- Page 1 Getting Started Guide Sabre 1553 Hand-held Scanner Guía de Iniciación Guida Introduttiva Guide de Démarrage Guia de Iniciação Anleitung für Einsteiger P/N 3-640049-01...
- Page 2 Introduction Use this Getting Started Guide to set up the Sabre 1553 laser scanner for most termi- nal connections and symbologies. If necessary, use the EasySet setup software for additional configuration possibilities and terminal connections. Basic setup Configuración básica Configuration de base...
- Page 3 Keyboard wedge (for PC) System power OFF Connect cables Din/mini-Din adaptor cable power supply (normally not required) System power ON Select keyboard QWERTY English QWERTZ German QWERTY Swedish / Finnish QWERTY Norwegian PC wedge cable P/N 3-604037-00 QWERTY Spanish Customize parameters (optional) (*) = default value Postamble = Enter (*) AZERTY French...
- Page 4 RS-232 C System power OFF Connect cables Direct RS-232 C cable P/N 3-604032-00 Scanner power ON System power ON Read this code (standard RS-232 C PC serial port compatible) 9600 baud, 7 data bits, even parity, 2 stop bits postamble = carriage return + line feed...
-
Page 5: Wand Emulation
System power OFF Connect cable Wand emulation cable P/N 3-606031-00 System power ON Wand emulation Digital wand emulation Analog wand emulation - Intermec interface, white high Symbology Disable all symbologies Select symbology Code 39 Code 128 / EAN 128 Test... -
Page 6: Default Setup
Scan EasySet setup code Start EasySet software Laser warnings The Sabre 1553 has a maximum laser output of 1mW at 630-680 nm and complies with the following safety standards: USA: CDRH - Class II Laser Product (CFR 21 Subpart J) IEC 825-1 EN 60825-1 - Class 2 Laser Product Fix these warning labels onto the product if they are not already present. -
Page 7: Regulatory Statements
Intermec. This device is UL listed (UL 1950/C22.2 No. 950) for safety when powered by a host system or by one of the following external Intermec power supplies: Catalog No. and P/N 0-302029-01 ~120V, 60 Hz.
