MODEL NO: JLSBI / JLS700BI
MODEL NAME:
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
ASSEMBLY, USE AND CARE MANUAL
LUX Series 3/4 Burner Built In
JACKSON GRILLS INC.
#106-2480 Mt. Lehman Rd.
Abbotsford, BC
V4X 2N3
TELEPHONE: (604) 855-6756
FAX:
SUPPORT: support@jacksongrills.com
WEB SITE: www.jacksongrills.com
FOR OUTDOOR
WARNING
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
(604) 855-5373
USE ONLY
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jackson Grills JLSBI
Summary of Contents for Jackson Grills JLSBI
- Page 1 V4X 2N3 TELEPHONE: (604) 855-6756 FAX: (604) 855-5373 SUPPORT: support@jacksongrills.com WEB SITE: www.jacksongrills.com ASSEMBLY, USE AND CARE MANUAL MODEL NO: JLSBI / JLS700BI LUX Series 3/4 Burner Built In MODEL NAME: FOR OUTDOOR USE ONLY DANGER WARNING If you smell gas: 1.
-
Page 2: Table Of Contents
Please record the serial number of your grill in your owner’s manual. Any questions please feel free to contact our service center or your local dealer; please refer to this Model No. JLSBI (LUX Series 3 Burner Built In) or JLS700BI (LUX Series 4 Burner Built In). Thank you. - Page 3 NOTE: It is normal for stainless steel surfaces to discolor due to high heat given off from the barbeque burners. Please take the time to fill out and return the Ownership and Registration Card below. It can be mailed to: Jackson Grills Inc. #106-2480 Mt. Lehman Rd. Abbotsford, BC V4X 2N3 Or Fax: 1-877-855-5373 Please complete and return within 10 days.
-
Page 4: Important
Important The symbols and boxes shown below explain what each symbol means. Read and follow every message found in this manual. !!! DANGER !!! DANGER: Indicates an imminently hazardous situation which will result in death or serious bodily injury if not followed. !!! WARNING !!! WARNING: Warning of the possibility of serious bodily injury if the instructions are not followed strictly. -
Page 5: Installation Safety Precautions
Installation Safety Precautions !!! WARNING !!! Do not try to install this appliance without reading the “INSTALLATION SAFETY PRECAUTIONS” section of this manual. 1. This grill is designed to use L.P. gas only. Only use this grill with L.P. gas and the regulator assembly supplied by the manufacturer. -
Page 6: Exploded View & Parts List
Exploded View & Parts List * May not be exactly as shown... - Page 7 Rotisserie Motor Bracket Flame Diffusers Hood Spacer Main Burners Inner Hood Cover Firebox Hood Washer LED Rotisserie Light ** Part number format for ordering replacement parts is as follows: JLSBI-REF# or JLS700BI-REF# Example: JLS700BI-11 : LUX700 Built In Rear Burner Cell...
-
Page 8: Assembly Instructions
Assembly Instructions Please ensure the proper tools are used for ease of installation. Please remove all components from the packaging and inspect all components to ensure there is no damage to any components in the packaging. Please remove all packaging from all components of the gas grill before operating. -
Page 9: Gas Connection
Gas Connection ONLY USE THE REGULATOR AND HOSE ASSEMBLY PROVIDED WITH THIS GRILL. REPLACEMENT PRESSURE REGULATORS AND HOSE ASSEMBLIES MUST BE THOSE SPECIFIED BY THE MANUFACTURER. This is a L.P. (Liquefied Petroleum Gas) configured grill. Do not attempt to use a natural gas supply unless the grill has been reconfigured for natural gas use. - Page 10 Do not use a wrench to tighten. Use of a wrench may damage quick coupling nut and result in a hazardous condition. (as the figure shown below) Open tank valve fully (counterclockwise). Use a soapy water solution to check all connections for leaks before attempting to light grill.
-
Page 11: Natural Gas Conversion
Natural Gas Conversion Tools required to convert this grill from Propane Gas to Natural Gas (tools not provided): 1. # 2 Phillips screwdriver 2. 7 and 9 mm wrenches The NG conversion kit is supplied with this grill: Item Description Quantity 3/4 pcs NG Orifice, Main Burner: #53 drill size... - Page 12 ROTISSERIE BURNER CONVERSION 1. Using a # 2 Phillips screwdriver, undo the 4 screws that hold the back cover plate to the inner hood. 2. Once the cover has been removed use a 9 mm wrench to remove the rear burner orifice from the rear burner.
-
Page 13: Installation
3” min. 5.5” min. 5.5” min. INSTALLING JLSBI / JLS700BI INTO A COMBUSTIBLE ISLAND NOTE: IMPORTANT!!! If these units are to be installed into a COMBUSTIBLE island a Zero Clearance Box MUST be installed. These zero clearance boxes are only available through your local dealer or Jackson Grills Inc. -
Page 14: Leaking Test
10. DO NOT STORE L.P. TANK IN OR NEAR AN AREA WHERE CHILDREN PLAY. 11. DISCONNECTED THE TANK AND REMOVE FROM THE GRILL IF THE GRILL IS STORED INDOORS. 12. ANY OTHER PROBLEM, SEE “TROUBLESHOOTING” OR CONTACT JACKSON GRILLS AT 1-877-855-5373. -
Page 15: Installer Final Check List
Installer Final Check List At least 36” clearance maintained from combustible constructions to the sides and back of this grill. There is no unprotected combustible construction over the grill. All internal packaging removed. Burners are sitting properly on orifices. ... - Page 16 4. Push and turn rear burner control knob to the “HIGH” position. Push and hold igniter button until burner lights. Up to 5 seconds is allowed for ignition. 5. Follow match lighting instruction if burner can’t be lit after repeating above steps 3-4 times. ...
-
Page 17: Operation Instructions
10. Turn off the gas supply when the grill is not in use. Always turn off the L.P. tank completely and detach from the grill before moving. TOTAL GAS CONSUMPTION: Total gas consumption (per hour) of grill with all burners on “HI”: JLSBI: JLS700BI: Main burners 45,000 Btu/hr Main burners... - Page 18 USING THE GRILL: Grilling requires high heat for searing and proper browning. Most foods are cooked at the “HI” heat setting for the entire cooking time. However, when grilling large pieces of meat or poultry, it may be necessary to turn the heat to a lower setting after the initial browning. This cooks the food through without burning the outside.
-
Page 19: Care & Maintenance
Care & Maintenance MAINTENANCE 1. Keep the grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids. 2. Keep the holes in the three sides of the cart clear and free from debris, thus ensure the flow of combustion and ventilation air is unobstructed. -
Page 20: Troubleshooting
Troubleshooting SPIDER AND INSECT WARNING Spiders and insects can nest in the burners after storing, these nest can cause fires inside the tube or beneath the grill. This is very dangerous condition. So always clean the burners before use after storing. ... -
Page 21: Grilling Tips
Grilling Tips The doneness of meat, whether rare, medium, or well done, is affected by the thickness to a large extent. The cooking time is affected by the kind of meat, the size and shape of the cut, the temperature of the meat when cooking begins, and the degree of doneness desired. -
Page 22: Limited Warranty
Jackson Grills Inc. or its parties will not be responsible for the installation, labor or any other costs or expenses related to the re installation of the warranted part, and such expenses are not covered by this warranty.
