  • Page 1 Getting Started Guide P/N x-xxxx49-01 Sabre 1555 Laser Scanner & RFID Reader/Programmer Guía de Iniciación Guida Introduttiva Guide de Démarrage Guia de Iniciação Anleitung für Einsteiger...
  • Page 2 Introduction Use this Getting Started Guide to set up the Sabre 1555 laser scanner and RFID reader/ programmer for most terminal connections and symbologies. If necessary, use the EasySet setup software or Installation Manual for additional configuration possibilities and terminal connections.
  • Page 3 Connect scanner cable (standard version shown) Scanner cable depends on your terminal Cables Accessories...
  • Page 4 RFID reader/programmer operation "beep" RFID reader/programmer reading distance Sabre 1555 1 cm - 60 cm 2450 MHz (0.4" - 24") 2.5 cm - 200 cm Sabre 1555 (1" - 80") 915 MHz...

  • Page 5: Scanner Operation

    Scanner operation "beep" Scanner reading distance Sabre 1555 6 cm - 34 cm Standard Range (2.5" - 13.5") 28 cm - 100 cm Sabre 1555 (11" - 39") Long Range...
  • Page 6 RS-232 C Ê Ê System power OFF Ë Ë Connect cable Direct RS-232 C cable P/N 3-604032-00 Ì Ì Scanner power ON Í Í System power ON Î Î Select standard RS-232 C (PC serial port compatible) 9600 baud, 7 data bits, even parity, 2 stop bits postamble = carriage return + line feed...
  • Page 7 Ï Customize parameters (optional) (*) = default value 9600 baud (*) 19200 baud 7 data bits (*) 8 data bits Even parity (*) Odd parity No parity Postamble = Carriage Return + Line Feed (*) Postamble = Carriage Return Postamble = none...
  • Page 8 RS-232 TTL Ê Ê System power OFF Ë Ë Connect cable Direct RS-232 TTL cable P/N x-xxxxxx-xx Ì Ì Scanner power ON Í Í System power ON Î Î Select RS-232 TTL 9600 baud, 7 data bits, even parity, 2 stop bits postamble = carriage return + line feed...
  • Page 9 Ï Customize parameters (optional) (*) = default value 9600 baud (*) 19200 baud 7 data bits (*) 8 data bits Even parity (*) Odd parity No parity Postamble = Carriage Return + Line Feed (*) Postamble = Carriage Return Postamble = none...

  • Page 10: Universal Serial Bus (Usb)

    Universal Serial Bus (USB) Ê Ê System power OFF Ë Ë Connect cable Direct USB cable P/N x-xxxxxx-xx Ì Ì Scanner power ON Í Í System power ON Î Î Select standard USB (PC serial port compatible) 9600 baud, 7 data bits, even parity, 2 stop bits postamble = carriage return + line feed...
  • Page 11 Ï Customize parameters (optional) (*) = default value Intermec representative needs to supply USB symbologies when the symbols are available.
  • Page 12 Symbology Ê Disable all symbologies Ë Select symbology Code 39 UPC-A, UPC-E, EAN-8, EAN-13 (UPC-A -> EAN-13) Code 128 / EAN 128 UPC-A, UPC-E, EAN-8, EAN-13 (UPC-A -> UPC-A) Ì Test Code 39 UPC-A CODE-39 Code 128 CODE-128 EAN 13 1234567890128...

  • Page 13: Online Setup

    Reset Online setup Ê System power OFF Ë Connect RS-232 C cable (P/N 3-604032-00) Ì Scanner power ON Í System power ON Î Scan EasySet setup code EasySet Ï Start EasySet software...

  • Page 14: Laser Warnings

    Laser warnings The Sabre 1555 has a maximum laser output of 1mW at 630-680 nm and complies with the following safety standards: USA: CDRH - Class II Laser Product (CFR 21 Subpart J) IEC 825-1 EN 60825-1 - Class 2 Laser Product Fix these warning labels onto the product if they are not already present.

  • Page 15: Regulatory Statements

    This device is UL listed (UL 1950/C22.2 No. 950) for safety when powered by a host system or by one of the following external Intermec power supplies: Catalog No. and P/N 043230 ~100V, 50/60 Hz or Catalog No. and P/N 047793 ~120V, 60 Hz. The device is CSA certified.
