LED
ACT (Activity)
USB1~USB2
WAN1~WAN2
VPN
QoS
WCF
DMZ
LED on Connector
Left
WAN1~
LED
WAN2
Right
LED
Left
LAN1~
LED
LAN5
Right
LED
Vigor2925 Series Quick Start Guide
p
l
a
n
a
t
i
o
n
p
l
a
n
a
t
i
o
n
o
r
2
9
2
5
o
r
2
9
2
5
Status
Explanation
Blinking
The router is powered on and running
normally.
Off
The router is powered off.
On
USB device is connected and ready for use.
Blinking
The data is transmitting.
On
Internet connection is ready.
Off
Internet connection is not ready.
Blinking
The data is transmitting.
On
The VPN tunnel is active.
On
The QoS function is active.
On
The Web Content Filter is active. (It is
enabled from Firewall >> General
Setup).
On
The DMZ function is enabled.
Off
The DMZ function is disabled.
Blinking
The data is transmitting.
On
The port is connected.
Off
The port is disconnected.
Blinking
The data is transmitting.
On
The port is connected with 1000Mbps.
Off
The port is connected with 10/100Mbps
On
The port is connected.
Off
The port is disconnected.
Blinking
The data is transmitting.
On
The port is connected with 1000Mbps.
Off
The port is connected with 10/100Mbps
