Chapter 8
Scenario 2: Business user with TOS marking.
Management label
GOLD label
100
Now we will need to do the same for the Management label.
Proceed as followed:
Select Management .
1
Set Marking to
2
DSCP.
Set the DSCP value to af42.
3
This will enable TOS marking by DSCP, and set the DSCP value to
which get this label assigned.
Now we will have to create three more labels:
A Gold label.
1
A Silver label.
2
A Bronze label
3
To create a label called Gold proceed as followed:
On the Label page click new . You will now get a configuration screen at the
1
bottom of the page.
Set the label name to
2
Set classification to
3
overwrite.
Set class to
4
11.
Set TCP ack class to
5
11.
Set Marking to
6
DSCP.
Set the DSCP value to
7
Click Apply to add the label to the list.
8
The label name can be any chosen name. Classification is set to overwrite as we
want to specify the internal class our selves. The internal class is set to 11 so
packets who get this label assigned will be placed in WFQ4.
DSCP will be used for TOS marking and will be set to af31.
GOLD.
af31.
for packets
af42
E-NIT-CTC-20041213-0013 v0.5
