WIRELESS MODEL INSTALLATION
SPEED TRANSMITTER & MAGNET
NOTE: WL2X Double wireless Speed & Cadence is optional.
Please refer to WIRED SPEED AND CADENCE/WL2X DOUBLE
The V100 is designed to operate as a wireless unit with the
installation of a special active mount and WL wireless speed
transmitter.
Use the zip-ties supplied to hold loosely the WL wireless
Step 1:
speed transmitter and mounting pad to the left fork leg.
Note: To maximize signal reception, position the
transmitter as high up on the fork leg as possible. (Fig.
9)
Step 2:
Tighten the spoke magnet to any spoke on the
"transmitter side" of the front wheel so that it passes
Step 3: over the alignment mark on the transmitter. (Fig. 9, 10)
Attach the alignment setup spacer to the magnet
temporarily. (Fig. 11 )
Step 4:
Slide and rotate the transmitter until the alignment mark
Step 5: just touches the spacer tip on the magnet. (Fig. 12)
Snug the zip ties down to hold the transmitter in its final
position.
Step 6:
Remove the spacer and verify that the magnet and
