- Page 1 OWNER’S MANUAL: Double Side Burner Models: JGSBDBL-LP (Propane) JGSBDBL-NG (Natural Gas) !Important Notice! Please read ALL safety notices on PP. 2 before assembling or operating this Side Burner Version: OCT 2015...
- Page 2 !SAFETY WARNINGS! IMPORTANT Please read and understand all warnings and precautions before using your Side Burner. !DANGER! !WARNING! If you smell gas: 1. Do not store or use gasoline or other Flammable liquids or 1. Shut off gas to the appliance. vapors in the vicinity of this or 2.
- Page 3 CERTIFICATION & TESTING This side burner has been tested by Labtest Certification (LC) and has been tested to ANSI Z21.58b-2012 & CSA 1.6b-2012, and Certified for Canada and the USA. NOTE: The use and installation of this product must conform to local codes. In the absence of local codes, use the National Fuel and Gas Code, ANSI A223.1, Storage and Handling of Liquefied Petroleum Gasses, NFPA / ANSI 58.
- Page 4 EXPLODED DIAGRAM & PARTS LIST: ORIFICE SIZES: JF-141 (x 2) #64 (11” W.C.) Propane: JF-142 (x 2) #53 (4” W.C.) Natural Gas: Natural Gas Regular JF-99 (NG units ONLY) Flexible Fuel Line: JF-83 Lid with Handle: JH-002 Cook Grids: JG-19 x 2 Control Heat Shields: JH-156 x 2...
- Page 5 INSTALLATION INTO BUILT-IN CABINET *: *NOTE: this side burner kit DOES NOT FIT Jackson Cart Model barbeques. !WARNING! SHUT OFF FUEL before attempting to install this side burner assembly. STEP 1 Cut hole in cabinet to size as shown: (Figure 1: J,K,L High-lighted in Yellow). Figure 1 Non-Combustible material J = 14.5”...
-
Page 6: Leak Testing
Clearance to Combustibles: A) TOP: from top of grate to any *combustibles above unit: 5 feet minimum *Such as decks, ceilings, hanging plants, etc. B) REAR: from rear of unit to any combustibles behind unit: 1 inch minimum C) SIDE: from the outside edges the unit to any adjacent combustibles: 1 inch minimum !WARNING! Please allow extra space when the grill is backed up to vinyl siding;... - Page 7 GAS CONVERSION*: (Optional Orifice not included) 1. Remove the Cook Grids, Control Heat Shield, and Burners. 2. Remove the original Orifices (2), using a ¼” Socket Wrench, with an extension and 7mm socket (Fig. 3) 3. Lightly coat threads of the replacement Orifices* with Teflon Tape or Gas Fitting Dope. 4.
-
Page 8: Limited Warranty
Limited Warranty: MODEL: JGSBDBL-LP & JGSBDBL-NG Side Burner Jackson Grills warrants the materials and workmanship in this accessory to be free of defects for two (2) years from the date of purchase. Limited Warranty Subject to the following Conditions & Limitations: NOTE1: Shipping and Labor Charges are NOT covered NOTE2: Bill of Sale MUST be presented at time of warranty claim.
