Speedtouch 716v5 (WL) Cli Reference Manual

Speedtouch 716v5 (wl) residential adsl gateway
Hide thumbs Also See for 716v5 (WL):
1
2
3
4
Table Of Contents
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579
580
581
582
583
584
585
586
587
588
589
590
591
592
593
594
595
596
597
598
599
600
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615
616
617
618
619
620
621
622
623
624
625
626
627
628
629
630
631
632
633
634
635
636
637
638
639
640
641
642
643
644
645
646
647
648
649
650
651
652
653
654
655
656
657
658
659
660
661
662
663
664
665
666
667
668
669
670
671
672
673
674
675
676
677
678
679
680
681
682
683
684
685
686
687
688
689
690
691
692
693
694
695
696
697
698
699
700
701
702
703
704
705
706
707
708
709
710
711
712
713
714
715
716
717
718
719
720
721
722
723
724
725
726
727
728
729
730
731
732
733
734
735
736
737
738
739
740
741
742
743
744
745
746
747
748
749
750
751
752
753
754
755
756
757
758
759
760
761
762
763
764
765
766
767
768
769
770
771
772
773
774
775
776
777
778
779
780
781
782
783
784
785
786
787
788
789
790
791
792
793
794
795
796
Table of Contents

Advertisement

Quick Links

Download this manual
SpeedTouch™716v5 (WL)
Residential ADSL Gateway
CLI Reference Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 716v5 (WL) and is the answer not in the manual?

Questions and answers

Related Manuals for Speedtouch 716v5 (WL)

Summary of Contents for Speedtouch 716v5 (WL)

  • Page 1 SpeedTouch™716v5 (WL) Residential ADSL Gateway CLI Reference Guide...
  • Page 3 SpeedTouch™ 716v5 (WL) CLI Reference Guide...
  • Page 4 Trademarks The following trademarks are used in this document: SpeedTouch™ is a trademark of THOMSON. Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. Ethernet™ is a trademark of Xerox Corporation. Wi-Fi® and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. "Wi-Fi CERTIFIED", "Wi-Fi ZONE", "Wi-Fi Alli- ance", their respective logos and "Wi-Fi Protected Access"...

  • Page 5: Table Of Contents

    Contents Contents About this Document ..................1 Root Commands .................... 3 ping................................4 traceroute..............................5 ADSL Commands................... 7 adsl config..............................8 adsl info................................. 9 ATM Commands ..................11 atm flush ..............................13 atm ifadd ..............................14 atm ifattach ..............................15 atm ifconfig..............................
  • Page 6 Contents atm oam ping ............................. 42 atm oam cc list ............................43 atm oam cc modify ............................ 44 atm oam cc send ............................45 atm oam vclb add............................46 atm oam vclb del............................47 atm oam vclb list ............................48 atm phonebook add ...........................
  • Page 7 Contents connection clear ............................83 connection config............................84 connection debug............................85 connection describe ........................... 86 connection flush ............................87 connection info............................88 connection list ............................89 connection refresh ............................. 90 connection stats ............................91 connection timerclear ..........................92 connection timerconfig..........................93 connection unbind .............................
  • Page 8 Contents dhcp client txoptions optionlist....................... 125 dhcp relay add ............................126 dhcp relay debug stats..........................127 dhcp relay debug traceconfig........................128 dhcp relay config............................129 dhcp relay delete ............................130 dhcp relay flush ............................131 dhcp relay ifconfig............................ 132 dhcp relay iflist ............................134 dhcp relay list ............................
  • Page 9 Contents dhcp server pool optdelete........................170 dhcp server pool rtadd..........................171 dhcp server pool rtdelete......................... 172 dhcp server pool ruleadd......................... 173 dhcp server pool ruledelete........................174 DNS Commands..................175 dns client config ............................176 dns client dnsadd ............................. 177 dns client dnsdelete ..........................178 dns client dnslist............................
  • Page 10 Contents dsd syslog list ............................208 dsd urlfilter config ............................ 209 dsd urlfilter rule add..........................210 dsd urlfilter rule delete..........................211 dsd urlfilter rule flush..........................212 dsd urlfilter rule list ..........................213 dsd urlfilter rule modify ........................... 214 DynDNS Commands.................. 215 dyndns add ...............................
  • Page 11 Contents eth bridge dynvlan config........................248 eth bridge dynvlan delete........................249 eth bridge dynvlan flush.......................... 250 eth bridge dynvlan list ..........................251 eth bridge flush ............................252 eth bridge ifadd ............................253 eth bridge ifattach ............................ 254 eth bridge ifconfig ............................ 255 eth bridge ifdelete ............................
  • Page 12 Contents Expr Commands..................289 expr add ..............................290 expr delete ..............................293 expr flush ..............................295 expr list..............................296 expr modify............................... 302 Firewall Commands................... 305 firewall config ............................306 firewall clear ............................. 308 firewall list..............................309 firewall chain add ............................. 310 firewall chain delete ..........................
  • Page 13 Contents grp rip show.............................. 341 Hostmgr Commands ................. 343 hostmgr add ............................. 344 hostmgr clear............................346 hostmgr config ............................347 hostmgr delete ............................348 hostmgr flush ............................349 hostmgr list............................... 350 IDS Commands ..................351 ids clear ..............................352 ids config..............................353 ids parser list ............................
  • Page 14 Contents igmp proxy debug traceconfig........................ 382 Interface Commands ................. 383 interface list .............................. 384 IP Commands ..................... 387 ip arpadd ..............................389 ip arpdelete ............................... 390 ip arplist ..............................391 ip config ..............................392 ip flush............................... 394 ip ifadd ..............................395 ip ifattach ..............................
  • Page 15 Contents IPQoS Commands..................429 ipqos config .............................. 430 ipqos list..............................432 ipqos ef config ............................433 ipqos ef list..............................434 ipqos ef stats............................. 435 ipqos queue clear ............................. 436 ipqos queue config........................... 437 ipqos queue list ............................439 ipqos queue stats ............................. 440 Label Commands ..................
  • Page 16 Contents mbus client test ............................475 mbus debug stats............................. 476 mbus debug traceconfig.......................... 477 mbus listobjects ............................478 mbus listtypes ............................479 mbus loadobjects ............................. 480 mbus unloadobjects..........................481 MEMM Commands ..................483 memm debug lock traceconfig ....................... 484 memm debug traceconfig ........................485 memm listobjects.............................
  • Page 17 Contents nat maplist ..............................518 nat tmpladd............................... 519 nat tmpldelete............................522 nat tmpllist ..............................523 nat tmplinst............................... 524 PPP Commands..................525 ppp flush ..............................526 ppp ifadd ..............................527 ppp ifattach ............................... 528 ppp ifconfig............................... 530 ppp ifdelete ............................... 534 ppp ifdetach ..............................
  • Page 18 Contents service host assign........................... 564 service host config ........................... 565 service host add ............................566 service host delete ........................... 567 service host disable..........................568 service host flush ............................. 569 service host list............................570 service host stats............................571 service host triggerlist ..........................572 service host rule add..........................
  • Page 19 Contents sntp flush ..............................605 sntp list..............................606 Software Commands................. 607 software download ..........................608 software upgrade ............................. 609 software version............................610 System Commands ................... 611 system config ............................612 system flush.............................. 614 system locale ............................615 system reboot............................617 system reset..............................
  • Page 20 Contents User Commands ..................643 user add ..............................644 user config ..............................646 user delete ..............................648 user flush ..............................649 user list..............................650 user rights ..............................652 Voice Commands..................653 voice config............................... 655 voice state ..............................657 voice codec list ............................658 voice codec config............................
  • Page 21 Contents voice services deactivate ......................... 693 voice services assign ..........................694 voice services assign_pxsc........................695 voice services flush ..........................696 voice sip config............................697 voice stats list ............................699 voice stats reset............................700 Wireless Commands.................. 701 wireless ifconfig ............................702 wireless reset............................
  • Page 22 Contents System Logging Messages ............... 737 Auto-PVC Module............................. 738 Configuration Module..........................738 DHCP Client Module..........................738 DHCP Relay Module ..........................739 DHCP Server Module ..........................739 Dyndns Module ............................740 Firewall Module............................740 LOGIN Module............................741 Kernel Module ............................741 Linestate Module............................

  • Page 23: About This Document

    For the Service Provider, this Reference Guide aims to be a concise and practical document for creating a customized Service Template file, based on the SpeedTouch™ CLI command set, to be used by the end user to configure the SpeedTouch™ and computer(s).
  • Page 24 Documentation and software updates THOMSON continuously develops new solutions, but is also committed to improve its existing products. For suggestions regarding this document, please contact documentation.speedtouch@thomson.net. For more information on THOMSON's latest technological innovations, documents and software releases, visit us www.speedtouch.com...

  • Page 25: Root Commands

    Root Commands Root Commands From the root prompt, you can choose one of the following commands: Command Description help Displays the help information. menu Displays the menu. exit Exits the shell. Exits group selection. saveall Saves current configuration. ping Send ICMP ECHO_REQUEST packets. traceroute Send ICMP/UDP packets to trace the ip path.

  • Page 26: Ping

    Root Commands ping Send ICMP ECHO_REQUEST packets. SYNTAX: ping proto = <{ip|atm}> addr = <ip-address> dest = <string> [count = <number{0-1000000}>] [size = <number{28-20028}>] [interval(ms) = <number{100-1000000}>] [DF-bit = <{disabled|enabled}>] [srcaddr = <ip-address>] where: proto The interface type to be used. REQUIRED Choose between: addr...

  • Page 27: Traceroute

    Root Commands traceroute Send ICMP/UDP packets to trace the IP path. SYNTAX: traceroute addr = <ip-address> [count = <number{1-10}>] [size = <number{1-20000}>] [interval = <number{1000-60000}>] [maxhops = <number{1-255}>] [dstport = <number{1-65535}>] [maxfail = <number{0-255}>] [type = <{icmp | udp}>] [utime = <{disabled | enabled}>] where: addr The destination IP address.
  • Page 28 Root Commands EXAMPLE: =>traceroute addr = 192.193.195.250 count=3 size=1 interval=1000 maxhops=30 dstport=33433 maxfail=5 type=icmp utime=yes :traceroute addr=192.193.195.250 ttl=1 192.193.195.250 676 us 1351 us 648 us => E-DOC-CTC-20060414-0006 v1.0...

  • Page 29: Adsl Commands

    ADSL Commands ADSL Commands Introduction This chapter describes the commands of the adsl command group. Contents This chapter covers the following commands: adsl config Show/set the Asymmetric Digital Subscriber Line (ADSL) configuration. adsl info Display the ADSL statistics and information about the DSL line status. E-DOC-CTC-20060414-0006 v1.0...

  • Page 30: Adsl Config

    The default is multi_adsl2plus. trace Enable or disable ADSL tracing. OPTIONAL The default is enabled. EXAMPLE: The example below shows the default configuration for a SpeedTouch™ ADSL/POTS variant: =>adsl config ADSL configuration: opermode = multi_adsl2plus trace = on modemoption = 00:00:00:00:00:00:00:00:00:00:00:00:00:00:00:00 =>...

  • Page 31: Adsl Info

    ADSL Commands adsl info Display the ADSL statistics and information about the DSL line status. Although the same command is used for both SpeedTouch™ ADSL/POTS and SpeedTouch™ ADSL/ISDN variants, the command features specific output parameters and counters per variant. SYNTAX: adsl info EXAMPLE (for a SpeedTouch™...
  • Page 32 ADSL Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 33: Atm Commands

    ATM Commands ATM Commands Introduction This chapter describes the commands of the atm command group. Contents This chapter covers the following commands: atm flush Flush all Asynchronous Transfer Mode (ATM) interfaces. atm ifadd Create a new ATM interface. atm ifattach Attach a ATM interface.
  • Page 34 ATM Commands atm oam vclb add Create a loopback connection for VC. atm oam vclb del Delete a loopback connection for VC. atm oam vclb list List all VC loopback connections. atm phonebook add Add a new phonebook entry. atm phonebook autolist Show the auto PVCs.

  • Page 35: Atm Flush

    ATM Commands atm flush Flush all Asynchronous Transfer Mode (ATM) interfaces. SYNTAX: atm flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 36: Atm Ifadd

    ATM Commands atm ifadd Create a new ATM interface. SYNTAX: atm ifadd intf = <string> where: intf The name for the new ATM interface. REQUIRED Note If not specified, the destination parameter must be specified. In this case the name of the destination will double as interface name. EXAMPLE: =>atm iflist atm_0_35...

  • Page 37: Atm Ifattach

    ATM Commands atm ifattach Attach a ATM interface. SYNTAX: atm ifattach intf = <string> where: intf The name of the ATM interface to be attached. REQUIRED EXAMPLE: =>atm iflist atm_0_35 : dest : atm_pvc_0_35 Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac Connection State : connected RtPPPoA_atm: dest : RtPPPoA...

  • Page 38: Atm Ifconfig

    This parameter is normally left disabled. retry A number between 0 and 65535. OPTIONAL Represents the number of times the SpeedTouch™ retries to set up a WAN connection before giving up. The default is 10. Select the Upper Layer Protocol (ULP) for this interface.
  • Page 39 ATM Commands EXAMPLE: =>atm iflist atm_0_35 : dest : atm_pvc_0_35 Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : mac Connection State : connected atm_8_35 : dest : atm_pvc_8_35 Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : mac Connection State : not-connected =>...

  • Page 40: Atm Ifdelete

    ATM Commands atm ifdelete Delete an ATM interface. SYNTAX: atm ifdelete intf = <string> where: intf The name of the ATM interface to be deleted. REQUIRED EXAMPLE: =>atm iflist atm_0_35 : dest : atm_pvc_0_35 Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac Connection State : connected RtPPPoA_atm: dest : RtPPPoA...

  • Page 41: Atm Ifdetach

    ATM Commands atm ifdetach Detach an ATM interface. SYNTAX: atm ifdetach intf = <string> where: intf The name of the ATM interface to be detached. REQUIRED EXAMPLE: =>atm iflist atm_0_35 : dest : atm_pvc_0_35 Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac Connection State : connected RtPPPoA_atm: dest : RtPPPoA...

  • Page 42: Atm Iflist

    ATM Commands atm iflist Display the ATM interfaces. SYNTAX: atm iflist [intf = <string>] where: intf The name of the ATM interface to be shown. OPTIONAL Note If not specified, all the ATM interfaces are shown. EXAMPLE: =>atm iflist atm_0_35 : dest : atm_pvc_0_35 Retry : 10 QoS : default...

  • Page 43: Atm Bundle Add

    ATM Commands atm bundle add Add a new bundle of interfaces. SYNTAX: atm bundle add name = <string> where: name The name of the new bundle. REQUIRED EXAMPLE: =>atm bundle add name=myBundle =>atm bundle list myBundle: Connection state : not-connected Retry: 10 Policy: priority Propagate: disabled...

  • Page 44: Atm Bundle Attach

    ATM Commands atm bundle attach Attach a bundle of interfaces. SYNTAX: atm bundle attach name = <string> where: name The name of the bundle to be attached. REQUIRED EXAMPLE: =>atm bundle attach name=myBundle =>atm bundle list myBundle: Connection state : connected Retry: 10 Policy: priority Propagate: disabled...

  • Page 45: Atm Bundle Config

    ATM Commands atm bundle config Modify a bundle of interfaces. The bundle of interfaces to be configured must not be connected at the time of configuration. If this should be the case, use the command :atm bundle detach before using the command :atm bundle config.

  • Page 46: Atm Bundle Clear

    ATM Commands atm bundle clear Clear the bundle statistics. SYNTAX: atm bundle clear [name = <string>] where: name The name of the bundle for which the statistics must be cleared. OPTIONAL Note If not specified, the statistics for all the bundles will be cleared. E-DOC-CTC-20060414-0006 v1.0...

  • Page 47: Atm Bundle Delete

    ATM Commands atm bundle delete Delete a bundle of interfaces. SYNTAX: atm bundle delete name = <string> where: name The name of the bundle to be deleted. REQUIRED RELATED COMMANDS: atm bundle add Add a new bundle of interfaces. atm bundle list Display the current bundles.

  • Page 48: Atm Bundle Detach

    ATM Commands atm bundle detach Detach a bundle of interfaces. SYNTAX: atm bundle detach intf = <string> where: intf The name of the bundle to be detached. REQUIRED RELATED COMMANDS: atm bundle attach Attach a bundle of interfaces. E-DOC-CTC-20060414-0006 v1.0...

  • Page 49: Atm Bundle Flush

    ATM Commands atm bundle flush Flush all bundles. SYNTAX: atm bundle flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 50: Atm Bundle Ifadd

    ATM Commands atm bundle ifadd Add an interface on a bundle. Up to 8 interfaces or (sub-)bundles can be added to one bundle. SYNTAX: atm bundle ifadd name = <string> intf = <string> [index = <number{0-6}>] where: name The name of the bundle to which an ATM interface must be added. REQUIRED intf The name of the ATM interface to be added.

  • Page 51: Atm Bundle Ifconfig

    ATM Commands atm bundle ifconfig Configure an interface from a bundle. The interface to be configured must not be connected at the time of configuration. If this should be the case, use the command :atm bundle ifdetach before using the command :atm bundle ifconfig. SYNTAX: atm bundle ifconfig name = <string>...

  • Page 52: Atm Bundle Ifdelete

    ATM Commands atm bundle ifdelete Remove an interface from a bundle. SYNTAX: atm bundle ifdelete name = <string> intf = <string> where: name The name of the bundle from which an ATM interface must be removed. REQUIRED intf The name of the ATM interface to be removed. REQUIRED EXAMPLE: =>atm bundle iflist...

  • Page 53: Atm Bundle List

    ATM Commands atm bundle list Display the current bundles. SYNTAX: atm bundle list EXAMPLE: =>atm bundle list Test : Connection state : not-connected Retry: 10 Policy: priority TX requested bytes: 0 requested frames: 0 TX bytes: 0 frames: 0 RX bytes: 0 frames: 0 Interface: Test State: enabled...

  • Page 54: Atm Cac Config

    ATM Commands atm cac config Configure the ATM connection admission control. SYNTAX: atm cac config config port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> state = <{disabled|enabled}> where: config port The port for which CAC is configured. REQUIRED state Enable/disable CAC for an ATM port. REQUIRED EXAMPLE: {Administrator}=>atm cac config...

  • Page 55: Atm Cac List

    ATM Commands atm cac list Display all the CAC parameters. SYNTAX: atm cac list EXAMPLE: {Administrator}[atm cac]=>list CAC: port: dsl0 state: enabled CAC: port: dsl1 state: enabled CAC: port: atm2 state: enabled CAC: port: aal5 state: disabled CAC: port: atm5 state: disabled Overbooking: realtime: 0% non-realtime: 0%.

  • Page 56: Atm Cac Overbooking

    ATM Commands atm cac overbooking Configure ATM overbooking parameters. SYNTAX: atm cac overbooking rt = <number{0-1000}> nrt = <number{0-1000}> where: A number between 0 and 1000. REQUIRED The realtime overbooking percentage. A number between 0 and 1000. REQUIRED The non-realtime overbooking percentage. EXAMPLE: {Administrator}[atm cac]=>overbooking rt 20 nrt 500 {Administrator}[atm cac]=>list...

  • Page 57: Atm Debug Aal5Stats

    ATM Commands atm debug aal5stats Display ATM Adaptation Layer 5 (AAL5) port specific ATM statistics. SYNTAX: atm debug aal5stats port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> vpi = <number{0-15}> [vci = <number{0-511}>] [clear = <{disabled | enabled}>] where: port The port number for which statistics will be retrieved. REQUIRED Choose between: DSL0...

  • Page 58: Atm Debug Gstats

    ATM Commands atm debug gstats Display ATM global statistics. SYNTAX: atm debug gstats [clear = <{disabled | enabled}>] where: clear Enable or disable clearing of the statistics after request. OPTIONAL EXAMPLE: {admin}[atm debug]=>gstats # of received octets = 1802. # of transmitted octets = 4346. # of received cells = 34.

  • Page 59: Atm Debug Portstats

    ATM Commands atm debug portstats Display port specific ATM statistics. SYNTAX: atm debug portstats port = <{dsl0} or number> [clear = <{disabled | enabled}>] where: port The port number for which statistics will be retrieved. REQUIRED Choose between: DSL0 Or specify a port number (dsl0 has port number 0). clear Enable or disable clearing of the statistics after request.

  • Page 60: Atm Oam Config

    ATM Commands atm oam config Modify the ATM Operation and Maintenance (OAM) settings. SYNTAX: atm oam config [clp = <number{0-1}>] [loopbackid = <string>] where: A number (0 or 1). OPTIONAL Represents the Cell Loss Priority (CLP) bit value of the OAM cells. The default is 1.

  • Page 61: Atm Oam List

    ATM Commands atm oam list Display the ATM OAM settings. SYNTAX: atm oam list EXAMPLE: =>atm oam list OAM config dump ------------------- CLP bit value : 1 Loopback id : 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a OAM data blocking mode -------------------------- Port dsl0: blocking...

  • Page 62: Atm Oam Modify

    ATM Commands atm oam modify Modify the ATM OAM data blocking mode. SYNTAX: atm oam modify port = <{dsl0} or number> blocking = <{disabled | enabled}> where: port The port for which OAM blocking is configured. REQUIRED Choose between: DSL0 Or specify a port number (dsl0 has port number 0).
  • Page 63 ATM Commands atm oam ping Send ATM loopback cells. E-DOC-CTC-20060414-0006 v1.0...

  • Page 64: Atm Oam Ping

    ATM Commands atm oam ping Send ATM loopback cells. SYNTAX: atm oam ping dest = <string> [count = <number{1-1000000}>] [interval = <number{100-1000000}>] where: dest The destination address for the request. REQUIRED This can be any ATM phonebook entry. count A number between 1 and 1000000. OPTIONAL Represents the number of pings to send.
  • Page 65 ATM Commands atm oam cc list Display Continuity Check (CC) configuration. SYNTAX: atm oam cc list EXAMPLE: =>atm oam cclist PORT = 0 VPI = 15 VCI = 16 End2End Mode = Auto Segment Mode = Auto PORT = 0 VPI = 0 VCI = 35 End2End Mode = Auto Segment Mode = Auto PORT = 0 VPI = 8 VCI = 35 End2End Mode = Auto Segment Mode = Auto...

  • Page 66: Atm Oam Cc Modify

    Select the CC span. OPTIONAL Choose between: end2end: monitoring occurs on the entire VC between two ATM end stations. segment: monitoring occurs on a VC segment between the SpeedTouch™ and a first-hop ATM switch. RELATED COMMANDS: atm oam cc list Display Continuity Check (CC) configuration.

  • Page 67: Atm Oam Cc Send

    Select the CC span. OPTIONAL Choose between: end2end: monitoring occurs on the entire VC between two ATM end stations. segment: monitoring occurs on a VC segment between the SpeedTouch™ and a first-hop ATM switch. action Activate or deactivate CC. OPTIONAL The default is deactivate.

  • Page 68: Atm Oam Vclb Add

    ATM Commands atm oam vclb add Create a loopback connection for VC. SYNTAX: atm oam vclb add port = <{dsl0} or number> vpi = <number{0-15}> [vci = <number{0-511}>] where: port The ATM port number. REQUIRED Choose between: DSL0 Or specify a port number (dsl0 has port number 0). A number between 0 and 15.

  • Page 69: Atm Oam Vclb Del

    ATM Commands atm oam vclb del Delete a loopback connection for VC. SYNTAX: atm oam vclb del port = <{dsl0} or number> vpi = <number{0-15}> [vci = <number{0-511}>] where: port The ATM port number. REQUIRED Choose between: DSL0 Or specify a port number (dsl0 has port number 0). A number between 0 and 15.

  • Page 70: Atm Oam Vclb List

    ATM Commands atm oam vclb list List all VC loopback connections. SYNTAX: atm oam vclb list EXAMPLE: =>atm oam vclb list PORT = 0 VPI = 0 VCI = PORT = 1 VPI = 0 VCI = => RELATED COMMANDS: atm oam vclb add Create a loopback connection for VC.

  • Page 71: Atm Phonebook Add

    ATM Commands atm phonebook add Add a new phonebook entry. SYNTAX: atm phonebook add name = <string> addr = <atmchannel : PVC syntax is [port.]vpi.vci port=dsl0 | ...> where: name The name of the new phonebook entry. REQUIRED This name can be freely chosen, however two limitations apply: The name of a phonebook entry intended for the Relayed PPPoA (PPPoA-to-PPTP Relaying) packet service may not start with capital P or capital T The name of a phonebook entry intended for the PPP-to-DHCP spoofing packet...

  • Page 72: Atm Phonebook Autolist

    ATM Commands atm phonebook autolist Show the auto PVCs. Auto PVCs are only shown if they are supported by the Central Office DSLAM. SYNTAX: atm phonebook autolist EXAMPLE: =>atm phonebook autolist 8.35 => RELATED COMMANDS: atm phonebook list Display the current phonebook. E-DOC-CTC-20060414-0006 v1.0...

  • Page 73: Atm Phonebook Delete

    ATM Commands atm phonebook delete Delete an existing phonebook entry. This command is only applicable for phonebook entries that are not used (in other words, not configured for any packet service). SYNTAX: atm phonebook delete name = <string> where: name The name of the phonebook entry to be deleted.

  • Page 74: Atm Phonebook Flush

    ATM Commands atm phonebook flush Flush all the phonebook entries. 1. Phonebook entries that are in use, cannot be flushed. 2. This command does not impact previously saved configurations. SYNTAX: atm phonebook flush EXAMPLE: =>atm phonebook list Name Address atm_pvc_0_35 1 0.35 RtPPPoA 8.35...

  • Page 75: Atm Phonebook List

    ATM Commands atm phonebook list Display the current phonebook. SYNTAX: atm phonebook list EXAMPLE: =>atm phonebook list Name Address atm_pvc_0_35 1 0.35 RtPPPoA 8.35 => RELATED COMMANDS: atm phonebook add Add a new phonebook entry. atm phonebook autolist Show the auto PVCs. atm phonebook delete Delete an existing phonebook entry.

  • Page 76: Atm Qosbook Add

    ATM Commands atm qosbook add Add a new QoS book entry. SYNTAX: atm qosbook add name = <string> [txctd = <string>] [rxctd = <string>] where: name The name of the new QoS entry. REQUIRED txctd The name of the Conformance Traffic Descriptor (CTD) for the transmit (upstream) OPTIONAL direction.

  • Page 77: Atm Qosbook Config

    ATM Commands atm qosbook config Modify the QoS book configuration. SYNTAX: atm qosbook config [format = <{bytes | cells}>] where: format The input/output format of the QoS book. OPTIONAL Choose between: bytes: the output is shown in Kbits or bytes. cells: the output is shown in cps or cells.

  • Page 78: Atm Qosbook Ctdadd

    ATM Commands atm qosbook ctdadd Add a Connection Traffic Descriptor (CTD). SYNTAX: atm qosbook ctdadd name = <string> conformance = <{UBR | CBR | VBR }> [peakrate = <number{0-27786}>] [sustrate = <number{0-27786} [maxburst = <number{0-12240}>] [realtime = <{enabled | disabled}>] where: name The name of the new CTD.
  • Page 79 ATM Commands IMPORTANT NOTE: The SpeedTouch™ always rounds up specified burst sizes to a multiple of 48 bytes (a multiple of ATM cells). Example: In the example below a burst size of 100 bytes is specified (maxburst=100). The SpeedTouch™ will round up the burst size to the closest matching multiple of 48 bytes, as can be seen when displaying the profile via the command :atm qosbook ctdlist (burst=144).

  • Page 80: Atm Qosbook Ctddelete

    ATM Commands atm qosbook ctddelete Delete a CTD. SYNTAX: atm qosbook ctddelete name = <string> [force = <{disabled | enabled}>] where: name The name of the CTD entry to be deleted. REQUIRED force Enable or disable to force delete the entry even when it is still in use. OPTIONAL The default is disabled.

  • Page 81: Atm Qosbook Ctdlist

    ATM Commands atm qosbook ctdlist Display all CTDs. SYNTAX: atm qosbook ctdlist EXAMPLE: =>atm qosbook ctdlist Name Ref Conf Peak Sust Burst Minrate Frame Cdvt (Kbits) (Kbits) (bytes) (Kbits) (bytes) default 2 linerate 0 disabled disabled High 27786 disabled disabled =>...

  • Page 82: Atm Qosbook Delete

    ATM Commands atm qosbook delete Delete a QoS book entry. SYNTAX: atm qosbook delete name = <string> [force = <{disabled | enabled}>] where: name The name of the QoS book entry to be deleted. REQUIRED force Enable or disable to force delete the entry even when it is still in use. OPTIONAL The default is disabled.

  • Page 83: Atm Qosbook Flush

    ATM Commands atm qosbook flush Flush all the QoS book entries. The flush command does not impact previously saved configurations. SYNTAX: atm qosbook flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 84: Atm Qosbook List

    ATM Commands atm qosbook list Display the QoS book. SYNTAX: atm qosbook list EXAMPLE: =>atm qosbook list Name Ref Type TX peak sust burst RX peak sust burst framediscard (Kbits) (Kbits) (bytes) (Kbits) (Kbits) (bytes) default 3 linerate 0 linerate 0 disabled TestVBR 0 vbr-nrt 1500...

  • Page 85: Autopvc Commands

    AutoPVC Commands AutoPVC Commands Introduction This chapter describes the commands of the autopvc command group. Contents This chapter covers the following commands: autopvc config Configure autopvc. autopvc list Show the retrieved information. E-DOC-CTC-20060414-0006 v1.0...

  • Page 86: Autopvc Config

    AutoPVC Commands autopvc config Configure autopvc. SYNTAX: autopvc config [mode = <{pseudo | passive | active}>] [type = <{bridge | pppoerelay | ipoa | ethoa | pppoa | pppoe}>] [overwrite = <{disabled | enabled}>] [peakrate = <number{0-27786}>] where: mode Select the autopvc mode: OPTIONAL pseudo: only pseudo-ILMI (VP/VC 15/16) is enabled.

  • Page 87: Autopvc List

    AutoPVC Commands autopvc list Show the retrieved information. SYNTAX: autopvc list [table = <{Port | AtmLayer | Vpc | Vcc | Address | AddressRegistrationAdmin | AtmServiceType | AtmServiceConnectionInfo | AAL1Profile | | AAL34Profile | AAL5Profile | AAL2CommonProfile | AAL2TrunkingProfile | AAL2LESProfile | AtmServiceConnInfoExtension | | AtmServiceTypeExtension | AAL5ProfileExtension}>] where:...
  • Page 88 AutoPVC Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 89: Config Commands

    Config Commands Config Commands Introduction This chapter describes the commands of the config command group. Contents This chapter covers the following commands: config delete Delete a user configuration file. config dump Show the saved configuration file. config flush Flush the loaded configuration. config list Show the current configuration set.

  • Page 90: Config Delete

    Name of the user configuration file to be deleted. OPTIONAL Note If not specified, all the user configuration files that were saved in the SpeedTouch™ permanent storage will be deleted. RELATED COMMANDS: config dump Show the saved configuration file. E-DOC-CTC-20060414-0006 v1.0...

  • Page 91: Config Dump

    Config Commands config dump Show the saved configuration file. SYNTAX: config dump RELATED COMMANDS: config delete Delete a user configuration file. E-DOC-CTC-20060414-0006 v1.0...

  • Page 92: Config Flush

    Config Commands config flush Flush the loaded configuration. 1. This flush command combines all the possible flush commands. 2. This command does not affect saved configurations. SYNTAX: config flush [flush_ip = <{enabled | disabled}>] where: flush_ip Flush IP settings (enabled) or not (disabled). OPTIONAL The default is enabled.

  • Page 93: Config List

    Config Commands config list Show the current configuration set. SYNTAX: config list [templates = <{disabled | enabled}>] where: templates List the template files (disabled) or not (enabled). OPTIONAL The default is disabled. RELATED COMMANDS: config load Load complete saved (backup) or default configuration file. config save Store the current configuration in a backup file.

  • Page 94: Config Load

    Config Commands config load Load complete saved (backup) or default configuration file. Use the command :config flush before loading a configuration file. SYNTAX: config load [load_ip = <{enabled | disabled}>] [defaults = <{enabled | disabled}>] [flush = <{enabled | disabled}>] [echo = <{disabled | enabled}>] [filename = <string>] where:...

  • Page 95: Config Save

    Store the current configuration in a backup file. All the existing configurations and modifications entered by the user are saved. The backup file is saved in the SpeedTouch™ permanent storage. This file can be downloaded via the SpeedTouch™ web pages or via an FTP session.
  • Page 96 Config Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 97: Connection Commands

    Connection Commands Connection Commands Introduction This chapter describes the commands of the connection command group. Contents This chapter covers the following commands: connection appconfig Configure the available CONN/NAT application helpers. connection appinfo Display CONN/NAT application specific info. connection applist List the available CONN/NAT application helpers. connection bind Create a new CONN/NAT application helper/port binding.

  • Page 98: Connection Appconfig

    Connection Commands connection appconfig Configure the available CONN/NAT application helpers. SYNTAX: connection appconfig application = <string> [trace = <{disabled | enabled}>] [timeout = <number{0-32000}>] [floating = <{disabled | enabled}>] [tracelevel = <number{1-4}>] [SIP_ALG = <{disabled|enabled}>] [RTP_predict_for_term_SIP_ALG = <{disabled|enabled}>] where: application The name of a CONN/NAT application helper.
  • Page 99 Connection Commands EXAMPLE: =>connection applist Application Proto DefaultPort Traces Timeout IP6TO4 6to4 enabled unavailable PPTP 1723 enabled unavailable unavailable 15' 0" disabled 15' 0" FLOATING 5060 disabled 6 0" trace level 1 LOOSE(UDP) enabled 5' 0" enabled unavailable =>connection appconfig application=SIP trace=enabled =>connection applist Application Proto DefaultPort Traces...

  • Page 100: Connection Appinfo

    Connection Commands connection appinfo Display CONN/NAT application specific info. SYNTAX: connection appinfo application = <{string}> where: application The name of a CONN/NAT application helper. REQUIRED Use the command :connection applist to obtain a list of CONN/NAT application helpers. EXAMPLE: =>connection appinfo application=SIP SIP ALG session SIPALG: pool=138, in use=0, bottom=138 =>...

  • Page 101: Connection Applist

    Connection Commands connection applist List the available CONN/NAT application helpers. SYNTAX: connection applist EXAMPLE: =>connection applist Application Proto DefaultPort Traces Timeout IP6TO4 6to4 enabled unavailable PPTP 1723 enabled unavailable unavailable 15' 0" disabled 15' 0" FLOATING 5060 disabled 6 0" trace level 1 JABBER 5222...

  • Page 102: Connection Bind

    Connection Commands connection bind Create a new CONN/NAT application helper/port binding. SYNTAX: connection bind application = <string> port = <port-range> where: application The name of a CONN/NAT application helper. REQUIRED Use the command :connection applist to obtain a list of CONN/NAT application helpers.

  • Page 103: Connection Bindlist

    Connection Commands connection bindlist List the current CONN/NAT application helper/port bindings. SYNTAX: connection bindlist EXAMPLE: =>connection bindlist Application Proto Portrange Flags LOOSE(UDP) JABBER 15222 JABBER 5222 6660-6669 H323 1720 1002 RTSP RAUDIO(PNA) 7070 CU/SeeMe 7648 5060 PPTP 1723 IP6TO4 6to4 =>...

  • Page 104: Connection Clean

    Connection Commands connection clean Clean the connection database by forcing timeouts. SYNTAX: connection clean [level = <number{0-9}>] where: level A number between 0 and 9. OPTIONAL Represents the desired scrubbing level. EXAMPLE: =>connection list proto state substate flags timeout ----- ----- -------- ----- -------...

  • Page 105: Connection Clear

    Connection Commands connection clear Kill all the connections. SYNTAX: connection clear EXAMPLE: =>connection clear Connection to host lost. E-DOC-CTC-20060414-0006 v1.0...

  • Page 106: Connection Config

    Connection Commands connection config Configure the connection handling. SYNTAX: connection config [configchangemode = <{immediate | delayed}>] [probes = <{disabled | enabled}>] [udptrackmode = <{strict | loose}>] where: configchangemode Select how configuration changes are handled. OPTIONAL Choose between: immediate delayed. The default is immediate. probes Enable or disable live probes on idle connections.

  • Page 107: Connection Debug

    Connection Commands connection debug The connection debug commands SYNTAX: connection debug [trace = <{disabled|enabled}>] where: trace Enable or disable traces. OPTIONAL The default is disabled. EXAMPLE: =>connection debug connection traces : disabled => =>connection debug trace enabled => =>connection debug connection traces : enabled =>...

  • Page 108: Connection Describe

    Connection Commands connection describe Describe the streams of a connection. SYNTAX: connection describe [id = <number{0-2048}>] where: A number between 0 and 2048. OPTIONAL Represents the ID of the connection to be described. Note If not specified, the connection with ID 0 will be described. Use the command :connection list to obtain the IDs of the different connections.

  • Page 109: Connection Flush

    Connection Commands connection flush Flush the current connection configuration. SYNTAX: connection flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 110: Connection Info

    Connection Commands connection info Show all the registered modules with some info. SYNTAX: connection info EXAMPLE: =>connection info Registered connection modules : - Module : FW, holds private data (F:10264 S:6592). - Module : IDS, holds private data (F:0 S:0). - Module : NAT, holds private data (F:0 S:0).

  • Page 111: Connection List

    Connection Commands connection list Display the currently known connections. SYNTAX: connection list [nr = <number{1-2048}>] [history = <{disabled|enabled}>] where: A number between 1 and 2048. OPTIONAL Represents the number of connections to be displayed. Note If not specified, all the connections will be displayed. history Enable or disable history display.

  • Page 112: Connection Refresh

    Connection Commands connection refresh Invalidate all the cached decisions. SYNTAX: connection refresh E-DOC-CTC-20060414-0006 v1.0...

  • Page 113: Connection Stats

    Connection Commands connection stats Display the connection and stream statistics. SYNTAX: connection stats EXAMPLE: =>connection stats Connection statistics: ------------------------------------------- Maximum number of connections : 1024 Maximum number of halfopen connections : 1024 ------------------------------------------- Number of active connections Number of halfopen connections Number of expected connections Number of closing connections Number of idle connections...

  • Page 114: Connection Timerclear

    Connection Commands connection timerclear Clear the connection timeout to default. SYNTAX: connection timerclear [timer = <{tcpidle|tcpneg|tcpkill|udpidle|udpkill| icmpkill|ipidle|ipkill}>] where: timer The name of the connection idle timer to be reset. REQUIRED Note If not specified, all the timers will be reset to their default values. EXAMPLE: =>connection timerconfig tcpidle...

  • Page 115: Connection Timerconfig

    Connection Commands connection timerconfig Configure the connection timeout handling. SYNTAX: connection timerconfig [timer = <{tcpidle|tcpneg|tcpkill|udpidle|udpkill| icmpkill|ipidle|ipkill}>] [value = <number{0-86400}>] where: timer The name of the connection idle timer to be configured. OPTIONAL Choose between: tcpidle tcpneg tcpkill udpidle udpkill icmpkill ipidle ipkill value...

  • Page 116: Connection Unbind

    Connection Commands connection unbind Delete an existing CONN/NAT application helper/port binding. SYNTAX: connection unbind application = <string> port = <port-range> where: application The name of a CONN/NAT application helper. REQUIRED Use the command :connection applist to obtain a list of CONN/NAT application helpers.

  • Page 117: Cwmp Commands

    CWMP Commands CWMP Commands Introduction This chapter describes the commands of the cwmp (CPE WAN Management Protocol) command group. Contents This chapter covers the following commands: cwmp config Configure the cwmpd as seen from the ACS. cwmp debug traceconfig Enable or disable tracing. cwmp server config Configure the cwmpd towards the ACS.

  • Page 118: Cwmp Config

    CWMP Commands cwmp config Configure the cwmpd as seen from the ACS. SYNTAX: cwmp config [state = <{disabled|enabled}>] [mode = <{readonly|full}>] [periodicInform = <{disabled|enabled}>] [periodicInfInt = <number>] [sessionTimeout = <number>] [noIpTimeout = <number>] [maxEnvelopes = <number>] [connectionRequest = <{disabled|enabled}>] [connectionReqPath = <string>] [connectionReqUserName = <string>] [connectionReqPsswd = <string>] [connectionReqAuth = <{none|basic|digest}>]...
  • Page 119 CWMP Commands connectionRequest Set the connection request flag of the cwmp daemon. OPTIONAL Choose between: enabled disabled. The default is enabled. connectionReqPath Set the path where the cwmp daemon can be reached. OPTIONAL connectionReqUserName Set the username the ACS must use to log in. OPTIONAL connectionReqPsswd Set the password the ACS must use to log in.

  • Page 120: Cwmp Debug Traceconfig

    CWMP Commands cwmp debug traceconfig Enable or disable tracing. SYNTAX: cwmp debug traceconfig [level = <number>] where: level Set the tracelevel. Choose a higher level for more detailed tracing. OPTIONAL E-DOC-CTC-20060414-0006 v1.0...

  • Page 121: Cwmp Server Config

    CWMP Commands cwmp server config Configure the cwmpd towards the ACS. SYNTAX: cwmp server config [url = <string>] [username = <string>] [password = <string>] where: Set the HTTP URL used to contact the ACS server. OPTIONAL username Set the username for ACS Digest Authentication. OPTIONAL password Set the password for ACS Digest Authentication.
  • Page 122 CWMP Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 123: Debug Commands

    Debug Commands Debug Commands Introduction This chapter describes the commands of the debug command group. Contents This chapter covers the following commands: debug exec Execute a 'Trace & Debug' command. E-DOC-CTC-20060414-0006 v1.0...

  • Page 124: Debug Exec

    Debug Commands debug exec Execute a 'Trace & Debug' command. This command is for qualified personnel only. SYNTAX: debug exec cmd = <quoted string> where: A quoted 'Trace & Debug' command string. REQUIRED E-DOC-CTC-20060414-0006 v1.0...

  • Page 125: Dhcp Commands

    DHCP Commands DHCP Commands Introduction This chapter describes the commands of the Dynamic Host Configuration Protocol (DHCP) command group. Contents This chapter covers the following commands: dhcp client flush Delete all the DHCP leases. dhcp client ifadd Create a DHCP client. dhcp client ifattach Activate a DHCP client.
  • Page 126 DHCP Commands dhcp relay ruledelete Delete a selection rule from a DHCP forward entry. dhcp rule add Add a rule for DHCP conditional selection. dhcp rule debug traceconfig Modify DHCP rule trace configuration. dhcp rule delete Delete a DHCP rule. dhcp rule flush Flush all DHCP rules.

  • Page 127: Dhcp Client Flush

    DHCP Commands dhcp client flush Delete all the DHCP leases. The flush command does not impact previously saved configurations. SYNTAX: dhcp client flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 128: Dhcp Client Ifadd

    DHCP Commands dhcp client ifadd Create a DHCP client. SYNTAX: dhcp client ifadd intf = <string> [defrqoptions = <{disabled|enabled}>] where: intf The name of the dynamic interface for which a DHCP lease must be created. REQUIRED defrqoptions Enable/Disable the creation of the default Parameter Request List. OPTIONAL EXAMPLE: =>dhcp client iflist...

  • Page 129: Dhcp Client Ifattach

    =>dhcp client iflist myPPP_ppp : [INIT] flags = bc dns rt IP address : 0.0.0.0 HW address [SpeedTouch] : 00 DHCP server: 255.255.255.255 metric : rt = 1, DNS = 1 Number of leases: 1 Total size of table: 36, in use: 1, free: 97 % =>dhcp client ifattach intf=myPPP_ppp...

  • Page 130: Dhcp Client Ifconfig

    DHCP Commands dhcp client ifconfig Configure a DHCP client. Use the command :dhcp client ifrelease before configuring the dhcp client. SYNTAX: dhcp client ifconfig intf = <string> [label = <label name>] [metric = <number{0-255}>] [dnsmetric = <number{0-100}>] [broadcast = <{disabled|enabled}>] where: intf The name of the dynamic interface to be configured.

  • Page 131: Dhcp Client Ifdelete

    EXAMPLE: =>dhcp client iflist myPPP_ppp : [INIT] flags = bc dns rt IP address : 10.0.0.1 HW address [SpeedTouch] : 00:90:d0:01:47:f1 DHCP server: 10.10.1.1 hostname : myHostName client identifier : [00] myClientID user class identifier : myUserID metric : rt = 1, DNS = 1...

  • Page 132: Dhcp Client Ifdetach

    DHCP Commands dhcp client ifdetach De-activate a DHCP client and releases its lease. SYNTAX: ifdetach intf = <string> where: intf The name of the dynamic interface. REQUIRED RELATED COMMANDS: dhcp client ifattach Activate a DHCP client. dhcp client ifrenew Renew the DHCP lease. dhcp client iflist List all the DHCP leases attached to dynamic interfaces.

  • Page 133: Dhcp Client Iflist

    Total size of table: 36, in use: 1, free: 97 % => EXAMPLE INPUT/OUTPUT IN A NETWORKED ENVIRONMENT: The SpeedTouch™ is configured as DHCP client disabled its Ethernet interface eth0. =>dhcp client iflist myPPP_ppp : [INIT] flags = bc dns rt IP address : 10.0.0.1...
  • Page 134 DHCP Commands dhcp client ifdelete Delete a DHCP client. E-DOC-CTC-20060414-0006 v1.0...

  • Page 135: Dhcp Client Ifrenew

    DHCP Commands dhcp client ifrenew Renew the DHCP lease. SYNTAX: dhcp client ifrenew intf = <string> where: intf The name of the dynamic interface for which the DHCP lease must be renewed. REQUIRED EXAMPLE 1: =>dhcp client iflist NewETHoA [BOUND] flags= IP address 10.0.0.10...
  • Page 136 DHCP Commands EXAMPLE 2: The SpeedTouch™ is configured as DHCP client disabled its Ethernet interface eth0. =>dhcp client stats DHCP client statistics: Corrupted packet recv OFFERs recv ACKs recv NAKs recv Pure BOOTP REPLIES Other message types DISCOVERs sent REQUESTs sent...

  • Page 137: Dhcp Client Debug Clear

    DHCP Commands dhcp client debug clear Clear the DHCP client statistics. SYNTAX: dhcp client debug clear EXAMPLE: =>dhcp client debug stats DHCP client statistics: Corrupted packet recv OFFERs recv ACKs recv NAKs recv Pure BOOTP REPLIES Other message types DISCOVERs sent REQUESTs sent DECLINEs sent RELEASEs...

  • Page 138: Dhcp Client Debug Stats

    DHCP Commands dhcp client debug stats Print the DHCP client statistics. SYNTAX: dhcp client debug stats EXAMPLE: =>dhcp client debug stats DHCP client statistics: Corrupted packet recv OFFERs recv ACKs recv NAKs recv Pure BOOTP REPLIES Other message types DISCOVERs sent REQUESTs sent DECLINEs sent RELEASEs...

  • Page 139: Dhcp Client Debug Traceconfig

    DHCP Commands dhcp client debug traceconfig Modify the DHCP client trace configuration. SYNTAX: dhcp client debug traceconfig [state = <{disabled | enabled}>] where: state Enable or disable tracing. OPTIONAL The default is disabled. EXAMPLE: =>dhcp client debug traceconfig tracing: disabled =>dhcp client debug traceconfig trace=enabled =>dhcp client debug traceconfig tracing: enabled...

  • Page 140: Dhcp Client Rqoptions Add

    DHCP Commands dhcp client rqoptions add Add a DHCP Option Code to the Parameter Request List. SYNTAX: dhcp client rqoptions add intf = <string> option = <string or number> [index = <number{0-255}>] where: intf The name of the dynamic interface. REQUIRED option The name or number of the option.

  • Page 141: Dhcp Client Rqoptions Delete

    DHCP Commands dhcp client rqoptions delete Delete a DHCP Option Code from the Parameter Request List. SYNTAX: dhcp client rqoptions delete intf = <string> option = <string or number> where: intf The name of the dynamic interface. REQUIRED option The name or number of the option. OPTIONAL RELATED COMMANDS: dhcp client rqoptions list...

  • Page 142: Dhcp Client Rqoptions List

    DHCP Commands dhcp client rqoptions list List all DHCP Option Codes in the Parameter Request List. SYNTAX: dhcp client rqoptions list [intf = <string>] where: intf The name of the dynamic interface. OPTIONAL RELATED COMMANDS: dhcp client rqoptions delete Delete a DHCP Option Code from the Parameter Request List. E-DOC-CTC-20060414-0006 v1.0...

  • Page 143: Dhcp Client Rqoptions Optionlist

    DHCP Commands dhcp client rqoptions optionlist List all DHCP Option Codes that can be used in the Parameter Request List. SYNTAX: dhcp client rqoptions optionlist RELATED COMMANDS: dhcp client rqoptions Add a DHCP Option Code to the Parameter Request List. dhcp client rqoptions List all DHCP Option Codes in the Parameter Request List.

  • Page 144: Dhcp Client Txoptions Add

    DHCP Commands dhcp client txoptions add Add an option. SYNTAX: dhcp client txoptions add intf = <string> option = <string or number> value = <Value : (type)value; type being 8-bit, 16-bit, 32-bit, addr, ascii, byte_array, clientid> [index = <number{0-255}>] where: intf The name of the dynamic interface.

  • Page 145: Dhcp Client Txoptions Delete

    DHCP Commands dhcp client txoptions delete Delete an option. SYNTAX: dhcp client txoptions delete intf = <string> option = <string or number> where: intf The name of the dynamic interface. REQUIRED option The name or number of the option. REQUIRED RELATED COMMANDS: dhcp client txoptions list List all options.

  • Page 146: Dhcp Client Txoptions List

    DHCP Commands dhcp client txoptions list List all options. SYNTAX: dhcp client txoptions list RELATED COMMANDS: dhcp client txoptions delete Delete an option. E-DOC-CTC-20060414-0006 v1.0...

  • Page 147: Dhcp Client Txoptions Optionlist

    DHCP Commands dhcp client txoptions optionlist Lists all DHCP Option Codes that can be used. SYNTAX: dhcp client txoptions optionlist RELATED COMMANDS: dhcp client txoptions add Add an option. dhcp client txoptions list List all options. E-DOC-CTC-20060414-0006 v1.0...

  • Page 148: Dhcp Relay Add

    DHCP Commands dhcp relay add Add an entry to the DHCP forward list. SYNTAX: dhcp relay add name = <string> where: name The forward entry name. REQUIRED RELATED COMMANDS: dhcp relay delete Delete an entry from the DHCP forward list. dhcp relay list List the DHCP forward list.

  • Page 149: Dhcp Relay Debug Stats

    DHCP Commands dhcp relay debug stats Show the DHCP relay statistics. SYNTAX: dhcp relay debug stats EXAMPLE: =>dhcp relay debug stats DHCP relay statistics ------------------------- Client packet relayed Server packet relayed Bogus relay agent Bogus giaddr recv Corrupt agent option Missing agent option Bad circuit id Missing circuit id...

  • Page 150: Dhcp Relay Debug Traceconfig

    DHCP Commands dhcp relay debug traceconfig Modify the DHCP relay trace configuration. SYNTAX: dhcp relay debug traceconfig [state = <{disabled | enabled}>] where: state Enable or disable tracing. OPTIONAL The default is disabled. EXAMPLE: =>dhcp relay debug traceconfig Tracing: disabled =>...

  • Page 151: Dhcp Relay Config

    DHCP Commands dhcp relay config Set the DHCP relay configuration settings. SYNTAX: dhcp relay config [agentinfo = <{disabled | enabled}>] [agentmismatch = <{disabled | enabled}>] where: agentinfo Set the relay agent info status (RFC3046) enabled or disabled. OPTIONAL The default is disabled. agentmismatch Forward/drop DHCP reply packet when a relay agent info mismatch is OPTIONAL...

  • Page 152: Dhcp Relay Delete

    DHCP Commands dhcp relay delete Delete an entry from the DHCP forward list. SYNTAX: dhcp relay delete name = <string> where: name The forward entry name. REQUIRED EXAMPLE: =>dhcp relay delete name = lan1_to_127.0.0.1 :dhcp relay delete name=lan1_to_127.0.0.1 => RELATED COMMANDS: dhcp relay add Add an entry to the DHCP forward list.

  • Page 153: Dhcp Relay Flush

    DHCP Commands dhcp relay flush Flush the DHCP relay settings. The flush command does not impact previously saved configurations. SYNTAX: dhcp relay flush EXAMPLE: =>dhcp relay list DHCP server Interface giaddr ------------------------------------------------------- 127.0.0.1 eth0 192.168.1.254 =>dhcp relay flush =>dhcp relay list No dynamic interfaces defined.

  • Page 154: Dhcp Relay Ifconfig

    DHCP Commands dhcp relay ifconfig Configure a DHCP relay interface. SYNTAX: dhcp relay ifconfig intf = <string> [relay = <{disabled | enabled}>] [maxhops = <number{0-16}>] [remoteid = <password>] [trusted = <{disabled | enabled}>] where: intf The name of the dynamic interface to be configured. REQUIRED relay Set the relay status to enabled or disabled.
  • Page 155 DHCP Commands EXAMPLE: =>dhcp relay iflist eth0 : admin state = up oper state = up max hops = 4 trusted = disabled remote id = Internet_trigger : admin state = down oper state = down max hops = 4 trusted = disabled remote id = Internet :...

  • Page 156: Dhcp Relay Iflist

    DHCP Commands dhcp relay iflist Show the configuration of the relay interfaces. SYNTAX: dhcp relay iflist [intf = <string>] where: intf The name of the dynamic interface to be listed. OPTIONAL Note If not specified, all the relay interfaces will be shown. EXAMPLE: =>dhcp relay iflist eth0 :...

  • Page 157: Dhcp Relay List

    DHCP Commands dhcp relay list List the DHCP forward list. SYNTAX: dhcp relay list [name = <string>] where: name The forward entry name. OPTIONAL EXAMPLE: =>dhcp relay list DHCP server Interface giaddr ------------------------------------------------------- 127.0.0.1 eth0 10.0.0.138 => RELATED COMMANDS: dhcp relay add Add an entry to the DHCP forward list.

  • Page 158: Dhcp Relay Modify

    DHCP Commands dhcp relay modify Modify an entry from the DHCP forward list. SYNTAX: dhcp relay modify name = <string> [addr = <ip-address>] [intf = <{None | guest1 | dmz1 | wan1 | lan1 | Internet}>] [giaddr = <ip-address>] [script = <>] where: name The forward entry name.

  • Page 159: Dhcp Relay Ruleadd

    DHCP Commands dhcp relay ruleadd Add a selection rule to a DHCP forward entry. SYNTAX: dhcp relay ruleadd name = <string> [key = <{or | and}>] rulename = <string> where: name The name of the forward entry. REQUIRED The logical key of the selection rule. OPTIONAL The default is or.

  • Page 160: Dhcp Relay Ruledelete

    DHCP Commands dhcp relay ruledelete Delete a selection rule from a DHCP forward entry. SYNTAX: dhcp relay ruledelete name = <string> rulename = <string> where: name The name of the forward entry. REQUIRED rulename The name of the DHCP selection rule. REQUIRED RELATED COMMANDS: dhcp relay ruleadd...

  • Page 161: Dhcp Rule Add

    DHCP Commands dhcp rule add Add a rule for DHCP conditional selection. SYNTAX: dhcp rule add name = <string> type = <{vci | uci | mac}> vci [!]= <quoted string> uci [!]= <quoted string> [match = <{exactly|as_substring}>] mac [!]= <hardware-address with wildcard | ex: '00:9f:aa:*:*:*'>...

  • Page 162: Dhcp Rule Debug Traceconfig

    DHCP Commands dhcp rule debug traceconfig Modify DHCP rule trace configuration. SYNTAX: dhcp rule debug traceconfig [state = {disabled | enabled}] where: state Set tracing to disabled or enabled. OPTIONAL The default is disabled. E-DOC-CTC-20060414-0006 v1.0...

  • Page 163: Dhcp Rule Delete

    DHCP Commands dhcp rule delete Delete a DHCP rule. SYNTAX: dhcp rule delete name = <string> where: name The name of the DHCP rule. REQUIRED EXAMPLE: =>dhcp rule delete name = new :dhcp rule delete name=new => RELATED COMMANDS: dhcp rule add Add a rule for DHCP conditional selection.

  • Page 164: Dhcp Rule Flush

    DHCP Commands dhcp rule flush Flush all DHCP rules. SYNTAX: dhcp rule flush EXAMPLE: =>dhcp rule list Name Value vci=test =>dhcp rule flush =>dhcp rule list Name Value => RELATED COMMANDS: dhcp rule add Add a rule for DHCP conditional selection. dhcp rule delete Delete a DHCP rule.

  • Page 165: Dhcp Rule List

    DHCP Commands dhcp rule list List all DHCP rules. SYNTAX: dhcp rule list EXAMPLE: =>dhcp rule list Name Value vci=test => RELATED COMMANDS: dhcp rule add Add a rule for DHCP conditional selection. dhcp rule delete Delete a DHCP rule. dhcp rule flush Flush all DHCP rules.

  • Page 166: Dhcp Server Config

    DHCP Commands dhcp server config Print the DHCP server configuration settings. SYNTAX: dhcp server config [state = <{disabled | enabled}>] where: E-DOC-CTC-20060414-0006 v1.0...

  • Page 167: Dhcp Server Flush

    DHCP Commands dhcp server flush Flush all DHCP server pool and lease entries. The flush command does not impact previously saved configurations. SYNTAX: dhcp server flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 168: Dhcp Server Policy

    DHCP Commands dhcp server policy Print the DHCP server policy settings. SYNTAX: dhcp server policy [verifyfirst = <disabled | enabled>] [trustclient = <disabled | enabled>] where: E-DOC-CTC-20060414-0006 v1.0...

  • Page 169: Dhcp Server Debug Clear

    DHCP Commands dhcp server debug clear Clear the DHCP server statistics. SYNTAX: dhcp server debug clear EXAMPLE: =>dhcp server debug stats DHCP server state: Running DHCP server statistics: Corrupted packet recv DISCOVER 2451 REQUEST DECLINE RELEASE INFORM Pure BOOTP REQUESTS Other message types OFFERs sent 2451...

  • Page 170: Dhcp Server Debug Stats

    DHCP Commands dhcp server debug stats Show the DHCP server statistics. SYNTAX: dhcp server debug stats EXAMPLE: =>dhcp server stats DHCP Server State: Stopped DHCP server statistics: Corrupted packet recv DISCOVER 2451 REQUEST DECLINE RELEASE INFORM Pure BOOTP REQUESTS Other message types OFFERs sent 2451 ACKs sent...
  • Page 171 DHCP Commands Second DHCP server seen: whether a concurrent DHCP server was found disabled the LAN or not. RELATED COMMANDS: dhcp server debug clear Clear the DHCP server statistics. E-DOC-CTC-20060414-0006 v1.0...

  • Page 172: Dhcp Server Debug Traceconfig

    DHCP Commands dhcp server debug traceconfig Modify the DHCP server trace configuration. SYNTAX: dhcp server debug traceconfig [state = <{disabled | enabled}>] where: state Enable or disable tracing. OPTIONAL The default is disabled. EXAMPLE: =>dhcp server debug traceconfig Tracing: disabled =>...

  • Page 173: Dhcp Server Lease Add

    DHCP Commands dhcp server lease add Add a DHCP server lease. SYNTAX: dhcp server lease add clientid = <client-id> pool = <string> [addr = <ip-address>] [offset = <number>] [leasetime = <number>] [expirytime = <number>] [gateway = <ip-address>] [macaddr = <hardware-address>] where: clientid The DHCP client identification string of the booting host.
  • Page 174 DHCP Commands RELATED COMMANDS: dhcp server lease delete Delete a DHCP server lease. dhcp server lease list List all the DHCP server leases. E-DOC-CTC-20060414-0006 v1.0...

  • Page 175: Dhcp Server Lease Delete

    DHCP Commands dhcp server lease delete Delete a DHCP server lease. SYNTAX: dhcp server lease delete [clientid = <clientid | none>] [index = <number>] where: clientid The DHCP client identification string of the DHCP lease. OPTIONAL Note If not specified, all DHCP clients are deleted. index The DHCP server lease table index.

  • Page 176: Dhcp Server Lease Flush

    DHCP Commands dhcp server lease flush Flush all the DHCP server leases. The flush command does not impact previously saved configurations. SYNTAX: dhcp server lease flush [pool = <string>] where: pool The name of the DHCP server pool to be flushed. OPTIONAL Only the leases belonging to this pool will be deleted.

  • Page 177: Dhcp Server Lease List

    DHCP Commands dhcp server lease list List all the DHCP server leases. SYNTAX: dhcp server lease list [clientid = <clientid | none>] [index = <number>] where: clientid The DHCP client identification string of the DHCP lease. OPTIONAL Note If not specified, the DSHCP server leases for all the DHCP clients are listed. index The DHCP server lease table index.

  • Page 178: Dhcp Server Option Flush

    DHCP Commands dhcp server option flush Flush all DHCP server option templates and instances. The flush command does not impact previously saved configurations. SYNTAX: dhcp server option flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 179: Dhcp Server Option Instadd

    DHCP Commands dhcp server option instadd Add a DHCP server option instance. SYNTAX: dhcp server option instadd name = <string> tmplname = <string> value = <Value : (type)value; type being 8-bit, 16-bit, 32-bit, addr, ascii, byte_array> where: name The name of the DHCP server option instance. REQUIRED tmplname The name of the DHCP server option template.

  • Page 180: Dhcp Server Option Instdelete

    DHCP Commands dhcp server option instdelete Delete a DHCP server option instance. SYNTAX: dhcp server option instdelete name = <string> where: name The name of the DHCP server option instance to be deleted. REQUIRED EXAMPLE: =>dhcp server option instlist yourInstance Tmpl name : yourTmpl Value : (ascii)&#33...

  • Page 181: Dhcp Server Option Instlist

    DHCP Commands dhcp server option instlist List all the DHCP server option instances. SYNTAX: dhcp server option instlist EXAMPLE: =>dhcp server option instlist yourInstance Tmpl name : yourTmpl Value : (ascii)&#33 myInstance Tmpl name : myTmpl Value : (32-bit)64 => RELATED COMMANDS: dhcp server option instadd Add a DHCP server option instance.

  • Page 182: Dhcp Server Option Tmpladd

    DHCP Commands dhcp server option tmpladd Add a DHCP server option template. SYNTAX: dhcp server option tmpladd name = <string> optionid = <number{1-254}> type = <{8-bit | 16-bit | 32-bit | addr | ascii | byte_array}> where: name The name of the DHCP server option template. REQUIRED optionid A number between 1 and 254.

  • Page 183: Dhcp Server Option Tmpldelete

    DHCP Commands dhcp server option tmpldelete Delete a DHCP server option template. SYNTAX: dhcp server option tmpldelete name = <string> where: name The name of the DHCP server option template to be deleted. REQUIRED EXAMPLE: =>dhcp server option tmpllist Name Option Type yourTmpl...

  • Page 184: Dhcp Server Option Tmpllist

    DHCP Commands dhcp server option tmpllist List all the DHCP server option templates. SYNTAX: dhcp server option tmpllist EXAMPLE: =>dhcp server option tmpllist Name Option Type yourTmpl ascii myTmpl 32-bit => RELATED COMMANDS: dhcp server option tmpladd Add a DHCP server option template. dhcp server option tmpldelete Delete a DHCP server option template.

  • Page 185: Dhcp Server Pool Add

    DHCP Commands dhcp server pool add Add a DHCP server pool. SYNTAX: dhcp server pool add name = <string> [index = <number>] where: name The name of the DHCP server pool. REQUIRED Note If not specified, the name is “dhcp_pool_x”, where x is a subsequent number.

  • Page 186: Dhcp Server Pool Config

    The default value of this parameter is 0 (not specified), which means that the gateway IP address will be communicated by the remote server as soon as the PPP IPCP subnetmasking connection is established or that the SpeedTouch™ acts as the LAN default gateway.
  • Page 187 DNS server will be communicated by the remote server as soon as the PPP IPCP subnetmasking connection is established or that the SpeedTouch™ acts as the LAN DNS server. secdns The IP address of the optional secondary DNS server for DHCP clients.

  • Page 188: Dhcp Server Pool Delete

    DHCP Commands dhcp server pool delete Delete a DHCP server pool. SYNTAX: dhcp server pool delete name = <string> where: name The name of the DHCP server pool to be deleted. REQUIRED Use the command :dhcp server pool list to obtain a list of all current DHCP leases.

  • Page 189: Dhcp Server Pool Flush

    DHCP Commands dhcp server pool flush Flush all DHCP server pools. The flush command does not impact previously saved configurations. SYNTAX: dhcp server pool flush EXAMPLE: =>dhcp server pool list Pool Start Intf State 0 LAN_Private 10.0.0.1 10.0.0.254 eth0 USED 1 My_Pool 192.6.11.101 192.6.11.254...

  • Page 190: Dhcp Server Pool List

    DHCP Commands dhcp server pool list List all DHCP server pools. SYNTAX: dhcp server pool list [name = <string>] where: name The name of the DHCP server pool to be shown. OPTIONAL Note If not specified, all the DHCP server pools are shown. EXAMPLE: =>dhcp server pool list Pool...

  • Page 191: Dhcp Server Pool Optadd

    DHCP Commands dhcp server pool optadd Add an option instance to the DHCP server pool. SYNTAX: dhcp server pool optadd name = <string> instname = <string> where: name The name of the DHCP server pool to which an option instance must be added. REQUIRED instname The name of the DHCP server option instance.

  • Page 192: Dhcp Server Pool Optdelete

    DHCP Commands dhcp server pool optdelete Delete an option instance from the DHCP server pool. SYNTAX: dhcp server pool optdelete name = <string> instname = <string> where: name The name of the DHCP server pool from which an option instance must be deleted. REQUIRED instname The name of the DHCP server option instance to be deleted.

  • Page 193: Dhcp Server Pool Rtadd

    DHCP Commands dhcp server pool rtadd Add a route to the DHCP server pool. SYNTAX: dhcp server pool rtadd name = <string> dst = <ip-address> [dstmsk = <ip-mask(dotted or cidr)>] [gateway = <ipaddress | 0>] where: name The name of the DHCP server pool to which a route must be added. REQUIRED The IP destination address of the route for DHCP clients.

  • Page 194: Dhcp Server Pool Rtdelete

    DHCP Commands dhcp server pool rtdelete Delete a route from the DHCP server pool. SYNTAX: dhcp server pool rtdelete name = <string> dst = <ip-address> [dstmsk = <ip-mask(dotted or cidr)>] [gateway = <ipaddress | 0>] where: name The name of the DHCP server pool from which a route must be deleted. REQUIRED The IP destination address of the route for DHCP clients.

  • Page 195: Dhcp Server Pool Ruleadd

    DHCP Commands dhcp server pool ruleadd Add a selection rule to the DHCP server pool. SYNTAX: dhcp server pool ruleadd name = <string> [key = {or | and}] rulename = <string> where: name The name of the DHCP server pool to which a selection rule must be added. REQUIRED The logical key of the selection rule.

  • Page 196: Dhcp Server Pool Ruledelete

    DHCP Commands dhcp server pool ruledelete Delete a selection rule from the DHCP server pool. SYNTAX: dhcp server pool ruleadd name = <string> rulename = <string> where: name The name of the DHCP server pool from which a selection rule must be deleted. REQUIRED rulename The name of the DHCP selection rule to be deleted.

  • Page 197: Dns Commands

    DNS Commands DNS Commands Introduction This chapter describes the commands of the dns command group. Contents This chapter covers the following commands: dns client config Modify the Domain Name System (DNS) resolver configuration. dns client dnsadd Add a DNS server. dns client dnsdelete Delete a DNS server.

  • Page 198: Dns Client Config

    DNS Commands dns client config Modify the Domain Name System (DNS) resolver configuration. SYNTAX: dns client config [timeout = <number{1-900}>] [retry = <number{0-10}>] [search = <{disabled | enabled}>] [list = <string>] [trace = <{disabled | enabled}>] where: timeout A number between 1 and 900 (seconds). OPTIONAL Represents the query timeout.

  • Page 199: Dns Client Dnsadd

    DNS Commands dns client dnsadd Add a DNS server. SYNTAX: dns client dnsadd addr = <string> [port = <number>] where: addr The IP address of the DNS server to be added. REQUIRED port The DNS server port number. OPTIONAL The default is 53. EXAMPLE: =>dns client dnsadd addr=150.150.150.150 =>dns client dnslist...

  • Page 200: Dns Client Dnsdelete

    DNS Commands dns client dnsdelete Delete a DNS server. SYNTAX: dns client dnsdelete index = <number{1-99}> where: index A number between 1 and 99. REQUIRED Represents the index number of the DNS server to be deleted. Use the command :dns client dnslist to obtain a list of DNS servers. EXAMPLE: =>dns client dnslist Entry...

  • Page 201: Dns Client Dnslist

    DNS Commands dns client dnslist List all DNS servers. SYNTAX: dns client dnslist EXAMPLE: =>dns client dnslist Entry State Family Server CONNECTED [port] 53 - [addr] 127.0.0.1 CONNECTED [port] 53 - [addr] 150.150.150.150 => RELATED COMMANDS: dns client dnsadd Add a DNS server. dns client dnsdelete Delete a DNS server.

  • Page 202: Dns Client Flush

    DNS Commands dns client flush Remove all DNS servers. SYNTAX: dns client flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 203: Dns Client Nslookup

    DNS Commands dns client nslookup DNS lookup for a domain name or an address. SYNTAX: dns client nslookup host = <string> where: host The DNS domain name string for which to query. REQUIRED E-DOC-CTC-20060414-0006 v1.0...

  • Page 204: Dns Server Config

    DNS Commands dns server config Modify the DNS resolver configuration. SYNTAX: dns server config [domain = <string>] [timeout = <number{0-2147483647}>] [suppress = <number>] [state = <{disabled | enabled}>] [trace = <{disabled | enabled}>] [WANDownSpoofing = <{disabled | enabled}>] [WDSpoofedIP = <ip-address>] where: domain The DNS server domain name.

  • Page 205: Dns Server Flush

    DNS Commands dns server flush Flush all local DNS hosts and routes. SYNTAX: dns server flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 206: Dns Server Debug Clear

    DNS Commands dns server debug clear Clear the DNS server/forwarder statistics. SYNTAX: dns server debug clear EXAMPLE: =>dns server debug stats Corrupted packets received Local questions resolved Local negative answers sent Total DNS packets forwarded External answers received Spoofed responses Forward table full, discard Spurious answers Unknown query types...

  • Page 207: Dns Server Debug Stats

    DNS Commands dns server debug stats Print the DNS server/forwarder statistics. SYNTAX: dns server debug stats EXAMPLE: =>dns server debug stats Corrupted packets received Local questions resolved Local negative answers sent Total DNS packets forwarded External answers received Spoofed responses Forward table full, discard Spurious answers Unknown query types...

  • Page 208: Dns Server Debug Spoof Clear

    DNS Commands dns server debug spoof clear Clear the intercept cache table SYNTAX: dns server debug spoof clear RELATED COMMANDS: dns server debug spoof Get the real ip for the given spoofed ip getaddress dns server debug spoof Get the error flags for the given spoofed ip getflags dns server debug spoof List the intercept cache table.

  • Page 209: Dns Server Debug Spoof Getaddress

    DNS Commands dns server debug spoof getaddress Get the real ip for the given spoofed ip SYNTAX: dns server debug addr = <ip-address> spoof getaddress where: addr The IP address of the spoofed server. REQUIRED EXAMPLE: {Administrator}=>dns server debug spoof getaddress addr=198.18.1.1 :dns server debug spoof getaddress addr=198.18.1.1 Resolved ip = 0.0.0.0.

  • Page 210: Dns Server Debug Spoof Getflags

    DNS Commands dns server debug spoof getflags Get the error flags for the given spoofed ip SYNTAX: dns server debug addr = <ip-address> spoof getflags where: addr The IP address of the spoofed server. REQUIRED EXAMPLE: {Administrator}[dns server debug spoof]=>:dns server debug spoof getflags addr = 192.168.1.254 :dns server debug spoof getflags addr=192.168.1.254 Invalid spoofed ip.

  • Page 211: Dns Server Debug Spoof List

    DNS Commands dns server debug spoof list List the intercept cache table. SYNTAX: dsn server debug spoof list EXAMPLE: {Administrator}[dns server debug spoof]=>list Spoof IP FQDN Real IP Flags 198.18.1.1 eu.thmulti.com 0.0.0.0 Not resolved 198.18.1.2 thmulti.com 0.0.0.0 Not resolved 198.18.1.3 0.0.0.0 Not resolved 198.18.1.4...

  • Page 212: Dns Server Debug Spoof Update

    DNS Commands dns server debug spoof update Update the intercept cache table. SYNTAX: dns server debug spoof update EXAMPLE: {Administrator}=>dns server debug spoof update {Administrator}=> RELATED COMMANDS: dns server debug spoof Clear the intercept cache table clear dns server debug spoof Get the real ip for the given spoofed ip getaddress dns server debug spoof...

  • Page 213: Dns Server Host Add

    =>dns server host add name=myDNS addr=150.150.150.150 ttl=3600 =>dns server host list Address Hostname TTL (s) 150.150.150.150 myDNS 3600 <local> speedtouch <local> dsldevice => RELATED COMMANDS: dns server host delete Delete a local DNS host. dns server host list List all the local DNS hosts.

  • Page 214: Dns Server Host Delete

    The name of the DNS host to be deleted. REQUIRED EXAMPLE: =>dns server host list Address Hostname TTL (s) 150.150.150.150 myDNS 3600 <local> speedtouch <local> dsldevice =>dns server host delete name=myDNS =>dns server host list Address Hostname TTL (s) <local> speedtouch <local>...

  • Page 215: Dns Server Host Flush

    Flush all the local DNS hosts. SYNTAX: dns server host flush EXAMPLE: =>dns server host list Address Hostname TTL (s) 192.168.1.64 * Unknown-00-10-a4-ad-32-cf <local> dsldevice 1200 <local> speedtouch 1200 =>dns server host flush =>dns server host list => E-DOC-CTC-20060414-0006 v1.0...

  • Page 216: Dns Server Host List

    =>dns server host list Address Hostname TTL (s) 192.168.1.64 * Unknown-00-10-a4-ad-32-cf <local> dsldevice 1200 <local> speedtouch 1200 => RELATED COMMANDS: dns server host add Add a local DNS host. dns server host delete Delete a local DNS host. E-DOC-CTC-20060414-0006 v1.0...

  • Page 217: Dns Server Route Add

    DNS Commands dns server route add Adds a DNS forwarding route. SYNTAX: dns server route add dns = <ip-address> [src = <ip-address>] [srcmask = <ip-mask(dotted or cidr)>] [domain = <string>] [metric = <number{0-100}>] [intf = <string>] where: The IP address of a DNS server. REQUIRED The source IP address(es) using this remote DNS server.

  • Page 218: Dns Server Route Delete

    DNS Commands dns server route delete Delete a DNS forwarding route. SYNTAX: dns server route delete dns = <ip-address> where: The IP address of the DNS server for which the forwarding route must be deleted. REQUIRED EXAMPLE: =>dns server route list DNS Server Source Domain...

  • Page 219: Dns Server Route Flush

    DNS Commands dns server route flush Flush all DNS forwarding routes. SYNTAX: dns server route flush EXAMPLE: =>dns server route list DNS Server Source Domain Metric Intf State 150.150.150.150 10.0.0.0/8 myDNS eth0 =>dns server route flush =>dns server route list =>...

  • Page 220: Dns Server Route List

    DNS Commands dns server route list List all the DNS forwarding routes. SYNTAX: dns server route list EXAMPLE: =>dns server route list DNS Server Source Domain Metric Intf State 150.150.150.150 10.0.0.0/8 myDNS eth0 => RELATED COMMANDS: dns server route add Adds a DNS forwarding route.

  • Page 221: Dsd Commands

    DSD Commands DSD Commands Introduction This chapter describes the commands of the dsd command group. Contents This chapter covers the following commands: dsd config Display/modify the Differentiated Service Delivery (DSD) framework configuration. dsd debug config Display/modify DSD debug settings dsd debug connection list Display the internal connection pool usage.

  • Page 222: Dsd Config

    DSD Commands dsd config Display/modify the Differentiated Service Delivery (DSD) framework configuration. SYNTAX: dsd config [state = <{disabled | enabled | automatic}>] where: state Choose between: OPTIONAL automatic (default): By default (DSD config state is automatic), the DSD framework is not active, for example no URL filtering or web site filtering is applied.

  • Page 223: Dsd Debug Config

    DSD Commands dsd debug config Display/modify DSD debug settings SYNTAX: config [turbomode = <{disabled|enabled}>] where: turbomode Enable/disable turbomode OPTIONAL E-DOC-CTC-20060414-0006 v1.0...

  • Page 224: Dsd Debug Connection List

    DSD Commands dsd debug connection list Display the internal connection pool usage. SYNTAX: dsd debug connection list [expand = <{disabled|enabled}>] where: expand Enable or disable the expanded listing. optional The default is disabled. E-DOC-CTC-20060414-0006 v1.0...

  • Page 225: Dsd Debug Proxy

    DSD Commands dsd debug proxy Display/modify the HyperText Transfer Protocol (HTTP) Intercept fixed proxy configuration. SYNTAX: dsd debug proxy [state = <{disabled | enabled}>] [dest = <ip-address>] [port = <{supported TCP/UDP port} or number>] where: state Enable or disable fixed proxy redirecting. OPTIONAL The default is disabled.

  • Page 226: Dsd Debug Recycling

    DSD Commands dsd debug recycling Display/modify HTTPI recycling settings SYNTAX: dsd debug recycling state = <disabled>|<enabled> interval = <number> httpidle = <number> otheridle = <number> where: state Enable/disable stream recycling OPTIONAL interval Time between successive activity checks OPTIONAL httpidle Minimal idle count for recycling (filtered) http streams OPTIONAL otheridle Minimal idle count for recycling other streams...

  • Page 227: Dsd Debug Stats

    DSD Commands dsd debug stats Display/clear DSD framework and module statistics SYNTAX: dsd debug stats name = <{intercept|urlfilter|recycling|syslog|all} clear = <{no|yes}> where: name Specify the name of a module REQUIRED clear Clear the specified statistics REQUIRED E-DOC-CTC-20060414-0006 v1.0...

  • Page 228: Dsd Intercept Config

    DSD Commands dsd intercept config Display/modify the HTTP Intercept configuration. SYNTAX: dsd intercept config [WDSpoofedIP = <ip-address>] [servertimeout = <number>] [servererrorurl = <string>] [categoryerrorurl = <string>] [monitorintercepturl = <string>] [urlblockedurl = <string>] [imageredirect = <{disabled | enabled}>] [imageredirecturl = <string>] [alwaysuseip = <{disabled | enabled}>] where: WDSpoofedIP...

  • Page 229: Dsd Syslog Config

    DSD Commands dsd syslog config Display/modify the HTTP Intercept logging configuration. SYNTAX: dsd syslog config [syslog = <{none | unauthorized | errors | intercepted | all}>] where: syslog Define the type of events to log. OPTIONAL Choose between: none: nothing is logged to syslog. unauthorized: only the HTTP requests that are blocked because of a LocalRule, BlockCategory, BlockIPAddress or BlockObscure event, are logged.

  • Page 230: Dsd Syslog List

    DSD Commands dsd syslog list Display the HTTP Intercept log file. SYNTAX: dsd syslog list EXAMPLE: =>dsd syslog list <86> SysUpTime: 00:22:37 [HTTPI] src=10.0.0.1 src_port=1965 dst=141.11.196.35 dst_port=80 event=Se rverConnect dst_name=aWebsite.com/icons/Button_Document.gif <86> SysUpTime: 00:22:59 [HTTPI] src=10.0.0.1 src_port=1968 dst=141.11.234.60 dst_port=80 event=Se rverConnect dst_name=anotherWebsite.com/rawgen.asp =>...

  • Page 231: Dsd Urlfilter Config

    DSD Commands dsd urlfilter config Display/modify the URL filtering configuration. SYNTAX: dsd urlfilter config [state = <{disabled | enabled}>] [blockproxy = <{disabled | enabled}>] [blockipaddress = <{disabled | enabled}>] [blockobscuredip = <{disabled | enabled}>] [defaultaction = <{block | accept}>] where: state Enable or disable URL filtering.

  • Page 232: Dsd Urlfilter Rule Add

    Choose between: block accept redirect. redirect The redirection URL. REQUIRED Note This parameter is only required when the action is redirect. EXAMPLE: =>dsd urlfilter rule add url=www.speedtouch.com action=redirect redirect=www.speedtouch.be =>dsd urlfilter rule list Index Action Redirect ----- ------ -------- redirect www.speedtouch.com www.speedtouch.be...

  • Page 233: Dsd Urlfilter Rule Delete

    OPTIONAL EXAMPLE: =>dsd urlfilter rule list Index Action Redirect ----- ------ -------- redirect www.speedtouch.com www.speedtouch.be accept www.baen.com Rule list statistics : 2 present, 128 total (0.0% used) =>dsd urlfilter rule delete index=1 =>dsd urlfilter rule list Index Action Redirect -----...

  • Page 234: Dsd Urlfilter Rule Flush

    EXAMPLE: =>dsd urlfilter rule list Index Action Redirect ----- ------ -------- redirect www.speedtouch.com www.speedtouch.be accept www.baen.com Rule list statistics : 2 present, 128 total (0.0% used) =>dsd urlfilter rule flush =>dsd urlfilter rule list Index Action Redirect...

  • Page 235: Dsd Urlfilter Rule List

    EXAMPLE: =>dsd urlfilter rule list Index Action Redirect ----- ------ -------- redirect www.speedtouch.com www.speedtouch.be accept www.baen.com Rule list statistics : 2 present, 128 total (0.0% used) => RELATED COMMANDS: dsd urlfilter rule add Add a rule. dsd urlfilter rule delete Delete a rule.

  • Page 236: Dsd Urlfilter Rule Modify

    Redirect ----- ------ -------- redirect www.speedtouch.com www.speedtouch.be accept www.baen.com Rule list statistics : 2 present, 128 total (0.0% used) =>dsd urlfilter rule modify index=0 newurl=www.speed*.* action=redirect redirect=www.speedtouch.be =>dsd urlfilter rule list Index Action Redirect ----- ------ -------- redirect www.speed*.* www.speedtouch.be accept www.baen.com...

  • Page 237: Dyndns Commands

    DynDNS Commands DynDNS Commands Introduction Dynamic DNS is a service that allows to bind a host name to an IP address. In contrast to classical DNS, this service allows regular updates of the IP address related to a host name. In this way, hosts of which the IP address regularly changes (for example due to a limited DHCP lease time) can be identified by a static host name that is unique throughout the Internet.

  • Page 238: Dyndns Add

    DynDNS Commands dyndns add Add a dynamic DNS client. SYNTAX: dyndns add name = <string> where: name The name of the new dynamic DNS client. REQUIRED Note A maximum of 5 clients can be configured. EXAMPLE: =>dyndns add name=WAN =>dyndns list [INIT] user = password =...

  • Page 239: Dyndns Delete

    DynDNS Commands dyndns delete Delete a dynamic DNS client. SYNTAX: dyndns delete name = <string> where: name The name of the dynamic DNS client to be deleted. REQUIRED EXAMPLE: =>dyndns list [INIT] user = password = addr = 0.0.0.0 =>dyndns delete name=WAN =>dyndns list =>...

  • Page 240: Dyndns Flush

    DynDNS Commands dyndns flush Delete all the dynamic DNS clients. SYNTAX: dyndns flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 241: Dyndns List

    DynDNS Commands dyndns list List all the dynamic DNS clients. SYNTAX: dyndns list EXAMPLE: =>dyndns list [INIT] user = password = addr = 0.0.0.0 => RELATED COMMANDS: dyndns add Add a dynamic DNS client. dyndns delete Delete a dynamic DNS client. E-DOC-CTC-20060414-0006 v1.0...

  • Page 242: Dyndns Modify

    DynDNS Commands dyndns modify Modify a dynamic DNS client. SYNTAX: dyndns modify name = <string> [intf = <string>] [user = <string>] [password = <password>] [group = <string>] [mx = <string>] [backmx = <{disabled | enabled}>] [wildcard = <{disabled | enabled}>] [offline = <{disabled | enabled}>] [service = <{dyndns | statdns | custom | No-IP | DtDNS | gnudip}>]...
  • Page 243 DynDNS Commands EXAMPLE: =>dyndns list [INIT] user = password = addr = 0.0.0.0 =>dyndns modify name=WAN intf=RtPPPoE user=DNSuser password=_DEV_BA8C0C963BD84130 service=gnudip =>dyndns list : RtPPPoE_ppp [INIT] options = gnudip user = my_DNS_user password = ******** addr = 0.0.0.0 => E-DOC-CTC-20060414-0006 v1.0...

  • Page 244: Dyndns Host Add

    DynDNS Commands dyndns host add Add a fully qualified host name. SYNTAX: dyndns host add group = <string> name = <string> where: group The dynamic DNS host group. REQUIRED Note A maximum of 4 different groups can be created. name The name of an IP host to add.

  • Page 245: Dyndns Host Delete

    DynDNS Commands dyndns host delete Delete a host name. SYNTAX: dyndns host delete name = <string> where: name The name of the IP host to be deleted. REQUIRED EXAMPLE: =>dyndns host list local : [ ] localhost.com public : [ ] publichost.com legend : not initialised update in progress...

  • Page 246: Dyndns Host Flush

    DynDNS Commands dyndns host flush Delete all hosts. The hosts cannot be flushed, if there is still a group referenced to the hosts. SYNTAX: dyndns host flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 247: Dyndns Host List

    DynDNS Commands dyndns host list List all host names. SYNTAX: dyndns host list EXAMPLE: =>dyndns host list local : [ ] localhost.com public : [ ] publichost.com legend : not initialised update in progress update successful error => RELATED COMMANDS: dyndns host add Add a fully qualified host name.

  • Page 248: Dyndns Service List

    DynDNS Commands dyndns service list List all dynamic DNS services. SYNTAX: dyndns service list EXAMPLE: =>dyndns service list dyndns server = members.dyndns.org port = 80 request = /nic/update update interval = 2097120 retry interval = 30 max retry statdns server = members.dyndns.org port = 80...

  • Page 249: Dyndns Service Modify

    DynDNS Commands dyndns service modify Modify specific dynamic DNS service settings. SYNTAX: dyndns service modify name = <string> [server = <string>] [port = <{supported TCP/UDP port name} or number>] [request = <string>] [updateinterval = <number{0-2097120}>] [retryinterval = <number{0-600}] [max_retry = <number{1-5}>] where: name The name of the dynamic DNS service.
  • Page 250 DynDNS Commands EXAMPLE: =>dyndns service modify name=custom server=mydyndns.org port=www-http request=hereiam updateinterval=2000000 retryinterval=15 max_retry=5 =>dyndns service list dyndns server = members.dyndns.org port = 80 request = /nic/update update interval = 2097120 retry interval = 30 max retry statdns server = members.dyndns.org port = 80 request...

  • Page 251: Env Commands

    Env Commands Env Commands Introduction This chapter describes the commands of the env command group. Contents This chapter covers the following commands: env flush Flush all the non-system environment variables. env get Get the current value of an environment variable. env list Show all the currently available environment variables.

  • Page 252: Env Flush

    Env Commands env flush Flush all the non-system environment variables. SYNTAX: env flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 253: Env Get

    = <string> where: The name of the environment variable. REQUIRED Use the command :env list to obtain a list of all environment variables. EXAMPLE: =>env get var=_PROD_FRIENDLY_NAME SpeedTouch v1.0 => RELATED COMMANDS: env list List all current environment variables. E-DOC-CTC-20060414-0006 v1.0...

  • Page 254: Env List

    Env Commands env list Show all the currently available environment variables. SYNTAX: env list RELATED COMMANDS: env get Get the current value of an environment variable. E-DOC-CTC-20060414-0006 v1.0...

  • Page 255: Env Set

    Env Commands env set Set an environment variable. SYNTAX: env set var = <string> value = <translated string> where: The name of the environment variable. REQUIRED When creating an environment variable, any name is allowed. However spaces are NOT allowed and the name may NOT start with: “CONF”...

  • Page 256: Env Unset

    The name of the environment variable to be deleted. REQUIRED Note System variables (built-in variables with names starting with an underscore “_”, “CONF” or “HOST”) cannot be unset, changed or deleted. EXAMPLE: =>env list _COMPANY_NAME=THOMSON multimedia _COMPANY_URL=http://www.speedtouch.com _PROD_NAME=SpeedTouch ..CONF_DATE=March 2004 CONF_REGION=World HOST_SETUP=user =>env unset var=CONF_REGION =>env list _COMPANY_NAME=THOMSON multimedia _COMPANY_URL=http://www.speedtouch.com...

  • Page 257: Eth Commands

    Eth Commands Eth Commands Introduction This chapter describes the commands of the eth command group. Contents This chapter covers the following commands: eth ifadd Create a new ETH interface. eth ifattach Attach an ETH interface. eth ifconfig Modify an ETH interface. eth ifdelete Delete an ETH interface.
  • Page 258 Eth Commands eth bridge vlan ifdelete Delete a bridge interface from a VLAN. eth bridge vlan iflist Display all VLANs. eth device ifconfig Configure an Ethernet interface. eth device iflist Show status of Ethernet interfaces. eth switch group flush Set all the ports to the default settings. eth switch group list List all the configured switch groups.

  • Page 259: Eth Ifadd

    Eth Commands eth ifadd Create a new ETH interface. SYNTAX: eth ifadd intf = <string> where: intf The name of the new ETH interface. REQUIRED RELATED COMMANDS: eth ifdelete Delete an ETH interface. eth iflist Display the ETH interfaces. E-DOC-CTC-20060414-0006 v1.0...

  • Page 260: Eth Ifattach

    Eth Commands eth ifattach Attach an ETH interface. SYNTAX: eth ifattach intf = <string> where: intf The name of the ETH interface to be attached. REQUIRED RELATED COMMANDS: eth ifdetach Detach an ETH interface. E-DOC-CTC-20060414-0006 v1.0...

  • Page 261: Eth Ifconfig

    Eth Commands eth ifconfig Modify an ETH interface. SYNTAX: eth ifconfig intf = <string> [dest = <string>] [retry = <number{0-65535}>] [vlan = <string>] where: intf The name of the ETH interface to be configured. REQUIRED dest The destination interface for this ETH interface. OPTIONAL retry A number between 0 and 65535.

  • Page 262: Eth Ifdelete

    Eth Commands eth ifdelete Delete an ETH interface. SYNTAX: eth ifdelete intf = <string> where: intf The name of the ETH interface name to be deleted. REQUIRED RELATED COMMANDS: eth ifadd Create a new ETH interface. eth iflist Display the ETH interfaces. E-DOC-CTC-20060414-0006 v1.0...

  • Page 263: Eth Ifdetach

    Eth Commands eth ifdetach Detach an ETH interface. SYNTAX: eth ifdetach intf = <string> where: intf The name of the ETH interface to be detached. REQUIRED RELATED COMMANDS: eth ifattach Attach an ETH interface. E-DOC-CTC-20060414-0006 v1.0...

  • Page 264: Eth Iflist

    Eth Commands eth iflist Display the ETH interfaces. SYNTAX: eth iflist [intf = <string>] where: intf The name of the ETH interface to be displayed. OPTIONAL Note If not specified, all the ETH interfaces will be displayed. RELATED COMMANDS: eth ifadd Create a new ETH interface.

  • Page 265: Eth Flush

    Eth Commands eth flush Flush all the ETH interfaces. The flush command does not impact previously saved configurations. SYNTAX: eth flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 266: Eth Bridge Clear

    Eth Commands eth bridge clear Clear the bridge statistics. SYNTAX: eth bridge clear E-DOC-CTC-20060414-0006 v1.0...

  • Page 267: Eth Bridge Config

    The bridge filter to be applied for all Wide Area Network (WAN) bridge ports. OPTIONAL Choose between: no_WAN_broadcast: broadcasts from the SpeedTouch™ itself to the WAN are filtered out, broadcasts from the LAN to the WAN are still passed through none: no broadcasts are filtered out.

  • Page 268: Eth Bridge Dynvlan Actlist

    Eth Commands eth bridge dynvlan actlist Display the active MAC entries for the dynamic VLAN membership. SYNTAX: eth bridge dynvlan actlist RELATED COMMANDS: eth bridge dynvlan add Add a dynamic VLAN membership entry. eth bridge dynvlan Modify the dynamic VLAN membership configuration. config eth bridge dynvlan Delete a dynamic VLAN membership entry.

  • Page 269: Eth Bridge Dynvlan Add

    Eth Commands eth bridge dynvlan add Add a dynamic VLAN membership entry. SYNTAX: eth bridge dynvlan add [id = <number{0-100000}>] hwaddr = <masked-hardware-address> vlan = <string> [remvlan = <{default}>] where: A number between 0 and 100000. OPTIONAL Represents the id of the dynamic VLAN membership entry. hwaddr The (masked) ethernet MAC address of the dynamic VLAN REQUIRED...

  • Page 270: Eth Bridge Dynvlan Config

    Eth Commands eth bridge dynvlan config Modify the dynamic VLAN membership configuration. SYNTAX: eth bridge dynvlan config [timeout = <number{0-100000}>] where: timeout A number between 0 and 100000 (seconds). OPTIONAL Represents timeout for the dynamic entries. RELATED COMMANDS: eth bridge dynvlan Display the active MAC entries for the dynamic VLAN membership.

  • Page 271: Eth Bridge Dynvlan Delete

    Eth Commands eth bridge dynvlan delete Delete a dynamic VLAN membership entry. SYNTAX: eth bridge dynvlan delete id = <number{0-100000}> where: A number between 0 and 100000. REQUIRED Represents the id of a dynamic VLAN membership. RELATED COMMANDS: eth bridge dynvlan Display the active MAC entries for the dynamic VLAN membership.

  • Page 272: Eth Bridge Dynvlan Flush

    Eth Commands eth bridge dynvlan flush Flush all dynamic VLAN membership entries. SYNTAX: eth bridge dynvlan flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 273: Eth Bridge Dynvlan List

    Eth Commands eth bridge dynvlan list Display a dynamic VLAN membership entry. SYNTAX: eth bridge dynvlan list RELATED COMMANDS: eth bridge dynvlan Display the active MAC entries for the dynamic VLAN membership. actlist eth bridge dynvlan add Add a dynamic VLAN membership entry. eth bridge dynvlan Modify the dynamic VLAN membership configuration.

  • Page 274: Eth Bridge Flush

    Eth Commands eth bridge flush Flush bridge interfaces and parameters. The flush command does not impact previously saved configurations. SYNTAX: eth bridge flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 275: Eth Bridge Ifadd

    Eth Commands eth bridge ifadd Create a new bridge interface. SYNTAX: eth bridge ifadd intf = <string> where: intf The name of the new bridge interface. REQUIRED RELATED COMMANDS: eth bridge ifdelete Delete a bridge interface. eth bridge iflist Display the current bridge interfaces. E-DOC-CTC-20060414-0006 v1.0...

  • Page 276: Eth Bridge Ifattach

    Eth Commands eth bridge ifattach Attach a bridge interface. SYNTAX: eth bridge ifattach intf = <string> where: intf The name of the bridge interface to be attached. REQUIRED RELATED COMMANDS: eth bridge ifdetach Detach a bridge interface. E-DOC-CTC-20060414-0006 v1.0...

  • Page 277: Eth Bridge Ifconfig

    The default is forwarding. retry A number between 0 and 65535. OPTIONAL Represents the number of times the SpeedTouch™ retries to set up a WAN connection before giving up. The default is 10. vlan Select the default VLAN. OPTIONAL prioconfig The priority configuration for this interface.
  • Page 278 Eth Commands regenprio The priority regeneration table for tagged ingress packets. OPTIONAL The default is 01234567. ingressfiltering Enable/disable discard of tagged ingress packets if the interface is not part of OPTIONAL the VLAN. The default is disabled. acceptvlanonly Enable or disable receipt of tagged ingress packets. OPTIONAL The default is disabled.

  • Page 279: Eth Bridge Ifdelete

    Eth Commands eth bridge ifdelete Delete a bridge interface. SYNTAX: eth bridge ifdelete intf = <string> where: intf The name of the bridge interface name to be deleted. REQUIRED RELATED COMMANDS: eth bridge ifadd Create a new bridge interface. eth bridge iflist Display the current bridge interfaces.

  • Page 280: Eth Bridge Ifdetach

    Eth Commands eth bridge ifdetach Detach a bridge interface. SYNTAX: eth bridge ifdetach intf = <string> where: intf The name of the bridge interface to be detached. REQUIRED RELATED COMMANDS: eth bridge ifattach Attach a bridge interface. E-DOC-CTC-20060414-0006 v1.0...

  • Page 281: Eth Bridge Iflist

    Eth Commands eth bridge iflist Display the current bridge interfaces. SYNTAX: eth bridge iflist [intf = <string>] where: intf The name of the bridge interface to be displayed. OPTIONAL Note If not specified, all bridge interfaces are shown. RELATED COMMANDS: eth bridge ifadd Create a new bridge interface.

  • Page 282: Eth Bridge Macadd

    Eth Commands eth bridge macadd Add a static MAC address to a bridge interface. This command allows to manually add static MAC addresses, which should normally be dynamically discovered by the bridge itself. SYNTAX: eth bridge macadd intf = <string> hwaddr = <hardware-address>...

  • Page 283: Eth Bridge Macdelete

    Eth Commands eth bridge macdelete Remove a MAC address from the filtering database. SYNTAX: eth bridge macdelete hwaddr = <hardware-address> [vlan = <string>] where: hwaddr The Ethernet MAC address of the entry to be deleted. REQUIRED vlan The VLAN. OPTIONAL EXAMPLE: =>eth bridge maclist 00:0d:9d:47:dd:aa -- dynamic, ethport1...

  • Page 284: Eth Bridge Maclist

    Eth Commands eth bridge maclist Display the MAC address database. SYNTAX: eth bridge maclist EXAMPLE: =>eth bridge maclist 00:0d:9d:47:dd:aa -- dynamic, ethport1, 300 seconds 00:90:d0:72:88:64 -- permanent 01:00:5e:00:00:67 -- static 01:00:5e:7f:ff:fa -- static 01:80:c2:00:00:00 -- permanent 01:80:c2:00:00:01 -- permanent 01:80:c2:00:00:02 -- permanent 01:80:c2:00:00:03 -- permanent 01:80:c2:00:00:04 -- permanent 01:80:c2:00:00:05 -- permanent...

  • Page 285: Eth Bridge Mcdadd

    Eth Commands eth bridge mcdadd Add a multicast group to be dropped to the database. SYNTAX: eth bridge mcdadd srcintfs = <string or combination of strings separated by '+'}> dstintfs = <string or combination of strings separated by '+'}> where: srcports The source bridge interfaces from which multicast packets must be dropped.

  • Page 286: Eth Bridge Mcddelete

    Eth Commands eth bridge mcddelete Delete a multicast group to be dropped from the database. SYNTAX: eth bridge mcddelete RELATED COMMANDS: eth bridge mcdadd Add a multicast group to be dropped to the database. eth bridge mcdlist Display the multicast group to be dropped from the database. E-DOC-CTC-20060414-0006 v1.0...

  • Page 287: Eth Bridge Mcdlist

    Eth Commands eth bridge mcdlist Display the multicast group to be dropped from the database. SYNTAX: eth bridge mcdlist RELATED COMMANDS: eth bridge mcdadd Add a multicast group to be dropped to the database. eth bridge mcddelete Delete a multicast group to be dropped from the database. E-DOC-CTC-20060414-0006 v1.0...

  • Page 288: Eth Bridge Rule Add

    Eth Commands eth bridge rule add Add a new constraint to the VLAN learning system. SYNTAX: eth bridge rule add type = <{shared | independent}> vlan = <string> [vlan2 = <string>] [isi = <number{0-32}>] where: type Type of constraint. REQUIRED Choose between: shared independent.

  • Page 289: Eth Bridge Rule Delete

    Eth Commands eth bridge rule delete Delete a constraint from the VLAN learning system. SYNTAX: eth bridge rule delete index = <number{0-32}> where: index Index of the constraint to be deleted. REQUIRED Use the command :eth bridge rule list to obtain a list of the indexes of the constraints.

  • Page 290: Eth Bridge Rule Flush

    Eth Commands eth bridge rule flush Flush all constraints from the VLAN learning system. SYNTAX: eth bridge rule flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 291: Eth Bridge Rule List

    Eth Commands eth bridge rule list Display all constraints from the VLAN learning system. SYNTAX: eth bridge rule list EXAMPLE: =>eth bridge rule list Index Type VLAN Parameter ----- ---- ---- --------- independant default Independent set identifier: 1 => RELATED COMMANDS: eth bridge rule add Add a new constraint to the VLAN learning system.

  • Page 292: Eth Bridge Vlan Ifadd

    Eth Commands eth bridge vlan ifadd Add a bridge interface to a VLAN. SYNTAX: eth bridge vlan ifadd name = <string> intf = <string> [untagged = <{disabled | enabled}>] where: name The VLAN name to which a bridge interface must be added. REQUIRED intf The name of the bridge interface to be added to the VLAN.

  • Page 293: Eth Bridge Vlan Ifconfig

    Eth Commands eth bridge vlan ifconfig Modify a bridge interface from a VLAN. SYNTAX: eth bridge vlan ifconfig name = <string> intf = <string> untagged = <{disabled | enabled}> where: name The VLAN name for which a bridge interface must be modified. REQUIRED intf The name of the bridge interface to be modified.

  • Page 294: Eth Bridge Vlan Ifdelete

    Eth Commands eth bridge vlan ifdelete Delete a bridge interface from a VLAN. SYNTAX: eth bridge vlan ifdelete name = <string> intf = <string> where: name The VLAN name for which a bridge interface must be deleted. REQUIRED intf The name of the bridge interface to be deleted. REQUIRED RELATED COMMANDS: eth bridge vlan ifadd...

  • Page 295: Eth Bridge Vlan Iflist

    Eth Commands eth bridge vlan iflist Display all VLANs. SYNTAX: eth bridge vlan iflist RELATED COMMANDS: eth bridge vlan ifadd Add a bridge interface to a VLAN. eth bridge vlan ifconfig Modify a bridge interface from a VLAN. eth bridge vlan ifdelete Delete a bridge interface from a VLAN.

  • Page 296: Eth Device Ifconfig

    Eth Commands eth device ifconfig Configure an Ethernet interface. SYNTAX: eth device ifconfig intf = <string> [type = <{auto | 10BaseTHD | 10BaseTFD | 100BaseTHD | 100BaseTFD} or number>] [state = <{enabled | disabled}>] where: intf The name of a physical interface. REQUIRED type The Ethernet type.

  • Page 297: Eth Device Iflist

    Eth Commands eth device iflist Show status of Ethernet interfaces. SYNTAX: eth device iflist EXAMPLE: =>eth device iflist Interface Type Result State ethif1 auto 100BaseTFD UP [forwarding] ethif2 auto 100BaseTFD UP [forwarding] ethif3 auto 100BaseTFD UP [forwarding] ethif4 auto 100BaseTFD UP [forwarding] usbif1 UP [forwarding]...

  • Page 298: Eth Switch Group Flush

    Eth Commands eth switch group flush Set all the ports to the default settings. All the ports are placed in group 0. SYNTAX: eth switch group flush EXAMPLE: =>eth switch group list Group 0 Ports: 4 Group 1 Ports: 1 Group 2 Ports: 2 3 =>eth switch group flush =>eth switch group list...

  • Page 299: Eth Switch Group List

    Eth Commands eth switch group list List all the configured switch groups. SYNTAX: eth switch group list EXAMPLE: =>eth switch group list Group 0 Ports: 4 Group 1 Ports: 1 Group 2 Ports: 2 3 => RELATED COMMANDS: eth switch group move Move a specified port to a specified switch group.

  • Page 300: Eth Switch Group Move

    Eth Commands eth switch group move Move a specified port to a specified switch group. SYNTAX: eth switch group move group = <number{0-3}> port = <number{1-4}> where: group A number between 0 and 4. REQUIRED Represents the group ID to which the port must be moved. port A number between 01 and 4.

  • Page 301: Eth Switch Mirror Capture

    Eth Commands eth switch mirror capture Define the specified port to be the Mirror Capture Port. Only one port can be the Mirror Capture Port at any one time. SYNTAX: eth switch mirror capture port = <number{1-4}> where: port The port to be the Mirror Capture Port. REQUIRED Note If no port number is specified, then the port number of the Mirror Capture Port...

  • Page 302: Eth Switch Mirror Egress

    Eth Commands eth switch mirror egress Enable or disable the specified port to be the Mirror Egress Port. Only one port can be the Mirror Egress Port at any one time. But a port can be the Mirror Egress Port and the Mirror Ingress Port at the same time. SYNTAX: eth switch mirror egress port = <number{1-4}>...

  • Page 303: Eth Switch Mirror Ingress

    Eth Commands eth switch mirror ingress Enable or disable the specified port to be the Mirror Ingress Port. Only one port can be the Mirror Ingress Port at any one time. But a port can be the Mirror Egress Port and the Mirror Ingress Port at the same time. SYNTAX: eth switch mirror ingress port = <number{1-4}>...

  • Page 304: Eth Switch Share Add

    Eth Commands eth switch share add Add a port to be shared. SYNTAX: eth switch share add port = <number{1-4}> shared = <number{1-4}> where: port A number between 1 and 4. REQUIRED Represents the port. shared A number between 1 and 4. REQUIRED Represents the shared port.

  • Page 305: Eth Switch Share Delete

    Eth Commands eth switch share delete Delete a shared port. SYNTAX: eth switch share delete port = <number{1-4}> shared = <number{1-4}> where: port A number between 1 and 4. REQUIRED Represents the port. shared A number between 1 and 4. REQUIRED Represents the shared port.

  • Page 306: Eth Switch Share List

    Eth Commands eth switch share list Display shared ports. SYNTAX: eth switch share list RELATED COMMANDS: eth switch share add Add a port to be shared. eth switch share delete Delete a shared port. E-DOC-CTC-20060414-0006 v1.0...

  • Page 307: Eth Vlan Add

    Eth Commands eth vlan add Add a new VLAN. SYNTAX: eth vlan add name = <string> vid = <number{2-4094}> [addrule = <{disabled | enabled}>] where: name The new VLAN name. REQUIRED A number representing the new VLAN ID. REQUIRED Note The ID 1 is reserved for the default VLAN.

  • Page 308: Eth Vlan Delete

    Eth Commands eth vlan delete Delete a VLAN. SYNTAX: eth vlan delete name = <string> where: name The name of the VLAN to be deleted. REQUIRED EXAMPLE: =>eth vlan list Name ---- default myVLAN =>eth vlan delete name=myVLAN vid=2 =>eth vlan list Name ---- default...

  • Page 309: Eth Vlan Flush

    Eth Commands eth vlan flush Flush all VLANs. All the VLANs, except the default VLAN will be flushed. SYNTAX: eth vlan flush EXAMPLE: =>eth vlan list Name ---- default myVLAN yourVLAN =>eth vlan flush =>eth vlan list Name ---- default =>...

  • Page 310: Eth Vlan List

    Eth Commands eth vlan list Display all VLANs. SYNTAX: eth vlan list EXAMPLE: =>eth vlan list Name ---- default myVLAN => RELATED COMMANDS: eth vlan add Add a new VLAN. eth vlan delete Delete a VLAN. E-DOC-CTC-20060414-0006 v1.0...

  • Page 311: Expr Commands

    Expr Commands Expr Commands Introduction This chapter describes the commands of the expr command group. Contents This chapter covers the following commands: expr add Add a subexpression to an expression. expr delete Delete an expression. expr flush Flush all the expressions. expr list List the expressions.

  • Page 312: Expr Add

    Expr Commands expr add Add a subexpression to an expression. SYNTAX: expr add name = <string> type = <{intf | ip | serv}> addr [!]= <ip-range> [intf [!]= <string>] [intfgroup [!]= <{wan|local|lan|tunnel|dmz|guest} or number>] [tos [!]= <number{0-255}>] [precedence [!]= <IP precedence type> or <number>] [dscp [!]= <DSCP name>...
  • Page 313 Expr Commands A number between 0 and 255. OPTIONAL Represents the Type of Service (ToS) specification in the IP packet. Note The parameters tos, precedence dscp are mutually exclusive. precedence The precedence in the IP packet (part of tos). OPTIONAL Select an IP precedence (see “...
  • Page 314 Expr Commands EXAMPLE: =>expr list name type use flags expression ------------------------------------------------------------------------------------------ _myPPP_ppp intf 1. intf=myPPP_ppp _eth0 intf 1. intf=eth0 intf 1. intfgroup=0 intf 1. intfgroup=2 local intf 1. intfgroup=1 notwan intf 1. intfgroup=2 2. intfgroup=1 _10.0.0.138 1. addr=10.0.0.138 _192.168.1.254 1. addr=192.168.1.254 DiffServ serv 1.

  • Page 315: Expr Delete

    Expr Commands expr delete Delete an expression. SYNTAX: expr delete name = <string> [index = <number>] where: name The name of the expression to be deleted. REQUIRED index The index of the subexpression to be deleted. OPTIONAL Note If not specified, all the subexpressions wil be deleted. E-DOC-CTC-20060414-0006 v1.0...
  • Page 316 Expr Commands EXAMPLE: =>expr list name type use flags expression ------------------------------------------------------------------------------------------ _myPPP_ppp intf 1. intf=myPPP_ppp _eth0 intf 1. intf=eth0 intf 1. intfgroup=0 intf 1. intfgroup=2 local intf 1. intfgroup=1 notwan intf 1. intfgroup=2 2. intfgroup=1 myEXPR intf 1. intf=Internet intfgroup=2 _10.0.0.138 1.

  • Page 317: Expr Flush

    Expr Commands expr flush Flush all the expressions. SYNTAX: expr flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 318: Expr List

    Expr Commands expr list List the expressions. SYNTAX: expr list [name = <string>] [type = <{intf | ip | serv}>] [format = <{pretty | cli}>] where: name The name of an existing expression. OPTIONAL Note If not specified, all the expressions will be listed. type The expression type.
  • Page 319 Expr Commands EXAMPLE 1: E-DOC-CTC-20060414-0006 v1.0...
  • Page 320 Expr Commands =>expr list name type use flags expression ------------------------------------------------------------------------------------------ _Internet intf 1. intf=Internet _LocalNetwork intf 1. intf=LocalNetwork HTTPI_if_0 intf 1. intf=LocalNetwork 2. intf=LocalNetwork 3. intf=LocalNetwork HTTP_if_0 intf 1. intfgroup=2 HTTPs_if_0 intf 1. intfgroup=2 FTP_if_0 intf 1. intfgroup=2 TELNET_if_0 intf 1.
  • Page 321 Expr Commands EXAMPLE 2: E-DOC-CTC-20060414-0006 v1.0...
  • Page 322 Expr Commands =>expr list format=cli :expr add name=_Internet type=intf intf=Internet :expr add name=_LocalNetwork type=intf intf=LocalNetwork :expr add name=HTTPI_if_0 type=intf intf=LocalNetwork :expr add name=HTTPI_if_0 type=intf intf=LocalNetwork :expr add name=HTTPI_if_0 type=intf intf=LocalNetwork :expr add name=HTTP_if_0 type=intf intfgroup=lan :expr add name=HTTPs_if_0 type=intf intfgroup=lan :expr add name=FTP_if_0 type=intf intfgroup=lan :expr add name=TELNET_if_0 type=intf intfgroup=lan :expr add name=DNS-S_if_0 type=intf intfgroup=lan...
  • Page 323 Expr Commands RELATED COMMANDS: expr add Add a subexpression to an expression. expr delete Delete an expression. E-DOC-CTC-20060414-0006 v1.0...

  • Page 324: Expr Modify

    Expr Commands expr modify Modify an expression. SYN TAX: expr modify name = <string> type = <{intf | ip | serv}> index = <number> addr [!]= <ip-range> [intf [!]= <string>] [intfgroup [!]= <{wan|local|lan|tunnel|dmz|guest} or number>] [bridgeport [!]= <number>] [tos [!]= <number{0-255}>] [precedence [!]= <IP precedence type>...
  • Page 325 Expr Commands intfgroup The IP interface group. OPTIONAL Choose between: local tunnel guest. Note Only for expression type intf. bridgeport The bridge port number. OPTIONAL Note Only for expression type intf. A number between 0 and 255. OPTIONAL Represents the ToS specification in the IP packet. Note The parameters tos, precedence...
  • Page 326 Expr Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 327: Firewall Commands

    Firewall Commands Firewall Commands Introduction This chapter describes the commands of the firewall command group. Contents This chapter covers the following commands: firewall config Configure the firewall options. firewall clear Flush the firewall configuration. firewall list List the firewall configuration. firewall chain add Add a chain.

  • Page 328: Firewall Config

    Firewall Commands firewall config Configure the firewall options. SYNTAX: firewall config [state = <{disabled | enabled}>] [keep = <{disabled | enabled}>] [tcpchecks = <{none | fast | exact}>] [udpchecks = <{disabled|enabled}>] [icmpchecks = <{disabled | enabled}>] [logdefault = <{disabled | enabled}>] [logthreshold = <{disabled | enabled}>] [tcpwindow = <number{0-1073725440}>] where:...
  • Page 329 Firewall Commands tcpwindow A number between 0 and 1073725440. OPTIONAL This parameter permits to modify the TCP window for fast TCP checks. The default is 65536. EXAMPLE: =>firewall config :firewall config state=enabled keep=disabled tcpchecks=none udpchecks=enabled icmpchecks=enabled logdefault=disabled logthreshold=enabled tcpwindow=65536 => E-DOC-CTC-20060414-0006 v1.0...

  • Page 330: Firewall Clear

    Firewall Commands firewall clear Flush the firewall configuration. SYNTAX: firewall clear E-DOC-CTC-20060414-0006 v1.0...

  • Page 331: Firewall List

    Firewall Commands firewall list List the firewall configuration. SYNTAX: firewall list [format = <{pretty | cli}>] where: format Select the output format in which the configuration must be shown. OPTIONAL Choose between: pretty: the configuration is shown as intuitive output in clear text. cli: the configuration is shown via the CLI commands configuration.

  • Page 332: Firewall Chain Add

    Firewall Commands firewall chain add Add a chain. SYNTAX: firewall chain add chain = <string> where: chain The name of the chain to be added. REQUIRED EXAMPLE: =>firewall chain list Chains ====== Name Description ----------------------------------------------------------------- sink system forward system source system sink_fire system...

  • Page 333: Firewall Chain Delete

    Firewall Commands firewall chain delete Delete a chain. SYNTAX: firewall chain delete chain = <string> where: chain The name of the chain to be deleted. REQUIRED EXAMPLE: =>firewall chain list Chains ====== Name Description ----------------------------------------------------------------- sink system forward system source system sink_fire system...

  • Page 334: Firewall Chain Flush

    Firewall Commands firewall chain flush Flush all chains. SYNTAX: firewall chain flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 335: Firewall Chain List

    Firewall Commands firewall chain list List all chains. SYNTAX: firewall chain list [format = <{pretty | cli}>] where: format Select the output format in which the chains must be shown. OPTIONAL Choose between: pretty: the chains are shown as intuitive output in clear text. cli: the chains are shown via the CLI commands configuration.

  • Page 336: Firewall Debug Clear

    Firewall Commands firewall debug clear Clear the firewall statistics. SYNTAX: firewall debug clear EXAMPLE: =>firewall debug stats Statistics ========== Used rule contexts Total rule contexts : 256 Total packets parsed : 2554 Packets parsed in hook sink : 1461 Packets parsed in hook forward : 12 Packets parsed in hook source : 1041...

  • Page 337: Firewall Debug Stats

    Firewall Commands firewall debug stats Display the firewall statistics. SYNTAX: firewall debug stats EXAMPLE: =>firewall debug stats Statistics ========== Used rule contexts Total rule contexts : 256 Total packets parsed : 2554 Packets parsed in hook sink : 1461 Packets parsed in hook forward : 12 Packets parsed in hook source : 1041...

  • Page 338: Firewall Debug Traceconfig

    Firewall Commands firewall debug traceconfig Configure the firewall trace options. SYNTAX: firewall debug traceconfig [tcpchecks = <{disabled | enabled}>] [udpchecks = <{disabled|enabled}>] [icmpchecks = <{disabled | enabled}>] [sink = <{none | all | accept | deny | drop | reset} or number>] [forward = <{none | all | accept | deny | drop reset} or number>] [source = <{none | all | accept | deny | drop...

  • Page 339: Firewall Level Add

    Firewall Commands firewall level add Add a security level. SYNTAX: firewall level add name = <string> [index = <number>] [readonly = <{disabled | enabled}>] [udptrackmode = <{strict | loose}>] [service = <{disabled | enabled}>] [proxy = <{disabled|enabled}>] [text = <quoted string>] where: name The name of the security level to be added.

  • Page 340: Firewall Level Delete

    Firewall Commands firewall level delete Delete a security level. SYNTAX: firewall level delete name = <string> where: name The name of the security level to be deleted. REQUIRED RELATED COMMANDS: firewall level add Add a security level. firewall level list List all the security levels.

  • Page 341: Firewall Level Flush

    Firewall Commands firewall level flush Flush the security level configuration. SYNTAX: firewall level flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 342: Firewall Level List

    Firewall Commands firewall level list List all the security levels. SYNTAX: firewall level list [format = <{pretty | cli}>] where: format Select the output format in which the security levels must be shown. OPTIONAL Choose between: pretty: the security levels are shown as intuitive output in clear text. cli: the security levels are shown via the CLI commands configuration.

  • Page 343: Firewall Level Modify

    Firewall Commands firewall level modify Configure a security level. SYNTAX: firewall level modify name = <string> [index = <number>] [readonly = <{disabled | enabled}>] [udptrackmode = <{strict | loose}>] [service = <{disabled | enabled}>] [proxy = <{disabled|enabled}>] [text = <quoted string>] where: name The name of the security level to be added.

  • Page 344: Firewall Level Set

    Firewall Commands firewall level set Set the security level or display the current security level. SYNTAX: firewall level set [name = <string>] where: name The name of the security level to be set. OPTIONAL Note If no security level is specified, the current security level will be shown. E-DOC-CTC-20060414-0006 v1.0...

  • Page 345: Firewall Rule Add

    Firewall Commands firewall rule add Add a firewall rule. SYNTAX: firewall rule add chain = <chain name> [index = <number>] [name = <string>] [clink = <chain name>] [srcintf [!]= <string>] [srcip [!]= <string>] [dstip [!]= <string>] [serv [!]= <string>] [log = <{disabled | enabled}>] [state = <{disabled | enabled}>] action = <{accept|deny|drop|reset|count|link}>...

  • Page 346: Firewall Rule Delete

    Firewall Commands firewall rule delete Delete a firewall rule. SYNTAX: firewall rule delete chain = <string> index = <number> where: chain The name of the chain in which a rule must be deleted. REQUIRED index The number of the rule in the chain. REQUIRED RELATED COMMANDS: firewall rule add...

  • Page 347: Firewall Rule Flush

    Firewall Commands firewall rule flush Flush all firewall rules. SYNTAX: firewall rule flush [chain = <string>] where: chain The name of the chain for which the rules must be flushed. OPTIONAL Note If not specified, the rules of all the chains will be flushed. E-DOC-CTC-20060414-0006 v1.0...

  • Page 348: Firewall Rule List

    Firewall Commands firewall rule list Show a list of the firewall rules in a chain. SYNTAX: firewall rule list [chain = <string>] [format = <{pretty | cli}>] where: chain The name of the chain for which the rules must be listed. OPTIONAL Note If not specified, the rules of all the chains are shown.
  • Page 349 Firewall Commands EXAMPLE: =>firewall rule list Rules (flags: C=Constant, D=Dynamic, E=Enable, L=Log) ===== Chain Flags Rule --------------------------------------------------------------------------------------- sink : link sink_fire : link sink_system_service sink_fire SSDP : accept ssdp_serv lan.* > *.ssdp_ip sink_system_service HTTPI : accept HTTPI_sv_0 HTTPI_if_0.* > *.* PING_RESPONDER : accept PING_RESPONDER_sv_0 PING_RESPONDER_...

  • Page 350: Firewall Rule Modify

    Firewall Commands firewall rule modify Modify a firewall rule. SYNTAX: firewall rule modify chain = <string> index = <number> [newindex = <number>] [name = <string>] [clink = <chain name>] [srcintf [!]= <string>] [srcip [!]= <string>] [dstintf [!]= <string>] [dstip [!]= <string>] [serv [!]= <string>] [log = <{disabled | enabled}>] [state = <{disabled | enabled}>]...

  • Page 351: Firewall Rule Debug Clear

    Firewall Commands firewall rule debug clear Clear the firewall rule statistics. SYNTAX: firewall rule debug clear [chain = <string>] [index = <number>] where: chain The name of the chain which contains the rule. OPTIONAL index The number of the rule in the chain. OPTIONAL Note If not specified, the statistics for all the rules in the chain will be cleared.
  • Page 352 Firewall Commands RELATED COMMANDS: firewall rule debug stats Show the firewall rule statistics. E-DOC-CTC-20060414-0006 v1.0...

  • Page 353: Firewall Rule Debug Stats

    Firewall Commands firewall rule debug stats Show the firewall rule statistics. SYNTAX: firewall rule debug stats [chain = <chain name>] [index = <number>] where: chain The name of the chain for which the statistics must be shown. OPTIONAL Note If not specified, the statistics for all the chains will be shown. index The number of the rule in the chain.

  • Page 354: Firewall Rule Debug Traceconfig

    Firewall Commands firewall rule debug traceconfig Display or modify the rule trace configuration. SYNTAX: firewall rule debug traceconfig [trace = <{disabled | enabled}>] where: trace Enable or disable rule traces. OPTIONAL The default is disabled. EXAMPLE: =>firewall rule debug traceconfig :firewall rule debug traceconfig state=disabled =>...

  • Page 355: Grp Commands

    GRP Commands GRP Commands Introduction This chapter describes the commands of the grp command group. Contents This chapter covers the following commands: grp config Set the Generic Routing Protocol (GRP) configuration settings. grp flush Flush the GRP interface settings and parameters. grp rtlist Show the current routes in the GRP interfaces routing table.

  • Page 356: Grp Config

    GRP Commands grp config Set the Generic Routing Protocol (GRP) configuration settings. SYNTAX: grp config [cdistance = <number{0-255}>] [kdistance = <number{0-255}>] [rdistance = <number{0-255}>] [trace = <{disabled | enabled}>] where: cdistance A number between 0 and 255. OPTIONAL Sets the distance of the connected route type. The default is 0.

  • Page 357: Grp Flush

    GRP Commands grp flush Flush the GRP interface settings and parameters. SYNTAX: grp flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 358: Grp Rtlist

    GRP Commands grp rtlist Show the current routes in the GRP interfaces routing table. SYNTAX: grp rtlist [dst = <ip-address>] [dstmask = <ip-mask (dotted or cidr)>] where: The destination IP address of the route. OPTIONAL Supports IP/mask notation. Note If no destination IP address is specified, all the current routes will be shown.

  • Page 359: Grp Rip Config

    GRP Commands grp rip config Configure the RIP settings. SYNTAX: grp rip config state = <{disabled | enabled}> [version = <{rip_unspec | rip_v1 | rip_v2}>] [defmetric = <number{1-16}>] [updatetime = <number{1-3600}>] [timeouttime = <number{1-3600}>] [garbagetime = <number{1-3600}>] [impcrt = <{disabled | enabled}>] [impkrt = <{disabled | enabled}>] [impsrt = <{disabled | enabled}>] [impdefkrt = <{disabled | enabled}>]...
  • Page 360 GRP Commands impsrt Enable or disable the import of static routes. OPTIONAL The default is enabled. impdefkrt Enable or disable the import of the default kernel route. OPTIONAL The default is enabled. impdefsrt Enable or disable the import of the default static route. OPTIONAL The default is enabled.

  • Page 361: Grp Rip Flush

    GRP Commands grp rip flush Flush the RIP interface settings and global parameters. SYNTAX: grp rip flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 362: Grp Rip Ifconfig

    GRP Commands grp rip ifconfig Configure a RIP interface. SYNTAX: grp rip ifconfig intf = <string> [rip = <{disabled | enabled}>] [rxversion = <{rip_unspec | rip_v1 | rip_v2 | rip_v1-2}>] [authmode = <{none | cleartext}>] [authstring = <quoted string>] [splithorizon = <{disable | enable}>] where: intf The name of the RIP interface to be configured.

  • Page 363: Grp Rip Show

    GRP Commands grp rip show Show the RIP settings and the routes in the RIP database. SYNTAX: grp rip show EXAMPLE: =>grp rip show RIP routing protocol config dump ------------------------------------ RIP daemon is enabled Global RIP queries received : 0 Global RIP route changes : 3 Default version : send rip_v2, receive rip_v2 Default redistribution metric is 1...
  • Page 364 GRP Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 365: Hostmgr Commands

    Hostmgr Commands Hostmgr Commands Introduction This chapter describes the commands of the hostmgr command group. Contents This chapter covers the following commands: hostmgr add Add host device info to the host manager. hostmgr clear Remove all the hosts from the list. hostmgr config Configure the host manager parameters.

  • Page 366: Hostmgr Add

    Hostmgr Commands hostmgr add Add host device info to the host manager. SYNTAX: hostmgr add mac_addr = <hardware-address> [ip_addr = <ip-address>] [name = <string>] [type = <{generic_device|desktop_computer|laptop_computer| set_top_box|pda|gaming_console|phone|mobile_phone| printer|mass_storage_device}>] [ipintf = <string>] [ethintf = <string>] [physintf = <string>] where: mac_addr The MAC address of the host to be added.
  • Page 367 Hostmgr Commands EXAMPLE: =>hostmgr list MAC-address IP-address Flags Type Intf Hw Intf Hostname ----------- ---------- ----- ---- ---- ------- -------- 00:10:a4:ad:32:cf 192.168.1.64 Generic Device LocalNetwork ethif4 MyComputer =>hostmgr add mac_addr=00:10:a4:33:56:53 name=Play type=Playstation =>hostmgr list MAC-address IP-address Flags Type Intf Hw Intf Hostname ----------- ----------...

  • Page 368: Hostmgr Clear

    Hostmgr Commands hostmgr clear Remove all the hosts from the list. SYNTAX: hostmgr clear EXAMPLE: =>hostmgr list MAC-address IP-address Flags Type Intf Hw Intf Hostname ----------- ---------- ----- ---- ---- ------- -------- 00:10:a4:33:56:53 0.0.0.0 Playstation ethif1 ethif1 Play 00:10:a4:ad:32:cf 192.168.1.64 Generic Device LocalNetwork ethif4...

  • Page 369: Hostmgr Config

    Hostmgr Commands hostmgr config Configure the host manager parameters. SYNTAX: hostmgr config [state = <{disabled | enabled}>] [scantime = <number{10-600}>] [autosave = <{disabled | enabled}>] [trace = <{disabled | enabled}>] where: state Enable or disable the host manager daemon. OPTIONAL The default is enabled.

  • Page 370: Hostmgr Delete

    Hostmgr Commands hostmgr delete Delete the host device info from the host manager. SYNTAX: hostmgr delete mac_addr = <hardware-address> where: mac_addr The MAC address of the host to be removed. REQUIRED EXAMPLE: =>hostmgr list MAC-address IP-address Flags Type Intf Hw Intf Hostname ----------- ----------...

  • Page 371: Hostmgr Flush

    Hostmgr Commands hostmgr flush Flush the host manager configuration. The host manager configuration is cleaned and returned to default values. SYNTAX: hostmgr flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 372: Hostmgr List

    Hostmgr Commands hostmgr list List all the host devices. SYNTAX: hostmgr list EXAMPLE: =>hostmgr list MAC-address IP-address Flags Type Intf Hw Intf Hostname ----------- ---------- ----- ---- ---- ------- -------- 00:10:a4:33:56:53 0.0.0.0 Playstation ethif1 ethif1 Play 00:10:a4:ad:32:cf 192.168.1.64 Generic Device LocalNetwork ethif4 MyComputer...

  • Page 373: Ids Commands

    IDS Commands IDS Commands Introduction This chapter describes the commands of the ids command group. Contents This chapter covers the following commands: ids clear Reset the IDS statistics. ids config Display/modify the Intrusion Detection System (IDS) configuration. ids parser list Display the IDS parser configuration.

  • Page 374: Ids Clear

    IDS Commands ids clear Reset the IDS statistics. SYNTAX: ids clear RELATED COMMANDS: ids parser list Display the IDS parser configuration. E-DOC-CTC-20060414-0006 v1.0...

  • Page 375: Ids Config

    IDS Commands ids config Display/modify the Intrusion Detection System (IDS) configuration. SYNTAX: ids config [state = <{disabled | enabled}>] [trace = <{disabled|enabled}>] where: state Enable or disable IDS checks. OPTIONAL The default is enabled. trace Enable or disable tracing. OPTIONAL The default is disabled.

  • Page 376: Ids Parser List

    IDS Commands ids parser list Display the IDS parser configuration. SYNTAX: ids parser list [parser = <parser>] where: parser The name of the parser REQUIRED EXAMPLE: =>ids parser list parser state ----------------------------------------- fragment enabled scan enabled enabled proto enabled rate enabled =>...

  • Page 377: Ids Parser Modify

    IDS Commands ids parser modify Modify the IDS parser configuration. SYNTAX: ids parser modify parser = <string> state = <{disabled | enabled}> where: parser The name of the IDS parser of which the configuration must be modified. REQUIRED state Disable or enable the parser. REQUIRED EXAMPLE: =>ids list...

  • Page 378: Ids Pattern Clear

    IDS Commands ids pattern clear Reset the pattern tracker. SYNTAX: ids pattern clear EXAMPLE: =>ids pattern stats Pattern tracker statistics: --------------------------- memory : 32768 bytes maximum number of patterns : 512 number of active patterns number of recycled patterns number of pattern searches number of new patterns maximum number of hash collisions % of hash entries with collisions...

  • Page 379: Ids Pattern List

    IDS Commands ids pattern list Display the patterns in the pattern tracker. SYNTAX: ids pattern list [size = <{10 | 100 | full} or number>] where: size The size of the IDS pattern list that will be shown. OPTIONAL Choose between: full or, alternatively, specify a number.

  • Page 380: Ids Pattern Stats

    IDS Commands ids pattern stats Display the pattern tracker statistics. SYNTAX: ids pattern stats EXAMPLE: =>ids pattern stats Pattern tracker statistics: --------------------------- memory : 32768 bytes maximum number of patterns : 512 number of active patterns number of recycled patterns number of pattern searches number of new patterns maximum number of hash collisions...

  • Page 381: Ids Signature List

    IDS Commands ids signature list Displays the ids signature configuration SYNTAX ids signature list [signature = <fragment_sweep|zero-length_fragment_size| small_fragment_size|fragment_size_overrun| fragment_overlap|fragment_out-of-order| ip_protocol_scan|tcp_port_scan|tcp_syn_scan| stealth_tcp_null_scan|stealth_tcp_fin_scan| stealth_tcp_xmas_scan| stealth_tcp_full_xmas_scan| stealth_tcp_vecna_scan| stealth_tcp_syn-fin_scan| udp_port_scan|ping_sweep_scan|tcp_syn_flood| udp_flood|ping_flood|icmp_unreachable_storm| smurf_broadcast_attack|smurf_storm_attack| fraggle_broadcast_attack| fraggle_storm_attack|land_attack}>] where signature The name of the signature OPTIONAL EXAMPLE: =>ids signature list signature fragment_sweep signature parser hits action...

  • Page 382: Ids Signature Modify

    IDS Commands ids signature modify Modify the states of the signatures. SYNTAX ids signature modify [signature = <fragment_sweep| zero-length_fragment_size| small_fragment_size| fragment_size_overrun| fragment_overlap| fragment_out-of-order| ip_protocol_scan| tcp_port_scan|tcp_syn_scan| stealth_tcp_null_scan| stealth_tcp_fin_scan| stealth_tcp_xmas_scan| stealth_tcp_full_xmas_scan| stealth_tcp_vecna_scan| stealth_tcp_syn-fin_scan| udp_port_scan|ping_sweep_scan| tcp_syn_flood|udp_flood|ping_flood| icmp_unreachable_storm| smurf_broadcast_attack| smurf_storm_attack| fraggle_broadcast_attack| fraggle_storm_attack|land_attack}>] state = <{disabled|enabled}> where signature The name of the signature...

  • Page 383: Ids Threshold Clear

    IDS Commands ids threshold clear Reset the IDS thresholds to their default values. SYNTAX: ids threshold clear EXAMPLE: =>ids threshold list index name window limit scaling ----------------------------------------------------------------- ids scan enabled ids flood disabled ids tcp rate enabled ids udp rate disabled ids icmp rate disabled...

  • Page 384: Ids Threshold List

    IDS Commands ids threshold list Display the IDS thresholds. SYNTAX: ids threshold list EXAMPLE: =>ids threshold list index name window limit scaling ----------------------------------------------------------------- ids scan enabled ids flood disabled ids tcp rate disabled ids udp rate disabled ids icmp rate disabled ids ip rate disabled...

  • Page 385: Ids Threshold Modify

    IDS Commands ids threshold modify Modify the IDS thresholds. SYNTAX: ids threshold modify index = <number> [window = <number>] [limit = <number>] [scaling = <{disabled | enabled}>] where: index The index of the IDS threshold to be modified. REQUIRED Use the command :ids threshold list to obtain the indexes. window A number (of seconds).
  • Page 386 IDS Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 387: Igmp Commands

    IGMP Commands IGMP Commands Introduction This chapter describes the commands of the IGMP command group. Contents This chapter covers the following commands: igmp host config Display or modify global IGMP configuration. igmp host flush Flush the IGMP settings. igmp host list Show the IGMP groups.

  • Page 388: Igmp Host Config

    IGMP Commands igmp host config Display or modify global IGMP configuration. SYNTAX: igmp host config [requirera = <{disabled | enabled}>] where: requirera Enable or disable the router alert IP option check. OPTIONAL The default is disabled. EXAMPLE: =>igmp host confighostmgr list Router alert IP option check : disabled =>...

  • Page 389: Igmp Host Flush

    IGMP Commands igmp host flush Flush the IGMP settings. SYNTAX: igmp host flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 390: Igmp Host List

    IGMP Commands igmp host list Show the IGMP groups. SYNTAX: igmp host list [intf = <string>] [expand = <{disabled | enabled}>] where: intf The IP interface name. OPTIONAL expand Enable or disable expanded listing of IGMP groups. OPTIONAL The default is disabled. EXAMPLE: =>igmp host list Interface...

  • Page 391: Igmp Host Ifconfig

    IGMP Commands igmp host ifconfig Configure an IGMP interface. SYNTAX: igmp host ifconfig intf = <string> version = <{none |IGMPv1 |IGMPv2 |IGMPv3}> where: intf The IP interface name. REQUIRED version The IGMP version of the IP interface. REQUIRED Choose between: IGMPv1 IGMPv2 IGMPv3...

  • Page 392: Igmp Host Iflist

    IGMP Commands igmp host iflist Show the configuration of the IGMP interfaces. SYNTAX: igmp host iflist [expand = <{disabled | enabled}>] where: expand Enable or disable expanded listing of IGMP interfaces configuration. OPTIONAL The default is disabled. EXAMPLE: =>igmp host iflist Interface Version loop...

  • Page 393: Igmp Host Debug Clear

    IGMP Commands igmp host debug clear Clear IGMP statistics. SYNTAX: igmp host debug clear RELATED COMMANDS: igmp host debug stats Print IGMP statistics. E-DOC-CTC-20060414-0006 v1.0...

  • Page 394: Igmp Host Debug Stats

    IGMP Commands igmp host debug stats Print IGMP statistics. SYNTAX: igmp host debug stats EXAMPLE: =>igmp host debug stats Total IGMP messages received Too small IGMP messages received Too long IGMP messages received IGMP messages with bad checksum received IGMP messages with bad TTL received IGMP messages with no router alert IP option received IGMPv1 membership queries received IGMPv2 membership queries received...

  • Page 395: Igmp Proxy Config

    IGMP Commands igmp proxy config Configure the IGMP proxy. SYNTAX: igmp proxy config [state = <{disabled | enabled}>] [qi = <number{1-86400}>] [qri = <number{1-86400}>] [lmqi = <number{1-86400}>] [rv = <number{2-10}>] [requirera = <{disabled | enabled}>] [localgroup = <{disabled | enabled}>] where: state Enable or disable the IGMP proxy.
  • Page 396 IGMP Commands RELATED COMMANDS: igmp proxy grouplist Show the learned groups on an IGMP proxy interface. E-DOC-CTC-20060414-0006 v1.0...

  • Page 397: Igmp Proxy Flush

    IGMP Commands igmp proxy flush Flush all IGMP proxy settings and learned groups. SYNTAX: igmp proxy flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 398: Igmp Proxy Grouplist

    IGMP Commands igmp proxy grouplist Show the learned groups on an IGMP proxy interface. SYNTAX: igmp proxy grouplist [intf = <string>] [expand = <{disabled | enabled}>] where: intf The name of the IGMP proxy interface to be listed. OPTIONAL expand Enable or disable expanded listing of the learned groups on an OPTIONAL IGMP proxy interface.

  • Page 399: Igmp Proxy Ifconfig

    IGMP Commands igmp proxy ifconfig Configure an IGMP proxy interface. SYNTAX: igmp proxy ifconfig intf = <string> [state = <{inactive | downstream | upstream}>] [version = <{IGMPv1 | IGMPv2 | IGMPv3}>] [fastleave = <{disabled | enabled}>] where: intf The name of the IGMP proxy interface to be configured. REQUIRED state The state of the IGMP proxy interface.

  • Page 400: Igmp Proxy Iflist

    IGMP Commands igmp proxy iflist Show the configuration of an IGMP proxy interface. SYNTAX: igmp proxy iflist [expand = <{disabled | enabled}>] where: expand Enable or disable expanded listing of IGMP proxy interface OPTIONAL configuration. The default is disabled. EXAMPLE: =>igmp proxy iflist Interface State...

  • Page 401: Igmp Proxy Mbslist

    IGMP Commands igmp proxy mbslist Show the IGMP proxy membership database (merge of all learned groups. SYNTAX: igmp proxy mbslist E-DOC-CTC-20060414-0006 v1.0...

  • Page 402: Igmp Proxy Debug Clear

    IGMP Commands igmp proxy debug clear Clear IGMP proxy statistics. SYNTAX: igmp proxy debug clear RELATED COMMANDS: igmp proxy debug stats Print IGMP proxy statistics. igmp proxy debug Modify IGMP proxy trace configuration. traceconfig E-DOC-CTC-20060414-0006 v1.0...

  • Page 403: Igmp Proxy Debug Stats

    IGMP Commands igmp proxy debug stats Print IGMP proxy statistics. SYNTAX: igmp proxy debug stats EXAMPLE: =>igmp proxy debug stats IGMP proxy statistics: Total IGMP packets recv Too short IGMP packets recv IGMP packets with bad checksum recv IGMP packets with bad ttl recv IGMP packets with no route alert option recv IGMPv1 queries recv IGMPv2 queries recv...

  • Page 404: Igmp Proxy Debug Traceconfig

    IGMP Commands igmp proxy debug traceconfig Modify IGMP proxy trace configuration. SYNTAX: igmp proxy debug traceconfig [state = <{disabled | enabled}>] where: state Enable or disable tracing. OPTIONAL The default is disabled. RELATED COMMANDS: igmp proxy debug clear Clear IGMP proxy statistics. igmp proxy debug stats Print IGMP proxy statistics.

  • Page 405: Interface Commands

    Interface Commands Interface Commands Introduction This chapter describes the commands of the interface command group. Contents This chapter covers the following commands: interface list Display interfaces. E-DOC-CTC-20060414-0006 v1.0...

  • Page 406: Interface List

    Interface Commands interface list Display interfaces. SYNTAX: interface list [expand = <{disabled | enabled}>] [reverse = <{disabled | enabled}>] where: expand Enable or disable expanded listing of interfaces. OPTIONAL The default is disabled. reverse Enable or disable reverse listing (lower layer first instead of upper layer first). OPTIONAL The default is disabled.
  • Page 407 Interface Commands EXAMPLE: =>interface list Name Type State UL Interfaces ethif1 physical connected bridge ethif4 physical connected bridge usbif1 physical connected bridge RELAY connected Internet_ppp bridge connected eth0 atm_0_35 connected ethoa_0_35 atm_8_35 connected ethoa_8_35 ethoa_0_35 connected ethoa_8_35 connected Internet_ppp ppp not-connected Internet Internet...
  • Page 408 Interface Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 409: Ip Commands

    IP Commands IP Commands Introduction This chapter describes the commands of the ip command group. Contents This chapter covers the following commands: ip arpadd Add an entry to the ARP cache of a broadcast Internet Protocol (IP) interface. ip arpdelete Delete an entry from the ARP cache.
  • Page 410 IP Commands ip debug sendto Send UDP packets. ip debug stats Display IP statistics. ip debug traceconfig Display/modify the IP stack trace configuration. E-DOC-CTC-20060414-0006 v1.0...

  • Page 411: Ip Arpadd

    IP Commands ip arpadd Add an entry to the ARP cache of a broadcast Internet Protocol (IP) interface. SYNTAX: ip arpadd intf = <string> ip = <ip-range> [hwaddr = <hardware-address>] where: intf The IP interface name. REQUIRED The IP address (or range) of the entry to be added to the Address Resolution Protocol REQUIRED (ARP) cache.

  • Page 412: Ip Arpdelete

    IP Commands ip arpdelete Delete an entry from the ARP cache. SYNTAX: ip arpdelete intf = <string> ip = <ip-range> [hwaddr = <hardware-address>] where: intf The IP interface name. REQUIRED The IP address (or range) of the entry to be deleted. REQUIRED hwaddr The hardware address (for example the Ethernet MAC address) of the entry to be...

  • Page 413: Ip Arplist

    IP Commands ip arplist Display the ARP cache. SYNTAX: ip arplist EXAMPLE: =>ip arplist Interface IP-address HW-address Type eth0 10.0.0.1 00:10:a4:ad:32:cf STATIC eth0 10.0.0.2 00:00:00:00:00:00 DYNAMIC eth0 10.0.0.3 00:a0:24:ae:66:e1 STATIC => RELATED COMMANDS: ip arpadd Add an entry to the ARP cache of a broadcast Internet Protocol (IP) interface. ip arpdelete Delete an entry from the ARP cache.

  • Page 414: Ip Config

    IP Commands ip config Show/set global IP stack configuration options. SYNTAX: ip config [forwarding = <{disabled | enabled}>] [redirects = <{disabled | enabled}>] [checkoptions = <{disabled|enabled|transparent}>] [netbroadcasts = <{disabled | enabled}>] [ttl = <number{0-255}>] [defragmode = <{disabled | enabled}>] [addrcheck = <{off | own | static | dynamic}>] [mssclamping = <{disabled | enabled}>] [natloopback = <{disabled|enabled}>] [bitrate-window(sec) = <number{10-3600}>]...
  • Page 415 Minimum level of checking. Only the address configuration on the SpeedTouch™ is checked. static: Checking of the address configuration of the SpeedTouch™ and also of traffic: addresses of incoming packets; this checking is related to constants (for example an address may not be entirely composed of one‘s or zero‘s).

  • Page 416: Ip Flush

    IP Commands ip flush Flush all the static IP parameters. Dynamic configurations (for example from PPP or CIP links) remain. The flush command does not impact previously saved configurations. The command :ip flush deletes all local IP connectivity. Do not use this command during an IP based local connection, for example a Telnet CLI session, or web based CLI access.

  • Page 417: Ip Ifadd

    IP Commands ip ifadd Create an IP interface. SYNTAX: ip ifadd intf = <string> dest = <string> where: intf The name of the IP interface to be created. REQUIRED dest An network interface name. REQUIRED EXAMPLE: =>ip iflist Interface Group TX-Drop Status HW-address loop...

  • Page 418: Ip Ifattach

    IP Commands ip ifattach Attach an IP interface. SYNTAX: ip ifattach intf = <string> where: intf The name of the IP interface to be attached. REQUIRED EXAMPLE: =>ip iflist Interface Group TX-Drop Status HW-address loop local 65535 123966 75177 [UP] 00:0e:50:0f:fc:2c Internet 1500...

  • Page 419: Ip Ifconfig

    IP Commands ip ifconfig Configure the parameters of an IP interface. SYNTAX: ip ifconfig intf = <string> [mtu = <number{68-65535}>] [status = <{down | up}>] [hwaddr = <hardware-address>] [group = <string> or number] [linksensing = <{disabled | enabled}>] [primary = <{disabled | enabled}>] [mcastpromisc = <{disabled|enabled}>] where: intf...
  • Page 420 IP Commands EXAMPLE: =>ip iflist Interface Group TX-Drop Status HW-address loop local 65535 123966 75177 [UP] 00:0e:50:0f:fc:2c Internet 1500 DOWN RtPPPoE_ppp 1500 DOWN LocalNetwork 1500 86589 125262 [UP] 00:0e:50:0f:fc:2c myIPintf 1500 DOWN 00:0e:50:0f:fc:2c =>ip ifconfig intf = myIPintf [mtu] = 1500 [status] = up [hwaddr] = 00:0e:50:0f:fc:2c [group] = wan...

  • Page 421: Ip Ifdelete

    IP Commands ip ifdelete Delete an IP interface. SYNTAX: ip ifdelete intf = <string> where: intf The name of the IP interface to be deleted. REQUIRED EXAMPLE: =>ip iflist Interface Group TX-Drop Status HW-address loop local 65535 123966 75177 [UP] 00:0e:50:0f:fc:2c Internet 1500...

  • Page 422: Ip Ifdetach

    IP Commands ip ifdetach Detach an IP interface. SYNTAX: ip ifdetach intf = <string> where: intf The name of the IP interface to be detached. REQUIRED EXAMPLE: =>ip iflist expand=enabled Interface Group TX-Drop Status HW-address loop local 65535 130597 82240 [UP] 00:0e:50:0f:fc:2c BRHW-address...

  • Page 423: Ip Iflist

    IP Commands ip iflist Display all the IP interfaces. SYNTAX: ip iflist [expand = <{disabled | enabled}>] where: expand Enable or disable expanded listing. OPTIONAL The default is disabled. EXAMPLE: =>ip iflist Interface Group TX-Drop Status HW-address loop local 65535 123966 75177 [UP] 00:0e:50:0f:fc:2c...

  • Page 424: Ip Ifwait

    IP Commands ip ifwait Wait for a status change of an IP interface. SYNTAX: ip ifwait intf = <string> [timeout = <number{1-600000}>] [adminstatus = <{down | up}>] [operstatus = <{down | up}>] [linkstatus = <{down | up}>] where: intf The IP interface name. REQUIRED timeout A number between 1 and 600000 (seconds).

  • Page 425: Ip Ipadd

    IP Commands ip ipadd Assign an IP address to an IP interface. SYNTAX: ip ipadd intf = <string> addr = <ip-address> [netmask = <ip-mask(dotted or cidr)>] [pointopoint = <ip-address>] [addroute = <{disabled | enabled}>] where: intf The IP interface name. REQUIRED addr The new IP address to be added.

  • Page 426: Ip Ipconfig

    IP Commands ip ipconfig Modify an IP address configuration. SYNTAX: ip ipconfig addr = <ip-address> [preferred = <{disabled | enabled}>] [primary = <{disabled | enabled}>] where: addr The IP address to be configured. REQUIRED preferred Make this IP address the preferred address for that subnet (enabled) or not OPTIONAL (disabled).

  • Page 427: Ip Ipdelete

    IP Commands ip ipdelete Remove an IP address from an IP interface. SYNTAX: ip ipdelete addr = <ip-address> where: addr The IP address to be deleted. REQUIRED EXAMPLE: =>ip iplist Interface Type IP-address Point-to-point/Mask eth0 Ethernet 10.0.0.2 255.255.255.0 eth0 Ethernet 10.0.0.138 255.255.255.0 eth0...

  • Page 428: Ip Iplist

    IP Commands ip iplist Display all the configured IP addresses. SYNTAX: ip iplist EXAMPLE: =>ip iplist Interface Type IP-address Point-to-point/Mask LocalNetwork Ethernet 10.0.0.138 255.255.255.0 LocalNetwork Ethernet *192.168.1.254 255.255.255.0 loop Ethernet 127.0.0.1 255.255.255.255 => RELATED COMMANDS: ip ipadd Assign an IP address to an IP interface. ip ipdelete Remove an IP address from an IP interface.

  • Page 429: Ip Mcast Rtadd

    IP Commands ip mcast rtadd Add a multicast route to the multicast routing table. SYNTAX: ip mcast rtadd srcintf = <string> [src = <ip-address>] grp = <ip-address> dstintf = <string> [ttl = <number{1-255}>] [ttlincr = {disabled | enabled}] where: srcintf The source IP interface.

  • Page 430: Ip Mcast Rtdelete

    IP Commands ip mcast rtdelete Delete a multicast route from the multicast routing table. SYNTAX: ip mcast rtdelete srcintf = <string> [src = <ip-address>] grp = <ip-address> dstintf = <string> where: srcintf The source IP interface. REQUIRED The source IP address. OPTIONAL The multicast group IP address.

  • Page 431: Ip Mcast Rtlist

    IP Commands ip mcast rtlist Display the multicast routing table. SYNTAX: ip mcast rtlist [expand = <{disabled | enabled}>}] where: expand Enable or disable expanded listing. OPTIONAL The default is disabled. RELATED COMMANDS: ip mcast rtadd Add a multicast route to the multicast routing table. ip mcast rtdelete Delete a multicast route from the multicast routing table.

  • Page 432: Ip Mcast Flush

    IP Commands ip mcast flush Flush the multicast routing table. SYNTAX: ip mcast flush RELATED COMMANDS: ip mcast rtadd Add a multicast route to the multicast routing table. ip mcast rtdelete Delete a multicast route from the multicast routing table. ip mcast rtlist Display the multicast routing table.

  • Page 433: Ip Rtadd

    IP Commands ip rtadd Add a route to the routing table. SYNTAX: ip rtadd dst = <ip-address> [dstmsk = <ip-mask(dotted or cidr)>] [label = <string>] [gateway = <ip-address>] [intf = <string>] [srcintf = <string>] [metric = <number{0-255}>] where: The destination IP address(es) for this route. REQUIRED Note Supports ip/mask notation.

  • Page 434: Ip Rtdelete

    IP Commands ip rtdelete Delete a route from the routing table. SYNTAX: ip rtdelete dst = <ip-address> [dstmsk = <ip-mask(dotted or cidr)>] [label = <string>] [gateway = <ip-address>] [intf = <string>] where: The destination IP address(es) for this route. REQUIRED Note Supports cidr notation.

  • Page 435: Ip Rtlist

    IP Commands ip rtlist Display the routing table. SYNTAX: ip rtlist [expand = <{disabled | enabled}>] where: expand Enable or disable expanded listing. OPTIONAL The default is disabled. EXAMPLE: =>ip rtlist Destination Label Gateway Interface Metric Status 10.0.0.138/32 127.0.0.1 loop [UP] 127.0.0.1/32 127.0.0.1...

  • Page 436: Ip Auto Flush

    IP Commands ip auto flush Flush the autoIP interfaces. SYNTAX: ip auto flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 437: Ip Auto Ifadd

    IP Commands ip auto ifadd Create an autoIP interface. SYNTAX: ip auto ifadd intf = <string> [addr = <ip-address>] where: intf The name of the IP interface for which a link-local address has to be allocated. REQUIRED dest The preferred link-local IP address. OPTIONAL EXAMPLE: =>ip auto ifadd intf=eth0...

  • Page 438: Ip Auto Ifattach

    IP Commands ip auto ifattach Select and assign a link-local address to an autoIP interface. SYNTAX: ip auto ifattach intf = <string> where: intf The name of the autoIP interface for which a link-local address has to be attached. REQUIRED EXAMPLE: =>...

  • Page 439: Ip Auto Ifconfig

    IP Commands ip auto ifconfig Configure an autoIP interface. SYNTAX: ip auto ifconfig intf = <string> [addr = <ip-address>] [poolstart = <ip-address>] [poolend = <ip-address>] [netmask = <ip-mask(dotted or cidr)>] [claim = <number{0-65535}>] [defence = <number{0-65535}>] [probe = <number{0-65535}>] [interval = <number{1-65535}>] where: intf The name of the autoIP interface to be configured.
  • Page 440 IP Commands EXAMPLE: => ip auto iflist eth0 : [INIT] 0.0.0.0 poolstart = 169.254.1.1 poolend = 169.254.254.254 netmask = 255.255.0.0 claim : 10 defence : 5 probe : 4 interval : 2 (sec) probes sent = 0 collisions =>ip auto ifconfig intf=ipsec0 claim=5 probe=5 =>...

  • Page 441: Ip Auto Ifdelete

    IP Commands ip auto ifdelete Delete an existing autoIP interface. SYNTAX: ip auto ifdelete intf = <string> where: intf The name of the IP interface to be deleted. REQUIRED EXAMPLE: =>ip auto iflist ipsec0 : [SELECTING] 169.254.80.236 poolstart = 169.254.1.1 poolend = 169.254.254.254 netmask = 255.255.0.0 claim : 10...

  • Page 442: Ip Auto Ifdetach

    IP Commands ip auto ifdetach Release the link-local address for the given autoIP interface. SYNTAX: ip auto ifdetach intf = <string> where: intf The name of the autoIP interface for which a link-local address has to be detached. REQUIRED EXAMPLE: =>ip auto iflist ipsec0 : [SELECTING] 169.254.80.236...

  • Page 443: Ip Auto Iflist

    IP Commands ip auto iflist Display the autoIP interfaces. SYNTAX: ip auto iflist [intf = <string>] where: intf The name of the autoIP interface to be listed. OPTIONAL Note If not specified, all the autoIP interfaces are shown. EXAMPLE: =>ip auto iflist eth0 : [CLAIMED] 169.254.138.1 poolstart = 169.254.1.1...

  • Page 444: Ip Debug Httpprobe

    RTT taken to send a request and get a response back from the HTTP Server (the probe retrieves the base HTML page only as body, and does not request hyperlinks within this page). The SpeedTouch will send the HTTP request, receive the reply, and report the RTT statistics (including the size of the page returned).

  • Page 445: Ip Debug Sendto

    IP Commands ip debug sendto Send UDP packets. SYNTAX: ip debug sendto addr = <ip-address> [count = <number{1-1000000}>] [size = <number{0-20000}>] [interval = <number{1-1000000}>] [listen = <{disabled | enabled}>] [dffield = <{disabled | enabled}>] [srcaddr = <ip-address>] [srcport = <number{1-65535}>] dstport = <number{1-65535}>...
  • Page 446 IP Commands EXAMPLE: =>ip debug sendto addr=10.0.0.148 listen=on srcport=19 dstport=1025 =>ip debug sendto addr=10.0.0.148 listen=on srcport=19 dstport=1025 1 bytes from 10.0.0.148:1025 =>ip debug sendto addr=10.0.0.148 count=3 listen=on srcport=19 dstport=1025 1 bytes from 10.0.0.148:1025 1 bytes from 10.0.0.148:1025 1 bytes from 10.0.0.148:1025 =>...

  • Page 447: Ip Debug Stats

    IP Commands ip debug stats Display IP statistics. SYNTAX: ip debug stats EXAMPLE: =>ip debug stats Total datagrams received : 8599 IP header errors Datagrams forwarded : 23 Datagram forwarding errors Datagram forwarding resource errors Total Fragments received Fragments dropped due to resources or timeouts Datagrams reassembled Datagrams fragmented successfully Datagram fragmentation errors...

  • Page 448: Ip Debug Traceconfig

    IP Commands ip debug traceconfig Display/modify the IP stack trace configuration. SYNTAX: ip debug traceconfig [input = <{none | label | -telnet | -host | -broadcast | all}>] [forward = <{none | label | -telnet | -host | -broadcast | all}>] [output = <{none | label | -telnet | -host | -broadcast | all}>] [drop = <{none | label | -telnet | -host | -broadcast...
  • Page 449 IP Commands EXAMPLE: =>ip debug traceroute addr = 192.193.195.250 count=3 size=1 interval=1000 maxhops=30 dstport=33433 maxfail=5 type=icmp utime=yes :ip debug traceroute addr=192.193.195.250 ttl=1 192.193.195.250 676 us 1351 us 648 us => E-DOC-CTC-20060414-0006 v1.0...
  • Page 450 IP Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 451: Ipqos Commands

    IPQoS Commands IPQoS Commands Introduction This chapter describes the commands of the ipqos command group. Contents This chapter covers the following commands: ipqos config Configure IPQoS for a given destination interface for the IPQoS queues instantiation. ipqos list Display the IPQoS configuration. ipqos ef config Configure the IPQoS Expedited Forwarding (EF) timer for an interface.

  • Page 452: Ipqos Config

    IPQoS Commands ipqos config Configure IPQoS for a given destination interface for the IPQoS queues instantiation. When enabling or disabling IPQoS, take the following into account: if the WAN interface (for example PPPoA, IP oA,...) is detached at the time of enabling/disabling IPQoS, then the WAN interface has to be attached in order for the enabling/disabling of IPQoS to take effect.
  • Page 453 IPQoS Commands realtimerate A number between 1 and 100. OPTIONAL Represents a percentage of the interface bandwidth for rate-limiting of the Real Time queue. In case of congestion, the Real Time queue will only use this percentage of the interface bandwidth when there is also traffic on the other queues. The default is 80.

  • Page 454: Ipqos List

    IPQoS Commands ipqos list Display the IPQoS configuration. SYNTAX: ipqos list EXAMPLE: =>ipqos list Name State Discard Priority Size Size Rate Burst Weights (Packets) (KBytes) (KBytes) Weights atm_pvc_0_35 disabled early 25% 25% 25% 25% atm_pvc_8_35 enabled early 25% 25% 25% 25% =>...

  • Page 455: Ipqos Ef Config

    IPQoS Commands ipqos ef config Configure the IPQoS Expedited Forwarding (EF) timer for an interface. SYNTAX: ipqos ef config intf = <string> [state = <{disabled | enabled}>] [timeout = <number{100-10000}>] [mtu = <number{68-65535}>] where: intf The name of the IP interface. REQUIRED state Enable or disable the IPQoS EF timer for the interface.

  • Page 456: Ipqos Ef List

    IPQoS Commands ipqos ef list Display the IPQoS EF timers. SYNTAX: ipqos ef list EXAMPLE: =>ipqos ef list Interface State Timeout (ms) (bytes) loop disabled 1000 65535 Rt_PPPoA2 enabled 1000 1500 eth0 disabled 1000 1500 => RELATED COMMANDS: ipqos ef config Configure the IPQoS Expedited Forwarding (EF) timer for an interface.

  • Page 457: Ipqos Ef Stats

    IPQoS Commands ipqos ef stats Display the IPQoS EF timer statistics. SYNTAX: ipqos ef stats EXAMPLE: =>ipqos ef stats Interface State Remain (ms) loop active Rt_PPPoA2 active eth0 disabled => RELATED COMMANDS: ipqos ef config Configure the IPQoS Expedited Forwarding (EF) timer for an interface. ipqos ef list Display the IPQoS EF timers.

  • Page 458: Ipqos Queue Clear

    IPQoS Commands ipqos queue clear Clear the IPQoS statistics. SYNTAX: ipqos queue clear EXAMPLE: =>ipqos queue stats Name Queue # packets # packets # packets # packets # packets Marking added marked removed dropped replaced PVC_1 0 1240 1240 1345 1345 =>ipqos queue clear =>ipqos queue stats...

  • Page 459: Ipqos Queue Config

    IPQoS Commands ipqos queue config Modify the IPQoS subqueue configuration. SYNTAX: ipqos queue config dest = <string> queue = <number{0-5}> [propagate = <{disabled | enabled}>] [ecnmarking = <{disabled | enabled}>] [ackfiltering = <{disabled | enabled}>] [maxpackets = <number{0-250}>] [maxbytes = <number{0-128}>] [respackets = <number{0-250}>] [resbytes = <number{0-128}>] [hold = <number>]...
  • Page 460 IPQoS Commands maxbytes A number between 0 and 128. OPTIONAL Represents the maximum size in kilobytes of this queue. The default is for the Real time queue and for the other queues. Note 0 means that a maximum size is not enforced. respackets A number between 0 and 250.

  • Page 461: Ipqos Queue List

    IPQoS Commands ipqos queue list Display the IPQoS subqueue configuration. SYNTAX: ipqos queue list [dest = <string}>] where: dest The destination interface for the IPQoS queues instantiation. OPTIONAL This is an ATM phonebook entry. Note If not specified, the IPQoS subqueue configuration for all the interfaces will be shown.

  • Page 462: Ipqos Queue Stats

    IPQoS Commands ipqos queue stats Show the IPQoS subqueue statistics. SYNTAX: ipqos queue stats [dest = <string}>] where: dest The destination interface for the IPQoS queues instantiation. OPTIONAL This is an ATM phonebook entry. Note If not specified, the IPQoS subqueue statistics for all the interfaces will be shown.

  • Page 463: Label Commands

    Label Commands Label Commands Introduction This chapter describes the commands of the label command group. Contents This chapter covers the following commands: label add Create a new label. label delete Delete a label. label flush Flush all labels. label list Display the labels.

  • Page 464: Label Add

    Label Commands label add Create a new label. SYNTAX: label add name = <string> where: name The name of the label to be added. REQUIRED EXAMPLE: =>label list Name Class Bidirect Inherit Tosmark Type Value Ttlover Trace DSCP overwrite dscp defclass disabled disabled disabled tos disabled 0...

  • Page 465: Label Delete

    Label Commands label delete Delete a label. SYNTAX: label delete name = <string> [force = <{disabled | enabled}>] where: name The name of the label to be deleted. REQUIRED force Force delete and cleanup references even when the label is still in use (enabled) or not OPTIONAL (disabled).

  • Page 466: Label Flush

    Label Commands label flush Flush all labels. The flush command does not impact previously saved configurations. SYNTAX: label flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 467: Label List

    Label Commands label list Display the labels. SYNTAX: label list [name = <string>] where: name The name of the label to be displayed. OPTIONAL Note If not specified, all the labels will be displayed. EXAMPLE: =>label list Name Class Bidirect Inherit Tosmark Type Value...

  • Page 468: Label Modify

    Label Commands label modify Modify a label configuration. SYNTAX: label modify name = <string> [classification = <{ignore | overwrite | increase}>] [defclass = <number{0-15} | dscp | default>] [ackclass = <number{0-15} | defclass | prioritize>] [bidirectional = <{disabled | enabled}>] [inheritance = <{disabled | enabled}>] [tosmarking = <{disabled | enabled}>] [tos = <number{0-255}>]...
  • Page 469 Label Commands bidirectional The label applies to the initiator stream, the returning stream (the current OPTIONAL connection) as well as to the child connections (enabled) or not (disabled). The default is disabled. inheritance The label will be copied to all child connection streams in the same direction OPTIONAL (enabled) or not (disabled).

  • Page 470: Label Chain Add

    Label Commands label chain add Add a new label chain. SYNTAX: label chain add chain = <string> where: chain The name of the chain to be added. REQUIRED EXAMPLE: =>label chain list Chains ====== Name Description ------------------------------------------------- routing_labels system rt_user_labels user rt_default_labels user...

  • Page 471: Label Chain Delete

    Label Commands label chain delete Delete a label chain. SYNTAX: label chain delete chain = <string> where: chain The name of the chain to be deleted. REQUIRED EXAMPLE: =>label chain list Chains ====== Name Description ------------------------------------------------- routing_labels system rt_user_labels user rt_default_labels user qos_labels...

  • Page 472: Label Chain Flush

    Label Commands label chain flush Flush all label chains. SYNTAX: label chain flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 473: Label Chain List

    Label Commands label chain list Display a list of chains. SYNTAX: label chain list [format = <{pretty | cli}>] where: format Select the output format of the list. OPTIONAL Choose between: pretty: the configuration is shown as intuitive output in clear text. cli: the configuration is shown via the CLI commands configuration.

  • Page 474: Label Rule Add

    Label Commands label rule add Add a label rule. SYNTAX: label rule add chain = <chain name> [index = <number>] [name = <string>] [clink = <chain name>] [srcintf [!]= <string>] [srcip [!]= <{ip address | private}>] [dstip [!]= <{ip address | private}>] [serv [!]= <{service name}>] [log = <{disabled | enabled}>] [state = <{disabled | enabled}>]...
  • Page 475 Label Commands EXAMPLE: =>label rule list Rules (flags: C=Constant, D=Dynamic, E=Enable, L=Log) ===== Chain Flags Rule -------------------------------------------------------------------------------------------------- routing_labels : link rt_user_labels : link rt_default_labels qos_labels : link qos_user_labels : link qos_default_labels qos_default_labels : VoIP sip *.* > *.* : VoIP h323 *.* >...
  • Page 476 Label Commands RELATED COMMANDS: label rule delete Delete a label rule. label rule list Display a list of label rules. E-DOC-CTC-20060414-0006 v1.0...

  • Page 477: Label Rule Delete

    Label Commands label rule delete Delete a label rule. SYNTAX: label rule delete chain = <string> index = <number> where: chain The name of the chain in which a rule must be deleted. REQUIRED index The index number of the rule in the chain. REQUIRED Use the command :label rule list to obtain the index number of the applicable rule.
  • Page 478 Label Commands RELATED COMMANDS: label rule add Add a label rule. label rule list Display a list of label rules. E-DOC-CTC-20060414-0006 v1.0...

  • Page 479: Label Rule Flush

    Label Commands label rule flush Flush all label rules. The chains themselves are not removed. The flush command does not impact previously saved configurations. SYNTAX: label rule flush [chain = <string>] where: chain The name of the chain to be flushed. OPTIONAL Note If not specified, all the rules for all the chains are flushed.

  • Page 480: Label Rule List

    Label Commands label rule list Display a list of label rules. SYNTAX: label rule list [chain = <string>] [format = <{pretty | cli}>] where: chain The name of the chain for which the rules must be listed. OPTIONAL Note If not specified, all rules for all chains are shown. format Select the output format of the list.
  • Page 481 Label Commands EXAMPLE: =>label rule list format=cli :label rule add chain=qos_default_labels index=1 serv=sip log=disabled state=enabled label=VoIP :label rule add chain=qos_default_labels index=2 serv=h323 log=disabled state=enabled label=VoIP :label rule add chain=qos_default_labels index=3 serv=telnet log=disabled state=enabled label=Interactive :label rule add chain=qos_default_labels index=4 serv=smtp log=disabled state=enabled label=Interactive :label rule add chain=qos_default_labels index=5 serv=imap4-ssl log=disabled state=enabled label=Interactive...

  • Page 482: Label Rule Modify

    Label Commands label rule modify Modify a label rule. SYNTAX: label rule modify chain = <chain name> index = <number> [newindex = <number>] [name = <string>] [clink = <chain name>] [srcintf [!]= <string>] [srcip [!]= <{ip address | private}>] [dstip [!]= <{ip address | private}>] [serv [!]= <{service name}>] [log = <{disabled | enabled}>] [state = <{disabled | enabled}>]...

  • Page 483: Label Rule Debug Clear

    Label Commands label rule debug clear Clear the label rule statistics. SYNTAX: label rule debug clear [chain = <string>] [index = <number>] where: chain The name of the chain in which the rule is to be found. OPTIONAL Note If not specified, the statistics for all the rules in all chains will be cleared. index The index number (determined by the position) of the rule in the chain.

  • Page 484: Label Rule Debug Stats

    Label Commands label rule debug stats Display the label rule statistics. SYNTAX: label rule debug stats [chain = <string>] [index = <number>] where: chain The name of the chain for which the statistics must be shown. OPTIONAL Note If not specified, the statistics for the rules applicable to all chains are shown. index The index number of the rule for which the statistics must be shown.

  • Page 485: Label Rule Debug Traceconfig

    Label Commands label rule debug traceconfig Display or modify the rule trace configuration. SYNTAX: label rule debug traceconfig [trace = <{disabled | enabled}>] where: trace Disable or enable rule traces. OPTIONAL The default is disabled. EXAMPLE: =>label rule debug traceconfig :label rule debug traceconfig state=disabled =>...
  • Page 486 Label Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 487: Language Commands

    Language Commands Language Commands Introduction This chapter describes the commands of the language command group. Contents This chapter covers the following commands: language config Select a language. language delete Delete one or all language archives. language list List the available language archives. E-DOC-CTC-20060414-0006 v1.0...

  • Page 488: Language Config

    Language Commands language config Select a language. SYNTAX: language config [language = <string>] [complete = <{yes | no}>] where: language Language code: OSI language code (2 chars) for language. OPTIONAL Example: for english. complete Enable translation for expert pages. OPTIONAL The default is yes.

  • Page 489: Language Delete

    Language Commands language delete Delete one or all language archives. SYNTAX: language delete [file = <string>] [all = <{yes | no}>] where: file The filename of the language archive to be removed. OPTIONAL Remove all languages archives (yes) or not (no). OPTIONAL The default is no.

  • Page 490: Language List

    Language Commands language list List the available language archives. SYNTAX: language list EXAMPLE: =>language list CODE LANGUAGE VERSION FILENAME en* English 5.3.0.10.0 <system> => The currently selected language is indicated by a “*” next to the OSI language code. RELATED COMMANDS: language config Select a language.

  • Page 491: Mbus Commands

    MBUS Commands MBUS Commands Introduction This chapter describes the commands of the mbus command group. Contents This chapter covers the following commands: mbus config Modify mbus parameters. mbus client config Modify client parameters. mbus client exec Execute mbus command. mbus client register Register cli client to mbus.

  • Page 492: Mbus Config

    MBUS Commands mbus config Modify mbus parameters. SYNTAX: mbus config [autoload = <{disabled | enabled}>] where: autoload Enable or disable autoload object tree at boot time. OPTIONAL The default is enabled. E-DOC-CTC-20060414-0006 v1.0...

  • Page 493: Mbus Client Config

    MBUS Commands mbus client config Modify client parameters. SYNTAX: mbus client config [writelock = <{enabled | disabled}>] [wlgetimeout = <number>] [wlidletimeout = <number>] [path = <quoted string>] [type = <idpath | keypath>] where: writelock Enable or disable mbus writelock. OPTIONAL The default is enabled.

  • Page 494: Mbus Client Exec

    MBUS Commands mbus client exec Execute mbus command. SYNTAX: mbus client exec cmd = <{addobject | deleteobject | getparamattributes | getparamcount | getparamnames | getparamvalues | getpath | setparamvalue}> [param = <quoted string>] [value = <quoted string>] [gettype = <{object | parameter | path}>] [depth = <number>] [processcmd = <{disabled | enabled}>] [readcommitted = <{disabled | enabled}>]...
  • Page 495 MBUS Commands RELATED COMMANDS: mbus client config Modify client parameters. mbus client register Register cli client to mbus. mbus client test Test functionality invoked. E-DOC-CTC-20060414-0006 v1.0...

  • Page 496: Mbus Client Register

    MBUS Commands mbus client register Register cli client to mbus. SYNTAX: mbus client register RELATED COMMANDS: mbus client config Modify client parameters. mbus client exec Execute mbus command. mbus client test Test functionality invoked. E-DOC-CTC-20060414-0006 v1.0...

  • Page 497: Mbus Client Test

    MBUS Commands mbus client test Test functionality invoked. SYNTAX: mbus client test [path = <quoted string>] [type = <{idpath | keypath}>] where: path Fully qualified mbus path. OPTIONAL type Path type. OPTIONAL Choose between: idpath keypath. The default is idpath. EXAMPLE: =>mbus client test pool name...

  • Page 498: Mbus Debug Stats

    MBUS Commands mbus debug stats Display mbus statistics. SYNTAX: mbus debug stats RELATED COMMANDS: mbus debug traceconfig Modify mbus trace settings. E-DOC-CTC-20060414-0006 v1.0...

  • Page 499: Mbus Debug Traceconfig

    MBUS Commands mbus debug traceconfig Modify mbus trace settings. SYNTAX: mbus debug traceconfig [level = <number{0-4}>] where: level A number between 0 and 4. OPTIONAL Represents the mbus trace level. RELATED COMMANDS: mbus debug stats Display mbus statistics. E-DOC-CTC-20060414-0006 v1.0...

  • Page 500: Mbus Listobjects

    MBUS Commands mbus listobjects Display the object instances. SYNTAX: mbus listobjects [path = <quoted string>] [type = <{idpath | keypath}>] [output = <{list | tree}>] [expand = <{disabled | enabled}>] where: path Fully qualified mbus path to list. OPTIONAL type Path type.

  • Page 501: Mbus Listtypes

    MBUS Commands mbus listtypes Display the registered objecttypes. SYNTAX: mbus listtypes [path = <quoted string>] [expand = <{disabled | enabled}>] where: path Fully qualified mbus path to list. OPTIONAL expand Enable or disable details. OPTIONAL The default is disabled. EXAMPLE: =>mbus listtypes - root + InternetGatewayDevice...

  • Page 502: Mbus Loadobjects

    MBUS Commands mbus loadobjects Load object instances of registered objecttypes. SYNTAX: mbus loadobjects [path = <quoted string>] [type = <{idpath | keypath}>] where: path Fully qualified mbus path. OPTIONAL type Path type. OPTIONAL Choose between: idpath keypath. The default is idpath. RELATED COMMANDS: mbus unloadobjects Unload object instances.

  • Page 503: Mbus Unloadobjects

    MBUS Commands mbus unloadobjects Unload object instances. SYNTAX: mbus unloadobjects [path = <quoted string>] [type = <{idpath | keypath}>] where: path Fully qualified mbus path. OPTIONAL type Path type. OPTIONAL Choose between: idpath keypath. The default is idpath. RELATED COMMANDS: mbus loadobjects Load object instances of registered objecttypes.
  • Page 504 MBUS Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 505: Memm Commands

    MEMM Commands MEMM Commands Introduction This chapter describes the commands of the memm command group. Contents This chapter covers the following commands: memm debug lock Modify lock trace settings. traceconfig memm debug traceconfig Modify memm trace settings. memm listobjects Display objects. memm stats Display memm statistics.

  • Page 506: Memm Debug Lock Traceconfig

    MEMM Commands memm debug lock traceconfig Modify lock trace settings. SYNTAX: memm debug lock traceconfig [level = <number{0-4}>] [name = <string>] where: level A number between 0 and 4. OPTIONAL Represents the memm trace level. name Application name filter for lock traces (empty displays all lock OPTIONAL traces).

  • Page 507: Memm Debug Traceconfig

    MEMM Commands memm debug traceconfig Modify memm trace settings. SYNTAX: memm debug traceconfig [level = <number{0-4}>] where: level A number between 0 and 4. OPTIONAL Represents the memm trace level. E-DOC-CTC-20060414-0006 v1.0...

  • Page 508: Memm Listobjects

    MEMM Commands memm listobjects Display objects. SYNTAX: memm listobjects [name = <quoted string>] where: name Select typename(s) to list (supports partial typename). OPTIONAL E-DOC-CTC-20060414-0006 v1.0...

  • Page 509: Memm Stats

    MEMM Commands memm stats Display memm statistics. SYNTAX: memm stats [name = <quoted string>] where: name Select typename(s) to list (supports partial typename). OPTIONAL EXAMPLE: =>memm stats pool name bytes cur,max,avail (max.%) count cur,max,avail ref cur,max,avail --------- ---------------------------- ------------------- ----------------- memm_pooldesc 1196, 1196,...
  • Page 510 MEMM Commands EXAMPLE: =>memm stats pool name bytes cur,max,avail (max.%) count cur,max,avail cur,max,avail ------------- --------------------------- ------------------- memm_pooldesc 1196, 1196, 1300 ( 92%) dynstr_pool 120 ( 60%) mbus_llist 2460, 2532, 4920 ( 51%) 205, 211, mbus_dynstr 2316, 2424, 4920 ( 49%) 193, 202, - strings buffer...

  • Page 511: Mlp Commands

    MLP Commands MLP Commands Introduction This chapter describes the commands of the mlp command group. Contents This chapter covers the following commands: mlp flush Flush all the Multi-Level access Policies (MLP) structures. mlp import Import all the scores. mlp debug export Export all the scores.

  • Page 512: Mlp Flush

    MLP Commands mlp flush Flush all the Multi-Level access Policies (MLP) structures. SYNTAX: mlp flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 513: Mlp Import

    MLP Commands mlp import Import all the scores. SYNTAX: mlp import [trace = <{disabled | enabled | full}>] where: trace Select the import trace level. OPTIONAL Choose between: disabled enabled full. The default is disabled. RELATED COMMANDS: mlp debug export Export all the scores.

  • Page 514: Mlp Debug Export

    MLP Commands mlp debug export Export all the scores. SYNTAX: mlp debug export RELATED COMMANDS: mlp import Import all the scores. E-DOC-CTC-20060414-0006 v1.0...

  • Page 515: Mlp Debug Stats

    MLP Commands mlp debug stats Display MLP statistics. SYNTAX: mlp debug stats EXAMPLE: =>mlp debug stats Roles (cur/free/max) : 8/7/15 Privileges (cur/free/max) : 35/25/60 ListItems (cur/free/max) : 31/119/150 => E-DOC-CTC-20060414-0006 v1.0...

  • Page 516: Mlp Debug Traceconfig

    MLP Commands mlp debug traceconfig Modify the MLP trace settings. SYNTAX: mlp debug traceconfig [trace = <{disabled | enabled | full}>] where: trace Select the trace level. OPTIONAL Choose between: disabled enabled full. The default is disabled. EXAMPLE: =>mlp debug traceconfig mlp trace: disabled =>...

  • Page 517: Mlp Privilege Add

    MLP Commands mlp privilege add Add a privilege. SYNTAX: mlp privilege add name = <quoted string> type = <{access | service}> [descr = <quoted string>] where: name The name of the new privilege. REQUIRED Note The maximum number of privileges is 60. type Select the privilege type.
  • Page 518 MLP Commands RELATED COMMANDS: mlp privilege delete Delete a privilege. mlp privilege list Display the privileges. E-DOC-CTC-20060414-0006 v1.0...

  • Page 519: Mlp Privilege Addzone

    MLP Commands mlp privilege addzone Add a zone to a privilege. Only one zone can be added at a time to a privilege. If multiple zones need to be added, the command :mlp privilege addzone must be executed for each zone to be added. SYNTAX: mlp privilege addzone name = <string>...

  • Page 520: Mlp Privilege Config

    MLP Commands mlp privilege config Modify a privilege. SYNTAX: mlp privilege config name = <string> [descr = <quoted string>] [score = <{hex-word}[:{hex-word}] ex: 'a12:c30f'>] where: name The name of the privilege to be modified. REQUIRED descr Set the privilege description. OPTIONAL Note The maximum length is 63 characters.

  • Page 521: Mlp Privilege Delete

    MLP Commands mlp privilege delete Delete a privilege. SYNTAX: mlp privilege delete name = <string> where: name The name of the privilege to be deleted. REQUIRED EXAMPLE: =>mlp privilege list type=access Privilege (type) Description ---------------------------- anyaccess (access) All access privileges granted AP1 (access) LAN _Local_all AP2 (access) LAN_Local with all secured channels AP3 (access) LAN_Local with all channels &...

  • Page 522: Mlp Privilege List

    MLP Commands mlp privilege list Display the privileges. SYNTAX: mlp privilege list [name = <string>] [type = <{access | service}>] [verbose = <{minimal | medium | all}>] where: name The name of the privilege to be listed. OPTIONAL Note If not specified, all the privileges will be shown. type Select the privilege type to be shown.
  • Page 523 MLP Commands RELATED COMMANDS: mlp privilege delete Add a privilege. mlp privilege delete Delete a privilege. E-DOC-CTC-20060414-0006 v1.0...

  • Page 524: Mlp Privilege Removezone

    MLP Commands mlp privilege removezone Remove a zone from a privilege. Only one zone can be removed at a time from a privilege. If multiple zones need to be removed, the command :mlp privilege removezone must be executed for each zone to be removed. SYNTAX: mlp privilege removezone name = <string>...

  • Page 525: Mlp Role Add

    MLP Commands mlp role add Add a role. SYNTAX: mlp role add name = <quoted string> parent = <string> [descr = <quoted string>] where: name The name of the new role. REQUIRED Note The maximum number of roles is 15. parent The name of the parent role.

  • Page 526: Mlp Role Addpriv

    MLP Commands mlp role addpriv Add a privilege to a role. SYNTAX: mlp role addpriv name = <string> access = <string> service = <string> where: name The name of the role. REQUIRED access The name of the access privilege to be added. REQUIRED service The name of the service privilege to be added.

  • Page 527: Mlp Role Config

    MLP Commands mlp role config Modify the role. SYNTAX: mlp role config name = <string> [parent = <string>] [descr = <quoted string>] where: name The name of the role to be configured. REQUIRED parent The name of the parent role. OPTIONAL descr The role description.

  • Page 528: Mlp Role Delete

    MLP Commands mlp role delete Delete a role. SYNTAX: mlp role delete name = <string> where: name The name of the role to be deleted. REQUIRED EXAMPLE: =>mlp role list Role (parent) Description ------------------------- root (-) The superuser SuperUser (root) Any service and any access from LAN/WAN/LOCAL TechnicalSupport (SuperUser) Any service and any channels from WAN Administrator (TechnicalSupport) Any service and any access from LAN/Local origin only PowerUser (Administrator) GUI(Service/overview page)via http/https from LAN origin...

  • Page 529: Mlp Role List

    MLP Commands mlp role list Display the roles. SYNTAX: mlp role list [name = <string>] [verbose = <{minimal | medium | all}>] where: name The name of the role to be listed. OPTIONAL Note If not specified, all the roles will be listed. verbose Limit the output list.

  • Page 530: Mlp Role Removepriv

    MLP Commands mlp role removepriv Remove a privilege from a role. SYNTAX: mlp role removepriv name = <string> access = <string> [service = <string>] where: name The name of the role. REQUIRED access The name of the access privilege to be deleted. REQUIRED service The name of the service privilege to be deleted.

  • Page 531: Nat Commands

    NAT Commands NAT Commands Introduction This chapter describes the commands of the nat command group. Contents This chapter covers the following commands: nat config Display/modify global NAT configuration options. nat flush Flush the current NAT configuration. nat ifconfig Modify address translation on an IP interface. nat iflist Display the address translation configuration on all the interfaces.

  • Page 532: Nat Config

    NAT Commands nat config Display/modify global NAT configuration options. SYNTAX: nat config [trace = <{disabled | enabled}>] where: trace Enable or disable traces. REQUIRED The default is disabled. EXAMPLE: =>nat config NAT traces : disabled =>nat config trace=enabled =>nat config NAT traces : enabled =>...

  • Page 533: Nat Flush

    NAT Commands nat flush Flush the current NAT configuration. SYNTAX: nat flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 534: Nat Ifconfig

    Address translation is disabled. enabled: Address translation is enabled. transparent: An inside address is translated into the same outside IP address. In fact, no translation happens and the IP packets passing through the SpeedTouch™ remain untouched. The default is disabled. EXAMPLE: =>nat iflist...

  • Page 535: Nat Iflist

    NAT Commands nat iflist Display the address translation configuration on all the interfaces. SYNTAX: nat iflist EXAMPLE: =>nat iflist Interface loop disabled Internet enabled RtPPPoE_ppp enabled LocalNetwork transparent => RELATED COMMANDS: nat ifconfig Modify address translation on an IP interface. E-DOC-CTC-20060414-0006 v1.0...

  • Page 536: Nat Mapadd

    NAT Commands nat mapadd Add an address mapping to a Network Address Translation (NAT) enabled interface. SYNTAX: nat mapadd intf = <string> [type = <{napt | nat}>] [outside_addr = <ip-range>] [inside_addr = <ip-range>] [access_list = <ip-range>] [foreign_addr = <ip-range>] [protocol = <{supported IP protocol} or number>] [outside_port = <port-range>] [inside_port = <port-range>] [mode = <{auto | inbound | outbound}>]...
  • Page 537 NAT Commands access_list The range of inside addresses to which the mapping is restricted. OPTIONAL This parameter is used for outbound traffic only. Represents the list of inside IP addresses (LAN devices) allowed to make use of this map. Allowed values are: An IP address (A.B.C.D or A.D, meaning A.0.0.D).
  • Page 538 NAT Commands mode The mode to create the portmap. OPTIONAL Choose between: auto inbound outbound. The standard is auto. EXAMPLE: =>nat maplist Idx Type Interface Outside Address Inside Address 1 NAPT eth0 any:80 127.0.0.1:8080 2 NAPT eth0 any:1080 127.0.0.1:8080 3 NAPT eth0 any:8080 127.0.0.1:8080 =>nat mapadd intf=myPPP_ppp type=napt outside_addr=100.100.100.1 access_list=10.0.0.0/24...

  • Page 539: Nat Mapdelete

    NAT Commands nat mapdelete Delete an address mapping from a NAT enabled interface. SYNTAX: nat mapdelete intf = <string> index = <number> where: intf The IP interface name. REQUIRED index The map index. REQUIRED Use the command :nat maplist to obtain a list of the mapindexes. EXAMPLE: =>nat maplist Idx Type Interface...

  • Page 540: Nat Maplist

    NAT Commands nat maplist Display the address mapping for a NAT enabled interface. SYNTAX: nat maplist [intf = <string>] [expand = <{disabled | enabled}>] where: intf The IP interface name. OPTIONAL Note If not specified, the address mapping for all the NAT enabled interfaces will be shown.

  • Page 541: Nat Tmpladd

    NAT Commands nat tmpladd Add an address mapping template. SYNTAX: nat tmpladd [intf = <string>] [group = <{wan|local|lan|tunnel|dmz|guest} or number>] [timeout = <number{0-65535}>] [type = <{napt | nat}>] outside_addr = <ip-range> [inside_addr = <ip-range>] [access_list = <ip-range>] [foreign_addr = <ip-range>] [protocol = <{supported IP protocol} or number>] [outside_port = <port-range>] [inside_port = <port-range>]...
  • Page 542 NAT Commands inside_addr The inside (typically private) IP address. OPTIONAL for NAT maps Inbound: Represents the address(es) to be used as destination address and NAPT after translation. maps. Outbound: This map will only apply if the source IP address is part of the inside address(es).
  • Page 543 NAT Commands outside_port The outside port number or range (only for maps of type napt). OPTIONAL for NAPT map. For a NAPT map: Represents the range of TCP/UDP ports to be used as dynamic port REQUIRED for range during the NAPT process. port-shifting map.

  • Page 544: Nat Tmpldelete

    NAT Commands nat tmpldelete Delete an address mapping template. SYNTAX: nat tmpldelete index = <number> where: index The index of the address mapping template to be deleted. REQUIRED Use the command :nat tmpllist to view the address mapping templates. EXAMPLE: =>nat tmpllist Idx Type Interface Ifgroup...

  • Page 545: Nat Tmpllist

    NAT Commands nat tmpllist Display the address mapping templates. SYNTAX: nat tmpllist [expand = <{disabled | enabled}>] where: expand Enable or disable expanded listing. OPTIONAL The default is disabled. EXAMPLE: =>nat tmpllist Idx Type Interface Ifgroup Outside Address Inside Address 1 NAPT any 100.200.100.1 unmapped...

  • Page 546: Nat Tmplinst

    NAT Commands nat tmplinst Instantiate address mapping templates for a given dynamic address. SYNTAX: nat tmplinst intf = <string> addr_index = <ip-address> dynamic_addr = <ip-address> where: intf The IP interface name. REQUIRED addr_index The outside IP address index/key to instantiate for. REQUIRED dynamic_addr The dynamic address to substitute the index/key with.

  • Page 547: Ppp Commands

    PPP Commands PPP Commands Introduction This chapter describes the commands of the ppp command group. Contents This chapter covers the following commands: ppp flush Flush all PPP interfaces. ppp ifadd Create a new PPP interface. ppp ifattach Attach a PPP interface. ppp ifconfig Configure a PPP interface.

  • Page 548: Ppp Flush

    PPP Commands ppp flush Flush all PPP interfaces. The flush command does not impact previously saved configurations. SYNTAX: ppp flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 549: Ppp Ifadd

    PPP Commands ppp ifadd Create a new PPP interface. SYNTAX: ppp ifadd intf = <string> where: intf The name for the new PPP interface. REQUIRED Note If not specified, the destination parameter must be specified. In this case the name of the destination will double as interface name. EXAMPLE: =>ppp iflist Internet: dest : RELAY...

  • Page 550: Ppp Ifattach

    PPP Commands ppp ifattach Attach a PPP interface. SYNTAX: ppp ifattach intf = <string> where: intf The name of the PPP interface to be attached. REQUIRED EXAMPLE: =>ppp iflist Internet: dest : RELAY [00:00:00] Retry : 10 mode = IP routing flags = echo magic accomp restart mru addr savepwd demanddial dns metric = 0 mru = 1492...
  • Page 551 PPP Commands RELATED COMMANDS: ppp ifdetach Detach a PPP interface. E-DOC-CTC-20060414-0006 v1.0...

  • Page 552: Ppp Ifconfig

    PPP Commands ppp ifconfig Configure a PPP interface. The interface to be configured must not be connected at the time of configuration. If this should be the case, use the command :ppp ifdetach before using the command :ppp ifconfig. SYNTAX: ppp ifconfig intf = <string>...
  • Page 553 The access concentrator is on this side of the PPPoE connection. OPTIONAL Choose between: enabled: the PPP connection is terminated on the Access Concentrator (here the SpeedTouch™ itself) disabled: the SpeedTouch™ is PPP client. The default is disabled. auth Select the authentication protocol. OPTIONAL Choose between: pap: Password Authentication Protocol (PAP) authentication will be forced.
  • Page 554 The IP address of the primary DNS server. OPTIONAL In case a primary DNS server is specified, the SpeedTouch™ will negotiate this IP address with the remote side. Note If not specified, the SpeedTouch™ will accept any IP address.
  • Page 555 PPP Commands idletrigger Consider the link being idle if no traffic is sent and/or received during the idle OPTIONAL time. Choose between: RxTx: The idle time period restarts when a packet is transmitted or received. Rx: The idle time period restarts when a packet is received. Transmitted packets are ignored.

  • Page 556: Ppp Ifdelete

    PPP Commands ppp ifdelete Delete a PPP interface. SYNTAX: ppp ifdelete intf = <intfname> where: intf The name of the PPP interface to be deleted. REQUIRED EXAMPLE: =>ppp iflist Internet: dest : RELAY [00:00:00] Retry : 10 mode = IP routing flags = echo magic accomp restart mru addr savepwd demanddial dns metric = 0 mru = 1492...

  • Page 557: Ppp Ifdetach

    PPP Commands ppp ifdetach Detach a PPP interface. SYNTAX: ppp ifdetach intf = <intfname> where: intf The name of the PPP interface to be detached. REQUIRED EXAMPLE: =>ppp iflist Internet: dest : RELAY [00:00:00] Retry : 10 mode = IP routing flags = echo magic accomp restart mru addr savepwd demanddial dns metric = 0 mru = 1492...
  • Page 558 PPP Commands RELATED COMMANDS: ppp ifattach Attach a PPP interface. E-DOC-CTC-20060414-0006 v1.0...

  • Page 559: Ppp Iflist

    PPP Commands ppp iflist Display the PPP interfaces. SYNTAX: ppp iflist [intf = <intfname>] where: intf The name of the PPP interface. OPTIONAL Note If not specified, all PPP interfaces are shown. EXAMPLE INPUT/OUTPUT : =>ppp iflist Internet: dest : RELAY [00:00:00] Retry : 10 mode = IP routing...

  • Page 560: Ppp Ifscan

    PPP Commands ppp ifscan Scan a PPPoE interface for available Access Concentrator and Service names. Use the command :ppp ifdetach for this interface before performing a scan on it. SYNTAX: ppp ifscan intf = <string> [time = <number{0-36000}>] where: intf The name of the PPPoE interface to be scanned.

  • Page 561: Ppp Rtadd

    PPP Commands ppp rtadd Add a route to the routing table when the PPP link comes up. This route configuration will determine which local hosts are allowed to use this link and/or which remote destinations should be or should not be reachable. The interface must not be connected when a route configuration is added.
  • Page 562 PPP Commands EXAMPLE: =>ppp iflist Internet: dest : RELAY [00:00:00] Retry : 10 mode = IP routing flags = echo magic accomp restart mru addr savepwd demanddial dns metric = 0 mru = 1492 Tx inactivity = 1200s left = 0s auth = auto user = password =...

  • Page 563: Ppp Rtdelete

    PPP Commands ppp rtdelete Delete the route for a PPP link. The interface must not be connected when a route configuration must be deleted. If the interface is connected, use the command :ppp ifdetach for this interface. SYNTAX: ppp rtdelete intf = <intfname>...
  • Page 564 PPP Commands EXAMPLE: =>ppp iflist Internet: dest : RELAY [00:00:00] Retry : 10 mode = IP routing flags = echo magic accomp restart mru addr savepwd demanddial dns metric = 0 mru = 1492 Tx inactivity = 1200s left = 0s auth = auto user = password =...

  • Page 565: Ppp Relay Flush

    PPP Commands ppp relay flush Remove all Ethernet interfaces from the PPP relay agent list and terminate all sessions. The flush command does not impact previously saved configurations. SYNTAX: ppp relay flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 566: Ppp Relay Ifadd

    PPP Commands ppp relay ifadd Add an Ethernet interface to the PPP relay list. SYNTAX: ppp relay ifadd intf = <string> where: intf The Ethernet interface to be added to the PPP relay agent list. REQUIRED EXAMPLE: =>ppp relay iflist Interface HWaddr Status...

  • Page 567: Ppp Relay Ifconfig

    PPP Commands ppp relay ifconfig Modify an ethernet interface from the PPP relay agent list. SYNTAX: ppp relay ifconfig intf = <string> hwaddr = <hardware-address> where: inft The ethernet intf to be added to the PPP relay agent list. REQUIRED hwaddr The hardware address (e.g.

  • Page 568: Ppp Relay Ifdelete

    PPP Commands ppp relay ifdelete Delete an Ethernet interface from the PPP relay agent list. SYNTAX: ppp relay ifdelete intf = <string> where: intf The Ethernet interface to be deleted from the PPP relay agent list. REQUIRED EXAMPLE: =>ppp relay iflist Interface HWaddr Status...

  • Page 569: Ppp Relay Iflist

    PPP Commands ppp relay iflist Display all Ethernet interfaces added to the PPP relay agent list. SYNTAX: ppp relay iflist where: intf The Ethernet interface to be added to the PPP relay agent list. REQUIRED EXAMPLE: =>ppp relay iflist Interface HWaddr Status ethoa_0_35...

  • Page 570: Ppp Relay Sesslist

    PPP Commands ppp relay sesslist Add an Ethernet interface to the PPP relay list. SYNTAX: ppp relay ifadd intf = <string> where: intf The Ethernet interface to be added to the PPP relay agent list. REQUIRED E-DOC-CTC-20060414-0006 v1.0...

  • Page 571: Pptp Commands

    PPTP Commands PPTP Commands Introduction This chapter describes the commands of the pptp command group. Contents This chapter covers the following commands: pptp ifadd Add a Point-to-Point Tunneling Protocol (PPTP) profile. pptp flush Flush the complete PPTP configuration. pptp list Show the current PPTP configuration.

  • Page 572: Pptp Ifadd

    PPTP Commands pptp ifadd Add a Point-to-Point Tunneling Protocol (PPTP) profile. Backwards compatible with previous release, use profiles instead. SYNTAX: pptp ifadd dest = <string> [rate = <number{10-10000}>] [encaps = <{vcmux | nlpid}>] [ac = <{never | always | keep}>] where: dest The WAN destination for this PPTP tunnel.

  • Page 573: Pptp Flush

    PPTP Commands pptp flush Flush the complete PPTP configuration. The flush command does not impact previously saved configurations. SYNTAX: pptp flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 574: Pptp List

    PPTP Commands pptp list Show the current PPTP configuration. SYNTAX: pptp list EXAMPLE: =>pptp list Dialstr Destination Encaps State User DIALUP_PPP3 default vcmux never CONNECTED (10.0.0.2) => E-DOC-CTC-20060414-0006 v1.0...

  • Page 575: Pptp Profadd

    PPTP Commands pptp profadd Define a new PPTP profile. SYNTAX: pptp profadd name = <string> [qos = <string>] [encaps = <{vcmux | nlpid}>] [ac = <{never | always | keep}>] where: name The name of the new PPTP profile. REQUIRED The name of the qosbook entry, containing the settings for this profile.

  • Page 576: Pptp Profdelete

    PPTP Commands pptp profdelete Delete a PPTP profile. SYNTAX: pptp profdelete name <string> where: name The name of the PPTP profile to be deleted. REQUIRED EXAMPLE: =>pptp proflist Profile Encaps Relay_PPP1 default nlpid always PPTPLink default vcmux never =>pptp profdelete name=PPTPLink =>pptp proflist Profile Encaps...

  • Page 577: Pptp Proflist

    PPTP Commands pptp proflist Display all the current PPTP profiles. SYNTAX: pptp proflist EXAMPLE: =>pptp proflist Profile Encaps Relay_PPP1 default nlpid always PPTPLink default vcmux never => RELATED COMMANDS: pptp profadd Define a new PPTP profile. pptp profdelete Delete a PPTP profile. E-DOC-CTC-20060414-0006 v1.0...
  • Page 578 PPTP Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 579: Script Commands

    Script Commands Script Commands Introduction This chapter describes the commands of the script command group. Scripting is not a general purpose mechanism but is only used in the autoPVC/ILMI mechanism. It is recommended not to change the default scripts. Contents This chapter covers the following commands: script add Add a line to a script.

  • Page 580: Script Add

    Script Commands script add Add a line to a script. SYNTAX: script add name = <string> [index = <number>] command = <quoted string> where: name Name of the script in which a line must be added. REQUIRED index Line number OPTIONAL Note Use 0 to add a line.

  • Page 581: Script Delete

    Script Commands script delete Delete a complete script or a line from a script. SYNTAX: script delete name = <string> [index = <number>] where: name Name of the script to be deleted. REQUIRED index Line number to be deleted. OPTIONAL Use the command :script list to view the line numbers.

  • Page 582: Script Flush

    Script Commands script flush Flush all scripts. The flush command does not impact previously saved configurations. SYNTAX: script flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 583: Script List

    Script Commands script list Display a script or all scripts. SYNTAX: script list [name = <string>] where: name Name of the script to be listed. OPTIONAL Note If not specified, all the scripts are displayed. EXAMPLE Some of the default scripts are shown below: =>script list Script: autopvc_add_qos 0: qosbook add name _auto_$1_$2 class $3 tx_peakrate $4 tx_sustrate $5 tx_maxburst $6...

  • Page 584: Script Run

    Script Commands script run Run a script. SYNTAX: script run name = <string> pars = <string> where: name Name of the script to be run. REQUIRED Use the command :script list to obtain the names of the different scripts. pars Parameters separated with comma.

  • Page 585: Service Commands

    Service Commands Service Commands Introduction This chapter describes the commands of the service command group. Contents This chapter covers the following commands: service host assign Assign a host service to a LAN device. service host config Get/set global host service configuration options. service host add Add a host service.

  • Page 586: Service Host Assign

    Service Commands service host assign Assign a host service to a LAN device. SYNTAX: service host assign name = <quoted string> [host = <ip-address>] [log = <{disabled|enabled}>] where: name The name of an existing host service. REQUIRED host The IP address of the LAN device. OPTIONAL Enable or disable logging.

  • Page 587: Service Host Config

    Service Commands service host config Get/set global host service configuration options. SYNTAX: service host config [trace = <{disabled | enabled}>] where: trace Enable or disable traces. REQUIRED The default is disabled. EXAMPLE: =>service host config Service traces : disabled l=> E-DOC-CTC-20060414-0006 v1.0...

  • Page 588: Service Host Add

    Service Commands service host add Add a host service. SYNTAX: service host add name = <quoted string> [mode = <{server | client | custom}>] where: name The name of the new host service. REQUIRED mode The service mode. OPTIONAL Choose between: server: The service is defined for server purposes.

  • Page 589: Service Host Delete

    Service Commands service host delete Delete a host service. SYNTAX: service host delete name = <quoted string> where: name The name of the host service to be deleted. REQUIRED EXAMPLE: =>service host list Service Name Host User-Defined Mode --------------------------------------------------------------------------- Age of Empires unassigned server AIM Talk...

  • Page 590: Service Host Disable

    Service Commands service host disable Disable a host service. SYNTAX: service host disable [name = <quoted string>] where: name The name of the host service to be disabled. OPTIONAL Note If not specified, all the host services will be disabled. EXAMPLE: =>service host list Service Name...

  • Page 591: Service Host Flush

    Service Commands service host flush Flush all host services. SYNTAX: service host flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 592: Service Host List

    Service Commands service host list Display a list of host services. SYNTAX: service host list [name = <quoted string>] where: name The name of the host service to be listed. REQUIRED Note If not specified, all the host services will be listed. EXAMPLE: =>service host list Service Name...

  • Page 593: Service Host Stats

    Service Commands service host stats Show the host service statistics. SYNTAX: service host stats EXAMPLE: =>service host stats Services : 113 of 150 in use. Service maps : 225 of 300 in use. Trigger ports: 0 of 25 in use. =>...

  • Page 594: Service Host Triggerlist

    Service Commands service host triggerlist List all triggers. SYNTAX: service host triggerlist EXAMPLE: =>service triggerlist Triggerport Portrange Timeout ----------- --------- ------- => E-DOC-CTC-20060414-0006 v1.0...

  • Page 595: Service Host Rule Add

    Service Commands service host rule add Create/define a host service portmap. SYNTAX: service host rule add name = <quoted string> [protocol = <{any|tcp|udp} or number>] [baseport = <supported UDP port | number>] portrange = <port-range> [triggerport = <supported UDP port | number>] [triggerprotocol = <{any|tcp|udp} or number>] where: name...

  • Page 596: Service Host Rule Delete

    Service Commands service host rule delete Delete a host service portmap. SYNTAX: service host rule delete name = <quoted string> [protocol = <{any|tcp|udp} or number>] [baseport = <supported UDP port | number>] portrange = <port-range> [triggerport = <supported UDP port | number>] [triggerprotocol = <{any|tcp|udp} or number>] where: name...

  • Page 597: Service System Ifadd

    Service Commands service system ifadd Add an interface group to the access list. SYNTAX: service system ifadd name = <string> group = <{wan|local|lan|tunnel|dmz|guest} or number> where: name The name of the system service for this access list. REQUIRED group The interface group for this access list. REQUIRED EXAMPLE: =>service system list name=SIPPBX expand=enabled...

  • Page 598: Service System Ifdelete

    Service Commands service system ifdelete Delete an interface group from the access list. SYNTAX: service system ifdelete name = <string> group = <{wan|local|lan|tunnel|dmz|guest} or number> where: name The name of the system service for this access list. REQUIRED group The interface group for this access list. REQUIRED EXAMPLE: =>service system list name=SIPPBX expand=enabled...

  • Page 599: Service System Ipadd

    Service Commands service system ipadd Add an IP address (range) to the access list. SYNTAX: service system ipadd name = <string> ip = <ip-range> where: name The name of the system service for this access list. REQUIRED The IP address (range) for this access list. REQUIRED EXAMPLE: =>service system list name=SIPPBX expand=enabled...

  • Page 600: Service System Ipdelete

    Service Commands service system ipdelete Delete an IP address (range) from the access list. SYNTAX: service system ipdelete name = <string> ip = <ip-range> where: name The name of the system service for this access list. REQUIRED The IP address (range) for this access list. REQUIRED EXAMPLE: =>service system list name=SIPPBX expand=enabled...

  • Page 601: Service System List

    Service Commands service system list Display the system services. SYNTAX: service system list [name = <string>] [expand = <{disabled | enabled}>] [dynamics = <{disabled | enabled}>] [members = <{disabled | enabled}>] where: name The name of the system service to be displayed. OPTIONAL Note If not specified, all the system services will be displayed.
  • Page 602 Service Commands EXAMPLE: =>service system list Idx Name Protocol SrcPort DstPort Group State --------------------------------------------------------------------------------- 1 DNS-C enabled 2 SNTP enabled 3 SLA_ICMP_PING icmp enabled 4 SLA_UDP_PING enabled 5 SLA_ICMP_TRRT icmp enabled 6 SLA_UDP_TRRT 33434 enabled 7 SYSLOG enabled 8 HTTP enabled 9 HTTPs enabled...

  • Page 603: Service System Mapadd

    Service Commands service system mapadd Add a port map for a system service. SYNTAX: service system mapadd name = <{string}> intf = <{auto|loop|Internet|LocalNetwork}> port = <supported port or number> where: name The name of the system service for this map. REQUIRED intf The interface for this map.

  • Page 604: Service System Mapdelete

    Service Commands service system mapdelete Delete a port map for a system service. SYNTAX: service system mapdelete name = <string> intf = <{auto|loop|Internet|LocalNetwork}> port = <supported port or number> where: name The name of the system service for this map. REQUIRED intf The interface for this map.

  • Page 605: Service System Modify

    Service Commands service system modify Modify a system service. SYNTAX: service system modify name = <string> [state = <{disabled | enabled}>] [port = <supported port or number>] [srcintf = <string>] [log = <{disabled|enabled}>] [forward = <{disabled|enabled}>] where: name The name of the system service for this map. REQUIRED state Disable or enable this system service.
  • Page 606 Service Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 607: Snmp Commands

    SNMP Commands SNMP Commands Introduction This chapter describes the commands of the snmp command group. Contents This chapter covers the following commands: snmp config Show/set global Simple Network Management Protocol (SNMP) parameters. snmp get Get from the supplied SNMP Object IDentifier (OID). snmp getnext GetNext from the supplied SNMP OID.

  • Page 608: Snmp Config

    The default is Customer Premises. EXAMPLE: =>snmp config SNMP System Contact : Service Provider SNMP System Name : SpeedTouch SNMP System Location : Customer Premises All SNMP traps : ENABLED Delay, in secs before first trap is sent : 90 =>...

  • Page 609: Snmp Get

    The Object Identifier. Object ID to get from ... must include the instance which is 0 OPTIONAL for scalar objects, for example .1.3.6.1.2.1.1.1.0 sysDescription. Note If not specified, the sysDescription OID .1.3.6.1.2.1.1.1.0 is assumed. Its value is SpeedTouch™. EXAMPLE: =>snmp get VB_octetStr .1.3.6.1.2.1.1.1.0 SpeedTouch™...

  • Page 610: Snmp Getnext

    SNMP Commands snmp getnext GetNext from the supplied SNMP OID. SYNTAX: snmp getnext [ObjectId = <string>] where: ObjectID The Object Identifier. OPTIONAL Object ID to getnext from for example .1.3.6.1.2.1.1 system returns sysDescription. EXAMPLE: =>snmp getnext ObjectId=.1.3.6.1.2.1.1.4.0 VB_octetStr .1.3.6.1.2.1.1.5.0 Sascha =>...

  • Page 611: Snmp Walk

    [ObjectId = <string>] where: ObjectID The Object Identifier. OPTIONAL Object ID to walk from for example .1.3.6.1.2.1.1 system walks the system group. EXAMPLE: =>snmp walk ObjectId=.1.3.6.1.2.1.1 VB_octetStr .1.3.6.1.2.1.1.1.0 SpeedTouch™ 620 VB_objId .1.3.6.1.2.1.1.2.0 .1.3.6.1.4.1.637.61.2 VB_timeTicks .1.3.6.1.2.1.1.3.0 2927636 VB_octetStr .1.3.6.1.2.1.1.4.0 Service Provider VB_octetStr .1.3.6.1.2.1.1.5.0...

  • Page 612: Snmp Community Add

    SNMP Commands snmp community add Configure an SNMP community string to allow SNMP access over IP. SYNTAX: snmp community add securityname = <{RWCommunity | ROCommunity}> communityname = <password> where: securityname Configure access rights/restrictions control for the community name. REQUIRED Choose between: RWCommunity: read/write access rights ROCommunity: read only access rights.

  • Page 613: Snmp Community Delete

    SNMP Commands snmp community delete Delete an SNMP community string to prevent SNMP access over IP. SYNTAX: snmp community delete securityname = <{RWCommunity | ROCommunity}> where: securityname Select the access rights/restrictions control for the community name to be REQUIRED deleted. Choose between: RWCommunity: read/write access rights ROCommunity: read only access rights.

  • Page 614: Snmp Community List

    SNMP Commands snmp community list List all SNMP community strings in use for SNMP access over IP. SYNTAX: snmp community list EXAMPLE: =>snmp community list Read-write SNMP community name ***** Read-only SNMP community name ***** => RELATED COMMANDS: snmp community add Configure an SNMP community string to allow SNMP access over IP.

  • Page 615: Snmp Community Modify

    SNMP Commands snmp community modify Modify an SNMP community string to allow SNMP access over IP. SYNTAX: snmp community modify securityname = <{RWCommunity | ROCommunity}> communityname = <password> where: securityname Configure access rights/restrictions control for the community name. REQUIRED Choose between: RWCommunity: read/write access rights ROCommunity: read only access rights.

  • Page 616: Snmp Ifadd

    SNMP Commands snmp ifadd Create a new SNMP interface. SYNTAX: snmp ifadd intf = <string> dest = <string> where: intf The name for the new SNMP interface. REQUIRED dest The destination interface for this SNMP interface. REQUIRED EXAMPLE: =>snmp ifadd intf = new dest = Internet :snmp ifadd intf=new dest=Internet...

  • Page 617: Snmp Ifdelete

    SNMP Commands snmp ifdelete Delete an SNMP interface. SYNTAX: snmp ifdelete intf = <string> where: intf The name of the SNMP interface. REQUIRED EXAMPLE: =>snmp ifdelete intf = new :snmp ifdelete intf=new => RELATED COMMANDS: snmp ifadd Create a new SNMP interface. snmp ifattach Attach an SNMP interface.

  • Page 618: Snmp Ifattach

    SNMP Commands snmp ifattach Attach an SNMP interface. SYNTAX: snmp ifattach intf = <string> where: intf The name of the SNMP interface. REQUIRED EXAMPLE: =>snmp ifattach intf = Internet :snmp ifattach intf=Internet => RELATED COMMANDS: snmp ifadd Create a new SNMP interface. snmp ifdelete Delete an SNMP interface.

  • Page 619: Snmp Ifdetach

    SNMP Commands snmp ifdetach Detach an SNMP interface. SYNTAX: snmp ifdetach intf = <string> where: intf The name of the SNMP interface. REQUIRED EXAMPLE: =>snmp ifdetach intf = Internet :snmp ifdetach intf=Internet => RELATED COMMANDS: snmp ifadd Create a new SNMP interface. snmp ifdelete Delete an SNMP interface.

  • Page 620: Snmp Ifconfig

    SNMP Commands snmp ifconfig Modify an SNMP interface. SYNTAX: snmp ifconfig intf = <string> [securityname = <{RWCommunity | ROCommunity}>] [communityname = <password>] where: intf The name of the SNMP interface to configure. REQUIRED securityname Configure access rights/restrictions control for the community OPTIONAL name.

  • Page 621: Snmp Iflist

    SNMP Commands snmp iflist Display the SNMP interfaces. SYNTAX: snmp iflist [intf = <string>] where: intf The name of an SNMP interface to configure. OPTIONAL E-DOC-CTC-20060414-0006 v1.0...
  • Page 622 SNMP Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 623: Sntp Commands

    SNTP Commands SNTP Commands Introduction This chapter describes the commands of the Simple Network Time Protocol (SNTP) command group. Contents This chapter covers the following commands: sntp add Add a Network Time Protocol (NTP) server to the NTP server list. sntp config Modify/display the SNTP client configuration.

  • Page 624: Sntp Add

    SNTP Commands sntp add Add a Network Time Protocol (NTP) server to the NTP server list. The internal SpeedTouch™ real time clock (SNTP client) will be synchronized with the NTP server. SYNTAX: sntp add [addr = <ip-address>] [name = <string>] [version = <number{1-4}>]...

  • Page 625: Sntp Config

    SYNTAX: sntp config [enable = <{enabled | disabled}>] [poll = <number{1-60}>] where: enable Enable or disable the SpeedTouch™ SNTP client. OPTIONAL The default is enabled. poll A number between 1 and 60 (minutes). OPTIONAL Represents the time interval for the SNTP client to poll the configured NTP server and, if needed, (re-)synchronize its internal clock.

  • Page 626: Sntp Delete

    SNTP Commands sntp delete Delete an NTP server from the NTP server list. SYNTAX: sntp delete [addr = <ip-address>] [name = <string>] where: addr The IP address of the NTP server to be removed from the list. OPTIONAL Note This parameter is optional in this respect that either an IP address or the name of an NTP server must be specified.

  • Page 627: Sntp Flush

    SNTP Commands sntp flush Flush the NTP server list and the SNTP client configuration. SYNTAX: sntp flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 628: Sntp List

    Contacting...: The SpeedTouch™ SNTP client is trying to contact this NTP server. Unable to contact: The SpeedTouch™ SNTP client is unable to contact this NTP server. It may be down, or no end-to-end connectivity exists (no connection, no DSL,...). Synchronized: The SpeedTouch™ SNTP client was able to contact this NTP server. If required the internal clock has been synchronized with this NTP server.

  • Page 629: Software Commands

    Software Commands Software Commands Introduction This chapter describes the commands of the software command group. Contents This chapter covers the following commands: software download Download parameters. software upgrade Reboot the modem to initiate the SW upgrade. software version Display the software version. E-DOC-CTC-20060414-0006 v1.0...

  • Page 630: Software Download

    Software Commands software download Download parameters. SYNTAX: software download filetype = <{firmware | configuration}> url = <string> [username = <string>] [password = <string>] filesize = <string> [targetfilename = <string>] where: filetype The type of the file to be downloaded. REQUIRED Set the HTTP URL where the file is to be found including remote REQUIRED filename.

  • Page 631: Software Upgrade

    Software Commands software upgrade Reboot the modem to initiate the SW upgrade. New software available on a remote LAN host will be uploaded to the modem. SYNTAX: software upgrade E-DOC-CTC-20060414-0006 v1.0...

  • Page 632: Software Version

    Software Commands software version Display the software version. SYNTAX: software version E-DOC-CTC-20060414-0006 v1.0...

  • Page 633: System Commands

    Set/get the regional settings. system reboot Reboot the SpeedTouch™. system reset Reset the SpeedTouch™ to its factory or ISP defaults and reboot the device. system timedreboot Set or change a timed reboot for the SpeedTouch™. system debug autosave Autosave debugging commands system debug stats Show the SpeedTouch™...

  • Page 634: System Config

    System Commands system config Set/change the system configuration parameters. For a good operation of UPnP and the discovery mechanism, it is highly recommended not to change the system configuration settings. SYNTAX: system config [upnp = <{disabled | enabled}>] [tr64 = <{disabled | enabled}>] [mdap = <{disabled | enabled}>] [drst = <{disabled | enabled}>] [led = <{green | red | orange | flash | off}>]...
  • Page 635 System Commands autosavedelay A number between 0 and 600. OPTIONAL Represents the autosave delay in seconds (0 for immediate save). EXAMPLE: =>system config upnp discovery : enabled TR-64 discovery : disabled mdap discovery : enabled drst support : disabled reset button : enabled digest authentication : enabled : enabled...

  • Page 636: System Flush

    System Commands system flush Flush the current system configuration. The system password and the system config settings (dcache excluded) are flushed. The flush command does not impact previously saved configurations. SYNTAX: system flush EXAMPLE: =>system flush Security notification: Password changed, use 'saveall' to make it permanent. =>...

  • Page 637: System Locale

    System Commands system locale Set/get the regional settings. SYNTAX: system locale [dec_symbol = <{, | .}>] [group_symbol = <{. | ,}>] [date_separator = <{/ | - | .}>] [date_format = <{iso | ddmmyyyy | ddmmyy | mmddyyyy | mmddyy}>] [time_format = <{iso | hmmss}>] [datetime_format = <{iso | date+time | time+date}>] [duration_format = <{dhmmss | hmmss}>] where:...
  • Page 638 System Commands time_format Set the time format. OPTIONAL Choose between: hmmss. The default is iso. Note h = hours; mm = minutes; ss = seconds. datetime_format Set the date-time format. OPTIONAL Choose between: date+time time+date. The default is date+time. duration_format Set the duration format.

  • Page 639: System Reboot

    Reboot the SpeedTouch™. Non-saved configuration settings will be lost after reboot. SYNTAX: system reboot EXAMPLE: =>system reboot ..(lost session connectivity due to reboot) ..RELATED COMMANDS: system timedreboot Set or change a timed reboot for the SpeedTouch™.. E-DOC-CTC-20060414-0006 v1.0...

  • Page 640: System Reset

    System Commands system reset Reset the SpeedTouch™ to its factory or ISP defaults and reboot the device. All user specific settings and all saved configuration changes are lost after reboot. SYNTAX: system reset factory yes/no = <{yes | no}> proceed no/yes = <{no | yes}>...

  • Page 641: System Timedreboot

    System Commands system timedreboot Set or change a timed reboot for the SpeedTouch™. SYNTAX timedreboot [state = <{disabled|enabled}>] [time = <number{0-16384}>] [date = <string>] where: state Enable/Disable timed reboot. OPTIONAL The default is disabled. time Change default countdown time (Min).

  • Page 642: System Debug Autosave

    System Commands system debug autosave Autosave debugging commands SYNTAX: system debug autosave [trace = <{disabled|enabled}>] where: trace Enable or disable autosave traces OPTIONAL E-DOC-CTC-20060414-0006 v1.0...

  • Page 643: System Debug Stats

    Memory used by the CPU (first MB from the RAM) – not cached since it has to be realtime. Application memory: Memory used by the applications. min: The least amount of free memory detected during the uptime of the SpeedTouch™. E-DOC-CTC-20060414-0006 v1.0...

  • Page 644: System Ra Config

    System Commands system ra config Configure Remote management access parameters. SYNTAX: system ra config [secure = <{disabled | enabled}>] [port = <number>] [timeout = <number>] where: secure Enable or disable https. OPTIONAL The default is enabled. port Set the destination port for remote access. OPTIONAL The default is 51003.

  • Page 645: System Rtc Synchronize

    System Commands system rtc synchronize Do a SNTP update and synchronize the realtime clock. SYNTAX: system rtc synchronize E-DOC-CTC-20060414-0006 v1.0...

  • Page 646: System Rtc Settime

    Set/get date, time, timezone, daylight savings time, uptime. When synchronization with an external NTP server via the SpeedTouch™ SNTP client fails, this command allows to manually configure its internal clock. In cases without regular synchronization, accurate realtime clock settings can not be guaranteed.

  • Page 647: Systemlog Commands

    Systemlog Commands Systemlog Commands Introduction This chapter describes the commands of the systemlog command group. Contents This chapter covers the following commands: systemlog flush Flush all messages in the internal Syslog message buffer. systemlog show Show messages in the internal Syslog message buffer. systemlog send Send messages from the internal Syslog message buffer to a specified local or remote syslog server host.

  • Page 648: Systemlog Flush

    Systemlog Commands systemlog flush Flush all messages in the internal Syslog message buffer. SYNTAX: systemlog flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 649: Systemlog Show

    754). Note If not specified, the messages of all the severities will be shown. hist Show messages over several SpeedTouch™ reboots (enabled) or show only messages OPTIONAL since latest startup (disabled). Note If not specified, only the recent messages will be shown.

  • Page 650: Systemlog Send

    754). Note If not specified, the messages of all the severities will be shown. hist Show messages over several SpeedTouch™ reboots (disabled) or show only messages OPTIONAL since latest startup (enabled). Note If not specified, only the recent messages will be shown.

  • Page 651: Upgrade Commands

    Upgrade Commands Upgrade Commands Introduction This chapter describes the commands of the upgrade command group. Contents This chapter covers the following commands: upgrade config Change the upgrade daemon configuration. upgrade start Start a new upgrade. upgrade debug traceconfig Enable/disable upgrade daemon tracing. upgrade debug sesslist Display the list of sessions.

  • Page 652: Upgrade Config

    Upgrade Commands upgrade config Change the upgrade daemon configuration. SYNTAX: upgrade config [state = <{disabled|enabled}>] [protocol = <{tftp|ftp|http|https}>] where: state Set the upgrade daemon state to enabled or disabled. OPTIONAL The default is disabled. protocol The transfer protocol to be used for file download. OPTIONAL Choose between: tftp...

  • Page 653: Upgrade Start

    Upgrade Commands upgrade start Start a new upgrade. SYNTAX: upgrade start protocol = <{tftp|ftp|http|https}> [server = <string>] [filename = <string>] where: protocol The protocol to be used for the download. REQUIRED Choose between: tftp http https The default is disabled. server The server name or IP address OPTIONAL...

  • Page 654: Upgrade Debug Traceconfig

    Upgrade Commands upgrade debug traceconfig Enable/disable upgrade daemon tracing. SYNTAX: upgrade debug traceconfig state = <{disabled|enabled}> where: state Set the upgared daemon state to enabled or disabled. REQUIRED E-DOC-CTC-20060414-0006 v1.0...

  • Page 655: Upgrade Debug Sesslist

    Upgrade Commands upgrade debug sesslist Display the list of sessions. SYNTAX: upgrade debug sesslist EXAMPLE: =>:upgrade debug sesslist Session 0: --------------------------------------------------------------- SessionId : 0x80c25850 State : IDLE Protocol : TFTP ServerName: FileName DestFile ServerIP : 0.0.0.0 Error Session 1: --------------------------------------------------------------- SessionId : 0x80c25c20 State : IDLE...

  • Page 656: Upgrade Profile Add

    Upgrade Commands upgrade profile add Add a new file profile description. SYNTAX: upgrade profile add extension = <{sts|ini}> [maxsize(KBytes) = <number>] action = <{none|config_load|script_load|reboot}> where: extension The extension of the new file profile. REQUIRED Choose between: maxsize The maximum filesize (in KBytes) allowed for files with the OPTIONAL extension of this profile.

  • Page 657: Upgrade Profile Modify

    Upgrade Commands upgrade profile modify Modify a file profile description. SYNTAX: upgrade profile modify extension = <{sts|ini}> [maxsize(KBytes) = <number>] action = <{none|config_load|script_load|reboot}> where: extension The extension of the new file profile. REQUIRED Choose between: maxsize The maximum filesize (in KBytes) allowed for files with the OPTIONAL extension of this profile.

  • Page 658: Upgrade Profile Delete

    Upgrade Commands upgrade profile delete Delete a file profile description. SYNTAX: upgrade profile delete extension = <{sts|ini}> where: extension The extension of the profile to be deleted. REQUIRED Choose between: RELATED COMMANDS: upgrade profile add Add a new file profile description. upgrade profile list Display a list of the file profile descriptions.

  • Page 659: Upgrade Profile List

    Upgrade Commands upgrade profile list Display a list of the file profile descriptions. SYNTAX: upgrade profile list RELATED COMMANDS: upgrade profile delete Delete a file profile description. upgrade profile modify Modify a file profile description. E-DOC-CTC-20060414-0006 v1.0...
  • Page 660 Upgrade Commands E-DOC-CTC-20060414-0006 v1.0...

  • Page 661: Upnp Commands

    UPnP Commands UPnP Commands Introduction This chapter describes the commands of the upnp command group. Contents This chapter covers the following commands: upnp config Configure the UPnP™ parameter(s). upnp flush Flush the UPnP™ configuration. upnp list List all registered devices. E-DOC-CTC-20060414-0006 v1.0...

  • Page 662: Upnp Config

    A number between 60 and 999999. OPTIONAL This parameter allows to configure how often the SpeedTouch™ sends a notification message to advertise its presence as an Internet Gateway Device (IGD) on the network. The default is 1800. Note...

  • Page 663: Upnp Flush

    UPnP Commands upnp flush Flush the UPnP™ configuration. The UPnP configuration will be reset to the default configuration. SYNTAX: upnp flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 664: Upnp List

    UPnP Commands upnp list List all registered devices. Use this command to check whether a PPP connection is properly configured and thus advertised as a PPP service. SYNTAX: upnp list [verbose = <number{0-2}>] where: verbose Verbose level. OPTIONAL The default is 1. EXAMPLE: =>upnp list ---------------- device: IGD.xml ------------...

  • Page 665: User Commands

    User Commands User Commands Introduction This chapter describes the commands of the user command group. Contents This chapter covers the following commands: user add Add a user. user config Modify a user. user delete Delete a user. user flush Flush the users. user list Display the users.

  • Page 666: User Add

    User Commands user add Add a user. You can only add a user whose privileges are the same or lower than your own privileges. SYNTAX: user add name = <quoted string> password = <password> role = <string> [hash2 = <string>] [descr = <quoted string>] [defuser = <{disabled | enabled}>] [defremadmin = <{disabled | enabled}>]...
  • Page 667 User Commands In the example below, the user Administrator creates a new user JohnDoe. This user has lower access rights than the user “Poweruser”. {Administrator}=>user list User Flags Role ---- ----- ---- Administrator Administrator tech TechnicalSupport {Administrator}[user]=>add name = JohnDoe password = **** Please retype password for verification.

  • Page 668: User Config

    User Commands user config Modify a user. You can only modify a user whose privileges are the same or lower than your own privileges. SYNTAX: user config name = <string> [password = <password>] [role = <string>] [descr = <quoted string>] [defuser = <{disabled | enabled}>] [defremadmin = <{disabled | enabled}>] [deflocadmin = <{disabled | enabled}>]...
  • Page 669 User Commands EXAMPLE: {Superuser}=>user list User Role ==== ==== Superuser root aPoweruser Poweruser {Superuser}=>user config name=aPoweruser role=LAN_admin {Superuser}=>user list User Role ==== ==== Superuser root aPoweruser LAN_admin {Superuser}=> E-DOC-CTC-20060414-0006 v1.0...

  • Page 670: User Delete

    User Commands user delete Delete a user. You can only delete a user whose privileges are the same or lower than your own privileges. SYNTAX: user delete name = <string> where: name The name of the user to be deleted. REQUIRED EXAMPLE: {Administrator}=>user list...

  • Page 671: User Flush

    Flush the users. After execution of this command, the access to the SpeedTouch™ will no longer be protected by a password. The first user that logs on, after initiating a new Telnet session, will have the same administrative rights as a user with the role root.

  • Page 672: User List

    User Commands user list Display the users. SYNTAX: user list [name = <string>] [channel = <{ftp | telnet | http | mdap | serial}>] [origin = <{lan | wan | local}>] [secure = <{disabled | enabled}>] where: name The user name. OPTIONAL Note If not specified, all the users will be listed.
  • Page 673 User Commands EXAMPLE: {Administrator}=>user list User Flags Role ---- ----- ---- Administrator Administrator tech TechnicalSupport {Administrator}=>user list name=tech channel=http origin=wan service(s): r_lan, r_wan, r_fs_view, r_fs_retrieve, r_rtg, r_fwdg, r_nat, r_frwl, r_ipsec_norm, r_ipsec_adv, r_certificates, r_remote_mgnt, r_local, r_qos, w_lan, w_wan, w_fs_passive, w_rtg, w_fwdg, w_nat, w_frwl_norm, w_frwl_adv, w_frwe_mgnt, w_ipsec, w_certificates, w_remote_mgnt, w_local, w_qos, snd_lan, snd_wan, snd_local, and_lan, and_wan, and_frwl, and_local, user_admin, mlp_admin, secure_ipsec_term, secure_br, cli, cgi, ftp, mdap,...

  • Page 674: User Rights

    User Commands user rights Display the session rights. The user rights of the currently logged-in user are shown. SYNTAX: user rights EXAMPLE: {Administrator}=>user rights Current session info: user: name='Administrator', role='Administrator' access: lan (origin_lan), telnet (channel_telnet), unsecure (unsecure_connection) service(s): r_lan, r_wan, r_fs_view, r_fs_retrieve, r_rtg, r_fwdg, r_nat, r_frwl, r_ipsec_norm, r_ipsec_adv, r_certificates, r_remote_mgnt, r_local, r_qos, w_lan, w_wan, w_fs_passive, w_rtg, w_fwdg, w_nat, w_frwl_norm, w_frwl_adv, w_frwe_mgnt, w_ipsec, w_certificates, w_remote_mgnt, w_local, w_qos,...

  • Page 675: Voice Commands

    Voice Commands Voice Commands Introduction This chapter describes the commands of the voice command group. Contents This chapter covers the following commands: voice config Configure general voice settings. voice state Show VoIP service states. voice codec list Show the CODEC capability configuration. voice codec config Configure a CODEC capability.
  • Page 676 Voice Commands voice services Deactivate a supplementary service. deactivate voice services assign Assign a servicecode to a supplementary service in standard mode. voice services Assign a servicecode to a supplementary service in non_standard mode. assign_pxsc voice services flush Show voice statistics. voice sip config Configure the SIP general parameters.

  • Page 677: Voice Config

    Voice Commands voice config Configure general voice settings. SYNTAX: voice config [autofxo = <{disabled | enabled}>] [digitrelay = <{auto | inband | rfc2833 | signalling}>] [click2dial_ports = <{FXS1 | FXS2 | all}>] [rtp_portrange = <port-range>][sign_internal = <{external | internal}>] [static_intf = <disabled | enabled>] [intf = <string>] [endofnumber = <{#|*}>...
  • Page 678 Voice Commands EXAMPLE:EXAMPLE: =>voice config autofxo : enabled digitrelay : auto click2dial_port : FXS1 rtp_portrange : 1024-49151 sign_internal : external static_interface: disabled interface => =>voice config autofxo : enabled rtp_portrange : 1024-49151 => E-DOC-CTC-20060414-0006 v1.0...

  • Page 679: Voice State

    Voice Commands voice state Show VoIP service states. SYNTAX: voice state EXAMPLE: =>voice state VOIP_SIP-admin. state : disabled VOIP_SIP-oper. state : disabled VOIP_SIP-IP address : 0.0.0.0 => E-DOC-CTC-20060414-0006 v1.0...

  • Page 680: Voice Codec List

    Voice Commands voice codec list Show the CODEC capability configuration. SYNTAX: voice codec list EXAMPLE: =>voice codec list Codec Type Packet Delay Voice Act. Detection Priority Status ------------------------------------------------------------------------ g711u enabled enabled g711a enabled enabled f726_40 enabled disabled g726_32 enabled disabled g726_24 enabled disabled...

  • Page 681: Voice Codec Config

    Voice Commands voice codec config Configure a CODEC capability. SYNTAX: voice codec type = <{g711u | g711a | g726_40 | g726_32 | g726_24 | g726_16 | config g729}> [ptime = <{10 | 30 | 20}>] [ptime_g723 = <{30}>] [vad = <{disabled | enabled}>] [priority = <number{1-8}>] [status = <{disabled | enabled}>] where:...

  • Page 682: Voice Country Config

    Voice Commands voice country config Configure country. SYNTAX: voice country config [country = <country>] where: country Load this country’s specific settings into the DSP. OPTIONAL EXAMPLE: =>voice country config Country : spain => RELATED COMMANDS: voice country list List available countries. E-DOC-CTC-20060414-0006 v1.0...

  • Page 683: Voice Country List

    Voice Commands voice country list List available countries. SYNTAX: voice country list EXAMPLE: =>voice country list Available countries: belgium etsi france1 france2 netherlands northamerica norway spain sweden => RELATED COMMANDS: voice country config Configure country. E-DOC-CTC-20060414-0006 v1.0...

  • Page 684: Voice Dialplan Add

    Voice Commands voice dialplan add Add an entry in the dialplan. SYNTAX: voice dialplan prefix = <0...9 - * #> defaultport = <{FXS1 | FXS2 | FXO | VoIP | NA}> fallbackport = <{FXS1 | FXS2 | FXO | VoIP | NA}> priority = <{NA | Low | High}>...
  • Page 685 Voice Commands fallback Enable or disable the fallback mechanism status of the entry. REQUIRED The default is disabled. minimumdigits A number between 1 and 31. REQUIRED Represents the minimum number of digits. maximumdigits A number between 1 and 31. REQUIRED Represents the maximum number of digits.

  • Page 686: Voice Dialplan Delete

    Voice Commands voice dialplan delete Delete an entry from the dialplan. SYNTAX: voice dialplan prefix = <{}> delete where: prefix The prefix which identifies this entry. REQUIRED RELATED COMMANDS: voice dialplan add Add an entry in the dialplan. voice dialplan modify Modify an entry in the dialplan.

  • Page 687: Voice Dialplan Modify

    Voice Commands voice dialplan modify Modify an entry in the dialplan. SYNTAX: voice dialplan prefix = <{}> modify newprefix = <0...9 - * #> defaultport = <{FXS1 | FXS2 | FXO | VoIP | NA}> fallbackport = <{FXS1 | FXS2 | FXO | VoIP | NA}> priority = <{NA | Low | High}>...
  • Page 688 Voice Commands priority The priority of the entry. REQUIRED Choose between: High The default is NA. fallback Enable or disable the fallback mechanism status of the entry. REQUIRED The default is disabled. minimumdigits A number between 1 and 31. REQUIRED Represents the minimum number of digits.

  • Page 689: Voice Dialplan List

    Voice Commands voice dialplan list Display an entry or the complete dialplan. SYNTAX: voice dialplan prefix = <{all | *96 | *95 | *94 | *43* | *43 | *30 | #96 | list #95 | #94 | #43* | #43 | #30}> where: prefix The prefix which identifies this entry.

  • Page 690: Voice Dialplan Flush

    Voice Commands voice dialplan flush Delete all user-entered dialplan entries. SYNTAX: voice dialplan flush RELATED COMMANDS: voice dialplan add Add an entry in the dialplan. voice dialplan delete Delete an entry from the dialplan. voice dialplan modify Modify an entry in the dialplan. voice dialplan list Display an entry or the complete dialplan.

  • Page 691: Voice Fax Config

    Voice Commands voice fax config Configure the fax parameters. SYNTAX: voice fax config [detect_timeout = <number{0-120}>] [transport = <{inband_auto|inband_reneg|t38}>] [udptl_redun = <number{0-3}>] where: detect_timeout A number between 0 and 120. OPTIONAL Represents the time-out in seconds used to detect FAX (0 is no time-out) transport The type of fax transport.

  • Page 692: Voice Fxoport Config

    Voice Commands voice fxoport config Configure the FXO port parameters. SYNTAX: voice fxoport config [incfxo = <{enabled|disabled}>] [fxodisconnect = <number{500-5000}>] where: incfxo Enable or disable incoming FXO calls. OPTIONAL The default is enabled. fxodisconnect The FXO disconnect timer (in ms). OPTIONAL Enter a number between 500 and 5000.

  • Page 693: Voice Fxsport Config

    Voice Commands voice fxsport config Configure the FXS port parameters. SYNTAX: voice fxsport config [interdigit = number{10-10000}] where: interdigit A number between 10 and 10000. OPTIONAL The interdigit timer (in ms) EXAMPLE: =>voice fxsport config Inter digit timer : 5000 =>...

  • Page 694: Voice Mgcp Config

    Voice Commands voice mgcp config Configure the MGCP general parameters. SYNTAX: voice mgcp config [callagentaddr = <string>] [callagentport = <string>] [seccallagentaddr = <string>] [seccallagentport = <string>] [failoverdelay = <number>] [maxrsipdelay = <number>] [maxretries = <number>] [retransmittimer = <number>] [cpedomain = <{IP-address|Reverse-DNS|MAC- Address|Serial-Number|Unique-Random-Id|Secure-Unique- Random-Id|Custom}>] [cpedomaincustom = <string>]...
  • Page 695 Voice Commands EXAMPLE: =>voice mgcp config Primary call agent address Primary call agent port : 2727 Secondary call agent address : Secondary call agent port : 2727 Fail-over delay : -1s CPE domain :IP-Address CPE domain brackets : automatic Maximum restart delay : Oms Request retransmit retries Maximum retransmit time-out...

  • Page 696: Voice Pb Add

    Voice Commands voice pb add Add phonebook entry in the phonebook. SYNTAX: voice pb add Lastname = <quoted string> Firstname = <quoted string> [Business = <quoted string>] [Home = <quoted string>] [Mobile = <quoted string>] [Other = <quoted string>] [E-mail = <quoted string>] where: Lastname The last name.

  • Page 697: Voice Phonebook Add

    Voice Commands voice phonebook add Add a phone number to the phonebook. SYNTAX: voice phonebook add e164number = <string> where: e164number The telephone number to be added. REQUIRED EXAMPLE: =>voice phonebook list Phonebook ( 1 entries) ---------------------- 003292321513 =>voice phonebook add e164number=00315674890 =>voice phonebook list Phonebook ( 2 entries) ----------------------...

  • Page 698: Voice Phonebook Delete

    Voice Commands voice phonebook delete Delete a phone number from the phonebook. SYNTAX: voice phonebook delete e164number = <string> where: e164number Enter the telephone number to be deleted or all to delete all the phonenumbers. REQUIRED EXAMPLE: =>voice phonebook list Phonebook ( 2 entries) ---------------------- 003292321513...

  • Page 699: Voice Phonebook List

    Voice Commands voice phonebook list Show all entries in the phonebook. SYNTAX: voice phonebook list EXAMPLE: =>voice phonebook list Phonebook ( 2 entries) ---------------------- 003292321513 00315674890 => RELATED COMMANDS: voice phonebook add Add a phone number to the phonebook. voice phonebook delete Delete a phone number from the phonebook.

  • Page 700: Voice Profile Add

    Voice Commands voice profile add Add profile. SYNTAX: voice profile add endpointname = <string> SIP_URI = <string> [username = <string>]> [password = <password>] [displayname = <string>] voiceport = <{FXS1 | FXS2 | COMMON}> [abbr = <string>] [status = <{disabled|enabled}>] where: endpointname The analogue line endpoint name.
  • Page 701 Voice Commands EXAMPLE: =>voice profile add endpointname = new voiceport = FXS1 [status] = disabled :voice profile add endpointname=new voiceport=FXS1 status=disabled => RELATED COMMANDS: voice profile delete Delete profile. voice profile modify Modify profile. voice profile list Show all profiles. voice profile flush Flush all profiles.

  • Page 702: Voice Profile Delete

    Voice Commands voice profile delete Delete profile. SYNTAX: voice profile delete SIP_URI = <string> endpointname = <all|aaln/2|aaln/1}> where: SIP_URI The SIP URI related to this voice port. REQUIRED endpointname The analogue line endpoint name. REQUIRED EXAMPLE: =>voice profile delete SIP_URI = new :voice profile delete SIP_URI=new =>...

  • Page 703: Voice Profile Modify

    Voice Commands voice profile modify Modify profile. SYNTAX: voice profile modify endpointname = <{aaln/2|aaln/1}> SIP_URI = <string> NEW_URI = <string> [username = <string>]> [password = <password>] [displayname = <string>] voiceport = <{FXS1 | FXS2 | COMMON}> [abbr = <string>] [status = <{disabled|enabled}>] where: endpointname The analogue line endpoint name.
  • Page 704 Voice Commands EXAMPLE: =>voice profile modify SIP_URI = new NEW_URI = newer [username] = [password] = [displayname] = voiceport = FXS2 [abbr] = :voice profile modify SIP_URI=new NEW_URI=newer voiceport=FXS2 => RELATED COMMANDS: voice profile add Add profile. voice profile delete Delete profile.

  • Page 705: Voice Profile List

    Voice Commands voice profile list Show all profiles. SYNTAX: voice profile list SIP_URI = <{all}> where: SIP_URI The SIP URI related to this voice port. REQUIRED RELATED COMMANDS: voice profile add Add profile. voice profile delete Delete profile. voice profile modify Modify profile.

  • Page 706: Voice Profile Flush

    Voice Commands voice profile flush Flush all profiles. SYNTAX: voice profile flush RELATED COMMANDS: voice profile add Add profile. voice profile delete Delete profile. voice profile modify Modify profile. voice profile list Show all profiles. E-DOC-CTC-20060414-0006 v1.0...

  • Page 707: Voice Qos List

    Voice Commands voice qos list Show the QoS configuration. SYNTAX: voice qos list EXAMPLE: =>voice qos list Traffic Type QOS field Value ---------------------------------------- sign&control dscp af42 realtime dscp => RELATED COMMANDS: voice qos config Configure the QoS parameters. E-DOC-CTC-20060414-0006 v1.0...

  • Page 708: Voice Qos Config

    Voice Commands voice qos config Configure the QoS parameters. SYNTAX: voice qos config type = <{sign&control | realtime}> qosfield = <{dscp | precedence}> [dscp = <{ef | af11 | af12 | af13 | af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs0 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7} or number>] [precedence = <{routine | priority | immediate | flash | flash-override | CRITIC-ECP | internetwork-control |...

  • Page 709: Voice Services Config

    Voice Commands voice services config General supplementary service configuration. SYNTAX: voice services [mwi_phone = <{immediate | deferred}>] config [mwi_network = <{sollicited | unsollicited}>] [prefix_servcode = <{standard | nonstandard}>] [servcode_cmd = <{standard | nonstandard}>] [cfu_dest = <string>] [cfnr_timer = <number{0-600}>] [cfnr_dest = <string>] [cfbs_dest = <string>] [hfhf_feature = <{disabled|enabled}>] where:...
  • Page 710 Voice Commands RELATED COMMANDS: voice services list Show the supplementary service configuration. voice services provision Provision a supplementary service. voice services withdraw Withdraw a supplementary service. voice services activate Activate a supplementary service. voice services Deactivate a supplementary service. deactivate voice services assign Assign a servicecode to a supplementary service in standard mode.

  • Page 711: Voice Services List

    Voice Commands voice services list Show the supplementary service configuration. SYNTAX: voice services list EXAMPLE: =>voice services list Service Status ActCode DeactCode RegCode Provisioned --------------------------------------------------------------------------------- transfer activated hold activated waiting activated deactivated clip activated clir deactivated colp deactivated 3pty activated forcedFXO deactivated *01*...

  • Page 712: Voice Services Provision

    Voice Commands voice services provision Provision a supplementary service. SYNTAX: voice services provision type = <string> where: type The supplementary service type. REQUIRED EXAMPLE: =>voice services provision type = transfer :voice services provision type=transfer => RELATED COMMANDS: voice services config General supplementary service configuration.

  • Page 713: Voice Services Withdraw

    Voice Commands voice services withdraw Withdraw a supplementary service. SYNTAX: voice services type = <string> withdraw where: type The supplementary service type. REQUIRED EXAMPLE: =>voice services withdraw type = transfer :voice services withdraw type=transfer => RELATED COMMANDS: voice services config General supplementary service configuration.

  • Page 714: Voice Services Activate

    Voice Commands voice services activate Activate a supplementary service. SYNTAX: voice services type = <string> activate where: type The supplementary service type. REQUIRED EXAMPLE: =>voice services activate type = hold :voice services activate type=hold => RELATED COMMANDS: voice services config General supplementary service configuration.

  • Page 715: Voice Services Deactivate

    Voice Commands voice services deactivate Deactivate a supplementary service. SYNTAX: voice services type = <string> deactivate where: type The supplementary service type. REQUIRED EXAMPLE: =>voice services deactivate type = hold :voice services deactivate type=hold => RELATED COMMANDS: voice services config General supplementary service configuration.

  • Page 716: Voice Services Assign

    Voice Commands voice services assign Assign a servicecode to a supplementary service in standard mode. SYNTAX: voice services type = <string> assign servicecode = <0...9> where: type The supplementary service type. REQUIRED servicecode The service activation code. REQUIRED EXAMPLE: =>voice services assign type = transfer servicecode = 2 :voice services assign type=transfer servicecode=2...

  • Page 717: Voice Services Assign_Pxsc

    Voice Commands voice services assign_pxsc Assign a servicecode to a supplementary service in non_standard mode. SYNTAX: voice services type = <string> assign_pxsc action = <{activate | deactivate}> action_cfnr = <{activate | deactivate | register}> action_act = <{activate}> servicecode = <0...9 * #> where: type The supplementary service type.

  • Page 718: Voice Services Flush

    Voice Commands voice services flush Flush all supplementary services. SYNTAX: voice services flush RELATED COMMANDS: voice services config General supplementary service configuration. voice services list Show the supplementary service configuration. voice services provision Provision a supplementary service. voice services withdraw Withdraw a supplementary service.

  • Page 719: Voice Sip Config

    Voice Commands voice sip config Configure the SIP general parameters. SYNTAX: voice sip config [useragentdomain = <string>] [primproxyaddr = <string>] [secproxyaddr = <string>] [proxyport = <{string} or number>] [primregaddr = <string>] [secregaddr = <string>] [regport = {string} or number] [regexpire = <number{60-65535}>] [notifier_addr = <string>] [notifier_port = <{string} or number>] [subscribe_expire = <number{60-65535}>]...
  • Page 720 Voice Commands CWreply The reply to be sent for a waiting call. OPTIONAL Choose between: 182. transport The transport type. OPTIONAL Choose between: UDP. rtpmapstaticPT Enable or disable adding RTP map i.c.o. static PT. OPTIONAL The default is disabled. reinvite_stop_audio Enable or disable the explicit stop of audio stream in the SDP OPTIONAL when sending a re-invite.

  • Page 721: Voice Stats List

    Voice Commands voice stats list Show voice statistics. SYNTAX: voice stats list voiceport = <{FXS1 | FXS2 | BT | all | VoIP}> type = <{detailed | generic | all}> where: voiceport Select the voice port to be used to get the statistics. REQUIRED Choose between: FXS1...

  • Page 722: Voice Stats Reset

    Voice Commands voice stats reset Reset the voice statistics. SYNTAX: voice stats reset voiceport = <{FXS1 | FXS2 | BT | all | VoIP}> type = <{detailed | generic | all}> where: voiceport The voice port used to reset the statistics. REQUIRED Choose between: FXS1...

  • Page 723: Wireless Commands

    Wireless Commands Wireless Commands Introduction This chapter describes the commands of the wireless command group. Contents This chapter covers the following commands: wireless ifconfig Configure the wireless settings. wireless reset Reset the wireless parameters. wireless debug stats Show the transfer statistics. wireless macacl add Add an ACL MAC entry.

  • Page 724: Wireless Ifconfig

    Make the SSID public or not. OPTIONAL Choose between: enabled: the SpeedTouch™ broadcasts its SSID and accepts every client. disabled: the SpeedTouch™ does not broadcast its SSID and accepts only those clients who have the correct SSID. The default is enabled. interop Select the interoperability mode.
  • Page 725 Wireless Commands EXAMPLE: =>wireless] ifconfig State : enabled Network name (SSID) : SpeedTouchBF4511 Public network (any) : enabled Channel : 1 [auto] RTS Threshold : 2347 Short Retry Limit Long Retry Limit Beacon Period : 100 Rate : 54 Mbps Interoperability : 802.11b/g Protection...

  • Page 726: Wireless Reset

    Wireless Commands wireless reset Reset the wireless parameters. The following wireless parameters are reset to their default settings: Access Point (AP) + communication channel Security mode MAC Access Control List (ACL) (MACACL mode) Pre-shared keys MACACL list is cleared. SYNTAX: wireless reset proceed = <{disabled | enabled}>...
  • Page 727 Wireless Commands EXAMPLE: =>wireless ifconfig State : enabled Network name (SSID) : SpeedTouchBF4511 Public network (any) : enabled Channel : 8 [manual] RTS Threshold : 2347 Short Retry Limit Long Retry Limit Beacon Period : 100 Rate : 54 Mbps Interoperability : 802.11b/g Protection...

  • Page 728: Wireless Debug Stats

    Wireless Commands wireless debug stats Show the transfer statistics. SYNTAX: wireless debug stats EXAMPLE: =>wireless debug stats Good Rx Packets : 1040 Bad Rx Packets Good Tx Packets : 1234 Bad Tx Packets => E-DOC-CTC-20060414-0006 v1.0...

  • Page 729: Wireless Macacl Add

    Wireless Commands wireless macacl add Add an ACL MAC entry. SYNTAX: wireless macacl add hwaddr = <hardware-address> permission = <{allow|deny}> [name = <quoted string>] where: hwaddr The Ethernet MAC address of the ACL entry. REQUIRED permission The action to be performed on ACL entry. REQUIRED Choose between: allow: the wireless client is allowed entry.

  • Page 730: Wireless Macacl Config

    Choose between: lock: The ACL is locked. No new entries are allowed in the ACL. unlock: Every wireless client can associate to the SpeedTouch™. register: A wireless client is only added to the ACL after using the Register Button. The default is unlock.

  • Page 731: Wireless Macacl Delete

    Wireless Commands wireless macacl delete Delete an ACL MAC entry. SYNTAX: wireless macacl delete hwaddr = <hardware-address> where: hwaddr The Ethernet MAC address of the ACL entry. REQUIRED EXAMPLE: =>wireless macacl list Station Name hardware address Permission ST120g 00:02:2d:5f:b6:9e accept Test2 01:67:d0:23:56:cd accept...

  • Page 732: Wireless Macacl Flush

    Wireless Commands wireless macacl flush Flush ACL entries. SYNTAX: wireless macacl flush proceed = <{disabled | enabled}> where: proceed Confirm to reset the ACL settings to factory defaults. REQUIRED Choose between: disabled enabled. EXAMPLE: =>wireless macacl list Station Name hardware address Permission ST120g 00:02:2d:5f:b6:9e...

  • Page 733: Wireless Macacl List

    Wireless Commands wireless macacl list Show a list of all configured ACL entries. SYNTAX: wireless macacl list EXAMPLE: =>wireless macacl list Station Name hardware address Permission ST120g 00:02:2d:5f:b6:9e accept Test2 01:67:d0:23:56:cd accept => E-DOC-CTC-20060414-0006 v1.0...

  • Page 734: Wireless Macacl Modify

    Wireless Commands wireless macacl modify Modify an existing ACL entry. SYNTAX: wireless macacl modify hwaddr = <hardware-address> [permission = <{allow | deny}>] [name = <quoted string>] where: hwaddr The Ethernet MAC address of the ACL entry. REQUIRED Note If the MAC address is not present in the ACL list, the command will not be excuted.

  • Page 735: Wireless Macacl Register

    After executing this command, the ACL will be unlocked for a time period of 60 seconds. Any wireless client who tries to assiociate with the SpeedTouch™ during this period and who has the correct wireless settings, will be added to the ACL.

  • Page 736: Wireless Multiuni Add

    Wireless Commands wireless multiuni add Add a multicast to unicast mapping. SYNTAX: wireless multiuni add multicast = <hardware-address> unicast = <hardware-address> where: multicast Multicast MAC. REQUIRED unicast Unicast MAC. REQUIRED E-DOC-CTC-20060414-0006 v1.0...

  • Page 737: Wireless Multiuni Delete

    Wireless Commands wireless multiuni delete Delete all multicast mappings. SYNTAX: wireless multiuni delete multicast = <hardware-address> where: multicast Multicast MAC. REQUIRED E-DOC-CTC-20060414-0006 v1.0...

  • Page 738: Wireless Multiuni Flush

    Wireless Commands wireless multiuni flush Flush all multicast to unicast mappings. SYNTAX: wireless multiuni flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 739: Wireless Multiuni List

    Wireless Commands wireless multiuni list Show configured multicast to unicast mappings. SYNTAX: wireless multiuni list E-DOC-CTC-20060414-0006 v1.0...

  • Page 740: Wireless Multiuni Scanresults

    Wireless Commands wireless multiuni scanresults Display detected multicast mac addresses. SYNTAX: wireless multiuni scanresults [rescan = <{no | yes}>] where: rescan Rescan for new multicast addresses. OPTIONAL The default is no. E-DOC-CTC-20060414-0006 v1.0...

  • Page 741: Wireless Qos Config

    Wireless Commands wireless qos config Configure QoS settings. SYNTAX: wireless qos config [mode = <{disabled | wmm}>] where: mode Active WMM. OPTIONAL The default is disabled. EXAMPLE: =>wireless qos config mode : wmm ackpolicy : normal => E-DOC-CTC-20060414-0006 v1.0...

  • Page 742: Wireless Qos Apacconfig

    Wireless Commands wireless qos apacconfig Configure AP EDCA parameters. SYNTAX: wireless qos apacconfig [class = <{AC_BE | AC_BK | AC_VI | AC_VO}>] [cwmax = <{1 | 3 | 7 | 15 | 31 | 63 | 127 | 255 | 511 | 1023 | 2047 | 4095 | 8191 | 16383 | 32767}>] [cwmin = <{0 | 1 | 3 | 7 | 15 | 31 | 63 | 127 | 255>] [aifsn = <number{1-15}>]...

  • Page 743: Wireless Qos Staacconfig

    Wireless Commands wireless qos staacconfig Configure STA EDCA parameters. SYNTAX: wireless qos staacconfig [class = <{AC_BE | AC_BK | AC_VI | AC_VO}>] [cwmax = <{1 | 3 | 7 | 15 | 31 | 63 | 127 | 255 | 511 | 1023 | 2047 | 4095 | 8191 | 16383 | 32767}>] [cwmin = <{0 | 1 | 3 | 7 | 15 | 31 | 63 | 127 | 255>] [aifsn = <number{1-15}>]...

  • Page 744: Wireless Secmode Config

    Wireless Commands wireless secmode config Configure/show the security mode. SYNTAX: wireless secmode config [mode = <{disable | wep | wpa-psk | wpa}>] where: mode The security mode. OPTIONAL Choose between: disable: no security wep: Wired Equivalent Privacy (WEP) wpa-psk: Wi-Fi Protected Access (WPA) - Pre-Shared Key (PSK) wpa: Wi-Fi Protected Access (WPA).

  • Page 745: Wireless Secmode Wep

    Wireless Commands wireless secmode wep Configure the WEP settings. If the current security mode is WEP, then the security mode must first be changed, before the WEP settings can be (re)configured. SYNTAX: wireless secmode wep [encryptionkey = <quoted string>] where: encryptionkey The secret key to be used for WEP encryption.

  • Page 746: Wireless Secmode Wpa-Psk

    Wireless Commands wireless secmode wpa-psk Configure the WPA-PSK settings. If the current security mode is WPA-PSK, then the security mode must first be changed, before the WPA- PSK settings can be (re)configured. SYNTAX: wireless secmode wpa-psk [presharedkey = <quoted string>] [version = <{WPA | WPA2 | WPA+WPA2}>] where: presharedkey...

  • Page 747: Wireless Secmode Wpa

    Wireless Commands wireless secmode wpa Configure the WPA settings. If the current security mode is WPA, then the security mode must first be changed, before the WPA settings can be (re)configured. SYNTAX: wireless secmode wpa [radiuskey = <quoted string>] [rekeysec = <number{0-86400}>] [radiusip = <ip-address>] [radiusport = <number{0-65535}>] [radiussto = <number{1800-172800}>]...

  • Page 748: Wireless Stations List

    Wireless Commands wireless stations list List the currently associated stations. SYNTAX: wireless stations list [hwaddr = <hardware-address>] where: hwaddr The MAC address of the station. OPTIONAL EXAMPLE: =>wireless stations list Station Name Hardware Address Authentication ST120g 00:02:2D:5F:B6:9E WEP-64 used Total number of associated stations : 1 =>...

  • Page 749: Wireless Wds Add

    The WDS Base Service Set Identifier (BSSID). REQUIRED name A user specified reference name. OPTIONAL EXAMPLE: =>wireless wds list SpeedTouch180 00:90:96:4F:38:E4 =>wireless wds add bssid=00:90:96:62:5d:69 name="SpeedTouch Sascha" =>wireless wds list SpeedTouch180 00:90:96:4F:38:E4 SpeedTouch Sascha 00:90:96:62:5D:69 => E-DOC-CTC-20060414-0006 v1.0...

  • Page 750: Wireless Wds Config

    Wireless Commands wireless wds config WDS configuration parameters. SYNTAX: wireless wds config [state = <{disabled | enabled}>] where: state Enable or disable the WDS functionality. OPTIONAL The default is enabled. EXAMPLE: =>wireless wds config State : enabled Own BSSID : 00:90:96:52:2D:89 =>...

  • Page 751: Wireless Wds Delete

    SYNTAX: wireless wds delete bssid = <hardware-address> where: bssid The BSSID of the WDS station to be deleted. REQUIRED EXAMPLE: =>wireless wds list SpeedTouch180 00:90:96:4F:38:E4 SpeedTouch Sascha 00:90:96:62:5D:69 =>wireless wds delete bssid=00:90:96:62:5d:69 =>wireless wds list SpeedTouch180 00:90:96:4F:38:E4 => E-DOC-CTC-20060414-0006 v1.0...

  • Page 752: Wireless Wds Flush

    Wireless Commands wireless wds flush Flush all WDS stations. SYNTAX: wireless wds flush E-DOC-CTC-20060414-0006 v1.0...

  • Page 753: Wireless Wds List

    Wireless Commands wireless wds list List the WDS stations. SYNTAX: wireless wds list EXAMPLE: =>wireless wds list SpeedTouch180 00:90:96:4F:38:E4 SpeedTouch Sascha 00:90:96:62:5D:69 => E-DOC-CTC-20060414-0006 v1.0...

  • Page 754: Wireless Wds Scanresults

    Wireless Commands wireless wds scanresults Scan all networks. SYNTAX: wireless wds scanresults [rescan = <{disabled | enabled}>] where: rescan Perform a new scan (enabled) or not (disabled). OPTIONAL The default is disabled. EXAMPLE: =>wireless wds scanresults rescan=yes All associations with the AP will be lost, due to the wireless network scan! SSID channel bssid noise...

  • Page 755: Abbreviations

    Abbreviations Abbreviations The table below lists all the abbreviations used in the CLI Reference Guide. Abbreviation Description AAL5 ATM Adaption Layer 5 Access Control List ADSL Asymmetric Digital Subscriber Line Advanced Encryption System Assured Forwarding Access Point Address Resolution Protocol Asynchronous Transfer Mode BSSID Base Service Set IDentifier...
  • Page 756 Abbreviations Abbreviation Description HDLC High-level Data Link Control HTTP HyperText Transfer Protocol ICMP Internet Control Message Protocol Intrusion Detection System Internet Gateway Device IGMP Internet Group Management Protocol Internet Key Exchange Internet Protocol IP oA IP over ATM IPCP Internet Protocol Control Protocol IPSec IP Security ISDN...
  • Page 757 Abbreviations Abbreviation Description Point-to-Point Protocol PPPoA PPP over ATM PPPoE PPP over Ethernet PPTP Point-to-Point Tunneling Protocol Power Spectral Density Pre-Shared Key Permanent Virtual Channel Quality of Service Routing Information Protocol Real Time Clock Round Trip Time Security Associations SFTP Secure File Transfer Protocol SHDSL Single Pair High-speed Digital Subscriber Line...
  • Page 758 Abbreviations Abbreviation Description VLAN Virtual Local Area Network VLSM Variable Length Subnet Masking Virtual Path Virtual Path Identifier Virtual Private Networking Wide Area Network Wireless Distribution System Wired Equivalent Privacy Weighted Fair Queueing WINS Windows Internet Naming Service WLAN Wireless LAN Wi-Fi Protected Access Weighted Round Robin E-DOC-CTC-20060414-0006 v1.0...

  • Page 759: System Logging Messages

    System Logging Messages System Logging Messages Introduction This chapter lists the different System Logging messages. Contents This chapter lists the different System Logging messages of the following modules: Auto-PVC Module Configuration Module DHCP Client Module DHCP Relay Module DHCP Server Module Dyndns Module Firewall Module LOGIN Module...

  • Page 760: Auto-Pvc Module

    System Logging Messages Auto-PVC Module Facility Severity Contents LOCAL5 WARNING AUTOPVC script <script_name> failed LOCAL5 WARNING AUTOPVC script <script_name> failed LOCAL5 WARNING AUTOPVC script <script_name> (name1, qosb_name) failed LOCAL5 WARNING AUTOPVC script <script_name> (name1, qosb_name, name2) failed LOCAL5 WARNING AUTOPVC script 'autopvc_change_qos (itable[i].intf, name1, qosb_name) failed LOCAL5 WARNING AUTOPVC script <script_name>...

  • Page 761: System Logging Messages

    System Logging Messages DHCP Relay Module Facility Severity Contents LOCAL2 WARNING DHCR relay: Dropping boot rqs on interface <intf_id> due to invalid giaddr for server (<ip-address>) LOCAL2 WARNING DHCR relay: Dropping boot reply with invalid relay agent option from <intf_id> LOCAL2 WARNING DHCR relay: Dropping boot request containing the relay agent option from...

  • Page 762: Dyndns Module

    System Logging Messages Dyndns Module Facility Severity Contents DYNDNS WARNING <DYNDNS_ STR_ID> Connection failed to <dyndns_service> for client <dyndns_client> DYNDNS WARNING <DYNDNS_ STR_ID> Failed to resolve host name <dyndns_service> for client <dyndns_client> DYNDNS WARNING <DYNDNS_ STR_ID> Server Timeout(<dyndns_service>) for client <dyndns_client>...

  • Page 763: Login Module

    System Logging Messages LOGIN Module Facility Severity Contents AUTH NOTICE LOGOUT User <user_id> logged out on <connection_type> (<ip-address>) AUTH NOTICE LOGOUT User <user_id> logged out on <connection_type> AUTH NOTICE LOGOUT <session_name> session of user <user_id> killed (<ip-address>) AUTH NOTICE LOGOUT <session_name> session of user <user_id> killed AUTH NOTICE LOGIN User <user_id>...

  • Page 764: Ppp Module

    System Logging Messages PPP Module Facility Severity Contents LOCAL0 WARNING PPP Link up (<intf name>) LOCAL0 WARNING PPP Link down (<intf name>) AUTH ERROR PPP PAP authentication failed (<intf name>) [protocol reject] AUTH INFO PPP PAP on intf <intf_id> no response to authenticate-request AUTH NOTICE PPP PAP remote user <remote_user_name>...

  • Page 765: Rip Module

    System Logging Messages RIP Module Facility Severity Contents LOCAL1 INFO RIP Packet received from unknown interface LOCAL1 INFO RIP Packet size is smaller than minimum size LOCAL1 INFO RIP Packet size is greater than maximum size LOCAL1 INFO RIP Wrong RIP packet alignment LOCAL1 INFO RIP RIP version 0 with command <command-name>...

  • Page 766: Session Module

    System Logging Messages Routing Module Facility Severity Contents LOCAL1 INFO GRP Default destination is routed via gateway <ip_address> LOCAL1 INFO GRP Default destination is not routed anymore via gateway <ip_address> SECURITY INFO LABEL Rule Id:<rule_id> Protocol: ICMP Src_ip: <ip_address> Dst_ip: <ip_address> ICMP message type: <message_type_name || message_type_id >...

  • Page 767: Software Module

    System Logging Messages Software Module Facility Severity Contents KERN INFO SOFTWARE File <Filename> <receive || transmit> initiated KERN INFO SOFTWARE File <Filename> <receive || transmit><““ || not> successful terminated" UPnP Module Facility Severity Contents WARNING SECURITY UPnP<ActionName> refused for ip=<ip_address> NOTICE SECURITY UPnP <ActionName>...
  • Page 768 System Logging Messages E-DOC-CTC-20060414-0006 v1.0...

  • Page 769: Supported Key Names

    Supported Key Names Supported Key Names Contents This chapter lists all the key names supported by the SpeedTouch™, that can be used for completing CLI command parameters: Supported IP Protocols Supported TCP/UDP Port Names Supported ICMP Type Names Supported Facilities...

  • Page 770: Supported Ip Protocols

    Supported Key Names Supported IP Protocols For more information on the listed IP protocols, see RFC1340 or www.iana.org. Protocol name Number Description Authentication Header (AH) Exterior Gateway Protocol (EGP) Encapsulating Security Payload (ESP) Gateway Gateway Protocol (GGP) General Routing Encapsulation (GRE) Host Monitoring Protocol (HMP) icmp Internet Control Message Protocol (ICMP)

  • Page 771: Supported Tcp/Udp Port Names

    Supported Key Names Supported TCP/UDP Port Names For more information on the listed TCP/UDP port assignments, see RFC1340 or www.iana.org. Port name Number Description echo Echo discard Discard systat Active Users daytime Daytime qotd Quote of the Day chargen Character Generator ftp-data File Transfer (Default data) File Transfer (Control)
  • Page 772 Supported Key Names Port name Number Description sntp Simple Network Time Protocol (SNTP) ingres-net INGRES-NET Service netbios-ns NETBIOS Naming System netbios-dgm NETBIOS Datagram Service netbios-ssn NETBIOS Session Service imap2 Internet Message Access Protocol (IMAP) v2 sql-net SQL-NET pcmail-srv PCMail Server snmp Simple Network Management Protocol (SNMP) snmptrap...
  • Page 773 Supported Key Names Port name Number Description utime UNIX Time Local routing process (on site); uses variant of Xerox NS Routing Information Protocol (RIP) timed Timeserver netwall For emergency broadcasts new-rwho uucpd remote who is uucp uucpd uucp-rlogin uucpd remote login rtsp Real Time Streaming Protocol (RTSP) whoami...

  • Page 774: Supported Icmp Type Names

    Supported Key Names Supported ICMP Type Names For more information on the listed ICMP type names, see RFC1340 or www.iana.org. ICMP Type name Number Description echo-reply Echo Reply destination-unreachable Destination Unreachable source-quench Source Quench redirect Redirect echo-request Echo router-advertisement Router Advertisement router-solicitation Router Solicitation time-exceeded...

  • Page 775: Supported Facilities

    UUCP subsystem cron Clock daemon security Security messages FTP daemon NTP subsystem audit Log audit logalert Log alert clock Clock daemon local0 Local use messages local1 local2 local3 local4 local5 local6 local7 All facilities (SpeedTouch™ specific facility parameter value. E-DOC-CTC-20060414-0006 v1.0...

  • Page 776: Supported Severities

    Supported Key Names Supported Severities For more information on the listed severities, see RFC3164. Severity Name Hierarchy Syslog severity Code (listed according descending importance) emerg Emergency conditions, system unusable alert Alert conditions, immediate action is required crit Critical conditions Error conditions warning Warning conditions notice...

  • Page 777: Differentiated Services Code Point (Dscp)

    Supported Key Names Differentiated Services Code Point (DSCP) For more information on DSCP, see RFC3260. PHB Name Binary value Expedited Forwarding 101110 af41 Assured Forwarding 41 100110 af42 Assured Forwarding 42 100100 af43 Assured Forwarding 43 100010 af31 Assured Forwarding 31 011110 af32 Assured Forwarding 32...
  • Page 778 Supported Key Names E-DOC-CTC-20060414-0006 v1.0...
  • Page 779 Index Index adsl config 8 aal5stats info 9 atm debug aal5stats 35 appconfig actlist connection appconfig 76 eth bridge dynvlan actlist 246 appinfo connection appinfo 78 atm bundle add 21 applist atm oam vclb add 46 connection applist 79 atm phonebook add 49 atm qosbook add 54 arpadd dhcp client rqoptions add 118...
  • Page 780 Index modify 44 clear send 45 atm bundle clear 24 config 38 connection clear 83 list 39 dhcp client debug clear 115 modify 40 dhcp server debug clear 147 ping 42 dns server debug clear 184 vclb dns server debug spoof clear 186 add 46 eth bridge clear 244 del 47...
  • Page 781 Index mlp privilege config 498 mlp role config 505 nat config 510 debug save 73 connection debug 85 service host config 565 exec 102 snmp config 586 sntp config 603 system config 612 atm oam vclb del 47 system ra config 622 delete upgrade atm bundle delete 25...
  • Page 782 Index clear 115 tmpldelete 161 stats 116 tmpllist 162 traceconfig 117 policy 146 flush 105 pool ifadd 106 add 163 ifattach 107 config 164 ifconfig 108 delete 166 ifdelete 109 flush 167 ifdetach 110 list 168 iflist 111 optadd 169 ifrenew 113 optdelete 170 rqoptions...
  • Page 783 Index debug config 248 connection delete 249 list 202 flush 250 proxy 203 list 251 recycling 204 flush 252 stats 205 ifadd 253 intercept ifattach 254 config 206 ifconfig 255 syslog ifdelete 257 config 207 ifdetach 258 list 208 iflist 259 urlfilter macadd 260 config 209...
  • Page 784 Index export dhcp server pool flush 167 dns client flush 180 mlp debug export 492 dns server flush 183 expr dns server host flush 193 dns server route flush 197 add 290 dsd urlfilter rule flush 212 delete 293 dyndns flush 218 flush 295 dyndns host flush 224 list 296...
  • Page 785 Index getflags atm ifadd 14 dhcp client ifadd 106 dns server debug spoof getflags 188 eth bridge ifadd 253 grouplist eth bridge vlan ifadd 270 eth ifadd 237 igmp proxy grouplist 376 ip auto ifadd 415 ip ifadd 395 config 334 ppp ifadd 527 flush 335 ppp relay ifadd 544...
  • Page 786 Index dhcp client ifdetach 110 ingress eth bridge ifdetach 258 eth switch mirror ingress 281 eth ifdetach 241 instadd ip auto ifdetach 420 ip ifdetach 400 dhcp server option instadd 157 ppp ifdetach 535 instdelete snmp ifdetach 597 dhcp server option instdelete 158 iflist instlist atm iflist 20...
  • Page 787 Index ipdelete modify 460 ip ipdelete 405 language service system ipdelete 578 config 466 iplist delete 467 list 468 ip iplist 406 list ipqos atm bundle list 31 config 430 atm cac list 33 atm oam cc config 43 config 433 atm oam list 39 list 434 atm oam vclb list 48...
  • Page 788 Index script list 561 config 471 service host list 570 exec 472 service system list 579 register 474 snmp community list 592 test 475 sntp list 606 debug upnp list 642 stats 476 user list 650 traceconfig 477 voice codec list 658 listobjects 478 voice country list 661 listtypes 479...
  • Page 789 Index ids signature modify 360 ping root command 4 ids threshold modify 363 policy label modify 446 dhcp server policy 146 label rule modify 460 service system modify 583 portstats snmp community modify 593 atm debug portstats 37 upgrade profile modify 635 wireless macacl modify 712 flush 526 move...
  • Page 790 Index register script mbus client register 474 add 558 wireless macacl register 713 delete 559 flush 560 removepriv list 561 mlp role removepriv 508 run 562 removezone send mlp privilege removezone 502 atm oam cc send 45 systemlog send 628 reset sendto system reset 618...
  • Page 791 Index getnext 588 LOGIN 741 ifadd 594 NAPT 741 ifattach 596 PPP 742 ifconfig 598 PPTP 742 ifdelete 595 RIP 743 ifdetach 597 Routing 744 iflist 599 Session 744 walk 589 SNTP 744 Software 745 sntp UPnP 745 add 602 VOIP 745 config 603 system...
  • Page 792 Index traceconfig list 650 rights 652 cwmp debug traceconfig 98 dhcp client debug traceconfig 117 dhcp relay debug traceconfig 128 dhcp rule debug traceconfig 140 dhcp server debug traceconfig 150 firewall debug traceconfig 316 firewall rule debug traceconfig 332 version ip debug traceconfig 426 software version 610 label rule debug traceconfig 463...
  • Page 793 Index config 728 delete 729 flush 730 list 731 scanresults 732 wpa-psk wireless secmode wpa-psk 724 E-DOC-CTC-20060414-0006 v1.0...
  • Page 794 Index E-DOC-CTC-20060414-0006 v1.0...
