Jackson Grills JLS400-LP Lux Owner's Manual

Cart style gas grill
Hide thumbs Also See for JLS400-LP Lux:
Table of Contents

Advertisement

Quick Links

Download this manual
Model # JLS400-LP Lux
!WARNING!
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from
appliance and immediately call your gas
supplier & fire department.
OWNER'S MANUAL:
JACKSON GRILLS INC.
#106-2480 Mt. Lehman Rd.
Abbotsford, BC V4X 2N3
TEL:
1(888) 287-3333
FAX:
1(877) 855-5373
SUPPORT: support@jacksongrills.com
WEB SITE: www.jacksongrills.com
Cart Style Gas Grill
FOR OUTDOOR USE ONLY
!WARNING!
1. Do not store or use gasoline or
other flammable liquids in the vicinity
of this appliance.
2.
Do
not
propane tanks in the vicinity of this
appliance.
1
store
disconnected
Version: Dec.12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JLS400-LP Lux and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jackson Grills JLS400-LP Lux

Summary of Contents for Jackson Grills JLS400-LP Lux

  • Page 1 TEL: 1(888) 287-3333 FAX: 1(877) 855-5373 SUPPORT: support@jacksongrills.com WEB SITE: www.jacksongrills.com OWNER’S MANUAL: Model # JLS400-LP Lux Cart Style Gas Grill FOR OUTDOOR USE ONLY !WARNING! !WARNING! If you smell gas: 1. Do not store or use gasoline or 1. Shut off gas to the appliance.
