Konlen MOBILE CALL GSM Alarm System User Manual page 6

Gsm alarm system
Table of Contents

Advertisement

LB-
1
LB+
2
3
GND
Z1
4
5
GND
Zone 2
6
7
Zone 3
8
GND
9
Zone 4
10
Zone 5
11
GND
12
Zone 6
13
Zone 7
SP-
14
SP+
15
Note:
1. "LB -" and "LB +"are to connect external speaker. If you think
the internal speaker is not loud enough, pleasecontact us for
professional speakers.
2.
Connect one cable of the wired sensor to GND and the other to
"Z1/Z2/Z3.../Z7".
3.
Please pay attention to the siren connection. Do not mix the two
cables together when connecting. Otherwise, it will damage the
transistor in the main panel.
3
Positive of two-way speaker (red cable)
Negative of two-way speaker (black cable)
Ground
Wired sensor 1: support both NO and NC
Ground
Wired sensor 2: support both NO and NC
Wired sensor 3: support both NO and NC
GND
Wired sensor 4: support both NO and NC
Wired sensor 5: support both NO and NC
GND
Wired sensor 6: support both NO and NC
Wired sensor 7: support both NO and NC
Negative of siren (black cable)
Positive of siren (red cable)
Alarm Host Diagram
Alarm Host Diagram
