR USE ONLY !WARNING! !WARNING! If you smell gas: 1. Shut off gas to the appliance. 1. Do not store or use gasoline or other 2.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Certification & Testing Safety Warnings Package Contents Checklist Side Burner Parts Blow-Up Installation Instructions: (Cart Version) Installation Instructions: (Built In Version) Leak Testing: Natural Gas Conversion: Lighting Instructions: Warranty: CERTIFICATION & TESTING This side burner has been tested by Labtest Certification (LC) and has been tested to ANSI Z21.58a-1198 & CGA 16a-M98, and Certified for Canada and the USA.

  • Page 3: Safety Warnings

    !SAFETY WARNINGS! SAFETY FIRST: Please read and understand all warnings and precautions prior to operating your Side Burner. This accessory is for outside use only, and shall not be used in any building, garage, enclosed area or vehicle. This Side Burner is set up from the factory for use with Propane Gas (LP). (Propane Cylinder /Tank not included) Do not use gasoline, alcohol or other volatiles for lighting purposes.

  • Page 4: Side Burner Parts Blow-Up

    SIDE BURNER PARTS LIST Lid with Handle: JH-000 Shoulder Bolt: JH-001 Cook Grid: JG-19 Electrode: JE-14 Burner: JB-22 Venturi: JF-85 Gas Valve: JF-02 Burner Support Plate: JB-23 Burner Fuel Line: JF-84 Control Knob: JK-14 Manifold: JF-80 Chrome Bezel: JK-15 Flexible Fuel Line: JF-83 Main Body (Call Dealer) CART MODEL INSTALLATION: TOOLS REQUIRED:...
  • Page 5 STEP 2 Drop the Side Burner assembly onto the rails that formerly supported the cutting board. This may be a tight fit; if so, please bend the rails down slightly using a pair of pliers (Fig. 1). This adjustment will allow the side burner to drop into place. Figure 1 Bend formed rails down slightly (if necessary)

  • Page 6: Installation Instructions: (Built In Version)

    FOR INSTALLATION INTO BUILT IN CABINET: STEP 1 Drop side burner unit into non-combustible hole in cabinet counter top. STEP 2 Connect Flex Fuel Line as shown in Step 3 of the section above; “Installation into Cart Models”. LEAK TESTING: STEP 1 Figure 6 Turn on Gas.

  • Page 7: Limited Warranty

    Limited Warranty: MODEL: JGSB Side Burner Jackson Grills Inc. warrants the materials and workmanship in this accessory to be free of defects for two years from the date of purchase. Limited Warranty Subject to the following Conditions & Limitations: (NOTE: Shipping and Labor Charges are NOT covered) ...
